Offshore Supply Vessel - 57.91m - For Sale

Equipment ID: 2845
Equipment name: Offshore Supply Vessel - 57.91m - For Sale
Category: Ships/Vessels
Specifications:

Used Offshore Supply Vessel for Sale

Offshore Supply Vessel - 57.91m - For Sale

Description :

General

Class : ABS, USCG, SOLAS, MARPOL

Dimension
LOA : 190ft (57.91m)
LBP : 180ft (54.86m)
Breadth : 44ft (13.41m)
Depth : 19ft (5.79m)

Draft (min. operation) : 10ft (3.05m)
Draft (normal operational) : 15ft (4.57m)
Draft (load line) : 16.3" (4.95m)
Freeboard @ nor. opr. draft : 4.0ft (1.22m)
Lightship (est.) : 1000 Ltns.
Gross Tonnage (ITC est.) : 1300

Deadweight
Deadweight @ 10ft (min ops draft) : 594 l.tns
Deadweight @ 15ft (normal ops draft) : 1710 l.tns
Deadweight @ 16.281ft (load line) : 1915 i. tns

Cargo Capacities
Deck -
Free Deck Space : 39.32m x 10.67m
Clear Deck Area : 419.46 sq.m.
Deck Strength : 540 # / ft2
Deck Cargo : 1300 l. tons

Speed (est@ SSO)
Speed @ 10ft Draft : 13.2 knots
Speed @ 10.5ft Draft : 13.1 knots
Speed @ 12.25ft Draft : 12.3 knots
Speed @ 13.75ft Draft : 11.6 knots
Speed @ Norm Ops Draft (15ft) : 11.3 knots
Speed @ Load Line (16.281ft) : 10.9 knots

Main Propulsion
1 x 3512 Cat Diesels
1280 BHP @ 1600 erpm each

Azimuth Drives
2 x 900H Ulstein
4 Blade FPP

Bow Thruster
1 x Ulstein TCNS 73/50 swing up (3508 Cat)

Generators
Ships Service Diesel Generator - 2 x 300kw (3406 Cats)
Emergency Diesel Generator - 1 x 170kw (3306 Cat)

Ship Motions
2 Passive Type Anti-Roll Tank
Bilge Keels

Accommodations
1 x 1 man
3 x 4 man
Total : 13

Life Saving
1 x Rescue Platform
1 x Rescue Lifeboat and SOLAS Davit
2 x 20mn. Inflatable Life Rafts
2 x 10mn. Inflatable Life Rafts
Other gear as required by USCG

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------
