Utility Support Vessel for Sale
2015 Built - 2000 hp Utility Support Vessel

General
Year Built : 2015

Length OA : 40.00 m
Breadth Moulded : 10.00 m
Depth Moulded : 4.00 m
Design Draft : 3.00 m
Gross Tonnage : 499 Tons
Net Tonnage : 179 tons
Displacement : 400 T @ 2m Draft
Classification : BV

Machinery
Main Engines :
2 x MITSUBISHI S6R2-T2MTK31
2 X 759kw @ 1406 rpm
Main Generator : 3 X Cummins,QSB7-DM,150kw
Propulsion System : 2 X Fixed Pitch
Bow Thruster : Transverse Tunnel,3 T Thrust
Shaft And Propellers : 4 Bladed,1800mm Diameter

Deck Equipment
Anchor Windlass : 1 x Jebsen&Jessen,2.5 t Pull@10m/min
Anchors : 2 x 780kg,JIS Stockless Anchors
Anchor Chain : 2 x 330m x 24mm dia
Tugger Winch : 1 x Jebsen&Jessen,5t@14m/min
Capstan : 2 x Jebsen&Jessen,5t@14m/min
Deck Crane : 1 x SWL 1 T @ 8 meter radius
Service Air :1 x 250 CFM @ 7 bar
Towing Hook : 1 X 35 Ton SWL Jebsen & Jessen Make

Cargo Deck
Deck Area : 140.0 m2
Deck Strength : 5.0t/m2
Dangerous Goods : CERTIFIED

Tank Storage Capacities
Freshwater : 77 tonnes
Fuel Oil : 120 tonnes
Lub. Oil : 2 tonnes
Sludge : 5.0 m3
Sewage : 14 m3
Dirty Oil/Slop : 2.5 m3
Oil Dispersant : 6.5 m3

Discharge Capacity
F.O. Transfer Pump : 8m3/hr @ 20m head
F.W. Cargo Pump : 10m3/hr @30m head

Navigation/Electronics
Primary Radar : JRC,96NM,X Band
Secondary Radar : JRC,48NM
Echo Sounder : JRC,JFE-380,IMO Approve
AIS : JRC,JHS-183
GPS : JRC JLR-7500
Auto Pilot : Navitron
Magnetic Compass Daiko SR-150PK,Reflector Type
Gyrocompass : JRC,IMO Compliance
MF/HF-DSC Radio Tel : Phontech,DC12 V
VHF-DSC Radio Tel : Phontech,DC 12V
INMARSAT C : JRC,Area 2 Operation

VHF : Phontech
Navtex : JRC NCR-333
EPIRB : SAFESEA E100
SART : SAFESEA S100
GMDSS : JRC,Area 2 Operation
PA System : Phontech
Anemometer : Davis
Searchlight : Francis ,1000W
Navigation Lights : Aqua Signal, Dual Lens
Speed Log : JRC JLN-205
BNWAS : Navitron NT99,Type Approve
SSAS : SAILOR 6120

Speed/Bollard Pull/Fuel Consumption
Speed : 12 knots @100% MCR
Endurance : 30 days
Designed deck loading : 5.0 tonnes/m2
Bollard Pull : 30 T ( approx)

Fire Fighting & Anti Pollution Equipment
External Fire fighting : Horizontal,Centrifugal,Self
Pump : Priming,100m3 @ 60m head
Monitor : 1 x Dual Purpose Monitor,100m3 @ 5 bar inlet pressure
Oil Dispersant System : 2 x 6 m Spray Boom

Safety Equipment
Life Raft : 4 x 30 men with hydrostatic release
Rescue Boat : 1 x 6 persons, Narwhal 39.IRB
Davit : NDM SCM 12-3R,SWL:1.0 T
H2S : Fixed H2S Detection System

Miscellaneous
Oily Water Separator : 1 X Gravity 2 stage,0.5m3/hr
Sewage Treatment : 1 x Biological Unit,MARPOL compliance
Water Maker : 2 x 5t/day, Reverse Osmosis Type with UV Filtration

Accommodation
4 x 1Men Berth Cabins : 4 Men
5 x 2 Men Berth Cabins : 10 Men
5X 4 Men Berth Cabins : 20 Men
TOTAL 34 Men

Seating Capacity
Passenger Seating :
26 Seating in passenger lounge
equipped with TV/DVD for Passenger
Transfer Safety Induction

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------
