Self Propelled Jack Up Barge - 225 ft - for Sale

Equipment ID: 1435
Equipment name: Self Propelled Jack Up Barge - 225 ft - for Sale
Category: Jack Up Barge
Specifications: Jack Up Barge 225 ft for Sale
Self Propelled Barge for Sale

Classification Notation
ABS, *A1, Self-Elevating Units, * PAS

Main Dimension
Length overall Loa : 66.90m
Length moulded : 43.80
Breadth moulded B : 39.00m
Depth moulded D : 5.20m
Design draft T : 3.20m

Main deck area : ≥ 500sqm
Maximum variable load : 800t
Dec load : 5t/sqm
Speed : ≥ 4.0kn

Accommodation : 55p
Main engine : 960 kw x 2
Main generator : 350 kw x 3
Emergency generator : 200 kw x 1
Main crane : 50t@8m/20t@28m
Auxiliary crane : 3t@28m

Helideck : Bell 212 or 412

Jacking Capacity
Leg length (including spud can) : 67.056m (220ft)
Leg configuration : Column
Lifting capacity (each leg) : 1000t
Jacking system : Hydraulic ram and pin type
Jacking speed : 12m/h (39.37ft/h)

Environmental Condition
Environmental Criteria / Operation / Storm Survival
Max. water depth (m) / 45 / 25
Max. wave height (m) / 5 / 7
Wave period (s) / 9.6 / 9.6
Wind (1-minute averaged) (m/s) / 25 / 51.5
Surface current (m/s) / 1.4 / 2.057
Max. air gap (m) / 5 / 6
Design temperature (oC) / 0~40 / 0~40
Design life (year) / 20 / 20

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------
