F.O capacity : approx 393 cub.mt
F.W capacity : approx 100 cub.mt
L.O capacity : approx 1.0 cub.mt

Main engine : 2 x cummins KTA 50 - M2 1600bhp @ 1800 rpm
Gear box : reintjes type WAF 663 ratio 5.95:1
Generator : 2 x cummins (China) 90kW 400V/3P/50Hz

Propeller :
Two (2) units of slid 4 blades nikel aluminum bronze
propeller complete with kort nozzle

Steering gear system : one (1) unit 3.0 tons electro-hydraulic

Anchor windlass :
26mm electric hydraulic 3 tons @ 10m/min c/w
double gypsy and double drum

Anchor : two (2) units of 660 kgs stockless
Anchor chain : 26mm 15 shots grade U2

Towing winch :
one (1) unit 40 tons double drum waterfall type.
Drum capacity for wire length 47.5mm dia x 700 m

Stern roller :
taizhou marine equipments works 600-900mm dia x 2,230mm L

Sewage treatment plant :
one (1) unit of wuhan zhongzhou marine for 14 men

Bilge & ballast pump :
two (2) unit jiangsu zhenhua pump industry co. ltd
36 cub.mt/hr, 30 m head, 400/3/50

GS & fire pump :
one (1) unit jiangsu zhenhua pump industry co ltd
36 cub.mt/hr, 30m head, 400/3/50

Fuel transfer pump :
two (2) unit jiangsu zhenhua pump industry co ltd
20 cub.mt/hr, 30m head, 400/3/50

FW / SW pressure pump :
two (2) units taizhou hailong marine equipment
c/w 3 cub.mt, 40 psi, 220/1/50

Dirty oil pump :
one (1) unit jiangsu zhenhua pump industry co ltd
5 cub.mt/hr, 30 m head, 400/3/50

Oil water seperator :
one (1) unit WUHAN zhongzhou marine 500ltr, at 2kg/mt.sq

Ship communications :
1 x electric engine telegraph
1 x 24 v electrical air horn c/w compressor
1 x hand operated mechanical fog horn
3 x wall mounted type intercom
1 x mini m tracphone
1 x furuno weather fax
1 x satellite EPIRB

Radio & navigational : 1 x daiko magnetic compass
Equipment :
1 x GMDSS area A1, A2 & A3
1 x Inmarsat C
2 x marine radar
2 x marine radio VHF
1 x marine SSB
1 x echo sounder
1 x navtex receiver
1 x GPS navigator
2 x two-way marine radio VHF (walkie-talkie)

Navigation lights/fire fighting equipments/life saving appliances :
All accordance with BV classification society's specification and
requirement of the government authority for the intended trade of
the subject

Air-conditioning : 5 x daikin ceiling type fitted at master cabin, c/engr cabin, crew
accommodation, mess room and bridge

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------
