Ideco H35 KD Double (4200) - Used Workover Rig for sale
Workover Rig for sale
Ideco H35 KD Double (4200) for sale

General
Ideco H-35 KD 4210-38
Self-propelled double drum back-in Rated capacity at 3,400m w/ 73mm tubing
Engine - Detroit Diesel 8V-92TA (357KW/480hp)
Transmission - Allison CLT 5860 - 6 speed
Main drum brakes - 25.4cm x 106.7cm

Hydromatic brakes - Parmac 122 w/1,500L fluid capacity
Sand line brakes - 20.3cm x 96.5cm
Mast - Ideco 102-212 rated 94,340daN w/six lines
Racking capacity - 3,400m - 73mm
Double tubing 4,000m - 19mm triple rods

Travel blocks - McKissick 73A - 100 ton c/w spring
Lights - vapour-proof fluorescent & quartz floods
Drilling Line - 25.4mm x 518m wire rope 19mm - 25mm sucker rods
Sand line - 12.7mm x 3,700m wire rope
Weight indicator

Combination
2.74m x 12m change house/tool house
40 KW - Isuzu diesel generator

Handling Equipment
Gill model 500 tubing tongs c/w air back-up
Cavins model C power air slips
King Oil Tool elevators
Standard equipment - 60.3mm & 73mm EUE tubing

19mm - 25mm sucker rods
2 - 2.4m x 12.1m rig mats
Catwalk w/2 sets of pipe racks

Safety Equipment
4 - 14kg dry chemical fire extinguishers
2 - self-contained breathing apparatus w/spare cylinder
Gas detector
Safety & directional signs
Electrical ground bonding equipment
1 stretcher

Crown saver
Pipe ram saver
2 self retracting life lines

BOP Equipment
AEUB Class III BOP
152mm - 35,000 kpa Shaffer Spherical
152mm - 35,000 kpa Shaffer LWS with valve
NL Shaffer - 180 L - 21,000 kpa accumulator w/3 station controls & nitrogen back-up system
Hoses, remote station

73mm EUE - 35,000 kpa tubing safety valve
89mm rod BOP c/w handles
HD hydraulic oil saver
76mm x 9.1m swab lubricator w/ jars & tool trap
76mm swabbing valve - 21,000 kpa

Pump
Ellis Williams - model 440 - 102mm plungers x 152mm stroke 35,000 kpa
Engine - Detroit Diesel 8V-71 (268KW/360hp)
Transmission - Spicer - 5 speed
Mission 76mm x 50mm charge pump
Seven-valve reverse circulating manifold
Enclosed in steel building

Mud Tank
32m3 c/w mud guns & hopper
90m of 50mm line pipe & 12m of 101mm suction hose
Circulation degasser


Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.




-------------------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Ideco H35 KD Double (4200) - Used Workover Rig for sale
Workover Rig for sale
Used American Workover Rigs
Workover Land Rigs in USA
Used Ideco H35 KD Double (4200) Workover Rig for Sale
Land Workover Rigs For Sale
Ideco H35 KD Double (4200) for sale
--------------------------------------------------------------------------------------------------------------------------------------

Subsea Manifold System For Sale
Subsea Oilfield Equipment for Sale
Subsea Kit For Sale

History :
This field was put onstream in 1994 and ceased production in 1999.
Located 21km from Frigg Complex. The field was de-commissioned
in 1999 and the 3 wells plugged and abandoned.

The 10,000psi wellhead was not ”On the Shelf” and specialised
development was required.

Design Parameters :

Based on 670 bars and 125 deg C with flowrates at 2.3MSM3/d. Compliance
based on Norwegian statutary authorities NPD etc meeting with the most
stringent requirements in the world. Water depth 120 metre. 3 off
production subsea wells tie back to TCP2 platform

Status :
Currently stored in Tananger Norway. Has been maintained
throughout delivery installation and return onshore.

Major Components :
Manifold System
• Manifold Cap – 13 5/8” – 10 M – Hydraulic high pressure (10.000 psi) cap,
  to seal 8-1/4” nominal 13   5/8” – 10 M hub with metal to metal seal. Hub to
  top for connection to running tool, with hydraulic  couplers.

• Subsea Pig Launcher Connector – For connection of pig launcher to manifold,
 13 5/8” – 5M connector, with tapered bore.

• 13 5/8” – 10M Full Bore Manifold Hub Assembly – 13 5/8” – 10M hub for manifold
  interfaces with 13    5/8” – 10M connectors with 13 5/8” – 10M flanged bottoms.

• Loose valves – 2 1/16” and 4 1/16” – 10M manual ROV operated gate valves.

• The Base Connector 13 5/8” – 10M Connector with 8 ¼” through bore.

Wellhead System :
• 18 ¾” Wellhead Assembly – 15 M SB system wellhead housing with 20”
  casing extension, inlays in seal areas.

• 30” Suspension Joint – Suspension Joint for interface with retrievable
  IDGB/ PGB and support  wellhead.

• 13 3/8” Casing Hanger – With buttress – thread, inlay on packoff seal area.

• 10 ¾” Casing Hanger – With new VAM thread, inlay on packoff seal area.

• Packoff seal assembly – Locks and seals casing hanger to wellhead housing,
  with aluminium bronze seal element.

• Drilling Guide Base – Retrievable guide base with removable 10 ft posts,
  Vetco post tops.

• Dummy Wellhead |- 18 ¾” wellhead outer profile, with simulated 10 ¾” inner profile,
  supported in a 30” housing on a base plate.

• Temporary Wellhead Protective Structure – Lands and supported on 30” housing.
  Internally acts as    corrosion cap for welhead and housing, externally provides
  protection against impact damage and over-trawlability.

Tubing Hanger System :
• Tubing hanger – 4” x 2” – 11M tubing hanger, with 5” pup joint, 4 SCSSV penetrations
  and one seal  test port with check valves, metal to metal sealing with inlayed seal areas.
• Tubing Hanger Running Tool and BOP/ Orientation Adaptor – 4” x 2” – 10M running tool
  for SB  system tubing hanger running and setting.
• Tubing Hanger Emergency Recovery Tool – Mechanical tool run inside the drilling riser
  on drill pipe.   Will land and lock inside tubing hanger allowing recovery.
• Tubing Hanger Orientation/ Elevation Check Tool – Tool which can be run inside the
  drilling riser to check the orientation and elevation of the tubing hanger in relation to the
  orientation pin. Utilises lead impression blocks.
• Tubing Hanger Washout Tool – Tool which is run on drill piupe with four arm guide wire
  frame, to washout tubing hanger seal pockets after removal of BOP prior to installation
  of Xmas tree.

Xmas Tree System :
• Production Guide Base – Similiar to/ connected Drilling Guide Base with flowline and
  service line hubs mounted to provide connection flexibility to the Xmas tree. Interfaces with
  30” housing and flowline/ service line flexibles.

• Xmas Tree – 4” x 2” – 10M valve block, with integral actuated and manual 10M valves.
 18 ¾” tree connector with flowline and service line connector, 13 5/8” – 10M hub mandrel
  top, tree protection frame.

• Xmas Tree cap Assembly – 13 5/8” – 10M hydraulic tree cap for 4” x 2” bores.

• Xmas Tree Test Stand – Fabricated base with short dummy PGB posts and mating test
  hubs for 18   ¾” connector and flowline and service line connectors.

• Xmas Tree Maintenance Stand – Independant extension feet which can be mounted over
  dummy PGB posts, or used individually to raise the height of the tree and support its weight.

• Universal Shipping Skid – Fabricated base to which either test stand sticks, or individual
  equipment   frames can be mounted and restrained for shipping.

Workover System
• Lower Riser Package – 4” x 2” – 10M Valve block with 4” and 2” isolation valves and coiled
  tube cutting BOP ram. 13 5/8” – 10M connector bottoms with 13 5/8” hub mandrel top. High
  angle release.

• Emergency Disconnect Package – 13 5/8” – 10M connector with riser weak link and stress
  joint   connector. Incorporating wireline plug profiles.

• Riser System – Consisting of 5” x 2 ½” – 10M riser, stress joint, standard joint, pup joints,
  tension joint and landing joint. Upper and lower riser adaptors.

• Surface Tree – 5” x 2 9/16” – 10M surface tree block with 4” and 2” actuated wing valves,
  supported   in tensin frame, with tree cap, suitable for wireline BOP.

EAST-FRIGG

History :
The field was put onstream in 1988 in a water depth of 100 metre. In 1997 the field was
shutdown and in 1999 the production wells were decommissioned, plugged and
abandoned. The field was located 18km from the Frigg complex.

A technological pioneer project developed for diverless installation and operation. The
first subsea field on the Norwegian shelf with remote controlled wells in several clusters.
The East-Frigg development was based on modular principles as the first of its kind.

Design Parameters :
EF installations were designed for a minimum flow-rate of 1.25MSM3/d and a maximum
flow-rate of 6.5MSM3/d. The maximum working pressure rating was 345bar. Bottom hole
flowing temperature approx 62 deg C, Wellhead hole flowing temperature approx 35-40
deg C, Wellhead static temperature 4-6 deg C. Design was based on 5 subsea production
wells located over 2 production templates PSA & PSB. For reduncy reasons and to
minimize intervention it was decided at this time to include 2 off Xmas trees in series
for each well. 1 off Vetco and 1 off ”Well Jumper Module tree Cameron.

There were 3 wells on PSA and 2 wells on PSB , the two production stations produced to a
central manifold station (CMS) located halfway between the 2 production stations which
were approx 3km from each other. Production flowed via the CMS to Frigg where it was
metered and treated.

Status :
Currently stored in Tananger Norway. Has been maintained throughout delivery installation
and return onshore.

Major assemblies comprises :
5 off Vetco Xmas tree and tree cap assemblies, each gas production tree comprising 18 ¾”
SG-5 wellhead connector, integral with 5” x 2” , 5,000psi working pressure valve block, with
fail safe closed valves, equipped with visual position indicators and overrides. Manifold spool
flanged to block, production spool, Xmas tree guide frame, control system components and piping.
Complete tubing hanger system including hydraulic running tools, adaptors, VAM-Hydril x over
riser couplings, emergency recovery tools, orientation/ inspection tools. Control systems for THRT.
Intervention amd maintenance systems incl; flowhead, 5,000 riser system, EDP/ LRP, hydraulic
control system, adaptors, test stumps, remote killing equipment, guide bases, hubs, sealing
caps, dummy Xmas tree etc

6 off Kongsberg/ Cameron WJM (Xmas trees)
Xmas trees made of forged steel block of low alloy steel, all sealing areas are inconel inlaid
(ring grooves, seal sub pockets, valve seat pockets)

Module M35 Description :
The module was delivered, installed and commenced production in 1993. Design life was
30 years. Production ceased as with Lille-Frigg in 1999. The purpose of the module was to
faciltate handling of process for both Lille-Frigg and the Oil producing satellite platform Frøy.
(Note Frøy platform has been returned onshore and been disposed of)
Dimensions of the module are 40.5m length x 24m width x 24.8m height. Weight for single lift
is 3216 ton. The module is located on the TCP2 platform located within Frigg process handling
complex.

The module is equipped with a pedestal crane with working radius at 36 tons between 9-30
metres and 12 tons with maximum radius of 60 metres. This crane carried out material handling
for all of the TCP2 platform, which meant that TOTAL could at the time dispose of the rest of the
smaller cranes which were out of date.

The module is in pristine condition ”As New” with all systems and equipment under full
preservation. and maintenance.

The module contains systems and equipment for treatment of oil & gas comprising the following
main functions;
Gas System
Oil System
DEG recovery
Fuel Gas Compression
Water Injection System
Electrochlorination System
Fine Filter System
Dearation System
Water Injection Pumps
Fiscal Metering Systems
Produced Water System
Heating Medium System
Chemical Injection System
Electrical and Control Systems
Firewater and Deluge systems
Fire & Gas monitoring and protection.
Lighting, normal and emergency.

Also included in the module are, intrument control room, low voltage rooms, high voltage room, drains,
stairs, platforms, escapes routes, vent/ flare systems, piping to ANSI standards manifolds and
distribution. All cabling routes etc are intact.

Module M52 description :
The module which is located on the support frame of TCP2 contains equipment for treatment of
condensate and gas and comrises the following main functions;
Pig traps
Condensate heaters
Separators
Pumps
Gas metering
Gas Lift compressor
Module dimensions; 31.3m long x 11.3m width x 8.2m height. Weight 573 ton.
The module has a design life of 30 years with a start of production 1993 ceased production 1999.

Module (pancake) P48 description :
The module which is located inside the support frame of the TCP2 contains equipment for stabilisation
of condensate and oil & gas comprising the following main functions;
Separator
DEG and condensate pumps
Condensate metering
Fuel gas compressor
Module dimensions; 16.2m long x 12.2m width x 5.2m height
The module has a design life of 30 years with a start of production 1993 ceased production 1999.

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------------------------------------------------------
Search words :
Subsea Manifold System For Sale
Subsea Equipment For Sale
Subsea Wellhead System for sale
Subsea Xmas Tree System For sale
Complete Subsea Kit For Sale
Subsea Kit For Sale
Subsea Field for Sale
Subsea Oilfield Equipment for Sale
-------------------------------------------------------------------------------------------------------------------------

Single Drum Winch Mitsubishi Model 147 for Lease
Marine Deck Winch for Charter
Offshore Winch for Charter
Deep Water Winches for Rent - 670,000 lbs. at Bare Drum
Mitsubishi Model 147 Single Drum Winch

Specifications
Line Pull : 670,000 lbs. at Bare Drum
Cable Capacity : 2 3/4" cable 9,800'
Engine Package Skid Assembly : 10,500 lbs
Winch Drum Assembly in Transport Frame : 78,000 lbs
Winch Frame Assembly : 92,000 lbs
Total Estimated Weight without Wire Rope : 180,500 lbs
Min. Air Pressure : 100 psi
Water : 50 GPM for heat exchanger (Sea Water)
Electrical Voltage (AC) : 110 V

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Single Drum Winch Mitsubishi Model 147 for Lease
Marine Winch for Rent
Rig Winch for Lease
Single Drum Winch for Hire - 670,000 lbs. at Bare Drum
Deep Water Rental Winches
Single Drum Winch for Charter - Mitsubishi Model 147
----------------------------------------------------------------------------------------------------------------------------

Pipelay Derrick Barge for sale
Newbuilding Barge for Sale - 3000t & 2000t
New building Pipelaying Barge for Sale

1. Introduction
The vessel is non-propelled shallow water pipelay barge. Pipe laying water depths
will be up to 300 m. the firing line be provided starboard on main deck. The pipe crane
be provided for pipe transfer and store.

The 2000T/3000T slewing crane will be installed on aft deck. Deck house will be on
the forecastle deck.

The barge has fully air-conditioned accommodation for up to 310 people in cabins
all with individual bathroom facilities. There are conference room, offices, gymnasium
and recreation rooms. Separate well equipped laundry facilities are available for use.
The barge has a well equipped medic room with hospital.

The barge will be designed for worldwide unrestricted service with exclusion of
Arctic waters. Primary operational area will be all shallow water area less than 300m.

2. Classification / Registration
2.1 Class
The barge, which including the hull, engine, electrical and special equipments, shall
satisfy the latest requirements of the current international convention, regulations and
ABS rules and regulations, and enter into the classification, obtaining the following class
notation:
A1 CRC Derrick/Pipelay Barge

2.2 Rules and Regulations
The latest revision of the rules, regulations and certificates of the classifying and
governing authortities shall be applied.

Following international convention and regulations will be complied :

1. ABS Rules for Classification and Building of Steel Barges.
2. International Convention on tonnage Measurements 1967/1969.
3. International Convention of the Prevention of Collisions at Sea 1972, including
    amendments.
4. International Convention for the Safety of Life at Sea, Consolidated Edition 2004
    including all amendments in force.
5. International Convention for the Prevention of Pollution from Ships, 1973,
    Protocol of 1978 Relating and Amendments of 1992 (MARPOL)73/78
6. IMO code on noise levels on board ships, A 468 . X11
7. International Convention on Load Lines, 1966
8. International Telecommunication and Radio Regulator of 1973/1976 and 1982
    including latest GMDSS-rules for radio communication.
9. International Electronical Commission, electrical Installation in Ship
10. ILO Convention for Crew Accommodation on Board Ships
11. ILO Convention regarding Safety of Working on Board Ships

2.3 Certificates
The following certificates will be available :
1. Classification Certificate for Hull
2. International Oil Pollution Prevention Certificate
3. International Tonnage Certificate
4. International Load Line Certificate
5. Ship Safety Radio Certificate
6. Ship Safety Equipment Certificate
7. Lifting Appliances Certificate
8. Live Saving Equipment Certificate
9. Seaworthiness Certificate
10. Crew Accommondation Certificate

3. General Specification
3.1 Design Conditions
3.1.1 Operating Modes
The Ship shall be designed for the following operations :
     • Pipe laying operations with a single joint S-lay system
     • Heavy lifting operations.

3.1.2 Environmental Conditions
Pipelaying Conditions
The vessel will be able to continue operations in the following environmental
conditions :
     • Wind speed : Vw = 16 [m/s]
     • Significant wave height : Hs = 2.5 [m]
     • Wave period (peak) : Tp = 6.0 – 12.0 [s]
     • Current speed : Vc = 1.5 [kn]
     • Spectrum type : Jonswap
     • Heading : 0°-360°

3.1.3 Design Temperatures and Humidity
  The following design temperatures are considered for the design :
     Maximum ambient air temperature : +45 ºC @ 90% relative humidity
     Minimum ambient air temperature : -15 ºC
     Max. seawater temperature : +32 ºC
     Min. seawater temperature : -2 ºC
     Maximum internal temperature in all s paces : 25 ºC
     (except the engine rooms)

The accommodation HVAC system shall be designed according the following :

Summer condition :
     • Ambient 40ºC@ 70% RH
     • Maintained 25ºC ±1@ 50% RH
Winter condition :
     • Ambient -20ºC @ 30% RH
     • Maintained 20±1ºC @ 30-40% RH
Fresh air supply should not be less than 28.8cbm/h.

3.2 Principal Dimensions
Length overall (LOA) excl. stinger : 169.00 m
Breadth (moulded) : 46.00 m
Depth moulded to main deck : 13.50 m
Operational draught : 7.00-9.00 m
Max displacement : 63,594 t (approx.)
Ballast capacity : 35,000 cbm
Fuel oil capacity : 4,000 cbm
Potable water capacity : 3,000 cbm
Accommodation cabin 310 beds

3.3 General Description
The vessel will be a steel, all welded barge with a helicopter platform will be
situated at forecastle deck.
One (1) full revolving crane to be installed in the after area of deck.
Summary of arrangement of decks is as following :

3.3.1 Under Double Bottom
Double bottom will be constructed between the two longitudinal bulkheads. There
will be some ballast tank, fuel oil tank, lubricate oil tank, sewage and dirty oil tank etc, in
the double bottom, and pipe tunnel will be at the each side of it.

3.3.2 On Double Bottom
There will be engine room, pump room, ballast water tank, fuel oil tank etc.

3.3.3 Middle Deck
Fore and aft side tank will be arranged as mooring position winch room. Middle
side tank will be as ballast water tank, ECR, CO2 room, store room, refrigerant,
air-condition, refrigerator etc.

3.3.4 Main Deck
Main deck is a continuous deck. The 2000T/3000T slewing crane will be situated
on the aft deck. The pipelaying work room will be on the starboard deck from aft end to
fore. Port side of the forecastle will be accommodation area. There will be hospital,
change room, shower room, laundry, drying room etc.

3.3.5 A Deck
A deck will be in the forecastle as accommodation quarters. There will be galley,
air-condition room will also be in this area.

3.3.6 B Deck
There will be twenty- eight (28) 4P cabins,air-condition room, lavatory, laundry,
drying room on the B deck.

3.3.7 C Deck
There will be twenty- one (21) 4P cabins, thirteen (13) 2P cabins, air-condition
room, lavatory, laundry, drying room on the C deck.

3.3.8 D Deck
There will be thirty-four (34) 2P cabins,air-condition room, lavatory, laundry, drying
room on the D deck.

3.3.9 E Deck
There will be four (4) 2P cabins, twlve (12) 1P cabin, meeting room, and lavatory,
laundry on the E deck.

3.3.10 F Deck
A central control room will be on the F deck. In the control room there will be
navigation console, mooring position console, ballast water console.

3.3.11 Helicopter Deck
The helicopter platform will be at the fore end of the barge. It is suitable for
SIKORSKY S-61N to take off and landing. Communication and navigation equipment,
leading light, skid-proof grid, draining system will be fitted on the platform.

4. Outfitting Part
4.1 Navigation Anchor
Two sets of navigation anchor equipments to be arranged on the B-deck. An
anchor, anchor chain cable, chain stopper, hawse pipe, chain pipe and windlass to be
included in every set.

4.1.1 Anchor
Weight : 12900 kg

4.1.2 The Combined Windlass
The vessel will be equipped with two windlasses with type of combined windlass.
Each windlass contains one declutchable cable lifter, declutchable mooring drum and
warping end

4.2 Mooring equipment
4.2.1 The Mooring Winch
The vessel is equipped with two double drum hydraulic mooring winches, arranged
on the main deck of stern.

4.2.2 Hydraulic Multifuction Winch
The vessel is equipped with five hydraulic multifunction winches totally. Two of the
winches are arranged on the middle of main deck and one above the firing line of stern.

4.3 Positioning System
A twelve point positioning system be installed.
The twelve point positioning system consist of :
Twelve single drum winches (1100kN rating force each)(Maker: ZPMC)
2500 m Ø 76 mm wires
Twelve (12) 12T anchors

4.4 Lifesaving Equipment
4.4.1 Lifesaving Boat
Enough lifesaving boats and rafts will be arranged on each side of B deck.Which
satisfy the SOLAS requirements.

5 Propulsion, Generators/Aux. Equipment
5.1 Electrical installation

General requirements
The electrical equipment is suitable for a humid, salt laden atmosphere and proof
against vibrations and accelerations normal to a marine environment.

The following electric systems are installed on board:
440 V, 60 Hz, 3 ph. For vessel’s auxiliaries, pipelay system, cranes and winches
220 V, 60 Hz, for lighting an small consumers
24 V, DC for alarm, main diesel control,engine room alarms

5.2 Generators
Main generators(Maker : Hyundai)
The four generators are of the brushless type, totally enclosed construction, suitable for
parallel operation.

Main data :
Type : HYUNDAI Diesel Engine 8H25/33, Generator HFC714-84K
Rated voltage : 450 V, 60 Hz, 3 phase
Rated power : 2256KW each

Emergency generator(Maker : Caterpillar)
The emergency generator is of the brushless type, air cooled.

Main data :
Type�FCaterpillar 3406 DITA
Nominal voltage : 450 V , 60 Hz, 3 phase
Rated power : 315 KW

5.3 Auxiliary equipment
The following auxiliary equipment is installed:
• Sewage treatment unit
• Incinerator
• Watermakers
• Sprinkler system
• Starting air compressors
• Barge air compressors
• MDO separator / purifier
• Bilge water separator
• Refrigeration plant
• HVAC plant
• Compactor
• Workshop equipment
• Pumps
• Fan
• Fifi pump

6 Electrical Equipment

6.1 General Principle
(1) The main electrical equipment will be to comply with the marine environmental
      conditions and to have ABS certificate.
(2) The marine cables temperature class will be to permitted in 85°C.The power
      cables conductor cross-section of less than 1.5mm2 and the lighting and control cables
      conductor cross-section of less than 1mm2 are not to be used.

6.2 General Rule
Item : Main generator
V : AC450
Hz : 60
Phase : 3
Wire : 3

Item : Emergency generator
V : AC450
Hz : 60
Phase : 3
Wire : 3

Item : Crane
V : AC440
Hz : 60
Phase : 3
Wire : 3

Item : Winch
V : AC440
Hz : 60
Phase : 3
Wire : 3

Item : Ballast Pump
V : AC440
Hz : 60
Phase : 3
Wire : 3

Item : Lighting
V : AC220
Hz : 60
Phase : 1
Wire : 3

Item : Alarm
V : AC220/DC24V
Hz : 60
Phase : 1
Wire : 3

6.3 Lighting and Illumination
The lighting lamp and control device will be to install according as the requirement
of various places

6.4 Inner Communication and Alarm
The following equipment is installed :
The command telephone
Daily service telephone
Public address system
Radio / TV antenna and satellite communication / TV device
Engineers call system
Refrigerating chamber call system
Sick bay call system
CCTV
Local area network
Fire alarm
General alarm
Watertight alarm
CO2 releasing alarm system
Engine room monitoring system

6.5 Navigation and Communication Apparatus
1) Sounding apparatus : 2 units
2) Radar : 2 units
3) DGPS : 2 units
4) Gyrocompass : 1 unit
5) Speed log : 1 unit
6) Weather map facsimile receiver : 1 unit
7) AIS (Automatic Identification System) : 1 unit
8) Rain-water cleaner and wiper : 6 units
9) Fog diaphone : 1 unit
11) Navigation data recorder : 1 unit
12) GMDSS : 1unit
13) NAVTEX : 1 unit
14) Satellite communication F station : 1 unit
15) Ultra short wave radio station for helicopter : 1 unit
16) Aviation wireless radio-phare set : 1 unit
17) Two-way VHF for life boat : 3 units
18) EPIRB : 1 unit
19) SART : 2 units

7. Pipelay System
Concept : Starboard mounted single joint S-lay system
Capacity : 4” – 48” diameter pipe
Maximum external diameter : 60 inch
Pipelaying speed : 3km/day

Conveyor system & powered transverse conveyors with elevating and non
elevating capabilities are provided.

Firing Line
5 welding stations (Maker: Serimax)
1 NDE station(Maker:Rd-tech or GE)
1 repair station
1 coating station(Maker: Selmer or Hennecke)

All stations sheltered

Control Room
Tension machines are remotely controlled from the working bridge. Local
controls provided in the pipe tunnelalong the firing line.

Tensioner (Maker : Remacut)
2 tensioners, 100 T each

A&R Winch(Maker : Remacut)
A&R winch, 1200 m, ö88 mm wire, 200T minimum tension

Davits
Five (5) mounted with load cells at starboard stored on board ,1×50t&4×30 t

Stinger (fixed)
Line-up tools and pipe facing/beveling machines are not included.

8 Crane (Maker : ZPMC)
8.1 General Description
The crane described in these plans and specifications will be a total revolving
heavy lift floating crane for installation on a crane ship, the vessel will be used for
offshore construction in world-wide service.

8.2 Main Parameter
(1) Main hook
Main hook load : 3000t x 30m(stationary over stern)
Max height (30m radius) :
80m
2000t x 35m (revolving)
Speed with full load : 1.5 m/min
Speed with empty load : 3.0 m/min

(2) Auxiliary 1# hook
Auxiliary 1# hook load : 600t,
Height above main deck(min radius) 80m
Depth under water 150m
Speed with load : 0-10.0 m/min

(3) Luffing
The time from boom horizontal to min radius 15min

(4) Revolving
Max. Main hook load : 2000t
Speed with load : 8 min / r
Speed with empty load : 4 min / r

(5) Whip (2 sets)
Hook load : 50t
Speed with load or without load : 60 m/min

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
-------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Pipelay Derrick Barge for Sale
2000Ton Pipelay Barge
Pipelay Barge for sale
3000Ton Pipelay Derrick Barge for Sale
Derrick Pipelay barge for sale
Newbuilding Pipelay barge for sale
2000t & 3000t New Pipelay Barge for Sale
Newbuilding Derrick Pipelay Barge for sale - 2000t & 3000t
------------------------------------------------------------------------------------------------------------------------------------

Caterpillar D6RIIIXL Crawler bulldozer for Sale
Used Mining Equipment - Caterpillar D6RIIIXL

Year : 2006
Manufacturer : Caterpillar
Model : D6RIIIXL
Condition : Used

Description
Alternator, 150 AMP
Lights, Sweeps
Guard, Fuel Tank
Guard, Radiator,Hinged, HD
Screen, Rear

Sweeps
Seat, Cloth, Air Suspension
Prescreener
Guide, Track, Moderate Service
Track, 22" ES (41 SEC)
Drawbar, Rigid Short
Batteries,Heavy Duty & Starter

6su Xl Bulldozer, Complete
S/N MGH00487
Hydraulics, Ripper
Domestic Truck
SMU/Hrs : 5605

Location : United States

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Caterpillar D6R III XL Crawler bulldozer for Sale
Used Caterpillar D6R III XL Crawler bulldozer
Used Mining Equipment
Crawler bulldozer - Mining Equipment for Sale in USA
2006 Caterpillar D6R III XL Used Equipment
---------------------------------------------------------------------------------------------------------------------------------

Shipard for sale in Europe
Shipyard for sale in Mediterranean

We have a shipyard for sale in the Mediterranean / Europe

Due to privacy and commercial reasons, the details cannot be disclosed here.

But if there is a genuine qualified buyer, the details can be disclosed and the shipyard can be sold.

Please contact us using the form below.

Subject to prior sale

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------------------------------------------
Search words -
Shipyard for sale in Mediterranean
Shipard for sale in Europe
Shipyard for sale
-------------------------------------------------------------------------------------------------------------------------------

Driltech T25K3W Drilling Rig for Sale
Driltech Drilling Rig - 1994 Built for Sale

Model : T25K3W Drill Rig
Manufacturer : Driltech
Year : 1994
Condition : Used

Description :

1994 Driltech T25K3W Drill Rig- S/N: 731889
Sullair 840 cfm / 350 psi Air Compressor
CAT 3406 DITA Diesel Deck Engine - rated 430 HP @ 1,800 RPM
30,000 LBS of Pullback
28 ft Head Travel
Pipe Rack Holds For 15 Pipe
(6) Rod Carousel
Rotary Head - rated 89 RPM & 62,600 in LBS. Torque
Jib Boom, Hydraulic Extend With 172 Degree Hydraulic Swing
Hydraulic Winch 7,500 LBS. Capacity
20" Openiing in Table With Hydraulic Adjustment
48" Jaw Type Breakout Wrench
Water Injection Pump is 20 GPM With Foam Pump
DTH Lubricator With 10 Gallon Tank
Fine Feed  & Torque Controls
420 ft. of Used Drill Pipe (4-1/2" O.D. X 20ft) & Basic Tooling Included
Gardner Denver 5 X 6 Air Drive Mud Pump on Board
Hydraulic Leveling Jacks
Mounted on a 1993 Ford LNT8000 - VIN #1FDZW82E0PVA18231
Cummins 8.3l 275 Hp Diesel Engine
10 Speed Transmission
18,000 Front Axle
46,000 Rear Axle

Location : USA

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------------------------------------------------------
Search words (for official use only) :
Drilling Rig - Driltech T25K3W- for Sale
Used Driltech T25K3W Drilling Rig for Sale
1994 Built Driltech Drilling Rig for Sale
Land Drilling Rig for Sale in USA
Driltech Used Drilling Rig for Sale in USA
--------------------------------------------------------------------------------------------------------------------

Caterpillar 992C Wheel Loaders For Sale
Used 2001 Caterpillar Loaders for Mining

Year : 2001
Manufacturer : Caterpillar
Model : 992C
Condition : Used

Description
Official CAT rebuild, with new s/n, a/c, hours since rebuild 12,151, very good condition
very tight, no oil leaks
good oil samples
have all records
45/65R45 Bridgestone @ 60 + %

Hours : 12,151
Location : USA

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Caterpillar  992C Wheel Loaders for Mining
Used Caterpillar 992C Wheel Loaders in USA
Wheel Loaders for Mining
2001 Caterpillar 992C Loaders for Sale
Caterpillar Used Wheel Loaders
2001 Caterpillar 992C Loaders for Sale in USA
------------------------------------------------------------------------------------------------------------------------------------

New DP2 Research Vessel for Sale
Diesel Electric Research / Supply Vessel - Newbuilding - For Sale
Newbuilding DPII Research/Supply Vessel for sale

Supervision : DNV
Class : 1A1 Stand-by Vessel, SF, EO, DYNPOS-AUTR

Main Characteristics :
Length overall : 55.20m
Length BP : 48.00m
Breadth mid : 12.70m
Depth mid up to 1st deck : 6.25m
Depth mid up to 2nd deck : 8.85
Design draft for rescue operations : 4.15m
Normal cargo draft mid : 4.65m
Max. draft by strength conditions : 5.00m
Deadweight : 960t
Estimated speed : 12.9kn
Crew : 22 persons

Total output of the 6 diesel generators : ab. 3500 kW

Stern rudder propellers : 2 x 900 kW
Bow thrusters :
Tunnel type : 1 x 350 kW
Azimuth type : 1 x 800 kW

Dynamic positioning system (DPII) is used for fixing
the vessel at a given point during rescue operations.

Capacity of main tanks :
Drinking water tank (for ship demands) : around 130 cbm
Fuel tank (for ship demands) : around 190 cbm
Ballast water (including for "anti-rolling") : around 550 cbm
Drinking water as cargo : around 280 cbm
Fuel oil as cargo : around 140 cbm
Cargo deck area : around 160 cbm

The vessel is privided with one fast rescue craft and one
daughter craft.

Both the FRC and the daughter craft are provided with single
motion compensated and shock absorbed davits.

The vessel is equipped with water spray system with capacity
up to 5 I/sq m.
The above system includes 2 remote- controlled fire fighting
monitors with capacity 400-2000 I/min.
To prevent oil spillage the aft of the vessel is fitted with the
dispersant spray system with capacity up to 100-130 I/min.

The survivors needs are attended to in the following additional
rooms on the vessel :
Survivors area for 75 persons
Non-survivors room for 30 bodies
Operating room
Sick- bay

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
New DP2 Research Vessel for Sale
Newbuilding DPII Research/Supply Vessel for sale in Singapore
DP2 Diesel Electric Research Vessel for sale - New
Diesel Electric Research / Supply Vessel - Newbuilding - For Sale
New DP2 Research Vessel for Sale in Europe, in Africa
Diesel Electric Research Vessel for Sale
Newbuilding DP2 Research Vessel For sale
Newbuilding DPII Research/Supply Vessel for sale
-----------------------------------------------------------------------------------------------------------------------------------------------

-----------------------------------------------------------------------------------------
Search words (for official use only) :

Crewboats for Sale
Fast Crewboats For Sale

For Sale : 2 X Newbuilding  Crew Boats
Subject to continued availability

General
2 X 36m Aluminium Hull Crew Boat
Ex Yard Thailand

Length OA : 36.00m
Length BP : 33.20m
Breadth MLD : 7.60m
Depth MLD : 3.65m
Design Draft : 1.88m
Complement : 8 Crew - 70 offshoreworkers

Deliveries : Nov + Dec 2011 respectively

Deck load max. 30 mt.

Max speed is 25.5-26 knots with 100 pct engine power
Max cruising speed is 24 knots
Recommended normal full ahead speed 22-23 knots.

Bow thruster fitted

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
--------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Crewboats for Sale
70pax Crew Boats For Sale
New Fast Crewboats
New Crewboats for Sale in Asia
----------------------------------------------------------------------------------------------------------------------------

CME 45 Auger Drilling Rig for Sale
Drilling Rig - CME 45 Auger - For Sale

Model : 45 Auger Drill Rig
Manufacturer : CME Drill
Year : 1978
Condition : Used

Description :

1978 CME 45 Drilling Rig Truck - Serial: 123884
Ford 4 Cylinder Gas Engine
Hours : 358
Auto Hammer
2 winch lines
22ft 4" auger sections
5ft 8" auger sections
23ft 5ft boring rod extensions
8" rock bit
4" rock bit
8" auger bit
Mounted on a 1997 Ford F450 Super Duty - VIN: 1FDLF47F8VEB32264
Miles : 235,967 on odometer
7.3L Power Stroke Diesel Engine
Manual 5 Speed Transmission
Suspension : Spring
Brakes : Hydraulic
GVWR : 15,000 lbs
Wheelbase : 161" & Tire Size: 235/85R16

Location : USA

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) :
1978 Built CME 45 Auger Drilling Rig for Sale
Used CME Drilling Rig for Sale
CME 45 Auger Used Drilling Rig for Sale
CME 45 Auger Land Drilling Rig for Sale
CME 45 Auger Drilling Rig for Sale in USA
---------------------------------------------------------------------------------------------------------------------------------

Drill Cuttings Skips For Hire
Environmental Drilling Protection Skips For Hire
Drilling Waste Skips For Hire
Drilling Waste Management Skips For Hire

Legislation and oil company policies have, in certain parts of the world driven the
industry to improve the management of drilling waste. Moving such waste
around a rig site or from a rig to a treatment and/or disposal site without spillage
is now essential.

These Drill Cuttings Skips easily meet these criteria by safely containing
drill waste, enabling transportation without fear of spillage.

These Drill Cuttings Skips have been designed to contain drill cuttings
from all types of transfer equipment, both on and offshore.

Features :

Design
In accordance with DNV 2.7-1

Practical
Large sealed door.
Angled front that deflects the cuttings into the middle of the skip.
Fitted vacuum points.
The skips are stackable

Safety
Fitted vacuum points reduce manual handling by eliminating the need for
vacuum lids.
The lids are fitted with a seal and secured by latches that are fully
adjustable to ensure seal.
Vacuum rated

Lifting
Skips are supplied with certified lifting slings and have 2 forklift pockets.

Specifications
Volume (Empty) 2.6m³ (16.5 bbls)
Design DNV 2.7-1
Weight (Approx.)
Gross Weight 6000 kg (13227 lb)
Payload Weight 4900 kg (10802 lb)
Tare Weight 1100 kg (2425 lb)

Dimensions
Length 1900 mm (74 in)
Width 1730 mm (68 in)
Height 1400 mm (55in)

Deck Loadings
Empty Container
1100kg (2425lb)
333Kg/m²
(71.3 lb/ft²)

Full Container
6000kg (13227lb)
1818 Kg/m²
(176.4 lb/ft²)

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) :
Drill Waste Management Methods
Drilling Cutting Disposal and Management Skips for rent
Drilling Waste Disposal Methods
Drilling waste disposal containers
Drilling Waste Disposal Bins
Drilling Waste management Boxes
Drilling waste Disposal Boxes
Drilling Cutting Boxes
Drill Waste Management techniques
How to dispose Drilling Waste & Cuttings
How to manage Drilling Waste
Drill Cuttings Skips
Environmental Drilling Protection Skips
Drilling Waste Skips
Drilling Waste Management Skips
Environment safety Drill Waste Skips
Drill waste Management Skips
Drill Cutting Disposal Skips
Drill Waste Disposal Skips for Rent
Drilling Cuttings Disposal Containers
Drilling Waste Management
------------------------------------------------------------------------------------------------------

Pipelaying barge For sale
292 Men Pipelaying Diving Maintenance Accommodation Barge
112M Pipelaying barge For sale
Pipelaying Accommodation Barge for Sale
2008 built Pipelaying barge For sale
Pipelay Capability for 200 mm – 1500 mm Pipe

Principal particulars
Class : ABS +A1 unrestricted service with MODU code attestation
Built : 2008
Gross Tonnage : 13,575 T
Nett Tonnage : 4,072
Dead Weight 10,233 T

Dimensions
Length overall : 111.63 m
Breadth moulded : 31.7 m
Depth : 9 m
Designed Draught : 4.8 m

Pipelaying facilities
Pipelay Equipment
Pipelay capability for 200 mm to 1500 mm
90 ton pipe lay tensioner capacity (30 m/min)
100 ton pipe lay abandonment / recovery winch
Automatic tensioner transfer system
Pipelay conveyor and transfer system rated to 32 ton

7 welding stations with semi-automatic welding system (STT & flux core)
1 NDT station
2 field joint stations
Dark Room
Stinger/Ramp
3 degree sloping production firing line
34 m outrigger stinger adaptable to different project requirements

Diving capability
In-built moon-pool (5.5 m x 5.5 m)
Support services for modular saturation diving spread
8 POINT MOORING SYSTEM
8 x single drum 90 ton mooring winches
c/w tensional sensor, wire length counter
8 fairleads, with 1500m of 52mm wire rope.
9 x 10 ton Delta Flipper anchors9 x Pennant Buoys

Helideck
Size : 22 x 22 m for Sikorsky S61

Safety systems
Mass Evacuation Slide and Raft System
Life rafts to 590 person capacity
600 life jackets/12 life rings
1 x fast rescue boat
Active high specification smoke and fire monitoring and extinguisher
system in all accommodation, engine, winch, paint and boiler rooms
Sprinkler system
Machinery guarding systems
Dedicated boat landing transfer points

Environmental
Sewage treatment system meeting MARPOL standards
Spill prevention systems

Other facilities
Hospital with 2 beads
Well equipped galley
Mess room with seating for 180 people
Large cinema, TV room for 110 people
Recreational Room for 60 people seating

Internet and email room
Well equipped gym
Laundry and large food storage facilities
5 Specialist Personnel Office rooms
2 Client office rooms
3 General office rooms
2 Control rooms with CCTV and metering

Navigation /Radio Control room with helicopter coms
Conference room for 25 people
Prayer room
Paramedic room
Change room with lockers and wash facilities
Work shop with Lathe, Drill press plus other tooling
2 water makers of 40 ton per day capacity

Machinery
Generators : 5 x Mitsubishi 1200 kva 60 cycle.
Emergency Generator : 1 x Diesel Caterpiller 500 kva 60 cycle.

Tank capacities
Fuel Oil : 2211 m3
Potable Water : 1926 m3
Grey Water 23 m3
Black Water 23 m3
Bilge 23 m3
Dirty Oil 27 m3
Cooling Water 750 m3

Pumps
Fire/General Service : 2 x 130 m 3 hr 80 m head
Fuel Oil : 2 x  20 m3 hr 30 m head
Ballast Water : 2 x 300 m3 hr 30 m head
Potable Water : 1 x 120 m3 hr 35 m head
Domestic F Water : 1 x 30 m3 hr 35 m head
Domestic S Water : 1 x 30 m3 hr 35 m head
Emergency Fire : 1 x 50 m3 55 m head

Deck area
Clear deck area over 2000 m2,
Deck Strength 12.5 t/m2 rating
Carriage Capacity over 11,000 tons
Provision on deck for suitable crawler crane

Accommodation
High Standard of Accommodation
Tank Top Cabins 30 x 2 = 60
Tween Deck Cabins 30 x 2 = 60
Deck 1 Cabins 24 x 2 = 48
Main Deck 1 x 2 = 2
Deck 2 Cabins 32 x 2 = 64
Deck 3 Cabins 28 x 2 = 56
Additional Deck 3 Cabins 2 x 1 = 2
Total Berths 292
Cabins with en-suites and fully air conditioned

Price & terms : Please enquire using the email form below

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Pipelaying barge For sale
112M Pipelaying Barge For sale
Pipelaying Diving Maintenance Accommodation Vessel
292 Men Pipelaying Diving Maintenance Accommodation Barge For Sale
2008 built Pipelaying barge For sale
Pipelaying accommodation Barge for Sale
Diving Accommodation Vessel with Pipelaying
------------------------------------------------------------------------------------------------------------------------------------------
