OSV- 1999 Built - For Sale

Equipment ID: 2887
Equipment name: OSV- 1999 Built - For Sale
Category: Ships/Vessels
Sub Category: OSV
Specifications: OSV- 1999 Built - For Sale
1999 Built Offshore Supply Vessel for Sale

Description :

General
Vessel Type : Offshore Supply Vessel
Year Built : 1999
Classification : ABS, USCG, MARPOL, SOLAS

Dimensions
Dimensions : 240 ft. X 56 ft. X 21 ft. (73.15 m X 17.07 m X 6.40 m)
Draft (Lightship) : 6 ft. 6 in. (1.98 m)
Draft (Loadline) : 18 ft. (5.49 m)
Clear Deck : 165 ft. x 46 ft. (50.29 m x 14.02 m)
Cargo Deck Area : 7,672 sq. ft. (712.75 sq. m)
Deck Cargo Capacity : 1,750 LT (1,778.08 MT)
Deadweight Tonnage : 3,264 LT (3,316.38 MT)

Capacities
Fuel Oil : 207,023.3 gals. (783.67 cu. m)
Ballast : 401,268.3 gals. (1,518.97 cu. m)
Potable Water : 24,031.6 gals. (90.97 cu. m)
Dry Bulk : 8,106.4 cu. ft. @ 80 psi (229.55 cu. m @ 5.5 bars)
Liquid Mud : 6,063 barrels (963.94 cu. m)

Machinery
Main Engines : Two (2) 3516 CAT Diesels, 3,200 BHP
Bow Thrusters : One (1) 340 HP CP Tunnel
Bow Thrusters : One (1) 1,280 HP Dropdown
Stern Thrusters : Two (2) Ulstein 1350 Azimuthing, 1,600 HP
Speed : 14.2 knots
Generators : Two (2) x 500 kW
Generators : One (1) x 170 kW

Special Features
Tuggers : Two (2) x 4 Tons
Ship Motion : Two (2) Passive Type Anti-Roll Tanks
Ship Motion : Bilge Keels
Positioning : DP 2
Cranes : One (1) 3,100 lb. SWL Hydraulic Deck Crane

ROV :
C-Innovations 2007 UHD with Dynacon Telescoping A-Frame,
Hydraulic Power Pack and Winch

Life Saving Equipment
Life Rafts : Four (4) x 20-Man Inflatable Life Rafts
Rescue Platform
Other gear as required by authorities

Electronics
Electronic Package :
Sailor R-501 2182KHZ Watchkeeper Receiver,
Young Wind Tracker
NAVTEX NCR-300A Receiver
Seacall 7000 MF/HF DC Watch Receiver
JUE-75C,
NDZ-127 C Inmarsat Data Terminal
Seator 3000 GMDSS
(2) Furuno FR-1510 Mark-2 Radars
Furuno FCV-667 Depth Sounder
(2) Sea F156 VHF/FM Radios
Raytheon NAV/398GPS/Loran
(2) Seacall F100 VHF DCS Controllers
NECODE DSC 1000
Kongsberg Simrad STS-01 Auto Pilot
Marine Tech Bridge Mate Dynamic Positioning System

Accommodations : 27

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------
Search words (for official use only) :
73.15M Offshore Supply Vessel for Sale
OSV - 14.2 Knots Speed - For Sale
240FT Offshore Supply Vessel for Sale
27 Accommodations Offshore Supply Vessel for Sale
73.15M OSV for Sale
ABS Class Offshore Supply Vessel for Sale
Used OSV - 240ft - for Sale
------------------------------------------------------------------------------------

Worldoils Oil, Gas and Offshore Marketplace - OSV- 1999 Built - For Sale

Images

1999 Built Offshore Supply Vessel for Sale
