Konsberg Dynamic Positioning System with Thrusters for Sale

Equipment ID: 2086
Equipment name: Konsberg Dynamic Positioning System with Thrusters for Sale
Category: Miscellaneous Equipment
Specifications: Unused Separate HPU with Thruster Mounted on Deck or Platform
Konsberg Dynamic Positioning System with Thrusters for Sale
2006 built Thruster Mounted on Platform or Deck for sale

Specifications
Equipment type : Separate HPU with Thruster Mounted on Deck or Platform
Thruster material of construction : ASTM A36, Grade B carbon steel
Prime mover : Caterpillar 3516B marine diesel propulsion engine
Prime mover mounting : Containerized Power Unit (HPU)

Rated Output Power : 2,028 bhp
Rated Input Speed : 1,600 rpm
Thruster Continuous Rating : 2,000 SHP

Nominal static bollard thrust : 39,600 LBF
Propeller and nozzle type :
81-inch Kaplan accelerator series in Kort type 19A nozzle

Propeller material of construction : Nickle-Aluminum-Bronze
Propeller direction of rotation : Bi-directional
Propeller speed of rotation : 305 rpm
Hydraulic flow at rated speed : 1,122 gpm
Hydraulic pressure at rated speed : 2,635 psid
Hydraulic reservoir capacity : 400usg

Diesel fuel day tank capacity : 1,060 usg (4012 L)
Steering speed of thruster : 3 rpm
Nominal weight of thruster : 160,000 lbm
Nominal weight of power unit : 95,000 lbm

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------------------------------------
