Platform Supply Vessel DP1 for Sale
1983 built 2960dwt PSV for Sale

General
Built : 1983
Class : ABS +A1E, +AMS

Characteristics
LOA : 67.2 m
Beam : 16.8 m
Depth : 7.1 m
Maximum draft : 6.1 m
Freeboard : 1.0 m
Deadweight : 2960 t
Clear deck space : 43.0 x 14.4 m
Deck strength : 5.9 t/sqm
Deck Area : 619 sqm

Capacities
Deck cargo : 1,550.0 t
Cargo water : 1,699.0 t
Fuel oil : 818.6 t
Potable water : 964.0 t
Bulk tanks (4) Total : 339.8 cbm
Drilling fluid : 305.2 cbm
Brine : 386.0 t
Oil dispersant system : 21.1 t

Machinery
Main engines :
(4) Diesel elect. AvK DIDB130 FG/G
Horsepower - 6960

Gears : (2) Liaaen TCN  92/68 (Z-Drive)
Propellers : (2) Azimuthing CP (Z-Drive)
Z-Drive : Yes
Kort nozzles : Yes
Primary Generators : (4) 1205 kW 600 V 60 hz
Secondary Generators : (1) 150 kW 440 V 60 hz
Auxiliary Generators : (1) 10 kW 220 V 60 hz
Emergency Generators : (1) 10 kW 220 V 60 hz
Bow Thruster : (2) 900 bhp

Performance (Assuming fair weather)
Speed / Fuel Consumption -
Maximum : abt 11 knots / about 130 gph
Cruising : abt 10 knots / about 115 gph
Economical : abt 10 knots / about 115 gph
Standby (Generator only) : 0 knots / about 10 gph
Range @ 11.0 knots : about 21,484 nm

Transfer rates -
Cargo water : 100.0 t/h @ 75.0 m
Fuel oil : 85.0 t/h @ 75.0 m
Potable water : 100.0 t/h @ 75.0 m
Bulk : 45.0 t/h @ 56.0 m
Drilling fluid : 100.0 t/h @ 100.0 m

Tow and Anchor Handling
Tugger : (2) Hydraulic (cent. low press)
Line pull : 22,046 lbs

Vessel Mooring
Windlass : Ankerspill Type R8
Anchors : (2) Stockless 4230 lb (+1 spare)
Chain (per side) : 3,250ft of 1.65 in
Capstans : (2) Hyd. (cent. low press.)

Accommodations
Staterooms : (10) - 1 man (6) - 2 men
Hospital : Yes
Air conditioning / Heating : Yes

Electronics
Radar(s) : 2
Radio (s) : VHF - 2 , SSB - 2
Depth Sounder : 1
Gyro Compass : 1
Satellite navigation : 1
GPS : 1
Wind speed indicator : 1
GMDSS : 1
Auto pilot : 1

Special Equipment
Oil dispersant system : Yes
Joystick controls : Yes, Kongsberg
Dynamic positioning : DP-1 unclassed
Rescue boat : Yes
Lube oil purifier : (4) for primary generators
Fuel oil purifier : 1

Price & terms : Please enquire using the email form below.
If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

------------------------------------------------------------------------------------------------------------------------
