1200bhp Towing Tug For Sale
Newbuilding 1200bhp Towing Tug For Sale

Principal Particulars
Class : NKK
Length Overall : 23.500m
Length B.P. : 21.322m
Breadth Moulded : 7.315m
Depth Moulded : 3.200m
Draft Moulded : 2.700m
Trial Speed : approx 10 knots

Machinery
Main Engine : Cummins KTA19-M3, 2 x 600BHP / 1800 rpm
Gear box : Twin Disc MG5170, Ratio: 5.00:1
Propeller : 2 x Solid Fixed Pitch Propellers
Main Generator : 2 x Cummins / Yanmar 24kw

Tankage
Fuel oil : 82.70M³
Fresh water : 25.00M³
Ballast : 29.00M³

Deck Machinery
Anchor : 2 x stockless bower anchors (360kg)
Chain Cable : 17.5mm Nine (9) lengths of Grade U2 chain
Anchor Windlass : 17.5mm anchor windlass
Towing Hook : 1 x 20 tons

Navigation & Communication Equipment
Echo sounder : 1
GPS : 1
Radar : 1
6” Compass : 1
4” Spare compass : 1
SSB Transceiver : 1
ICOM VHF IC-M45 : 1
EPIRM : 1
Klaxon horn : 1
Battery clock : 1
Barometer : 1
Binocular : 1
Clinometer : 1
Marine clock : 1
Ship bell : 1
Floodlight : 4
Searchlight : 1

Auxiliary Equipment
F.O. Transfer pump : 1 x 4HP Wonder three phase induction motor c/w self-priming
pump 2DV Y100L-4
Bilge & Ballast pump : 1 x 4HP Wonder phase induction motor c/w self-priming pump
2DV Y100L-2
GS pump & fire pump : 1 x 4HP Wonder three phase induction motor c/w self-priming
pump 2 DV Y100L-2
Oily water separator : 0.25M³/hr

Fire Fighting System
2½ IB Fireman Axe : 1 set
Three Foam : 1 unit
Extinguisher fire buckets : 3 sets
Fire extinguisher : 8 sets
Portable diesel fire pump : 1 set

Life Saving Equipment
Life Raft : 8 sets
Life Buoy light : 4 sets
Fireman outfit : 1 set
Life Jackets with lights : 14 sets
Parachute distress : 12 units
Smoke signal : 2 sets
10 men Liferaft with Hydrostatic release units : 2 sets

Accommodation
Total Complement : 10 Crews

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------------------------------------------
