Kobelco CKS800 Crawler Crane for sale

Equipment ID: 1510
Equipment name: Kobelco CKS800 Crawler Crane for sale
Category: Cranes / Lifting equipment
Specifications: Kobelco CKS800 Crawler Crane for sale
80T Hydraulic Crawler Crane for sale

Main Specifications

Crane Boom
Max. Lifting Capacity : 80 t x 3.0 m
Max. Length : 54.9 m

Fixed Jib
Max. Lifting Capacity : 7.0 t x 20.0 m
Max. Combination : 42.7 m + 18.3, 45.7 m +12.2 m

Main & Aux. Winch
Max. Line Speed (1st layer) : 120 m/min
Rated Line Pull (Single line) : 78 kN {8 tf}
Wire Rope Diameter : 22 mm
Wire Rope Length : 220 m (Main), 130 m (Aux.)
Brake Type (free fall) : Wet-type multiple disc brake (Optional)

Working Speed
Swing Speed : 4.0 min-1{rpm}
Travel Speed : 1.7/1.1 km/h

Power Plant
Model : HINO J08E-VM
Engine Output : 213 kW/2,100 min-1
Fuel Tank : 400 liters

Hydraulic System
Main Pumps : 3 variable displacement
Max. Pressure : 31.9 MPa {325 kgf/cm2}
Hydraulic Tank Capacity : 440 liters
Self-Removal Device : Counterweight/self-removal device (Option)

Weight
Operating Weight : 75.1 t *1
Ground Pressure : 84.7 kPa
Counterweight : 27,200 kg
Transport Weight : 39,850 kg *2

Line speeds in table are for light loads. Line speed varies with load.
*1 Including upper and lower machine, 27.2 ton counterweight, 6.5 ton carbody
weight, basic boom, hook, and other accessories.
*2 Base machine with boom base, gantry, crawlers, and wire ropes (front/boom
hoist)

We also have used cranes.

Additional information regarding this equipment will be shown on request

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------------
