40,000TLC Floating Dock for sale

Equipment ID: 2162
Equipment name: 40,000TLC Floating Dock for sale
Category: Floating Docks
Specifications: 40,000TLC Floating Dock for sale
282M Floating Dock for sale
Floating Dock - 1973 Built - For Sale

General
Year built : 1973
Type of floating dock : Self-docking type - 10 pontoons welded to side walls
Lifting capacity : 40,000 tons
Class and survey position : Not classed

Specifications
Length overall : 282.20m
Length of pontoon : 250.20m

Breadth extreme : 59.00m
Breadth outside walls : 57.00m
Breadth between walls : 49.00m at crane deck
Breadth between fenders : 47.00m

Height of dock walls : 23.00m
Height of pontoon at centre line : 6.20m with 0.20 camber
Height of keelblocks : 1.45m
Draft above keelblocks : 7.30m

Number/capacity of main pumps(s) :
5 x 3,500m3 x 15m (one pump for two pontoons)

Lifting time : Approx. 4 hours

Number/capacity of tank test pump(s) : 1 x 700m3
Number/capacity emergency fire pump(s) : 1 x 320m3 x 42m
Number/capacity of fresh water pump(s) : 1 x 100m3 x 40m
Number/capacity of generator(s) : 1 x 36kw x 440Vac x 60Hz
Number/capacity of mooring capstan(s) : 4 x 10t x 17m/min
Number/capacity of air winch(es) : 2 x 2t x 32m/min
Number/capacity of dockarm(s) : 2 x 2t x 18m
Number/capacity of crane(s) : 2 x 10t x 30m
Numbr of watertight tanks : 30 ballast tanks
Lightweight of floating dock : 21,000 metric tons

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------
