Principal Particulars
Year built : 2008
Length overall : 69.90m
Length B.P. : 61.20m
Beam overall : 16.60m
Depth moulded : 7.20m
Design draft : 4.50m
Scantling draft : 5.90m

Classification
ABS + A1(E) Offshore Support Vessel, Towing Service, Fifi 1, +AMS + DPS-1

Capacities
Gross tonnage : 2538 tons
Net tonnage : 761 tons
Deadweight :
1200 tons @ 4.5m draft
2596 tons @ 5.9m draft

Fuel tank : 992 cbm
Potable water : 580 cbm
Drill water : 560 cbm
Mud tank : 432 cbm
Brine : 200 cbm
Dry bulk : 250 cbm in 4 tanks

Foam : 10 cbm
Dispersant : 11 cbm
Deck cargo area : 450 sqm
Deck cargo  : 900 tons
Cargo deck load : 10t/sqm for area abt 160 sqm
Reefer points : 4 (2 x 440v, 2 x 220v)

Machinery and Equipment
Main engines : 2 x man B&W 8L27/38-VBS980. Total output 2 x 3,973bhp @ 800rpm
Generators :
2 x 1200kW shaft generators Leroy Somer @ 440V 3ph 60Hz
2 x 370kW diesel alternators Cat3408C @ 440V 3ph 60Hz
1 x 99kW emergency diesel alternator Volvo Penta @ 440V 3ph 60Hz

Propellers : 2 x 3.4m CP propellers in fixed nozzles. Two independent high lift type rudders
Bollard pull : 106 tons
Bow thruster : 2 x 430kW CP rated 6.5t tunnel thruster
Stern thruster : 1 x 430kW CP rated 6.5t tunnel thruster
Deck crane : 5t knuckle boom @ 18m radius (mounted on stbd side aft of accom)

Tow/Anchor-handling Equipment
Tow/AH winch :
1 x double drum waterfall, low pressure
Stall pull 200t brake holding 300t
Brake holding capacity @ 400 tons
Rig chain size 76mm dia

Wire drum : 2 x 1500m each @ 64mm dia wire
Storage drum : 1 x 5t @ 0-30m/min 1500m 64mm sw rope
Tugger winch : 2 x 10t each @ upto 16m/min
Shark jaw : 1 x triplex H200, swl 200 tons
Tow pin : 1 x triplex S115, swl 115 tons

Capstans : 2 x 5t each @ 0-15m/min
Stern roller : 1 x 300 tons swl, 6m x 2m dia
Grapnel hook : 1 x 110 tons
J hook : 1 x 150 tons
Wildcats : 2 units
Chain lockers : 2 x 80 cbm

Towing / AH Wires
Main tow wire : 1500m x 56mm dia, spare 150m x 65mm dia
AH wire : 350m x 76mm dia

Mooring Equipment
Windlass : 10t @ 9m/min for chain cables
Anchors ; 2 x HY-14 stockless anchors each 2120kg/2115kg
Cables : 550m x 44mm dia x 15 shackles

Speed / Fuel
Max speed : 14 knots
Quality of fuel : MDO

Discharging Rates
Drill water/pump : 1 x 150 cbm/hr @ 70m head
Fresh/water/pump : 1 x 150 cbm/hr @ 70m head
Fuel/pump : 1 x 150 cbm/hr @ 70m head
Brine/pump : 1 x 80 cbm/hr @ 120m head
Liquid mud/pump : 1 x 100 cbm/hr @ 85m head
Loading computer : Bridge control
Flow meter :
1 for FO with printer output, 1 for DW, 1 for mud/brine, 1 for FW

Bulk Plant :
250 cbm in 4 tanks
Working pressure 6 bar
Refrigeration air dryer units

Accommodation
Officer/crew : 14
Berth total : 40
Cabins total : 16
Hospital : 1
Air conditional throughout

DP/Joystick Control
Converteam ADP1 system

FiFi 1 System/Oil Pollution Control :
FiFi 1, dispersant

Navigation and Communication
HF/FM/Telex : Furuno FS-2570-C
Watch receiver : Furuno FS-2580
VHF fixed  : Furuno FM-8800S
VHF portable - McMurdo R1

Inmarsat C : Furuno Felcom 15 SSAS
Navtex : Furuno NX-700B
Autopilot : Simrad AP50
Radar ARPA : Furuno FR2115 / FR1510MK3

Surface plotting : Yes
DGPS : Furuno GP 32
Gyro : Simrad GC 80
Echo sounder : Furuno FE 700

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------------
