Accommodation Vessel For sale
Accommodation/work Barge For Sale
300 pax work barge for sale

Principal Particulars
Length Overall : 111.324 m
Breadth Moulded : 30.480 m
Depth Moulded : 6.864 m
Draft (Max) : 4.50 m
Built : 2008
Class : ABS
Notation : ABS + A1 Accommodation Barge

Cargo Capacities
Deadweight : approx.13942 tons
Deck Strength : approx. 20 T/sq.m
Clear Deck Area : approx . 1350 cbm
Fuel Oil : approx. 1200 cbm
Fresh Water : approx. 1200 cbm
Ballast Water : approx. 7500 cbm
Freezer/Chiller : approx. 50 cbm / 55 cbm

Pumps
Fuel Oil : 1 x 80 cbm/hr @ 60 m/head
Fresh Water : 1 x 100 cbm/hr @ 60 m/head
Ballast Water : 2 x 300 cbm/hr @ 40 m/head

Deck Equipment
8-point Mooring : 8 x single drum electro-hydraulic; min. 60 Tons
                         c/w tension sensors, wire length counter,
                         16 vertical sheaves & 8 universal fairleaders
Drum : suit' for 1500 m (L) x 48 mm (Ø) SWR
Brake Capacity : 120 mt static @ 1st layer
Anchor Wire : 8 x 1500 m (L) x 48 mm (Ø) SWR
Anchors : 9 x 10000 kg Flipper Delta Anchors
Pennant Buoy : 10 x 2.45m (L) x 1.83m (Ø) foam-filled type

Helideck
suitable for N61
25.62m x 25.62m

Deck Crane
Pedestal mounted L500-120 crane

Accommodation
Single berth : 12 x 1 berth
Double berth : 14 x 2 berth
Four (4) men berth : 65 x 4 berth
Total : 300 berth
All cabins fully air-conditioned, comply to ILO 92, IMO Resolution A468 (XII), PGBOOM

Radio & Navigational Equipment
GMDSS : Area 2 comprising
SSB : 1 x Furuno FS-1570T
Inmarsat C : 1 x Furuno Felcom 70
VFH Radio : 2 x Furuno FM 3000 with built-in DSC
                   1 x Furuno FM 8800S wth built-in DSC
Navtex Receiver : 1 x Furuno NX 700A
SART : 2 x Mc Murdo S4
EPIRB : 1 x Mc M urdo E3A
Portable VHF Radio : 3 x Mc Murdo R2
Portable Marine VHF Radios : 3 x Motorola GP-328
                                            8 x ICOM M88
VHF Air Band T'receiver : 1 x ICOM IC-A200
                                     1 x ICOM IC-A6 (HLO)
Satellite Mini-M : 1x Sailor Trane
VHF for Crane : 1 x Simrad RT62
Radar : 1 x Furuno FR-7062
Echo Sounder : 1 x Furuno FE700
GPS : 1 x Furuno GP150
Gyro Compass : 1 x RAYTHEON ANSCHUTZ
Weather Fax : 1 x Furuno FAX 207
Barge also fitted with PA System and Sound Powered Telephones

Fire Fighting & Survival Equipment
Fire Pump : 1 x 300 m3/hr @ 80 m/head; KSB
Fire Monitors : 2 x 73.5 m3/hr@7 bar; Skum FJM-80
Emergency Fire Pump : 1 x 300 m3/hr @ 80 m/head; Engine Driven
Life Rafts : 24 x 25 man SOLAS approved
Rescue Boat : 1 x 6 persons SOLAS approved c/w davit
Fire Detection System in all enclosed spaces.
Fixed CO2 system for generator room and paint store.
Fixed automatic water sprinkler system for whole accommodation spaces incld
store & workshop.

Other Facilities
Hospital : 2 x double berth hospital with attached paramedic room
Offices : Total 4
Conference Rooms : 1 with seating capacity for 20 men
Messrooms : 1 x main mess with seating capacity for 150 men
Recreation Rooms : 1 main room with seating capacity for 48 men
                              1 x Prayer Rooms, 1 x Meeting Room,
                              1 x Control Room, 1 x Change Room,
                              1 x Laundry/Drying Room, 1 x Dry Provision Room,
                              1 x Gym Room
Workshop : 1 complete w/ lathe, drilling machine, grinding
                  machine, electric saw, milling machine
                  oxy/acetlyene
                  Welding machine

Miscellaneous
Oil Water Separator : 1 x 2.5 m3/hr c/w 15 ppm alarm;
Sewage Treatment Plant : 2 x 250men
Water Maker : 2 x 50 m3/day reverse osmosis; Hansun

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-------------------------------------------------------------------------------------------------------------
