Offshore Supply Vessel - 1999 Built - For Sale

Equipment ID: 2879
Equipment name: Offshore Supply Vessel - 1999 Built - For Sale
Category: Ships/Vessels
Sub Category: OSV
Specifications: 240FT Offshore Supply Vessel for Sale
1999 Built OSV for Sale

Description :

General
Vessel Type : Offshore Supply Vessel
Year Built : 1999
Classification : ABS, USCG, SOLAS, MARPOL

Dimensions
Dimensions : 240 ft X 56 ft X 21 ft (73.15 m X 17.07 m X 6.4m)
Draft (Lightship) : 6 ft. 6 in. (1.98 m)
Draft (Loadline) : 17 ft 5.6875 in. (5.33 m)
Clear Deck : 165 ft x 46 ft (50.29 m x 14.02 m)
Cargo Deck Area : 7,590 sq. ft. (705.13 sq. m)
Deck Cargo Capacity : 1,750 LT (1,778.08 MT)
Deadweight Tonnage : 2,872.42 LT (2,918.38 MT)

Capacities
Fuel Oil : 315,260 gals. (1,193.39 cu. m)
Ballast : 262,209 gals. (992.57 cu. m)
Potable Water : 24,031 gals. (90.97 cu. m)
Dry Bulk : 8,050 cu. ft. @ 80 psi (227.95 cu. m @ 5.5bars)
Liquid Mud : 6,063 barrels (963.94 cu. m)

Machinery
Main Engines : Two (2) 3516 CAT Diesels, 3,200 BHP
Bow Thrusters : One (1) Ulstein TCNS Swing Up
Bow Thrusters : One (1) 340 HP CAT 3406
Stern Thrusters : Two (2) Ulstein 1350H Azimuthing
Speed : 14.2 knots
Generators : Two (2) x 3412 CAT
Generators : One (1) x 3306 CAT

Special Features
Tuggers : Two (2) x 4 Tons
Ship Motion : Two (2) Passive Type Anti-Roll Tanks
Ship Motion : Bilge Keels
Positioning : DP-2

Life Saving Equipment
Life Rafts : Four (4) x 20-Man Inflatable Life Rafts
Rescue Platform
Other gear as required by authorities

Electronics
Electronics Package :
Two (2) Young Wind Tracker
NAVTEX NCR-300A Receiver
Seacall 7000 MF/HF DC Watch Receiver
NDZ-127C Inmarsat Data Terminal
Seator 3000 GMDSS
Two (2) Furuno FAR-2117 Radars
Furuno FCV-600L Depth Sounder
Two (2) FM-8900S VHF/FM Radios
J-NAV 500 GPS/Loran
One (1) Seacall 7000 VHF DCS Controllers
NECODEDSC 1000
Kongsberg Simrad SJS-01 Autopilot
Marine Technologies Bridge Mate DP 2 System
Two (2) DGPS Units
Two (2)Gyro Compasses
One (1) Laser Ranging Reference Unit

Accommodations : 29

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------------
