Twin Screw Tug for Sale
New Building towing Tug for Sale
3200 BHP Twin Screw Tug for Sale

Principal Particulars
Class : American Bureau of Shipping
Classification : *A1 *AMS Tug Circle E Towing Vessel
Year Built : 2009
Length O.A. : 30.50m
Breadth Moulded : 9.00m
Depth Moulded : 4.25m
Draft (Designed) : 3.50m

Machinery
Main Engines :
2 x 1,600 BHP Cummins KTA 50-M2
@ 1,800 rpm Total : 3,200 BHP

Auxillary Engines :
2 x 99ekW Cummins – 415 V 3Ph 50Hz;
1 15kW Cummins (Emergency Generator set)

Propellers : 2 x 4 bladed FPP in nozzles – 2.3m Ø
Steering Gear : 2 x Electro-hydraulic 3 MT torgue

Start Air Compressor : 2 x 10cbm/hr @ 10 bar

Performance
Maximum Speed : 12.0K at 8 1/4 MT/24 hrs (approx)
Economical Speed : 11.0K at 8.0 MT/24 hrs (approx)
Type of Fuel : Marine Gas Oil

Range : 26 days approximately

Deck Equipment
Anchor Windlass : Electric c/w warping drums – 4T @ 15m per min

Anchors & Chain :
2 x Stockless Bower Anchors each 480kg;
Each 300m x 24mm Ø U2 steel stud link chains

Towing Winch :
1 x 50 MT double-drum electro-hydraulic @ 5m/min 1^st layer

Brake holding :
80 MT at 1^st layer static

700m x 44mm Ø wire rope

Towing Hook : 1 x 40MT (Hydraulic Quick Release)
Bollard Pull : Approx. 40MT (static)

Radio & Navigation Equipment
Radar : 1 unit 15” screen, 72NM, IMO approved, Furuno

Echo Sounder : 1 unit 50kHz c/w transducer, Furuno

Magnetic Compass : 1 unit standard (reflector binnacle)

GPS Navigator : 1 x Furuno (6” LCD)
Mini-M : 1 set Mini-M system, FurunoInternal Communications :
1 x Engine Telegraph, 1 x PA System & sound power;  telephone system
GMDSSMF/HF Transceiver : Full GMDSS (For Area 3)

Fire Fighting Equipment
Internal Fire-fighting :
Fully complies with SOLAS
CO2 Fire extinguishing system for engine room
Fire main : 4 x 40mm bronze hydrants
Fireman outfit : 1 complete set

Life Saving Equipment
Liferafts : 2 x 12 men inflatable liferafts
Lifebuoys : 8 pieces
Life Jackets : 16 pieces

Cargo Capacities
Deadweight : tones (approx)
Fuel Oil  : 250cbm
Fresh Water : 60cbm
Dirty Oil : 3.6cbm
Flow meter : Range 50cbm/hr

Accomodation
(Total 12 persons)  (All Cabins fully Air-conditioned)
1 – Berth Cabin : 2 x 1 man
2 – Berth Cabin : 1 x 2 men
4 – Berth Cabin : 4 x 2 men
