Used 26M Multicat for Sale

Equipment ID: 2074
Equipment name: Used 26M Multicat for Sale
Category: Ships/Vessels
Sub Category: Multicat
Specifications: Used 26M Multicat for Sale
32T Bollard Pull for Sale
2009 built Multicat for sale

General
Year Built : 2009
Type of Vessel : Multicat
Classification : BV Tug - Unrestricted Navigation

Dimensions
Lenght Over All : 26m
Length Between Perpend : 23.99m
Breadth : 11.5m
Depth : 3.5m
Maximum Draught : 2.2m
Gross Tonnage : 290T

Propulsion(3 X Fixed Pitch Propellers)
Main Engines : 3 x Yanmar 6AYM-ETE / 829 BHP @ 1900 rpm each
Total Output : 2,487bhp
Gearboxes : 3 x Reintjes WAF 364 5:1
Bowthruster : Hydraulically driven, 315 bhp, 360º Water Jet Propulsion

Performance
Bollard Pull : 32T
Speed :
11.5 knots maximum
8 knots economically

Deck Equipment
Deck Crane 1 : Heila HLRM 240T/2SL, 13.7T at 14.3m
Deck Crane 2 : Heila HLRM 140T/3s, 10T at 12.25m
Towing Winch : 500m x Ø36mm, 30T pull
Anchor Handling Winch : 100m x Ø50mm, 80T pull

Capstans : 2 x 15T
Tugger Winch : 15T Hydraulic
Shark Jaws : For 3” Chain Max
Towing Pins : Fore and Aft

Bow Roller : For work load of 80T, 5.4m x Ø1.20m (200T S.W.L.)
Stern Roller : For work load of 30T, 1,50m x Ø0.70 (60T S.W.L.)
Spud-fittings : 2 x Ø550mm
* Pre-Installation for 4 point mooring
*Deck floor fully covered with interchangeable wooded inserts, a/h area
reinforced steel

Accommodation
Cabins : 3 Cabins
Type : Double
Maximum Crew : 6 Persons
* Galley, sanitary facilities, Air conditioning (heat & cold)

Auxiliaries
Diesel Generator :
1 x Iveco 520 BHP @ 1500 rpm for hydraulics
1 x Emergency Electro-hydraulic Group of 70 cv

Generators : 2 x Iveco 100kW, 50 Hz 230/400V, 1500 rpm
Port Generator : 1 x Yanmar 20kVa (soundproof)
Transfer Pumps : 1 x 60 m³/h FW
Sewage Treatment Plant :
Ecomar 8, loys approved to IMO resolution MEPC.159(55)

Tank Capacities
Fuel Oil : 121.005 m³
Fresh Water : 68.292 m³
Lube Oil : 3.446 m³
Hydraulic Oil : 5.998 m³
Dirty Oil : 2.060 m³
Slop Tank : 2.350 m³
Black Water : 10.780 m³
Ballast Water : 76.929 m³
Sewage Treatment Plant : 4000LPD

Navigational and Communication Equipment
Radar Systems : 2 x Furuno 72 Mile
Compass : Furuno Triple-reciever System
Echo Sounder : Furuno FCV 585
Reciever DGPS : GP 150
Auto Pilot : Simrad AP50
Navtex : Furuno NX-700A
VHF Radio-phones : 1 x RT2048; 1 x RT2055; 1 x CU1500

GMDSS VHF Portable : 3 x ICOM IC - GM1600E
Chart Plotter : 2 x Furuno NAV Net VX2
Inmarsat Mini C GMDSS : TT - 3000E Navigation area A1/A2
Navigation Software : Navionics Gold
Anemometer : Waler, winde speed and direction
AIS : Transmitter & Reciever
Sat Phone : Sailor F33

Miscellaneous
Moonpool : Ø1,000mm Deck container fittings

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where
needed.

The details mentioned above are believed to be accurate but are not guaranteed.
----------------------------------------------------------------------
