Principal Particulars
Class Notation :
ABS class Maltese cross +A1Barge Unrestricted
service Derrick/PipeLay Barge

Length Overall : 169.00m
Beam Moulded : 46.00m
Depth Moulded : 13.50m
Draft Moulded : 7.00m

Operation drought approx. : 63,500T
Ballast capacity : 35,000 cbm
Fuel oil capacity 4,000 cbm
Potable water capacity : 3,000 cbm

Accommodation
12 x One-man cabins : 12 men
51 x Two-man cabins : 102 men
49 x Four-man cabins : 196 men
Total Complement : 310 men

Pipelay Equipment
Capacity : 4"~48", Max. 60" outdia.
Tensioner : 2 Tensioners, 100T each
A&R winch : Ø88 x 1200m 200T Min. tension
Davit : 5 mounted, capacity 30T each
Stinger : Fixed

Crane (ZPMC)
Main hook :
3000MT x 30m(stern)
2000MT x 35m(revolving)

Auxiliary hook : Load 600MT
Height : 95m
Depth under water : 150m

Machinery
Diesel engine :
Hyundai 8H25/33, 4 x 2400Kw, 450V/3pH/60Hz

Main generator :
Hyundai 1 x 2256Kw, 450V/3pH/60Hz
Auxiliary gen. set Caterpillar 1 x 315Kw

Life Saving
Life raft : 22 x 25 men
Life buoy : 16 sets
First Aid Kit : 1 set
Rescue boat : 1 Unit with single arm davit
Life jacket : 17 pcs

Deck Machinery (SKW)
Mooring Winch : 12 sets of mooring winch with 200t drake brake
Mooring Anchor : 12 tones Delta Flipper type
Wire ropes : 12 sets x 76mm wire rope and 2500m long each

The main deck is capable of store abt.5000t pipes. The loading, unloading and
transfer of pipes is to be carried out by one (1) pipe crane, roller and transport
be fitted on stern.

Navigation & Communication (Raytheon/Furuno)
DCPS 2 sets
Navtex receiver : 1 set
VHF : 1 set
Two way VHF for life boat : 3 sets
Echo sounder : 2 sets
GPS : 1 set
Magnetic Compass : 1 set
Radar system : 2 sets
Gyro Compass : 1 set

Auxiliary Equipment
Sewage treatment units
Fresh Water maker
F.O. transfer pump
Ballast system
F.W. pump
Fresh Water transfer pump
Dirty Oil pump
Bilge & ballast pump
Oily water separator
Sewage treatment plant
Intended Area of working : Worldwide

Crane expected completion/delivery Feb 2012

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
---------------------------------------------------------------------------------------------------------------
