Offshore Support Vessel - 58m - for sale - 2003 built
OSV for sale

Specifications :
Type of Vessel : Offshore Support Vessel
Year built : 2002
Registered : 2003
GRT/NRT : 1368/410

Plying Limit : Unrestricted
Classification : American Bureau of Shipping.
Class Notation : ABS + A1 E Offshore Support Vessel *AMS* FiFi Class1
Horse Power : 2 x 2100 BHP
Cruising Speed : 12 Knots

Fuel Consumption :
Cruising Speed 650 Litres/hour
Generator 80 Litres/hour

Main Characteristics :
L.O.A : 57.50 M
Breath Moulded : 13.80 M
Depth Moulded : 5.50 M
Max Draft : 4.50 M
Deck Strength : 7 MT/sq m
Clear Deck space : Approx. 350 sq. m
Deck Cargo : 700 MT
Deadweight : 1369 Tonnes

Capacities :
Fuel Oil : 350 cu.m
Fresh Water : 200 cu.m
Drill Water : 380 cu.m
Liquid Mud : 2 x 125 cu.m
Dry Bulk : 4 x 1650 cu. ft
Foam : 11 cu.m
Detergent : 11 cu. m
Freezer : 6 cu. m
Chiller : 8 cu. m

Auxiliaries :
3 x Caterpillar 3408 C
Genset 315KW/415V/3Ph/50Hz

Pump :
2 x 1200 cbm/hr @ 11 bar cu.m. at head 30m.
Main fire pump : 1 x Allen gwynnes nimbus pump capacity of 50 cu.m at head 100 m.
Emergency fire pump : 1 x Yanmar VDP20E pump capacity 500 ltrs/min at head 30m.

Deck Machinery :
3 x 5 MT electric capstan.
1 x 8 MT @ 12 m/min electric hydraulic type c/w 2 x wildcats plus 2 x warping drums
2 x 1590 kg stockless bower anchors
Total 372 m x 34 mm U2 stud-link chain

Propulsion Machinery :
Main Engines : 2 x Caterpillar 3516 B each of 2100 BHP
Marine Gearbox : 2 x Reintjes WAF 862 L with ratio 5.50 : 1
Propulsion : 2 x Berg controllable pitch in kort nozzles
Bow Thruster : 1 x 325 KW Kawasaki KT-43 B1 (CPP) tunnel units of 5 MT thrust

Navigation & Communication Equipment :
GMDSS : Area 3
Gyro Compass : 1 x Furuno
Radar : 2 x Furuno
Echo sounder : 1 x Furuno
SART : 2 x Joltron
EPIRB : 1 x McMurdo MCM-406A
Navtax Receiver : 1 x Furuno
Autopilot : 1 x Anschuetz
Weather Fax : 1 x Furuno
Speed Log : 1 x Furuno
GPS Plotter : 1 x Furuno

Accommodation :
Fully air conditioning total 50 berth
1 x 2 berth hospital & 1 x office

Fire Fighting Equipment :
Fire Pump : 2 x 1200 cbm/hr @ 11 bar
Fire Monitor : 2 x 1200 cbu/hr @ 12 bar
Fire Extinguish system : Fixed Co2 system for engine room
Fire Hydrants and Extinguishers : As per Classification’s requirement

Life Saving Appliances :
As per SOLAS 74/78, Port of Registry and Classification’s requirements

Other Equipment
Life Rafts : 4 x 25 men
Rescue Boat : 1 x 6 men rigid rescue craft c/w davit & 25 HP outboard engine.
Manoverboard : 2 x Comet.
Deck flood light : 3 x 1000 W deck flood light.
Compressor : 1 x BA recharging compressor

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------------------------------
