A. Draw-works:
Gardner-Denver 800 with a 342 Parmac hydromaEc, 1 1/4" drilling line, powered
by (2) C-15 CAT diesel engines with (2)  NaEonal 195-80 torque converter.

B. Substructure & Mast:
DSI 142' mast, 796,000# hook load on 12 lines, Pyramid 25' substructure,
setback capacity 750,000# with a 6’ pony sub

C. Generators:
(2) 455kw AC generators powered by (2) CAT 3456 diesel engines,
(1) MCC Capable of 480v, 220v or 120v electricity

D. Mud Pumps:
(2) FB-1300 HP triplex driven by (2) 399 CAT diesel engines

D. Rotating & Traveling Equipment:
National rotary table - 27 1/2“, Ideco Big Shorty - 400 Ton,
Ideco 815 swivel - 500 Ton, 5 1/4" hex x 44' long kelly,
BJ type DB tongs

E. Blowout Prevention:
13 5/8" annular BOP - 5000 psi, 13 5/8" double gate ram BOP - 5,000 psi,
Model 120-gallon automatic accumulator, 5-station air actuated
remote control panel, 4" x 3"x 5,000 psi, choke manifold with gauges and (1)
manual choke

F. Doghouse, Water, Fuel & Mud Tanks:
Heated doghouse, (1) fuel tank - 18,000 gal, (1) water tank - 400 bbl,
(2) tank mud system 850 bbl with (4) 5”x6”x11” centrifugal pumps
on low pressure system, mud agitators, mud guns, (2) Fluid System
shakers (1) Fluid System desander (1) Fluid System desilter

G. Handling Tools/Auxiliary Equipment :
(2) air winches, (1) Pilot II automatic driller, (1) Sure Shot 7 degree A-1
survey instrument, Martin Decker
type D weight indicator, (1) heated safety shack

H. Drill Pipe & Drill Collars :
15,000' - 4 1/2" 16.60# Grade G Drill Pipe, (14) 6.25" x 2.25" x 30'
slick drill collars
