Diving Support Vessel For Sale
DSV for Sale
Survey Vessel For Sale

Dimensions
Length Overall:  49.0 m
Breadth moulded:  12.2 m
Depth moulded:  4.5 m
Summer Draft:  3.65 m
GRT / NRT  783/234

Registration
Built:  1982
Class:  DNV +A1(E) + MAS Ocean going towing service

Machinery
Main Propulsion:  2 x 1500 BHP Yanmar T260-ET
Schottel/ Thruster: 1 x 485 BHP 3.5 ton Any direction
Generators:  3 x 160 kW, 440V, 60Hz

Capacities
Fuel oil:  495 m3
Fresh water:  234 m3
Clear deck area:  236 m2 250 ton
16.0 x 8.5 m

Deck Machinery
Crane:  Sekigahara Hydraulic Telescopic
Capacity:  3 tonnes @ 12 m outreach
Weather Anchoring System  :
2 x electro-hydraulic 7.5 tonne @ 9m/min windlass
with 2 x 1315 kg anchors with 520 m x 32 mm chain
Capstan:  1 x 5 tonne

Accommodation (Total 30 berths)
Cabins / Berths:
4 x 1 berth
3 x 2 berth
5 x 4 berth
Other:  Galley, mess / recreation room
Optional Accommodation :1 x 4 Berth Porta-Cabin

Diving Support
Workshop : Lathe, drill, grinder, arc welder – 25kVA
Diving Air Comp  167 m3 /hr @ 14 kg/cm2

Electronics
Radars:  Furuno FR-2115 x 72 miles
Auxiliary Radar: Furuno FR7111 x 72 miles
Auto Pilot: Tokyo Keiki with Sperry ES11 Gyro Compass
Satellite Navigation: GPS RS5700 Shipmate
Furuno DGPS receiver

Communications
GMDSS: 1
VHF: 2
VHF Portable: 3
SART:  1
EPIRB:  1
Navtex:  1
Inmarsat M : 1
Iridium : 1

Miscellaneous
Deck : Wood Sheathed Main Deck
FRV/Workboat:  Zodiac Inflatable
Safety Equipment:  Statutory Life buoys, jackets, pyrotechnics
Air Diving System:  Optional
Insp. Class ROV:  Optional
Work Class ROV:  Optional

Performance
Speed :
@ 100% - 13 kts
@ Economic – 10 kts
Consumption :
@ 100% MCR: 8.5 tonne/day
@ Economic: 7 tonne/day
@ ROV Ops: 2.5 tonne/12 hours

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------------------------------------------
