280 Feet Accommodation Work Barge
Principle Particulars
Length Overall : 85.344 m (280ft)
Length BP : 81.93 m
Breadth Moulded : 24.38 m (80 ft)
Depth Moulded Admidship : 4.88 m (16 ft)
Displacement Max. Draft : 8935.77 T
Draft (Max) : 4.50 m
Built : 2008
GRT / NRT : 4441/ 1332 / 3951 T
Class : B.V.(Bureau Veritas)
Notation : 1 + HULL Special Service-Offshore Work Barge
Cargo Capacities
Deadweight : 3951.22 T
Deck Strength : 15T/sq.m
Clear Deck Area : 650 Sq.Mtr (W/out Crane Space)
Fuel Oil : 906.40 M3 (approx)
Fresh Water :
895.6 M3 (approx)
3070.2 M3
Freezer/Chiller : 2 x 25.54 m3
Seawage Tank : 53.70 M3
Dirty Oil : 21.5 M3
Pumps
Fresh Water Cargo Transfer Pump : 1 X 80 m3/hr @ 50m/head
Fresh Water Pressure Pump : 2 x 50 m3/hr @ 50m/head
Sea Water Pressure Pump : 2 x 100 m3/hr @ 600m/head
Machinery
Generator : 3 x Cummins Chongqing - Model KTA19G4M
Alternator : 500kVA, 0.8pf, 400kW, 415/230V, 50Hz 1500rpm
Emergency Generator :
1 x Cummins Marine - Model 6CT8.3-GM115
123.75kVA, 0.8pf, 99kW, 415/230V, 50Hz 1500rpm
Deck Equipment
2 x 1 man Cabin : 2 men
1 x 10 men Cabin : 8 men
Total : 12 men
Deck Machineries
8-point Mooring:
4 x Diesel driven drum waterfall winch, 77 tones line Pull (AM HOIST-AM77EF)
Drum Cap 1200m (L) x 38mm (Ø) SWR
16 vertical sheaves & 8 fairleaders
Brake Capacity : 72 tons static
Anchor Wire : 9 x 1200 m (L) x 38 mm (Ø) IWRC Wire
Anchors : 10 x 5000 kg Flipper Delta Anchors
Suitcase Buoy : 10 x 2.45m (L) x 1.83m (Ø) (Buoyancy 1.2mt)
Capstan Winch : 4 x 10 mt, Electric Drive
Deck Mounted Pedestal Crane :
"Liebherr" CBO 3600-70 Litronic (6.2M @ 70T)
(Power 440V, 60Hz,3 phase/Max Radius 51 mtrs)
Rescue Boat w/ Davits :
1 (SCM12-3,5R,Winch 04-03E)
(Max SWL 10kn, Testload Stastic 22kn)
Auxiliary Equipment
Single berth : 6 x 1 berth (6 men)
Double berth : 4 x 2 berth (8 men)
Four (4) men berth : 34 x 4 berth (136 men)
Total : 150 men
All cabins fully air-conditioned.
(AHU Central Air Cond' System on M'Dk, Level 1, Level 2 )
Radio & Navigation Equipment
GMDSS : Sea Area A1+A2
SSB : 1 x Furuno FS-1570 (MMSI-370940000)
Link Sintel-Tel Net (F.B.B) : 1 x Sailor 150 Fleetbroad band
VHF Radio : 2 x Furuno FM 8800 wth built-in DSC
Navtex Receiver : 1 x Furuno NX 700
SART : 2 x Mc Murdo S4
EPIRB : 1 x Mc Murdo E5
GMDSS ,VHF Rdo : 3 x Mc Murdo R2
Portable Marine VHF Rdo(IS) : 8 x Motorola GP-328
Radar : 1 x Furuno 1932 MK2
Echo Sounder (Color) : 1 x Furuno FCV585
GPS , GPS Compass : 1 x Furuno GP32 , 1 x Navigator GP150
Weather Fax : 1 x Furuno FAX 408
AIS : 1 x Furuno fa150
Magnetic Compass : 1 x Daiko T-150B
Wind Monitor /Tracker : 2 x Young 05103-58/06206
Air Band VHF (Hand Held) : 1 x Icom IC-A6
Helicopter Comm. Equipment : 1 Set Non DF Radio Beacon,VR-125/250
VHF Airband Transceiver : 1 x IC-A110
THD satellite compass : 1 x Furuno SC-50
Barge also fitted with Vingtor PA Talkbalk System and Sound Powered
Telephones (18 lines)
Batteryless Telephone Vingtor (VSP-213-L) 6 lines
Fire Fighting & Survival Equipment
Ballast / Bilge/ GS/ Fire pump : 2 x 100 m3/hr @ 60m/head
Main Fire Pump : 1 x 150 m3/hr @ 110m/head
Sprinkler Fire Pump) : 1 x 84 m3/hr @ 65m/head
Sprinkler Jockey Pump : 1 x 3 m3/Hr @ 112m/head
Emergency Fire Pump : 1 x 40m3/hr @ 60m/head
Rescue Boat :
1 x 6 persons with outboard engine driven
as per SOLAS (RB400) approved type,25HP
Fix Fire Pump (motor drive) : 1 x 40 m3/hr
Life Rafts : 12 X 25 Men SOLAS Approved
Fire Detection & Alarm System in all enclosed spaces.
Fixed CO2 system generator room, paint store, Gally
Fixed automatic water Sprinkler system for whole accommodation
spaces incl. store & workshop.
Other Facilities
Hospital : 1 x double berth hospital with attached paramedic room
Galley :
1 w/ cooking utensils, refrigerators etc.
(Prov' 25.54M2/Freezer 22.54 & Chiller 25.50M2)
Messroom : Level 1 (99.21M2) Seating capacity 80 men
Offices : 2 Rooms on Main Deck
Conference Rooms :
1 with seating capacity for 18 men
(LAN-Type A available)
Others :
1 x Prayer Room
1 x Laundry/Drying Rm, 1 x Dry Provision Room
1 x Winch Control Rm, 1 x Barge Radio Room
Winch Control Room :
1 c/w VHF/SSB & CCTV system for winches
Gym Room : 1 on Main Deck fitted with 5 sets Gym Equipments
Changing Room : 1 on Main Deck w/146 locker
Work Shop :
1 on Main Deck c/w Lathe, Drill, Grinder,
3 Welding Machines, high speed cutting machine,
2 Air Compressor, Air dryer & etc.
Helideck :
Designed to suit Sikorsky-61 or equil.
(Deck strength 9.3 T/ 22.2 Sq.M)
Consumption :
2 Gen Running: 4 M3
3 Gen Running: 7 M3
Price & terms : Please enquire using the email form below.
If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.
We can arrange delivery of equipment and towage of rigs and vessels where needed.
The details mentioned above are believed to be accurate but are not guaranteed.
----------------------------------------------------------------------------------------------------------
