Main Particulars :
Length O.A. : 30m
Length B.P. : 25.2m
Beam MLD. : 10.8m
Depth MLD. : 5.4m
Crew : 12
Design Draft : 3.6m
Max Draft : 4.7m
GRT : 469
NRT : 140

Classification Notation :
BVâ…  Hull Mach, Salvage Tug / Utility Boat / Fire Fighting Ship 1
unrestricted navigation

Year Built : 2010

Main Capacity :
FO : ~267m3
FW : ~80m3
Fi-Fi Foam : 18.16m3
Spilled Oil Dispersant : 4.5m3
Lube Oil : 1.0m3

Anchoring and Towing Equipment :
-Single Reel Hydraulic Towing Winch Set :
Maker : Plimsoll - Singapore
Capacity(Steel Wire) : φ46mm×770M
Brake Holding : 150 MT
Rated pull : 20MT@0~10M/min and 5MT@0~30M/min
Hydraulic emergency release

-Hydraulic Anchor/Escort (Towing) Winch Set :
Maker : Plimsoll - Singapore
Anchor weight : 2 × 570 kg
Diameter of anchor chain : Φ20.5 mm
Rated hauling speed : 1.83MT@0~15M/min
Capacity(P.P. Wire) : φ100mm×110M
Brake Holding : 120 MT
Rated pull : 18MT @ 0~10 M/min

- Electro-hydraulic collapsible mast : 1set

Main Machinery & Propulsion Unit :
Main Engine Sets : CUMMINS – USA-UK
- Power 2,200 BHP @1,800rpm/min
- Model CUMMINS QSK60-M
- Quantity Two Sets

Marine Gen. Sets CATERPILLAR – USA
- Model CATERPILLAR 3406MGS
- Power 245eKW /400V/50HZ/ 3Φ
- Quantity Two Sets

Harbour Genset 1×DuFong-CUMMINS CCFJ-60J– US-China
- Power 60KW /400V/50HZ/ 3Φ

Marine Crane SQ8ZB3
- Max. Lifting SWL0.98MT@12M/ 8MT@2M
- Quantity One Set

ASD Propellers
- Model AQUAMASTER US205MK2 FP
- Maker ROLLS ROYCE – Finland
- Quantity : One set

Bow Thruster 1×STT110L-FP
Power 90KW

Oily Water Separator 0.25M3 x One Set

Sewage Treatment 20-22 persons
Plant One Set

External FIFI System (SOLAS – FIFI 1 Class)
- Firefighting Monitor  2×1200/300M3/hr(water/foam),
range120/70M(water/foam) height water throwing 50M(water)
- Firefighting Pump  1×2400M3@1.17MPa
- Maker  FFS – Norwegian
F.O. Separator 1 x 1500L/h

Lifesavng and FiFi Equipment :
- In compliance with the SOLAS requirements, Hong
Kong merchant shipping ordinance and class notation
requirements as regards Lifesaving & FiFi equipment.
- CO2 System as per BV Rules
- 8 x Life buoy; 16 x Life jacket; 2 x 15persons Liferaft;
Portable Fire Extinguisher : 11 x 9kg foam; 6 x 5 kg CO2; 9
x 6kg Dry Powder; 1x 45 L Foam Fire Extinguisher
(cart-pushing); 4 sets fireman outfit with breathing
apparatus; 2 sets breathing apparatus of artificer diver; 2
sets gas mask with filter; 4 sets flood protection unit of1M
x 2M; 12 x parachute distress rocket; 2 x Orange Smoke
signal; 6 x Floating Light
- Salvage and support Pump ability : 100M3/h & 90M3/h
- Electric Fifi General Pump ability : 25M3/hr
- Spare Electric Fifi Pump ability : 25M3/hr
- Spilled Oil Dispersant System

Main Radio & Navigation Equipment :
Radar 1×FR-1510MK3
Echo Sounder 1×Furuno FE-700
Speed Log 1×Furuno DS-80
Anemometer 1×Furuno FI-50
GPS 1×Furuno GP-150
Electrical Horn 1×Yahagi E3M-24
Autopilot 1×Alphaseapilot MFC
Vertical Standard Magnetic Compass 1×CPL-165
Steering Magnetic Compass 1×CPT-130
Sound Power Tele. 1×12KSL
Public address system 1×KSGB-JQ
AIS  1×Furuno FA-150

A3 sea GMDSS
MF/HF SSB 1×Furuno FS-2570
Inmarsat-C(SSAS) 1×FELCOM-15(IC-307)
Inmarsat-C 1×FELCOM-15
VHF telephone 2×Furuno FM-8800S
NAVTEX 1×Furuno NX-700B
SART 1×Pathfinder 3 SART
EPIRB 1×ACR RLB-32
Portable VHF 2×ACR SR-102

Air Conditioning System :
-Equipped centralized air- conditioning for
Wheelhouse, Mess Room, Captain’s and Chief
Eng. Room and other crew room.
-Equipped split-type air handling unit for
engine room centralized control room and
split-type air- conditioner for wheelhouse.

Accommondation & main living facility
2×Senior Officer Cabin for single
1×Senior Officer Cabin for two men
2×Crew Cabin for four men
1×Assemble-type Provisions Freezer
2×Twin Head-type Induction Hob
1×Berlin centralized electric water heater
1×Cleemann Captain Chair – Germany
- Model : Nautic D GZ
- Material : Synthesized leather
- Width : 610mm
- Height : Min558mm / Max718mm
- Length of rail : 2200mm

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------
