Mooring System
Mooring points : 8 points
Winch drum : 8 nos. singe drum ; electro-hydraulic
Winch drive : motor driven
Line pull :  70 T
Brake capacity :  120 T ; Static @ 1st layer
Anchors :  9 nos. ; 10 T (Flipper Delta)
Anchor wire :  8 coils, 46 mm SWR ; 1500 m (L)
Pennant wire :  9 nos., 46 mm SWR ; 130 m (L) each
Anchor marker buoys : 9 nos. foam filled ; 2.4 m (L) x 1.6 m (W)
Tugger winch :
3 nos.
1 x 10 T (engine driven)
2 x 5 T (motor driven)

c/w tension sensors, wire length counter, 16 vertical sheaves, 8 Universal
fairleaders

Helideck
Sikorsky S92 or equivalent
Length : 25.62 m
Breadth : 25.62 m

Facilities (living, working & other)
Accommodation : 300 persons
Client office : 3 nos.
Barge master office : 1 no.
Conference room :  1 no. , 20 persons capacity
Radio room :  1 no.
Control room : 1 no.
Hospital :  1 no. ,3 beds
Dinning room (officers) : 1 no. ,10 persons capacity
Mess room (crew) :  1 no. ,  150 persons capacity
Laundry room : 1 no.
Change room :  1 no.
Recreation room : 1 no. , 48 persons capacity
Gymnasium : 1 no.
Pantry room : 1 no.
Prayer room :  1 no.
Dry provision room :  3 nos.
Air conditioning unit : Comply to ILO 92, IMO Resolution A468 (XIII), PGBOOM
Meat / fish chiller : 50m3
Vegetable freezer : 50 m3

Machineries & Equipment
Generators
Main Genset :
Engine - 3 nos., each 1000 KVA
Cummins KTA -38-DM 440 V, 3 Ph, 60 Hz
Alternator - Stamford

Emergency Genset :
Engine - 1 no., Cummins 250 KVA
NTA 855-DM, 440 V, 3 Ph, 60 Hz
Alternator - Stamford

Air Screw Compressor :
1 no. (Motor Driven)
294 m3 / hr (1 Cyl /1 stage) @ 13 bar

Fresh Water Maker :
2 nos. x 50 m3 / day
Reverse Osmosis (Hansun)

Sewage Treatment Plant :
2 nos. x 250 men, WCB 250

Oil Water Separator
1 no. (3 m3 / hr c/w 15 ppm alarm)
IOPP :  Comply
Workshop :  1 no.

Deck Crane
Pedestal Mounted Techcrane 500-120
Capacity : 250 T
Boom Length :  120 Ft (36.5 m)

Others
Communication & Navigation System
GMDSS set : Area comprising A1, A2 & A3
SSB radio : 1 no. , Furuno FS 2571T
Navtex receiver : 1 no., Furuno NX-700A
Inmarsat C : 1 no., Furuno Felcom 15
VHF air band T'receiver : 1 no. , Icom IC-A-110
VHF radio (fixed) : 2 nos. , Furuno FM 8800S with built-in DSC
Portable VHF radio (GMDSS) : 3 nos. , ACR
Portable marine VHF : 3 nos, Motorola GP-328
Radios : 6 nos. , Icom M32
Intercom & PA system : Entire barge
Aero VHF : 3 nos., Icom ( IC-A4E,IC-A24,IC A5)
Satellite Phone, Fax & Email : One - FBB 500, Sailor Thrane & Thrane
GPS : 1 no., Furuno GP150
Radar : 1 no. , Furuno FR-062
Gyro compass : 1 no. Raytheon Anschuitz
Magnetic compass : 1 no, Portable
Echo sounder : 1 no., Furuno FE700
Wind Dir. & Wind speed indicator : 1 no., wind tracker, Navalynx
Anemometer & Clinometers : Walker P1249 & QB55-200,
John Lilley & Gillie Ltd. & Pendulus Inclinometer-QZ 70

Safety (FFA & LSA)
FFA (As per Solas) :
Fire pump : 1 no. (electric driven), 300 m3 / hr @ 90 m head
Emergency fire pump : 1 no. (engine driven), 300 m3 / hr @ 90 m head
Fixed Foam Fire Fighting : foam tank capacity : 400 liters For helideck
Fire monitors : 2 nos., 140 m3 / hr @ 7 bar
Fire hydrants : 51 nos., As per FFA plan
Intl. shore connection : 1 nos.,  As per FFA plan

Barges also fitted with PA Talkbalk System and sound
powered telephones & CC TV Systems

Fixed CO2 System for generator room
Area protected = Generator room, paint
store & galley duct
Sinoking

Automatic Water Sprinkler System :
Area protected = Entire accommodation area,
including paint store galley and workshop
1 x 150 m3/hr @ 80m head

General Alarm, Fire Detection System :
Area protected = Entire barge

LSA (As per Solas) :
Rescue Boat : 1 no., 6 persons cap. c/w davit
Life Raft : 36 nos. (25 men capacity) , total capacity 900 persons (both sides)
Life Jackets : 550 nos., 150 % of the maximum
POB carrying capacity
Life buoys with MOB : 2 nos., mounted as per barge safety plan
Life buoys with SI Light : 10 nos., mounted as per barge safety plan
Life buoys with Line : 2 nos, mounted as per barge safety plan
Life buoys : 6 nos. , mounted as per barge safety plan
EPIRB : 1 nos., ACR RLB 32
SART : 2 nos., ACR Pathfinder 3
Line Throwing App. :
2 sets comprising of 4 Cartridges each
