274FT Well Stimulation Vessel for Sale

Equipment ID: 2802
Equipment name: 274FT Well Stimulation Vessel for Sale
Category: Ships/Vessels
Specifications: Well Stimulation Vessel - 274ft - for Sale
OSV for Sale

Description :

General
Vessel Type : WSV - Well Stimulation Vessel
Vessel Class : OSV - Offshore Supply Vessel
Year Built : 1999
Classification : ABS, SOLAS, MARPOL

Dimensions
Dimensions : 274ftx 56ft x 21ft (83.5m x 17.07m x 6.4m)
Length Overall : 274 ft.
Draft (Lightship) : 7ft-2" (1.98m)
Draft (Loadline) : 16ft-10" (5.49m
Deadweight Tonnage : 2928.7 LT (2975.7 MT)

Capacities
Fuel Oil : 189,266 Gallons (716.4 m3)
Ballast : 396,973 Gallons (1502.7 m3)
Potable Water : 24,032 Gallons (91 m3)
Brine : 153,342 Gallons (3,651 bbls)
Dry Bulk : 7,946.3 ft3 @ 85 psig (225 m3 @ 5.8 bar)
Liquid Mud : 51,114 Gallons (1,217 bbls)
Special Products(SAND) : 4,217 ft3 (119.4 m3)
Acid : 60,720 Gallons (229.8 m3)
Gel : 12,600 Gallons (300 bbls)

Special Features
Ship Motion : Two (2) x Passive Type Anti-Roll Tanks
Ship Motion : Bilge Keels
Positioning : DPS-2 Dynamic Positioning System
Deck Crane : One (1) x 5,000 lb @ 30ft outreach Fixed Boom
Firefighting : One (1) 1250 GPM Fire Monitor

Machinery
Main Engines : Two (2) CAT 3516, 1,710 HP
Bow Thrusters : One (1) Schottel 820 kw 4-Blade CPP
Drop Down Thrusters : One (1) Ulstein 1,200 HP 4-Blades, FPP
Z-Drives : Two (2) Ulstein 1,600 HP Z-Drives
Speed : 13.9 Knots @ (12ft-0" Draft)
Emergency Generators : One (1) x 170 kw CAT-3306
Ships Service Generators : Two (2) CAT 3412, 500kw

Life Saving Equipment
Life Rafts : Four (4) x 20 Man Inflatable Life Rafts
Life Boat : One (1) 5.8m, 6 Person Capacity
Other gear as required by authorities

Accommodations : 29 bunks

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------
Search words (for official use only) :
274FT Well Stimulation Vessel for Sale
ABS Class Well Stimulation Vessel
1999 Built Well Stimulation Vessel for Sale
29 Bunks OSV for Sale
Well Stimulation Vessel - 274ft - For Sale
Offshore Vessel for Sale - 1999 Built - For Sale
-------------------------------------------------------------------------------------------------------

Worldoils Oil, Gas and Offshore Marketplace - 274FT Well Stimulation Vessel for Sale

Images

1999 Built Well Stimulation Vessel for Sale
