4400bhp Seismic Support Vessel for Sale - Worldoils Oil, gas and offshore equipment marketplace

4400bhp Seismic Support Vessel for Sale

Equipment ID: 2132
Equipment name: 4400bhp Seismic Support Vessel for Sale
Category: Ships/Vessels
Sub Category: Seismic
Specifications: 4400bhp Seismic Support Vessel for Sale
2005 built Seismic Support Vessel for Sale
67.8m Seismic Support Vessel for Sale

General
Year Built : 2005
Class : ABS
Notation : A1 (E), AMS
GRT / NRT : 2943 / 883

Dimensions
Length Overall : 67.80m
Breadth Moulded : 16.00m
Depth Moulded : 5.50m
Draft (max) : 4.20m

Performance
Maximum Speed : 12.5 knots @ 12MT/24 hours
Economical Speed : 10 knots @ 8MT/24 hours

Cargo Capacities
Deadweight : 1,300 MT
Deck Loading : 7.5 MT/m²
Clear Deck Area : 360m²
Fuel Oil : 545m³
Fresh water : 285m³
Drill water/water ballast : 750m³
Chiller / Freezer : 13m³ / 10m³

Cargo Pumps
Fuel Oil Cargo Pump : 1 x 100m³/hr @ 60M head
Drill Water Cargo Pump : 1 x 100m³/hr @ 60M head

Deck Equipment
Windlass : Electro-hydraulic– c/w Warping drums
Anchors & Chains :
2 x AC14 Anchors each 1575kg 2 x 330m x
34mm Ø Grade 2 steel stud link chains

Tugger Winch :
2 x 10 MT electro-hydraulic @ 10m/min c/w with one wire
drum and one warping head – speed light load – 30m/min

Capstan : 2 x electro-hydraulic 5MT at 15m/min

Accommodation (All cabins are full air-conditioned)
Berths :
1 x 2 men cabin = 2 (Main deck)
4 x 2 men cabin = 8 (Crane deck)
6 x 1 man cabin = 6 (Crane deck)
2 x 4 men cabin = 8 (Forecastle deck)
2 x 1 man cabin = 2 (Forecastle deck)
12 x 2 men cabin = 24 (Forecastle deck)
Total : 50 men

Navigation and Communication Equipment
GMDSS (3)
MF/HF Transceiver :
2 x VHF Radio Telephone 25W with DCS
1 x DCS Watch Keeping Receiver
1 set fully synthesized SSB Transceiver 250W

EPIRB : 1 set
Portable : VHF Radios 5 x walkie talkie set
SART : 2 units
Navtex Receiver : 1 unit NAVTEX Receiver
Intercom : 1 system for 15 positions
PA System : 1 with talk back facility with 2 loudspeakers
Radar : 2 units – one with daylight display (colour)
Echo Sounder : 1 unit with repeater at aft
Gyro Compass : 1 Master fitted with three repeaters
Magnetic Compass : 1 unit standard 7” reflector
Speed Log : 1 Speed Log System
Auto Pilot : 1 unit compatible with gyro & steering compass
GPS : 1 unit Global Positioning System

Propulsion System
Main Engine : 2 x 2,200 BHP CAT3518B; 1566kW each
Auxillary Engine : 2 x Cummins 350 kW each 415/3/50
Propeller : 2 x 4 bladed CPP in fixed nozzles
Bow Thruster : 1 x Kawasaki 8 tons CPP – Prop:1450mm Ø driven
by Cummins : 815 BHP @ 1800 rpm.
Emergency Generator : 1 x Cummins 78 kW 415/3/50
Rudders : 2 x electro-hydraulic 7MT torque

Fire-Fighting Equipment
External : -

Internal :
CO2 system Engine Room
Emergency Fire Pump : 1 x electric-driven 35mᵌ/hr @ 4.5 bars
Firemain : A firemain with 12 hydrants
Fireman's Outfit : 4 complete sets with breathing apparatus
Dispersant System : 2 spray nozzles with dispersant pump 36 m³/hr at 30m head

Life Saving Equipment
Life Rafts : 4 x 25 men (inflatable type)
Life Buoys : 8 pieces
Rescue Craft : 1 x 6 men c/w davit
All other life saving appliances as per SOLAS requirements

Seismic Air Compressor
Main Data -
Type : LMF 51 / 138-207 - D
Number of stages : 4
Compressed medium : air
Inlet pressure : 1,013 bara = 14,65 psia
Inlet temperature max. : 45°C = 113°F
FAD 1 (at inlet conditions) : 51 m3/min = 1800 cfm
Discharge pressure 1 : 138 bar = 2000 psig
Discharge pressure 2 : 207 bar = 3000 psig
Nominal speed of main drive (screw) : 1116 rpm
Nominal speed of piston compressor : max. 1200 rpm
Power consumption : 842 kW

Power Supply -
Operating voltage : 3 x 415 V
Control voltage : 220 V AC / 24
Frequency : 50 Hz (cps)”

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
---------------------------------------------------------------------------------------------------------
