General Characteristics
Occupants : 1 pilot and 2 passengers
Maximum Operating Depth :
100 meters / 330 feet
200 meters / 650 feet
300 meters / 1,000 feet
Possibility to upgrade depthrating after acquisition

Operational Autonomy : Up to 6 hours
Type : Dry, 1 atmosphere

Classification : DNV-GL

Dimension and Weight
Freeboard : 80 cm with freeboard extender
Dimensions (standard) :
315 x 241 x 172 cm
Fits in standard shipping container without sidefenders

Dimensions (LX) : 315 x 249 x 179 cm
Weight (standard) : 3,750 kg
Weight (LX) : 4,150 kg
Maximum Allowable Payload : 350 kg (Salt water)

Pressure Hull
Pressure Hull Material : Acrylic + Steel
Hatch Type : Top-Hatch

Propulsion
Propulsion Type : Electrical, Brushless DC
Propulsion Horizontal : 2 x 5.5 kW Thrusters
Propulsion Vectored Vertical : 2 x 6.4 kW Thrusters
Surface Speed : 2.8 knots
Underwater Speed : 2.8 knots

Life Support Systems
Oxygen System : Continuous Flow
Mission Oxygen Capacity : 3 Liter (Quick Exchange)
Emergency Oxygen Capacity : 2 x 20 Liter @ 200 bar
Carbon Dioxide Removal : 8 hours with Calcium Hydroxide
Survival Period  : 96 hours
Emergency CO2 Removal : Lithium Hydroxide Blankets
Autonomous Breathing Devices : 3
Life Support Monitoring : 2 independent life support monitors (O2 - CO2)

Price & terms : Please enquire using the email form below

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------
