Drawworks :
Main drum : 42 x 12
Sand drum : 42 x 8
Disc assist (double)

Winch :
Hydraulic winch is 10,000 lbs

Mast :
104 foot; 250,000lb
The mast has a tubing board and rod basket that automatically
deploys as the mast is extended.

Engine :
Detroit Diesel 60 Series

Transmission :
4500 OFS Allison automatic transmission heavy-duty 5 axle
oilfield carrier with two front steering axle, two rear-drivng
axles, one pusher or one tag axle.

Front Axles :
Front tandem axle set is steer able and is rated at 20,000 lbs each
per axle and spring suspension rated at 40,000 lbs.

Rear Driving Axle :
Arvin Meritor Tandem Series rear driving axles rated at 46,000 lbs. Hendrickson
walking beam rear suspension.

Rear Tage and Pusher Axle :
Rear tag and pusher axle are non-driving axles with air suspension, brakes and are rated
for 25,000 lb. capacity.

Tires and Wheels :
The four front tires are 425/65 R22.5 wide-base tires mounted on 12 in. x 22.5 in. steel
hub-piloted  “bud” type wheel. The twelve rear tires are 11R x 22.5 all-terrain tires mounted on
8.25in. x 22.5 in. Hub-piloted steel “bud” style wheels. hydraulic leveling jacks with locks

Other Equipment :
Rig stairs, operator side fold-down walk ways, and guardrails,
driveline covers, one tong retractor , one locking tool box

Additional Equipment @ extra cost Guylines :
Mast includes two load guys from the crown to carrier and
belly guys from center derrick to belly four wind guys
and two board guys.

Folding Work Platform :
Platform is constructed of rectangular tubing and is decked with a reduced slip grating. Platform
is adjustable in height from 3 ft. (0.91 m) to 9 ft. (2.74 m) from ground level.
Life line w/ harness
Stand pipe
Drilling application (includes) hydraulic catworks (make up and break out)
Aned elevated torque tube.

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------
