70TBP AHT for sale - Worldoils Oil, gas and offshore equipment marketplace

70TBP AHT for sale

Equipment ID: 2079
Equipment name: 70TBP AHT for sale
Category: Ships/Vessels
Sub Category: AHT
Specifications: 70TBP AHT for sale
45M Used Anchor Handling Tug for Sale
2009 built AHT for sale

General
Year Built : 2009
Class Bureau Veritas
Notation : I HULL MACH, Tug; Special Service- Anchor Handling
Vessel Unrestricted Navigation
GRT / NRT : 874/262
Deadweight : 539 MT

Dimensions
Length Overall : 45.00 m
Length Waterline : 43.50 m
Breadth Moulded : 12.60 m
Depth Moulded : 5.30 m
Draft (max) : 4.50 m

Performance
Maximum Speed : 13.0 knots at 15 MT/24 hrs
Economical Speed : 10.0 knots at 10 MT/24 hrs
Type of Fuel : Marine Gas Oil
Endurance About : 40 days

Cargo Capacities
Fuel Oil : 486 m³
DW/SWB : 77 m³
Fresh Water : 266 m³
Freezer/Chiller : 30 m³
Deck Cargo : 100 MT
Deck Strength : Uniform 5 T/m² main deck & 15 T/m² stern
Clear Deck Area : 200 m²

Radio & Navigation Equipment
GMDSS (For Area 3) : 1 x Furuno RC-1800 IT
SSB : 1 x Furuno FS 2570C
VHF : 2 x Furuno FS 8800S/ Icom IC-M422
Radar : 1 x Furuno FAR 2117/ 1942 Mark 2
Echo Sounder : 1 x JRC Model JFC-582-200 Khz
Gyro Compass : 1 x unit at main steering position at sterring gear
Magnetic Compass : 1 x unit standart suara model MR-150
Speed Log : 1 Doppler log JRC Model JLN -205
Auto Pilot : 1 unit Syncronized to gyro steering compass
Navtex Receiver : 1 x Furuno NX 700
GPS Navigator : 2 x Furuno GP-150
AIS : 1 x Furuno FA-150
SART : 2 x Mcmurdo S4
EPIRB : 1 x Mcmurdo E5
Portable VHF (GMDSS) : 3 x Jotron TR20

Deck Equipment
Anchor Windlass c/w bow : 1 x electro-hydraulic 24 MT
Anchors & Chain :
2 x Stockless Anchor 1160 kg each;
2 x 605m x 34mm Ø U2 Stud Link Chains

Anchor Handling / Tugger Winch :
1 x electro hydraulic; double drum waterfall type
Line Pull at 1st Layer :
150T @ 6m/min (1st speed)
75T @ 12m/min (2nd speed)
12T @ 36m/min (2nd speed)

Brake Holding : 225 MT at 1st layer
Drum Capacity : 1000m (L) x 58 mm (Dia) SWR
Bollard Pull : 70.0T6
Tugger Winch : 2 x electro hydraulic 10T@ 15 m/min
Capstan : 2 x electro hydraulic 5T@ 15 m/min
Towing Pin : 2 x SWL 100T
Shark Jaw : 1 x SWL 200T
Stern Roller : 1 x 1500mm Ø x 4200 mm width – SWL 200T

Life Saving Equipment
Life Rafts : 1x25 men & 1x20 men, SOLAS compliant
Rescue Boat c/w Davit :
1 x 6 men, 20HP c/w outboard engine, SOLAS compliant
All other life saving appliances as per SOLAS requirements

Propulsion System
Main Engines :
2 x Niigata 6MG28HX, 2500 BHP/ 1823 KW
Total: 5000 BHP/ 3646 KW

Auxiliary Engines : 3 x 300 KW - 415V, 3PH, 50HZ
Emergency Generator : 1 x 80 KW - 415V, 3PH, 50 HZ
Bow Thruster : 1 x 441 KW
Propellers : 2 x FPP
Steering Gear System : 2 x Electro Hydraulic
Rudder : 2

Fire-Fighting Equipment & Anti-Pollution Equipment
External
Equivalent to 1/2 FiFi
Fire pump : 1 x 1500 m³/hr @140m head

Internal
CO² System : Engine Room
Fire Fighting Equipment : Fully compliant with SOLAS requirements
Emergency Fire Pump : 1 x 30 m³/hr @ 60m head
Water Mist System : Engine Room

Accommodation (All cabins are fully air-conditioned)
Berths :
4 x 1 berth cabins = 4
2 x 2 berth cabins = 4
4 x 4 berth cabins = 16
Total : 24

Dispersant System
Fresh Water Maker : Nil
Oily Water Separator : 1 x 1.2 m³/hr
Sewage Treatment Plant : 5.5 m³/hr

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where
needed.

The details mentioned above are believed to be accurate but are not guaranteed.
----------------------------------------------------------------------
