Single Drum Winch Skagit Model ETW 300 for Charter

Equipment ID: 872
Equipment name: Single Drum Winch Skagit Model ETW 300 for Charter
Category: Winches
Specifications: Single Drum Winch Skagit Model ETW 300 for Charter
Deep Water Winch for Rent
Marine Deck Equipment for Charter
Offshore Winch for Lease
Deep Water Winches for Charter
Single Drum Winch for Lease - Skagit Model ETW 300

Specifications
Line Pull : 815,000 lbs. at Bare Drum
Cable Capacity :
1 ½” cable 19,200’
2 ½” cable 7000’

Engine Package Skid Assembly : 8,500 lbs
Winch Drum Assembly in Transport Frame : 64,000 lbs
Winch Frame Assembly : 57,000 lbs
Optional Levelwind Assembly : 16,000 lbs
Total Estimated Weight without Wire Rope : 129,500 lbs
Min. Air Pressure : 100 psi
Water : 50 GPM for heat exchanger (Sea Water)
Electrical Voltage (AC) : 110V
Cable Diameter : 3 in

Used for Subs Sea Installation of :
J Tube pulls
Jacket pulls
Jumper installations
Mooring line installations
Pipe line pulls
Steel lead Installations
Trees
Tubing head spools

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-------------------------------------------------------------------------------
Search words (for official use only) -
Single Drum Winch Skagit Model ETW 300 for Charter
Rig Winch for Lease
Single Drum Winch for Hire
Deep Water Rental Winches
Marine Winch for Charter
Skagit Model ETW 300 Single Drum Winch for Lease
---------------------------------------------------------------------------------

Worldoils Oil, Gas and Offshore Marketplace - Single Drum Winch Skagit Model ETW 300 for Charter

Images

Skagit Model ETW 300 Single Drum Winch for Lease

Deep water single drum winch for charter

Skagit Model ETW 300 Single Drum Winch for Rent
