Principal Particulars
Length Overall : 75.00 m
Length Waterline : 71.40 m
Breadth Moulded : 20.40 m
Depth Moulded : 7.00 m
Design Draft : 5.30 m
GRT / NRT : 3906/1171
Class : American Bureau of Shipping
DPS·2 For Unrestricted Service

Deck Equipment
Anchor Windlass :
1 x electro-hydrau lic Macgregor / PC-HAW/GG-50
Gypsies :
suit for 50 mm chains rated pull 10.6 mt @ 10 m/min
Warping drum : 400 mm (dia) x 660 mm (L)
Bow Anchors : 2 x 3,060 kg StockJess Bower anchors
Chains :
495 Total Length x 38 mm (dia) Grade 2
Capstan :
2 x 5 mI@ l 5m/minelectro-hydraulic;
MacGregor / PC·HVC-05/400
Mooring Winch :
4 x 50 mt @ 10m/min eleclro-llydraulic;
Macgregor / PC-HMW/SD-4O/090D
Drum Capacity : 1500 m (L) x 38 mm
(0)SWR
Deck Crane Capacity : 45T@ 8m
Personel Lift : 1.5 T@ all radi
Provision Crane :
1 x electro-hydraulic Amco Veba /807/3S - 3 Ton @ 1.7m

Accomodation
Beths : 8 x 1 berth cabins = 8
6 x 2 berth cabins = 12
30 x 4 berth cabins = 120
Total : 140
Hospital : 1 x 2 berth cabin = 2
All cabins fully air-conditioned & c/w attached washroom.

Fire Fighting Equipment & Anti-Pollution Equipment
Internal
Emergency Fire Pump :
1 x 40 cbm/hr @ 45m head; Bombas Azcue
BA Recharging Comp :
1 x 100 hr/min @ 200 bar Brand/ModeITBA
CO2 system in engine room
Fire Detection & Alarm System in living spaces & engine room.

Radio and Navigation Equipment
GMDSS : Furuno RC-1800T 250W (Area 3) comprising :
SSB : 1 x Furuno FS·2570 with buiH in DSC
Inmarsat C : Felcom-15 SSAS & LRIT
VHF Radio : 2 x Furuno FM-8800S with built in DSC
Navtex Receiver : 1 x Furuno NX-700 (518 KHz)
SART : 2 x McMurdo S4
EPIRB : 1 x McMurdo E5
Portable VHF Radios : 3 x McMurdo R2 (25KHz)
Radar (S-Band) : 1 x Furuno FAR-2137S ARPA 96 NM
Radar (X-Band) : 1 x Furuno FAR-2117 RP-ARPA 96 NM
Echo Sounder : 1 x Furuno FE·700
GPS : 3 x Veripos LD3 System
GPS : 1 x Furuno GP-150
Gyrocompass : 3 x Anschuetz Standard 22
Autopilot : 1 x Anschuetz Pilotstar D
Magnetic Compass : 1 x Cassens & Plath REFLECTA 1
Weather Fax : 1 x Furuno FAX408
Speed Log : 1 x Furuno DS-80
Wind Indicator :
3 x Gill lnstruments WindObserver II 1390-PK-006
AIS : 1 x FurunoFA·15O
VDR : 1 x Furuno VR-3000
DP : Converteam Duplex C-Series
Joystick : Converteam Independent Joystick
Vessel also fitted with Vingtor PA Talkbalk System &
Self-Powered Telephones

Miscellaneous
Liferafts : 4 x 25 men SOLAS approved type
Life Boat : 2 x 60 men totally enclosed Vanguard
Rescue Boat : 1 x 8 men Rescue Boat
Inboard Diesel Engine Driven Vanguard
Oily Water Separator : l x 1 cbm/hrc/w15ppm
Water Maker : 2 x 20 cbm/day Reverse Osmosis, Coffin
Sewage Treatment Plant : 1 x 140 men; Hamworthy / ST13

Performance
Maximum Speed : 12 knots at MCR
Type of Fuel : Marine Diesel Oil
Fuel Consumption :
Approx 17 cbm/24hr @85%MCR(MainEngine)
Approx 20 cbm/24hr (5 X CAT 3412 gen sets)
Approx 4.5 cbm/24hr (CAT C32 Thruster Engine)

Cargo Capacities
Deadweight : 2660 m/t
Deck Cargo : 800 m/t
Deck Strength : 5.0 mt/m21 uniform loading
Clear Deck Area : 650 sq.m
Fuel Oil : 1,180 cbm
Fresh Water : 830 cbm
Ballast Water : 1,644 cbm
Freezer / Chiller : TBC
Foam / Detergent : TBC

Pumps
Fuel Oil :
1 x 30 cbm/hr @ 20m head; Bombas Azcue
Fresh Water :
1 x 60 cbm/hr @ 40m head; Bombas Azcue
Bilge / Fire Pump :
3 x 60 cbm/hr @ 45m head;BombasAzcue
Bilge / Ballast Pump :
1 x 150 cbm/hr @ 25m head; Bombas Azcue

Propulsion System
Main Engines  :
2 x 1,600 kWm @ 1,000 rpmWartsila 8L20
Main Generators :
5 x S90 ekW @ 1,800 rpm Caterpillar / 3412C cJw alternator SR4
Emergency Generator :
1 x 99 ekw @ 1,800 rpmCaterpiliar / C4.4 rate at 99 ekW/440
V/3 Ph/60Hz
Shaft Generator : NIL
Bow Thruster :
1 x Caterpillar C32 1,000 bhp diesel engine driven HRP 5007 TT
tunnel type (CPP); 11.5 T thrust
Stern Thruster :
HRP 5007 IT tunnel type (CPP); 8T thrust
Steering Gear :
2 x Wagner LA2 7. 1-45-CB2 7.1 TM; 45 deg
Propulsion : 2 x CPP in Kort Nozzles; Ups 40650
Rudders : 2 x Becker Rudder / SA 20S0 203 F.2

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
-----------------------------------------------------------------------------------
