Kobelco CKE4000C Crawler Crane for Sale

Equipment ID: 1509
Equipment name: Kobelco CKE4000C Crawler Crane for Sale
Category: Cranes / Lifting equipment
Specifications: Kobelco CKE4000C Crawler Crane for Sale
400 Tons Kobelco CKE4000C 400tons Crawler Crane

Specifications

Standard Crane
Max. Lifiting Capacity : 350t / 6.0m
Boom Length : 18m to 78m

HL Crane
Max. Lifiting Capacity : 350t/7.0m
Boom Length : 30m to 84m

SHL Crane
Max. Lifiting Capacity : 350t/12.0m
Boom Length : 30m to 84m

Light-Duty Crane
Max. Lifiting Capacity : 113.5t/14.0m
Boom Length : 30m to 96m

Luffing Jib
Max. Lifting Capacity : 113.5t/16.0m
Max. Combination : 66m + 66m/72m + 54m

HL Luffing Jib
Max. Lifting Capacity : 113.5t/16.0m
Max. Combination : 72m + 66m/78m + 54m

SHL Luffing Jib
Max. Lifting Capacity : 113.5t/16.0m
Max. Combination : 78m + 66m/84m + 54m

Main & Aux. Winch
Max. Line Speed : 130m/min (5th layer)
Wire Rope : 28mm
Brake Type : Spring set hydraulically release brake

Working Speed
Swing Speed : 1.3 min (rpm)
Travel Speed : 1.0/0.4 km/h

Power Plant
Model : HINO K13C-UV
Engine Output : 295kW/2,000min (rpm)
Fuel Tank Capacity : 600 litres

Hydraulic System
Main Pumps : 6 variable displacement pump
Max. Pressure : 31.9 MPa (325 kgf/sq.cm)
Self-Erection Device : Option

Weight
Operating Weight : Approx.346t
Counterweight : std.120t (Upper) + 41t (Lower)
Transport Weight : 60.0t (Main machine)
Ground Pressure : 150 kPa (1.52 kgf/sq.cm)

We also have used cranes.

Additional information regarding this equipment will be shown on request

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------------
