Air Conditioner - Monobloc - Eex-d IIB T3 ATEX II 3G Used Monobloc Air Conditioner for Sale
Specifications
Production of a monobloc air conditioner with pressurizer in execution Eex-d IIB T3 ATEX II 3G.
The monobloc unit has been designed to be of easy coupling to any cabin through ducts.
The monobloc unit is produced in stainless steel 316L, with a cooling capacity of ( 8,0 ) kW and thermal power of ( 4,5) kW, Outdoor airflow rate 360 mc/h, Recirculation airflow rate 2.200 mc/h. Available on order Price & terms : Please enquire using the email form below.
If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you.
We can arrange delivery of equipment and towage of rigs and vessels where needed.
The details mentioned above are believed to be accurate but are not guaranteed.
-------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : Eex-d IIB T3 ATEX II 3G Monobloc Air Conditioner Monobloc Air Conditioner for Sale Used Monobloc Air Conditioner - Eex-d IIB T3 ATEX II 3G for Sale ----------------------------------------------------------------------------------------------------------------------------------
Linear Winch KTC 240 for Sale or Charter Winch for Sale - KTC 240 Scope of supply : Equipment : 1 Continuous linear winch KTC-240, 240 tonnes @ 1.3 m/min 2 Hydraulic control modules, itegrated on the KTC-240 1 PLC control cabinet for the winch command 1 Control console Factory testing of the unit Commissioning and start-up spare parts Painting and Protective coatings Tagging Documentation DNV witness certificate Weighing Preservation, Packing & Marking Delivery FCA Paris workshop Operator training Commissioning and start-up assistance
General characteristics : Pulling capacity : 240T @ 0 to 1.3 m/min 115T @ 0 to 2.4 m/min Operating temperature : -15°C +5°C Storage temperature : -20°C -20°C Environment : marine, on open deck Hazardous area : zone 1 IIB T4
KTC-240 Linear winch : The blocks are guided along 2 parallel U rails with stainless steel removable supports and self lubricated interchangeable bearings. For weight reasons, the frame is built in 2 seperate bolted parts, and the gripped are removable from the frame. The linear winch is attached working hanging or rested, horizontally on deck foundations (yard supply). Continuous motion. Strong construction frame.
Characteristics : Pull-in capacity (SWL) : 240 metric tones (to be tested during fat) Speed at up to 240T : 1.3 m/min continuous and adjustable Speed at up to 130T : 2.4 m/min continuous and adjustable Oil consumption at maximum speed : 2 × 120 l/min Pressure at SWL : 290 barg Back tension at SWL : not required Jack stroke : 950 mm Wire rope diameter : 72 mm (with changeable inserts) Maximum cable dia : 89 m (3" 1/2) Overall dim : 2.24 m (W) × 8.10 m (L) × 0.80 m (H) Weight : 23.5 tonnes = 2 ×(6.95 t + 4.8 t) Design life : 25 years operation
The winch shall be capable of hauling-in and paying-out under any load, in automatic and manual mode, in continuous operation. It also includes 4 guide rollers (2 horizontal and 2 vertical ones) for the back side (low tension side).
Hydraulic control modules : The linear winch frame includes 2 hydraulic modules (one for each gripper) for the synchronization, control and safety of the grippers of the linear winch. They are mounted and piped on the frame itself. They are suitable to operate into a hazardous area (Atex zone 1).
They are equipped with an integrated line-pull limitation. A potentiometer adjusts the line-pull between 0 and 100%, and a software preset adjusts the 100% betweem 50 t and 240 t.
For the powering of the linear winch, an external and independent 2 × 75 kW. HPU in LS control and with 2 × 130 l/min @ 310 barg. The HPU has 4 outlets on each pump : pressure, return, drain and LS. The linear winch must be fitted to this system for male connections (hydraulic inlet power to the linear winch).
Required oil power for the linear winch should be as follows : two identical and independent supplies (1 for each gripper) of 3 lines each, with each the following utilities requirements : P with 130 l/min at 310 bar per gripper R with 160 l/min at ≤ 5 bar per gripper D with 15 l/min at ≤ 1 bar per gripper LS connections
Fittings internal on the linear winch : On the main connections/ tubing it's require with SAE flanges. On the smaller connections/ tubing where SAE flange won't be used (10 and 12 mm tubes) it's required with parker EO2 fittings. The hydraulic connections shall be assembling on one place (scot plate) for each gripper. Connections shall be as follow : Pressure : 5/4" bsp male Return : 1.1/2" bsp male Drail : 3/4" bsp male LS : 1/4" bsp male
Local control cabinet & panel : The winch is supplied with the PLC control and command, necessary for its full control and located remotely to the winch. It is suitable for hazardous area (Zone 1)
a) PLC Cabinet : The PLC cabinet is supplied loose, to be mounted into a weather protected control container
It will include : EExd cabinet Power supply 230 v - 50/60 hz delivered with electrical supply cable H07RN-F rubber cable 2,5G3 (2,5 mm2 with 2 conductors + earth) PLC, Siemens S7 I/O cards Profibus card Terminals block
This PLC is used to control the linear winch functions (in automatic and manual operations).
There is also a Profibus port available for connection with the HPU PLC. It may be used for interfacing the HPU commands (on-off) and to monitor the HPU faults and alarms.
Control panels : It will include the following : 316L stainless steel panel, 3 mm (385 mm (H) × 540 mm (W) Synoptic panel Control buttons & lamps Linear winch Speed potentiometer Line-pull potentiometer Button manual / 0 / automatic Push-buttons for manual speed control Wedges opening controls Pull / pay-out selector Start / stop Stop buzzer / fault reset Lamp test Emergency stop Pilot lamps : 5" 1/2 Exe screen for cable tension, speed & length displays, status and faults & alarms displays, and calibration set & preset inputs. Connection block
Party verification : This order includes a 3rd party FAT witness certificate from DNV. It includes : Witness of pressure tests (hydraulic cylinders, piping) Witness of FAT Lifting pad-eyes certificate DNV 2.7.3 for offshore handling. Drop tests and lifting on 2 points are not provided. Manufacturing documentation review FAT witness
Protection : This equipment is designed to be operated on open deck. Painting : A 3 coating marine paint, 320 µ is included. It will be according to Norsok M501 RAL 1007 system 1. Concerning the piping on the winch, it is CS made, and the manifold blocks have BSP ports for fitting quick release couplings.
Quality control : Quality control is carried out according to ISO 9001-2008. An ITP is issued during the first month after contract, and progress plan and reports are regularly controlled.
Documentation : All the necessary documentation ( according to Norsok Z-015) related to the design, fabrication, testing, inspection and maintenance of the riser pulling equipment will be provided
This will include : Design drawlings and as-built GA drawings Material certificates and test reports Equipment and instrumentation data sheets Traceability records of raw materials such as steel plate, fasteners, pins and shafting from Kley France sub-vendors. Welding procedures (WPS's), Procedure qualification reports (PQR's), and welder qualifications NDE procedures, records, and qualifications of NDE personnel Non-conformance/discrepancy reports and final dispositions Dimensional control reports Weight and centre of gravity data sheets and certificates Kley France certificate of compliance DNV certificates Installation and preservation procedures Operasjon and maintenance manuals Lists of available spare parts Sale/charter rate & terms : Please enquire using the email form below.
----------------------------------------------------------------------------------------------------------------------------------- Search words : Linear Winch for Sale Linear Winch KTC 240 for Sale or Charter KTC240 Linear Winch for Charter Winch for Sale - KTC 240 Linear Winch KTC 240 for Sale Linear Winch for Charter Winch for Sale or Charter ----------------------------------------------------------------------------------------------------------------------------------------
LCT for Sale 37M Landing Craft for sale 1985 built LCT for sale
Technical Specifications :
Craft Type : Twin Screw Steel Ramp Powered Lighter (Landing Craft) Plan approval for major structures was obtained from ABS Not class-maintained.
Year Construction 1985 Length (LOA) : 36.70m Breadth (Moulded) : 8.50m Depth (Moulded) : 2.50m Maximum Draft (up to Loadline mark) : 1,647m Displacement : 334.60 tonnes Maximum Deadweight : 148 tonnes
Propulsion Engine : 2 X M.A.N D2540 MLE Watercooled with keel coolers Direct injection with turbocharger Power output : 320kW at 1800rpm
Rudder Propeller : 2 X Schottel Rudder Propeller SRP 152/151 Generator Engine : 2 X Deutz F6L912 Air-cooled direct injection Power output : 57kW at 1800rpm
Alternator : 2 X AVK, DKBN 32/50-4TS Rated capacity : 54KVA
Main Switchboard : Manufacturer : LK-Nes (SEA) Pte Ltd Type : Marine, multi-cubicle, front and back Access, floor standing design Class : ABS
Battery Charger : E/R battery charger rating : 115V/24V, 40V Wheelhouse battery charger rating : 115V/24V, 20A
Bilge and Ballast : Pump : Desmi self-priming centrifugal pump (Rated capacity : 20cbm /h at 30m head ; Identical pumps with interconnecting piping such that any two can be used for servicing bilge, ballast or fire system) Motor : Electrim SF 132S-4X (7.5hp, 404V, 3 phase, 60Hz, 1750rpm)
Fuel Oil Transfer : Pump : Desmi self-priming centrifugal pump, S-70-50-275 (Rated capacity : 20cbm /h at 30m head Motor : Electrim SF 132S-4X (7.5hp, 404V, 3 phase, 60Hz, 1750rpm)
Fresh Water : Transfer Pump : Desmi self-priming centrifugal pump, S-70-50-275 (Rated capacity : 20 cbm /h at 30m head Motor : Electrim SF 132S-4X (7.5hp, 404V, 3 phase, 60Hz, 1750rpm)
Domestic F.W. : Pump : Sony CK series centrifugal pump Motor : ASEA MT 80A19-2 (1hp, 440 V, 3 phase, 60Hz, 3480rpm)
Ramp Winch : Winches : 2 X Electric Ramp Door Winch KERW-2010 (2-tonne capacity, 10m/min winding speed, 14mm dia X 50m wire size) Motor : Miyako Seisakusho MIC-B-132S (3.7kW, 440V, 3 phase 60Hz, 1150rpm)
Anchor Winch : Winch : Electric Anchor Winch KEAW-2010 (2-tonne capactiy, 10m/mm winding speed, 16mm dia x 190m wire size) Motor : Miyako Seisakusho MIK-B-160M (7.5W, 440V, 3 phase 60Hz, 1150rpm)
Public Address System : Phonico P.A. System p-2700/4 Echo Sounder : NJA-550MII Navigational Radar : Decca 270 Price & terms : Please enquire using the email form below.
------------------------------------------------------------------------------------------------------------------------ Search words(for official use only) - LCT For Sale 37M Landing Craft for sale Landing Craft For Sale Used LCT For Sale LCT Brokers 37M LCT for sale in Singapore, Malaysia, Indonesia Landing Craft for sale in middle East, Dubai 1985 built LCT for sale Old LCT For Sale - 1985 built Used Landing Craft For Sale LCT Sellers ---------------------------------------------------------------------------------------------------------
Housing Apartments for sale in North Dakota 12 Bedrooms Housing Unit for Sale in USA 12 bedrooms Housing Unit for Sale 12 bedroom apartments for sale in North Dakota. For more information regarding this, please contact us on email mail@worldoils.com
Multi Storey Housing for USA Housing Homes for USA Multi Storey Housing Homes Housing Homes for North Dakota
Chemical Tanker For Sale 2011 built Chemical Tanker - 7000DWT 7000dwt Chemical Tanker for Sale General Classification Notation : BV I + Hull + Mach Chemical Tanker ESP Unrestricted navigation
Principal Dimension and Capacity Length overall : 104.90m Length (BP) : 98.50m Breadth moulded : 19.05m Depth moulded : 9.90m Design draft : 6.50m Scantling draft : 6.70m Speed : 12 knots Complement : 25 men
Main Machinery Main Engine : 1 x 3997bhp Daihatsu 6DKM-36 Generator : 3 x 350 kW Emergency Generator : 1 x 75 kW Boiler : 1 x 4000kg/h oil fire steam
Cargo System Cargo pump : 10 x 200 cbm/h electric deepwell pumps 2 x 100 cbm/h electric deepwell pumps
Number of cargo : 10 cargo tanks Slop tanks : 2 slop tanks Tank coating type : Marine line coating Grade of cargo : 10
Deck Machinery Windlass : 2 x electro hydraulic Mooring winch : 2 x electro hydraulic
Navigation and Communication Equipment Radar : 2 GPS Navigator : 2 Gyro compass : 1 EPRIB : 1 SSB : 1 Inmarsat : 1
Life Saving Lifeboat : 2 x 25 persons Life raft : 2 x 25 persons Price & terms : Please enquire using the email form below.
The details mentioned above are believed to be accurate but are not guaranteed. ---------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) - Chemical Tanker for Sale Over 104m in length - Chemical Tanker - For Sale Chemical Tanker - 2011 built - 7000DWT 7000 dwt Chemical Tanker for Sale 2011 built Chemical Tanker - 7000DWT Tankers for Sale ------------------------------------------------------------------------------------------------------------------------
Caterpillar 236 Skid Steer Loader for Sale Skid Steer Loader of 2006 Model : 236 Skid Steer Manufacturer : Caterpillar Year : 2003 Condition : As-is Description 2003 Caterpillar 236 Skid Steer Loader Note : for Parts or Repair Serial # CAT00236V4YZ06771 Comes with : Bucket, Auxiliary Hydraulic, Solid Tires Location : USA Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed. ---------------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) - Caterpillar 236 Skid Steer Loader for Sale 2006 Caterpillar 236 Skid Steer Skid Steer Loader - Caterpillar Caterpillar 236 Skid Steer Loader for Sale in USA ----------------------------------------------------------------------------------------------------------------------------------
Offshore Supply Vessel for Sale 2400bhp OSV - Offshore Supply Vessel for Sale Offshore Supply Vessel for sale - 2400bhp
General Yard : TBN Name : TBN Classification : IRS / American Bureau of Shipping Year Built : 2010 Main Dimensions Length O.A : 48.00 M Beam : 11.00 M Depth : 03.50 M Designed Draft : 02.79 M Max Draft : 02.79 M Gross/Net Tonnage : 495 / 149 Machinery Generator : 2 x 120KW, 1 x 65KW Bow thruster : HRP 3001 TT @ 350 HP Control : Fwd & aft Main Engines : Cummins KTA-38-M2 Deck Machinery Bow Anchor : 2 X 900 kg Stockless Anchor with 9 shackles anchor chain Elector Hydraulic Windlass Twin Gypsy c/w 2 wraping heads c/w hydraulic electro power pack Performance Speed : 11 Knots Endurance : 18 Days Power : 2 x 1200 BHP @ 1800 RPM (keel cooled) Tank & loading capacities Long range fuel : 204.0 MT Fuel Tank : 149 MT Potable Water : 55 MT Domestic water : 192mt Deck Area : 320 Sq m Dead Weight : 520.9 Tonnes Displacement : 1026.8 T Approx lt ship : 506mt Navigation and Communication Complied with GMDSS A3 for vessel < 500 GRT GMDSS Hand held radio : 3 GPS : 2 Navtex 1 : 1 Magnectic compass : 1+1 VHF : 2 MF/HF/SSB Radio : 1 INMARSAT C : 2 Radar : 1 x 48 NM range Echo sounder : 1 Accomodation Fully air-conditioned : 22 berths Crew complement : 10 Passenger : 12 LSA is for 22 -men complement
Price & terms : Please enquire using the email form below.
-------------------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) : Offshore Supply Vessel for sale 2000bhp OSV for sale 2400bhp Supply Vessel for sale Offshore Supply Vessel for Sale in Singapore, Malaysia, Indonesia 2400bhp OSV for sale 2400bhp Offshore Supply Vessel for sale OSV for sale in India, Middle East, Dubai, UAE 2000hp OSV --------------------------------------------------------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------------------------------ Search words(for official use only):
5 Pieces special lamps 4 x 6 rectangular, halogen, more than 200,000 candelas power of 12 volts, 50 watts of power for outdoor work, for night operations, with manual adjustment mechanism. 1 turret part of cab which includes: - Halogen lamp, amber light, two halogen bulbs of 55 watts, 12 volts DC, 8 amp, a flat mirror between rotating, 400 flashes per minute, amber polycarbonate base and lens. - Rack storage of hoses 3 "pipes 1 1/2" on the back of the unit under the tank service. - 2 chemical handling tanks, located at the rear, with a capacity of 50 liters each. - Drain valve 4 in the bottom of the Duty tank. - Relief valve, vacuum / pressure, emergency. Includes fixed base hinged mast 2.5 meters, cone gauge frame to place wind direction and wind cone. The unit has diamond signaling transport of dangerous substances according to the rules
Control Manifold Composed of three sections, working pressure up to 6000 PSI. Section A (suction lines). Pipe 3-inch Schedule 40 carbon steel. Solder connections 3 inch, Schedule 40 carbon steel. Butterfly valve of carbon steel 3 inch carbon steel 300 PSI. Connects carbon steel loading and unloading on each side of the drive to the rear. Pipe Schedule 40 3 inch butterfly valve for sucking the service tank high pressure pump. Section B (Manifold). Carbon steel pipe 2 inch Schedule 80 seamless. Solder connections 2 inch Schedule 80 carbon steel. 2 ball valves 2 inch carbon steel high pressure (6000 PSI). Two gate valves 2-inch black steel high pressure 1440 PSI, between the control manifold and highpressure discharge. 2 inch pipe carbon steel seamless identification card 160. Connectors 2 inch weld carbon steel identification card 160. Two check valves 2 inch 6000 PSI, installed between the pump high pressure (6000 PSI), the control manifold and the discharge line. 2 swivel Unions 6000 PSI 1 ½ inches chicksan connection type. Bypass arrangement for 6000 PSI composite pipe 1 1/2 "swivel joints chicksan type, hit Union nuts, check valve
DP2 PSV FiFi 1 for sale 7500bhp DP2 ROV Support and Platform Supply Vessel for DP2 ROV Support and Platform Supply Vessel for Sale - 7500bhp 2007 built DP2 ROV Support and Platform Supply Vessel for Sale
General Built : 2007 Classification : DNV +1A1 Supply Vessel, FiFi 1, OILREC, EO, TMON, DYNPOS AUTR NV
Dimensions LOA : 72m Breadth (moulded) : 16m Draft (max) : 5.85m GRT : 2305T NRT : 848T Deadweight : c.3,184T
Machinery Main Engines : 2 x 3,741BHP Thrusters Bow : 2 x 885BHP Thrusters Stern : 2 x 800BHP Shaft Altenators : 2 x 1800kW Aux Generators : 2 x 375kVA + 1 x 150kVA Rudders : 2 Rolls Royce High Lift Propellers : 2 x CPP Deck Crane : 1 x 5T @ 16m Tugger Winch : 2 x 10T Capstans : 2 x 8T
Cargo Capacity Deck Area : 640sqm (47m x 13.6m) Deck Load : 1,550T Fuel Oil : 931cbm @ 100% Potable Water : 800cbm @ 100% Drill Water : 1,255cbm @ 100% Oil Based Mud* : 6,304bbls @ 100% Base Oil : 689bbls @ 100% Brine* : 6,304bbls @ 100% Oil Recovery : 800cbm (8 tanks) Dry Bulk : 11,300cuft @ 100% (80psi)
*Mud/Brine tanks (S.G. 2.5) 10 dual purpose mud / brine tanks. Can be split 6/4; mud /brine with total segregation.
Agitators Electric agitators in all mud/brine tanks.
Tank Washing Toftejorg fixed tank cleaning system in mud/brine tanks. Hot water and chemical dosing applications.
Discharge Rates Fuel : 250cbm/hr @ 90m hd Pot Water : 200cbm/hr @ 90m hd Oil Based Mud : 2 x 70cbm/hr @ 90m hd Base Oil : 90cbm/hr @ 90m hd Brine : 75cbm/hr @ 90m hd Cement : 80T/hr @ 90m hd Barytes : 60T/hr @ 90m hd Bentonite : 100T/hr @ 90m hd Drill Water : 150cbm/hr @ 90m hd
Fuel Consumptions c. 14.5kn @ c. 25t / 24hrs c. 13kn @ c. 15.9t / 24hrs c. 11kn @ c. 12.3t / 24hrs c. 9kn @ c. 9.8t / 24hrs
Navigation Equipment 1 x Sperry Bridgemaster 10cm ARPA Radar 1 x Sperry Bridgemaster 3cm Radar 1 x Leica GPS Satellite Navigator 3 x Sperry Navigat Gyro Compass 1 x Sperry Navipilot Autopilot 1 x Sailor AIS 1 x Sperry Echosounder 1 x Sperry Naviknot Speed Log 1 x JRC Weather Fax
Communication Equipment 1 x Inmarsat F / 2 x Inmarsat C 1 x Internal Intercom System Radio plant according to GMDSS requirements 4 x Motorola GP 340 Atex 3 x VHF’s (Bridge) 2 x Sailor VHF RT 4722 1 x Sailor VHF C 4900 External communication according to GMDSS – 3 x Sailor SP 3300 1 x Sailor 406 MHz EPIRB
Fire Fighting FiFi 1 with self drenching system 2 x 1800cbm/hr pumps 2 x 1200cbm/hr monitors (water/foam)
Accommodation 5 x 1 Man 22 x 2 Man Max. 26 berths available for charterers personnel during DP operations
DP System Konsberg – Simrad SDP-21 Green DPS (DP II) References : 1 x HiPAP 500 Acoustic Positioning System 1 x Fanbeam MK4 laser system 1 x DGPS DPS-200 with IALA receiver 1 x DGPS DPS-100
Manoeuvring Equipment 1 x Poscon Joystick (portable)
Additional Features Removable Wheelhouse for transiting low air draft areas Minimum air draft : 14.4m Deck Power Outlets : 2 x 500Amp Outlets (440v) Reefer sockets : 12 x 110v / 32Amp Mob Boat : Norsafe Midget 5.0 Dispersant Spraying : 2 x 10m stainless steel booms Dispersant Storage : 9.8cbm Oil Recovery : 800cbm @ 450cbm/hr discharge Power pack for oil rec. equipment Removable bulwarks : 1 x 5m (Port side) 1 x 11m (Stern)
Tank : Fuel (11+2) Fuel Oil in Cubic Metres - 105.3 119.9 65.9 (x 2) 47.1 54.8 (x 2) 49.1 134.2 (x 2) 41.7 (x 2) 16.2 Tank : Freshwater (6+2) Potable Water in Cubic Metres - 113.7 104.3 58.7 33.4 (x 2) 79.2 173.1 189.9 Drill Water in Cubic Metres - 173.1 189.9 Tank : Drill Water (11) Drill Water in Cubic Metres - 69.5 50.7 97.7 (x 2) 100.7 (x 2) 112.4 166.5 96.2 Tank : Dual Purpose Mud/Brine (6+4)* in barrels 634 634 634 634 634 634 614.5 614.5 635.3 635.3 Tank : Mud (6) in barrels Mud - 634 634 634 634 634 634 Tank : Brine (4) in barrels 614.5 614.5 635.3 635.3 Tank : Base Oil (2) in barrels 344.7 344.7 Total : Fuel Oil (Cubic Metres) : 931 Portable Water (Cubic Metres) : 786 Drill Water (Cubic Metres) : 1,255 DP Mud/Brine (in barrels) : 6,304 Mud (in barrels) : 3,804 Brine (in barrels) : 2,500 Base Oil (in barrels) : 689 Price & terms : Please enquire using the email form below.
The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : DP2 PSV FiFi 1 for sale 7500bhp Platform Supply Vessel for Sale PSV for sale - 7500bhp 2007 built Platform Supply Vessel PSV-DPII FiFi 1 for Sale PSV for Sale - 7500bhp - 2007 built Platform Supply Vessel for Sale -------------------------------------------------------------------------------------------------------------------------------
Tugs for Sale Tug Boat 4000hp for Sale
Principal Particulars Length Overall : 40.00 m LBP. : 38.00 m Breadth Moulded : 11.40 m Depth Moulded : 4.95 m Draft Designed : 4.40 m approx. DeadWeight : 402.42 tonne Gross Tonnage : 499 Deck Loading : 5 tonne/sq.m Clear Deck Area : 100 sq.m Speed : 12 Knots Classification : American Bureau of Shipping (ABS) Notation : + A1, Towing Vessel, E , + AMS
Main Machinery Main Engines : 2 x 2,000 bhp Total Power : 4,000 bhp Propulsion System : Fixed Pitch Propeller in Kort Nozzle Bow Thruster : 1 x 250 kw Generator : 3 x 300 ekW, 415/3 ph/50 Hz
Performance Maximum Speed : 12.5 Knots Type of Fuel : Marine Diesel Oil Speed/Consumption : 4.40 m draft Maximum Speed (100%) : 15.04 tons per day at 12.5 knots Service Speed (80%) : 12.03 tons per day at 11 knots Economical Speed (75%) : 11.27 tons per day 10.5 knots Bollard Pull : Approx. 50 ton
Tank capacities Fuel Oil Tank : 312 cbm (98%) Fresh Water Tank : 74 cbm (98%) Foam : 15 cbm (98%) Detergent : 16 cbm (98%) Deck Cargo : approx. 800 tonne
Cargo Discharge Rates F.O. Cargo Pump : 1 x 36m3/hr @ 60m Head F.W. Cargo Pump : 1 x 36m3/hr @ 60m Head Ballast Pump : 1 x 36 m3/hr @ 60 m Head
Deck Machinery Tugger Winch : Double drums in waterfall arrangement 1 x 10 tonne @ 14 m/min (each) Capstan : 2 x 10 tonne @ 14 m/min Anchor Windlass : 6 tonne @ 12 m/min AHTW : 1 x 1,000 m, 100 tonne @ 5 m/min Provision Crane Capacity : 2T @ 8 m (SWL) Provision Crane Maker : Jiangsu Haitai Ship
Accomodation Single Berth : 2 x 1 Berth Double Berth : 2 x 2 Berth Four Men Berth : 1 x 4 Berth Six Men Berth : 1 x 6 Berth Total Complement : 16 Berth
Navigation & Communication Equipment 1 Main Radar, ARPA 96 NM 1 Secondary Radar, 96 NM 2 units DGPS,GPS 1 Echo Sounder 1 Speed Log 1 Weather Fax Receiver 1 Auto Pilot 1 unit GMDSS extended packaged 1 Navtex Receiver Integrated Internal Communication System 3 sets Portable VHF Transceiver Ship Security Alert System Inmarsat C Satellite DPS2
Fire Fighting Equipment External FiFi Pump : 1 x 360 cbm /Hr @ mlc Water / Foam Monitor : 2,800 LPM @ 120 m Fire Fighting Connection : 2 x 4-way deck head fire hydrate Fire Hose : 7 x 15 m hose c/w coupling and nozzle Fire Hydrant : 7 x 50 mm Fireman's Outfit : 1 set Dry Chemical Powder : 11 x 4.5 kg Foam Extinguisher : 2 x 9 kg Fire Extinguisher : 1 x 45 ltr Fire Extinguiher : 6 x 9 ltr Oil Dispersant System : Inline Inductor (G.S. / Fire Pump Driven) Spray Nozzle 1 1/4" pipe connection
Life Saving Equipment Liferaft : 2 x 16 pxt Lifebuoy : sets c/w throwing apparatus Lifejacket : 22 sets Immersion Suit : sets Pyrotechnic : as per Class requirement First Aid Kit : 1 x 16 men first aid kit
Other Facilities Sewage Plant : 16 pxt/day Oily Water Seperator : 1 cbm/hr 15ppm according to IMO MEPC 107(49) Reverse Osmosis Plant : 2.5 cbm/day Galley : 1 unit c/w equipment Mess & Conference Room : 1 Room c/w entertainment equipment Laundry Room : 1 Room c/w 10 kgs of washer and dryer Toilets : All toilets are c/w electric shower heater Price & terms : Please enquire using the email form below.
The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) - Tug for Sale 4000hp Tug Boat for Sale 40m Tug Boat for Sale Tugboat for Sale - 4000hp ---------------------------------------------------------------------------------------------------------------------------
Landing Craft for Sale - Newbuilding Newbuild Landing Craft For Sale in the Middle East Landing Craft For sale - 64M - Under Construction
Specifications Class : B.V. LOA : 64m Beam : 13m Depth : 3.25m Light Weight : 500mt Dead Weight : 1350mt Draft : 2.45m Engines : 2 X 650 HP Caterpillar or Mann Generators : Perkins or Cummins 120 X 2 kw Accomodation : 7 Cabins - Accomodating 20 persons
Vessel is scheduled to be completed within 6 months
The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------------- Search words(for official use only) - Landing Craft for Sale - Newbuilding Landing Craft For Sale - 3.25M in Depth 64M Landing Craft For sale - Under construction Under Construction Landing Craft for Sale Landing Craft For Sale in the Middle East 20 Pax Newbuild Landing Craft For Sale Landing Craft For sale - 64M ------------------------------------------------------------------------------------------------------------------------
UMD 135 Land Drilling Rig - For Sale in Europe New Semi Mobile Drilling Rig For Sale - UMD 135 Main Technical Specifications Engine type : C 15 ACERT Nominal engine power hp (kW) : 475 (354) Transmission : Allison 4700 OFS Nominal hoisting capacity metric ton (lbs) : 135 (297000) Workover depht (m) drill pipe (2 7/8”) : 5800 Drilling depht (m) (4 1/2“) : 2500 Rope diameter (mm) : 26 Mast height (m) : 32 Drilling floor height (m) : 5 Travelling system : 5x4 Working pressure (mpa) : 0, 65-0, 8 Technical Specifications Engine type : C 15 ACERT Nominal engine power hp (kW) : 475 (354) Transmission : Allison 4700 OFS Nominal hoisting capacity metric ton (lbs) : 135 (297000) Workover depht (m) drill pipe (2 7/8”) : 5800 Drilling depht (m) (4 1/2“) : 2500 Rope diameter (mm) : 26 Mast height (m) : 32 Drilling floor height (m) : 5 Travelling system : 5x4 Working pressure (mpa) : 0, 65-0, 8 Drawworks Main Drum - Input power (hp) : 500 Barrel size : D18” W38” Brake rim size : D44” W12” Wire line size : 1 ” (26 mm) Drum speed : 7F/1R Brake cooling : Water circulation Brake system : Band / disc / auxiliary (Parmac SSR-28 hydro-brake) Lubrication : Automatic or manual Drum clutch : Air flex type Chain drives : All chains are fully encloded for oil bath lubrication ensuring longer life and cleaner operation Sand Line Drum - Barrel size : D13” W37“ Brake rim size : D44” W9½” Spooling capacity : 16114’ Sand line wire size : 9/16” (14 mm) - 5/8” (16 mm) Rig Power & Transmission Diesel engine(s) : Caterpillar C-15 ACERT, 540Hp, 2.100rpm Transmission(s) : ALLISON OFS 4700 series with torque converter Right angle gear box : Min 500 hp gear box in oil bath gear case Compound box : Twin engine drive through transmission includes disconnect clutches at compound shaft for engines Mast & Crown Block Mast - Mast complete set : Design and conform to API 4F specification Mast height : 32m ( 105ft ) Max. static hook load capacity : 1.323kN ( 300.000lbs ) Racking capacity : 2.500m ( 4 ½’’ DP 19.2m double ) Height of the monkey board : 17.2m ( from floor ) Mast type : Hydraulic telescopic Accessories : Two (2) X hydraulic catheads, Two (2) X tong weight boxes, standpipe, exproof lightning....etc Crown Block - Crown block complete set : Design and conform to API 4F specification Max. hook load : 1.323kN (300.000lbs) Number of sheaves : (3) Main + (1) fast line + (1) deadline + (1) sandline + (2) sheaves for service winch Sheaves OD : Fast Lines Ø32" ( Ø813mm ) Dead Line Ø28" ( Ø711mm ) Sand Line Ø28" ( Ø711mm ) Dia. of sheave’s grove : Fast & Dead Lines Ø1" ( Ø26mm ) Sand & Winch Lines Ø 5/8" ( Ø16mm ) Substructure Substructure complete set : Design and conform to API 4F specification Height of substructure substructure : 5m Area of substructure : 40m2 Max. static rotary load : 1.400kN Set back capacity : 700kN BOP lifting tools : 3tons capacity electric or mechanic winches Accessories : Mouse, rat hole, dog house Rotary Table Diameter of opening : 20½" Center of table to centerline of sprocket teeth : 44" Maximum static load, ton : 350 Max speed, rpm : 300 Gear ratio : 3.79 Dimensions (LxWxH), in : 78×56×24 Approximate Weight, lbs : 12,020 Traveling Block & Hook Traveling block : 1.400kN max. statik load, 4 sheaves, Ø32’’ sheaves dia. Ø1’’ (Ø26mm ) groove dia. Hook : 1.400kN max. statik load, 5tons spring stroke. Elevator link(s) : 1.400kN rated load capacity. Swivel Static hook load, ton : 135 Working pressure, psi : 5,000 Maximum speed, rpm : 300 Coupling thread to stem : 4-1/2" Reg LH Coupling thread to kelly : 6-5/8" Reg LH Stem I.D. : 2- 1/2" Trailer & Other Systems Trailer : Three axles semi mobile trailer, 16 wheels, fabricated high tensile steel vehicle frame reinforced at points of greatest stress. Highway equipment and cab included. Installed fuel tank. Tool box. Auxilary drill line drum, all axles dressed brake, folding walkwayss on both sides of trailer. Hydraulic jacks : Four hydraulic operated leveling jacks Hydraulic service winch : 5 metric tons drum pull capacity Deadline anchor : Deadline anchor attached directly to trailer frame Air system : Compressor (engine drive), air tank, relief valves, air dryer, gauges, all clutches Hydraulic system : Hydraulic pump, system operate hydraulic cylinders on mast, hydraulic jacks, hydraulic pipe tong, and hyraulic winch. Control valves, hydraulic oil tank, filters, pipes, hydraulic and air valve connections, fittings. Electrical lighting system : All the electrical equipments on the mast, and substructure are ex-proof type Instrumentation : Driller control panel, weight indicator, gauges, air valves, cables, hoses, fittings, transducers, paint Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) : UMD 135 Land Drilling Rig for Sale UMD 135 Semi Mobile Drilling Rig For Sale New Semi Mobile Drilling Rigs New UMD 135 Drilling Rig For Sale in Europe Land Drilling Rigs For Sale -------------------------------------------------------------------------------------------------------------------------------------
Crane Barge with Accommodation for Sale Accommodation Barge for sale 1600Ton Crane Barge with 300 men Accommodation for Sale 300 Pax Accommodation Barge for sale with 1600Ton crane Accommodation Crane Barge for Sale
Principal Dimensions Length overall 120.00 m Beam moulded 36.00 m Depth moulded 9.60 m Operation draft 6.00 m Scantling draft 6.50 m
Complement 8 x 1 - man cabins 8 men 18 x 2 - man cabins 36 men 64 x 4 - man cabins 256 men Total 300 men
Tankage SWB - approx 17077 m3 Fresh water tank (potable) –approx 1568 m3 Fuel oil tank - approx 2022 m3 Dirty oil tank (approx.) 34 m3 Overflow tank (approx.) 17 m3 Sludge tank (approx.) 17 m3 Bilge tank (approx.) 34 m3 Grey water tank (approx.) 252 m3 Lube oil tank(approx.) 10 m3
Main deck strength 20 tonnes/m2
Machinery & Main Equipment Generating set 8 x 1000KW each Mooring System 10 x single drum winch
Deck Floating Crane (WISON make and install) Lifting capacity : 1600tons Rated over stern load : 1600t Revolving load : 1200t out reach 32m Auxiliary hook : 300t Whip hook : 50t
The details mentioned above are believed to be accurate but are not guaranteed. ---------------------------------------------------------------------------------------------------------------------- Search words(for official use only) - Crane Barge with Accommodation for Sale Accommodation Barge For Sale 1600Ton Crane Vessel for sale 1600Ton Crane Barge with Accommodation for Sale Newbuilding Crane Barge for sale 300 Men Accommodation Barge for Sale 300 Persons Accommodation Barge for sale Accommodation Barge with Crane for sale Newbuilding Accommodation Vessel for sale Crane Work Barge For Sale --------------------------------------------------------------------------------------------------------
Ocean Going Tug for sale 1340 HP Ocean Going Tug - For Sale 1996 Built Ocean Going Tug For Sale
Year of built : Nov 1996
Principal dimensions : Length overall : 25.00 m Length B.P. : 23.50 m Breadth moulded : 7.50 m Depth moulded : 3.20 m Draft design : 2.50 m GRT/NRT : 174/52
Capacity : F.W. Capacity : 30 tonnes F.O. Capacity : 115 tonnes F.O. Consumption : 4.7 T.P.D. Cruising F.O. Consumption : 3.8 T.P.D. Endurance : 28 days
Nozzle : 2 kort nozzles
Navigational equipment : Furuno FS-1500 Furuno FM-2510/DC24V/25W Furuno 1941 Furuno GP 50 Furuno FCV-665 PA system
Accommodation : 10 persons (air conditioned)
Main propulsion : Twin caterpillar D.3412 TA BTA 2 x 671 bhp
Gear box : Twin disc 520-2
Bollard pull : 15 tonnes
Speed : 10 knots
Auxiliaries : Generators 2 x cummins 4 BT 39 (m) GCI 415V/50 HZ/40 kW
---------------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) - Ocean Going Tug For Sale 1340 HP Ocean Going Tug - For Sale Tugs For Sale in Middle East, India Ocean Going Tug For Sale in Singapore, Malaysia, Indonesia Used 1340 HP Ocean Going Tugs for Sale 1996 Built Ocean Going Tug For Sale
-----------------------------------------------------------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------------------------------------------
Multi-purpose Field Support Vessel for sale Newbuilding MPSV Slot For sale Multi-purpose Field Support Vessel - Newbuilding - MT6007 MKII MPSV New Norwegian Built MT6007 MKII Support Vessel For Sale
4 slots available
Only the very basic information is given here. For more information, please contact us by sending and email to mail@worldoils.com The hull to be dimensioned for a maximum draft of approx. 6,22 m. Two fixed pitch azimuth main propellers, two tunnel thrusters to be installed. Main deck to be arranged for deck cargo with an area of approx. 51m x 13,4m and for a load of 5 t/m2. The vessel to be arranged with accommodation for 40 persons. Main Particulars Length overall 79,67 m Length between p.p. 72,00 m Breadth moulded 16,40 m Max. draft midship 6,220 m Depth maindeck midship 7,45 m Depth shelterdeck 10,20 m Capacities Fuel oil approx. 1355 m3 Water ballast approx. 1135 m3 Drill water approx. 965 m3 Cement tanks (5 tanks) approx. 320 m3 Fresh water approx. 650 m3 Liquid Mud (s.q. 2,5) approx. 1083 m3
Brine (s.q. 2,5) approx. 424 m3 Base oil (s.q. 0,9) approx. 347 m3 Glycol approx. 1290 m3 Metanol approx. 206 m3 Dead-weight appr. : ~3500 tonnes Gross tonnage : ~2995 T Net tonnage : ~1100 T
Speed at d = 4,5m, approx. : ~14,5 knots Cargo deck 55,8 m x 13,4 m = 745 m2 Hull to be built of steel with full strength to main deck, and to class Det norske Veritas +1A1 - E0 - SF, dk(+), hl(2,5), AUTR, LFL* Class notation CLEAN, COMF-V (rating 3), Bridge arrangement to comply with the following recommodations : Naut OSV, without class notation. Thruster capacities : Document of compliance after noise measurement acc. to DnV. Price & terms : Please enquire using the email form below.
The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) - Multi-purpose Field Support Vessel for Sale Newbuilding MPSV Slot For sale Newbuild MPSV for Sale Multi-purpose Field Support Vessel - Newbuilding - MT6007 MKII MPSV New MPSV for sale New Norwegian Built MT6007 MKII Support Vessel For Sale Norwegian Built MPSV Newbuild slot for sale New MT6007 Slot For Sale MPSV MT6007 MKII Newbuild for sale --------------------------------------------------------------------------------------------------------------------------------------------
Fast Crew Boat for sale 34M Fast Crew boat For Sale 2003 built Fast Passenger Ferry for Sale
Specifications Year built : 2003 Capacity : 188 pax Class : KST GRT : 173 ton LOA : 34.26 m Breadth : 6.80 m Depth : 3.01 m Draft : 0.9m (bow) / 1.0m (stern) LBP : 34.00 m Material : Aluminum
Passenger : 188 pax (Max 238 pax) + 4 crews Speed : Max 33 knots, service speed : 28 knots Main engine : MTU 1450 KW / 1800 rpm / 2 units Fuel consumption : MGO 400 liters / hour
Delivery : Prompt
The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) - Fast Crew Boat for sale 188pax Passenger Ferry For sale Crewboat for sale in Thailand, Malaysia, Indonesia 34M Fast Crewboats from China, Korea, Japan 188 person Crewboat for sale Crewboats for sale in South America, North, Africa, Middle east 2003 built Crewboats for sale for West Africa, Nigeria, Libya Crewboats for South America, Brazil, Trinidad ------------------------------------------------------------------------------------------------------------------------------------
550hp Workover Rig for Sale 2008 built Workover Rig Used Workover Rig
Service Conditions : The rig is capable for undertaking work over operations in Oil/ Gas / Injection / Effluent disposal wells/CBM wells etc. up to depth of 3000 mts approximately with tubing string of 2 7/8" to 3-1/2" in 5" to 9 5/8" casings, depending on the weight of completion equipment. The work over jobs include but are not limited to servicing/ installation of artificial lift equipment, cleaning of well bore, gravel packing, sand screening, stimulation, well abandonment, transfer of horizons, water shut off, gas shut off, water injection profile modification and re-completion, retrieval of gravel pack assembly, fishing & releasing of stuck up, multi-layer testing, casing repair etc. in vertical/deviated/horizontal multilateral / ERD / USRD wells etc.
1. Workover Rig The Rig XJ 550 is a brand new self propelled rig and capable of workover / testing / completion/service upto 5800m using 2 7/8 " drill pipe and and 4500m using 3 1/2" drill pipe. The rig is having the hook load capacity of 135 ton and manufactured as per latest API standards applicable in the oilfield Industry.
The rig is equipped with : a) Four leg leaning type, Hydraulically telescoping, two section, foldable, SJ Petroleum Machinery Co., China make, Model JJ135/34 Mast with clear height of 112 ft from ground level and rated static hook load capacity 135 T with 8 lines strung on traveling block.
The mast is designed as per latest API 4E/4F standard code and practice. The Mast can is equipped with suitable Finger Board which can accommodate 5200 mts of range-II, 2 7/8" tubulars in doubles.
b) Twin safety device (floor-o-matic and crown-o-matic) is available. c) Top man escape device will be provided. d) Suitable locking system would be provided with additional safety manual lock for telescoping of mast to full height. e) The mast is designed to withstand wind speed of minimum 60 knots as per Clause 6.2.3 of API 4F with full pipe/ setback with all guy ropes properly placed as per standard API pattern. f) Hydraulic Cat works : For make up & breakout consisting of hydraulic make up (spinning) cylinder providing 10000lbs (4444kg) minimum line pull and hydraulic break out cylinder to develop a minimum line pull of 20000lbs. Control for make up & breakout is located at Driller's console. g) Draw works with suitable rating for handling 100MT hook load capacity, equipped with suitable auxiliary hydromatic brake for safe running in of the string. The Draw works should have sufficient range of forward speed and one reverse speed.
XJ 550 Draw Work Input HP rating 550 HP. Nominal depth rating 2000 mts with tubing, fitted with compatible mechanical brake system and driven by a suitable Detroit make diesel engine. Draw works having 4 forward and one reverse speed. Draw works drum having main drum Lebus Groove for 1 1/8” line. Main drum brake having maximum wrap around feature energizing type brake. Crown-o-matic protection device to protect the Crown is also provided. g) The draw works is powered by 1 no. of "CATERPILLAR"make, model C-15 ACERT diesel engine of 540 HP at 2100 rpm with ALLISION make, heavy duty transmission consists of torque converter, model "M5610AR" and suitable power trend through compound/chain drive and gear boxes.
The power pack is perfectly suitable for effective hook load of 135 MT and to work on 5000m deep well. The power pack is completed with standard gauges, meter, safety equipment and spark arrestor. Engine is equipped with independent interlock pneumatically operated starting system during the workover mode and the electric starting system during the roading.
h) SJ Petroleum Machinery Co. make Model "YG-150"hydrahook with combination block having 4 nos. of sheavesof 30" diameter. The hook has built in hydraulic snubber,conventional rotation lock and safety positioner etc.,rated capacity is 150 tonne and is capable to operate 2-7/8" to 3-1/2" tubing and 2-7/8" to 3-1/2" drill pipes up to required depth.
j) Racking Board is of adjustable type and completed with topman emergency escape device from monkey board to ground, railings & safety belts. The Racking Board is having sufficient provision to rack 3 1/2" / 2 7/8" tubulars/drill pipes for 5000m Drill pipe/ 6000m tubing and having provision for height adjustment at three different convenient positions.
2. Substructure S J Petroleum make Sub-Structure,made as per API-4F rigid type, completed with all respect to carry out drilling jobs, 13' below the rotary beam. Substructure having sufficient space to accommodate the 3 stack BOP (one Pipe Ram + One Blind Ram+ one Annular) with riser nipple in workover mode. The structure is completed with rotary beam, railing,side platform, setback area and stair way. The sub-structure can accommodate 17 ½” Rotary Table on it.
3. Rotary Equipment SJ Petroleum Machinery Co., China make, Model "ZP175"or equivalent rotary table with 17.5" opening without master bushing.
The table is completed with master bushingand kelly bushing.The rotary table is driven by chain-sprocket and the mechanism is powered by the drawworks.
4. Kelly 40 feet Square / hexagonal Kelly 3" size as per API 7 suitable for working upto 350 kg / cm2 (5000 psi) working pressure with required connections along-with saver subs will be provided. Upper and lower Kelly cock of suitable size with pressure rating of 5000 psi will also be available.
5. Swivel a) SJ Petroleum Machinery Co., make, Model "SL-135", rotary swivel having static/dead load capacity of 135 tonnes and working pressure rating 5000 psi and completed with bail bumper support, goose neck connection to rotary hose etc. Swivel bottom pin connection 6 5/8" API regular left hand.
(b) With 3” diameter quick change goose neck assembly with working pressure 5000 psi.
6. Hydraulic Winch The Rig is provided with minimum 1 no. of hydraulic winch with catline for handling tubulars having pulling capacity not less than 3MT.
7. Mud System Mud system is capable to handle drilling mud Sp. Gr. upto approximately 1.8.
7.1 Mud Pump (a) BOMCO China Make, model "F-500" triplex slush pump rated at 500 HP, unitized to a reputed Make diesel engine having sufficient capacity, through belt drive compound with shaft or chain drive is acceptable and 5 speed heavy duty gear box with Centrifugal supercharging pump, having pulsation dampener, safety relief valve, pressure gauge etc.
Mounted on a steel oil field skid, 20 gallon, heavy duty Type-F 6000 psi mud gauge, Pumps dressed with 3 1/2" to 6" liners as per operational requirement. The pump is capable of handling work over operation in 5 1/2"casing with 2 7/8" tubular upto a depth of 6500 mts. with mud of specific gravity- 2.3.
(b) Capacity of Pump Discharge : Minimum 12 cbm / hr. at 5000 psi. Minimum 52 M3 / hr. at 2000 psi.
7.2 Discharge System a) Rotary hose of suitable size having working pressure of 350 Kg/Cm2 (5000 psi) with suitable connections will be provided. b) Suitable end connections of suction line and delivery manifold will be provided. c) Stand pipe of suitable size and pressure rating along with pressure gauge is also present.
7.3 Mud/Work over fluid storage/ Handling arrangement i) Tanks having capacity (volume) not less than 80 cubic meter with permanent level markings from bottom will be provided. ii) Arrangement is provided for brine/mud preparation, mud mixing, mud agitators / bottom gun jets of best engineering iii) Transfer pump for working fluid / mud from tankers into tank and tank to tank and back to tanker (if required) along with pumping system. iv) Necessary system lines wherever required. v) Calibrated mud hopper of suitable size with butterfly valve and proper line connection will be provided with gunning arrangement. vi) One trip tank of approximately 8 m3 with suitable connections and valves will be available. It will be equipped with sufficient capacity of centrifugal transfer pump & motor suitable for hazardous area. vii) Skid mounted / portable filtration unit for brine to get the out let brine solution of 5 micron quality at flow rate 40M3/hr at working pressure 10Kg/cm2 after fine filter with suitable motor for hazardous area .
8. Fuel Storage Sufficient fuel storage to undertake the workover operations will be provided
9. Water Storage Tank with storage Capacity of 40 m3 equipped with transfer pump of suitable capacity with necessary hook up lines/ system will be provided.
10. Well Control Equipment The following well control equipment will be provided : a) Hydraulically operated Cameron / Shaffer / Hydril make, one double ram type Blow Out Preventor of 7-1/16" X 5000 PSI working pressure having one set of blind ram and one set pipe rams to handle size 3-1/2" and 2-7/8". b) Hydraulically operated Cameron / Shaffer / Hydril make, one annular Blow Out Preventor of 7- 1/16"X5000 PSI working pressure. c) Or one no of 3 stack unitized BOP containing items as mentioned at a) & b) above. d) One set of stem & wheel for manually closing BOP as per OISD standard-174. e) One. No of shanghai shenkai petroleum chemical equipment, 6/8 bottle hydraulic control unit, capable of operating the BOP with suitable Pneumatic and electric motor driven pump. The system pressure is 3000 PSI. Necessary 1" BOP control hose to connect BOP with control unit.
1 (one) nos., of remote control unit placed on drillers console. Unit will have two charging systems i.e. Pneumatic and electric with auto start and stop facility. Flame proof DGMS approved motor will be used. One set of stem and wheel to operate the BOP mechanically.
f) Adapter flange/ spool/dummy spools of following size will also be available :- Change over spool 7-1/16" 5000 psi x 7-1/6" 10000 psi - 1 no
g) 1 no. BOP test plugs or Cup tester/ accessories will also be provided.
h) Plug valves, tubing shut off valve and FOSV of 5000 PSI having necessary connections and changeovers for 2-7/8" & 3-1/2" NU /EUE tubings/ Drill pipes will also be provided.
11. Choke and Kill Manifold Choke & Kill manifold is as per API of size minimum 2-1/16" having minimum 5000 psi WP along with sufficient quantity of flexible steel piping of minimum 5000 psi WP of suitable size fitted with NRV in kill lines. It has a suitable combination of valves having provision to flow the well through fixed choke, variable choke and one bypass also. There is also a provision to kill the well through kill line as well as one additional line for making connection through cementing.
12. Handling tools as per API 8C a) Center latch elevator for minimum 100MT capacity and minimum 01 no. for each category will also be provided.
Sizes 2-7/8" : Upset Tubings 2-7/8" : Plain Tubings 3-1/2" : Plain Tubings 2-7/8" : I.F Drill Pipe 3-1/2" : I.F Drill Pipe 3-1/2" : Upset Tubing b) Elevator links Elevator links-forged as per API 8C, rated capacity-minimum 100MT, size 1-3/4"x72". qty 2 nos will be provided.
c) Power (Pneumatic) slips We will provide Light Weight pneumatic slip/spider, with sufficient spares, inserts suitable for 2-7/8" and 3-1/2" tubing and drill pipes along with all associated connections, hoses and Couplings. Operating valve at driller's console.
d) Hydraulic tubing tong (Qty-1) A Light weight hydraulic tubing tongs as per relevant API for 2 7/8" and 3-1/2" tubings with replaceable jaws minimum torque rating 8000 ft lbs along with sufficient spares would be provided.
e) Heavy duty Tong. (Qty-02) Range 2-3/8" to 4-1/2", and to handle all fishing tools and milling tools as per relevant API, torque rating minimum 35000 ft-lbs with hanger arrangement along with sufficient spares will also be provided.
f) Handling Tools for Sucker Rods and Polished Rods Tongs & elevators for handling 5/8", 3/4", 7/8", 1", 1-1/8" & 1-1/4" sucker rods and polished rods will be provided.
13) Cross Over Subs Bit subs, cross over subs and all necessary subs to handle work with 2-7/8" & 3-1/2" tubing and drill pipe string or their combinations will be provided.
14) Rig instrumentation suitable for Hazardous area. a) Deadline weight indicator with sensator/ load cell on driller console/control panel, indicating load on hook for the designed capacity of the rig will be provided. b) Suitable recorder for recording hook load will be provided and it will be mounted in weight indicator box c) Mud pump pressure indicator would be complete, on drillers console/control panel. 0- 6000 PSI. d) Mud pump pressure gauge is mounted on stand pipe of 0-6000 PSI. e) SPM indicator for mud pump discharge at drillers console/ local mud pump control panel. f) Indicators for B.O.P rams open/close for blindram, pipe rams & annular BOP on drillers console/control panel is provided.
15. Safety Equipment The rig is equipped with following fire fighting & safety equipment : I. Fire fighting system as per OISD standard -189 :- Para 6.0 i) Fire water storage facilities with fire pump. ii) Portable Fire extinguishers. Para 11.0 - Material specification of Fire water system. Para 12.1 - Fire alarm system. II. Explosion proof rig lighting at all hazardous locations as per Indian Oil Mines Regulation in force. III. Flame proof portable lamps (minimum 2 nos.) IV. Emergency Kill system for derrick engine (control from driller's panel). V. Electrical system will have suitable ELR (Earth leakage relay) VI. First aid box with stretcher facilities as per OISD standards - 204 para 6.5 and Annexure - H. VII. Safety kits & liveries (as per standard statutory body) will be provided for operating personnel. Top man safety belt also to be provided. VIII. All the rotating parts must have proper safety Guards.
16. Drill String a) Drill pipes 2-7/8" OD IF Right Hand, G grade of 10.4 ppf, premium Class I, Range II, 3000 meter will be provided with rig along with latest NDT certificate. b) Drill collars of sizes 3-1/2" of total length 50m with cross over to run 2-7/8" & 3-1/2" drill pipe will be provided.
17. Other Equipments The following equipment will also be provided : a) Air system: Air compressor system of suitable capacity with air tank for operating pneumatic Cellar pump, Hydraulic pump of BOP control unit etc. b) Rig warehouse and POL store. c) Rig In-charge Office. d) One A/C bunk house for coordinator. e) One bunk house for Contractor's operating personnel. f) V door & cat walk with pipe racks on both sides. g) Necessary transport equipment for movement of rig from one location to another. h) Cellar pump- Air operated (Pneumatic) with suction hose of sufficient length. i) Circulating head 5000 psi working pressure for 3-1/2" and 2-7/8" Drill pipes and tubings with necessary change over j) All trailor mounted equipments including rig trailor will meet the RTO regulation including Registration k) POWER GENERATOR: 2 nos. 125 KVA power generators, powered by Kirlosker/ Cummins or equivalent make diesel engine with "STAMFORD/JYOTI" make alternator and properly designed control panel for rig operation and illumination of work area with each other. l) Sufficient number of suitable flanges, chicksens/ flexible joints and rubber hoses for making all types of connections for working pressure 5000 psi will be available, m) Welding machine/ Welding transformer powered by contractor's Gen Set along with all associated welding and oxy - acetylene cutting accessories, gases and consumables etc. n) Potable water storage, filter and water cooler, o) One no of red aviation light flickering type fitted with lamp at crown block shall be available having independent circuit. p) Mud balance q) All rig equipments and facilities like bunkhouse store etc. will have effective double distinct earthing system as per IER 1956. Price & terms : Please enquire using the email form below.
The details mentioned above are believed to be accurate but are not guaranteed. ----------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : 550hp Workover Rig For Sale in India Used Workover Land Rig 550 HP Workover Rig For Sale in the Middle East 2008 built Workover Rig for sale in India Used Workover Land Rig 550 HP For Sale Land Workover Rig For sale - 2008 built Workover Rig - 550hp - 2008 built Used Workover Rig for Sale in the Middle East -----------------------------------------------------------------------------------------------------------------------------
Platform Support Vessel for Sale PSV for sale Newbuilding PSV for sale Delivery Q1, 2011 Principal Particulars : Port of Registry : TBA Length Overall : 74.87 m LBP : 67.2 m Breadth Moulded : 16.4 m Depth Moulded : 7.45 m Max. Draft : 6.23 m Depth shelterdeck : 10.20 m Deadweight at SWL : approx. 3,250 tonne Gross Tonnage : approx. 2,820 tonne Net Tonnage : approx. 1,060 tonne Deck Loading : 5 tonne/m2 Clear Deck Area : 684 m2 Speed : 13 Knots Classification : DNV+1A1(E)-E0-SF,dk(+),hl (2,5),AUTR,LFL*, COMF-V (rating 3)
Main Machineries : Main Engines : 4 x 1,239 eKW Total Power : 4,956 eKW Propulsion System : 2 x Rotatable (360 degree) Stern mounted el. Motor Driven Azimuth Thruster Type Twin (Push and Pull) Bow Thruster : 2 x Fixed Pitch Tunnel Thruster Generator : 4 x 1,239 eKW, 690V/60HZ Emergency Generator : 1 x 99 KW, 690V/60Hz
Tank Capacities : Fuel Oil Tank : 1266 m3 (approx) Liquid Mud (s.g 2.5) : 1083 m3 (approx) Water Ballast : 1100 m3 (approx) Drill Water : 930 m3 (approx) Fresh Water : 650 m3 (approx) Brine (s.g 2.5) : 424 m3 (approx) Methanol (s.g 0.9) : 206 m3 (approx) Base Oil (s.g 0.9) : 340 m3 (approx) Glycol : 1290 m3 (approx) Deck Cargo : 684 m2 (approx) Bulk Cargo (Cement) : 256 m3 (approx)
Accommodation : Single Berth : 4 x 1 Berth Double Berth : 18 x 2 Berth Total Complement : 40 Berth Hospital : 1 room
Cargo Discharge Rates : F.O. Cargo Pump : 1 x 200 m3/hr (Freq. Controlled) F.W. Cargo Pump : 1 x 200 m3/hr (Freq. Controlled) Base Oil Pump : 1 x 150 m3/hr (Freq. Controlled) Methanol Pump : 2 x 75 m3/hr (Centrifugal) Ballast / G.S. Pump : 1 x 150 m3/hr (Freq. Controlled) Liquid mud Pump : 2 x 85 m3/hr (Freq. Controlled) Brine Pump : 1 x 125 m3/hr (Freq. Controlled) Deck Cranes : 1 x 3 tonnes @12 m, Knuckle Boom Type with 4m Jib Cargo Securing Winches : 3 x 3 tonnes hoisting capacity 5 tonnes brake Capstan : 2 x 10 tonnes Anchor Windlass : According to class
Navigation & Communication Equipment : 1 Main Radar, ARPA 120 NM 1 Secondary Radar, 96 NM 1 Echo Sounder 1 Speed Log 1 Auto Pilot 1 Conning Display System 1 ECDIS 1 Clinometer 1 unit GMDSS extended packaged 1 Navigation / Direction Finder 1 NMEA Distribution unit with interface to DP 1 GyroCompass 1 off 12 channels DGPS satellite type FURUNO - 90 VHF and UHF Radio Telephone System Intercommunication System with PABX line and line from VSAT Command and Intercomm System Sound Powered Telephone System
Fire Fighting System : Internal FiFi System : FiFi System with CO2 FiFi System with Water mist FiFi System With Hand Extinguisher FiFi System With Spot FOG (Galley)
Life Saving Equipment : MOB Boat with Davit : 1 off SOLAS approved type Life Raft with Equipment : SOLAS approved type for 120 persons Life Jacket : SOLAS approved type for 40 persons
Price & terms : Please enquire using the email form below
The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------- Search words (for official use only) - Platform Support Vessel for Sale MT 6009 MK II Platform Supply Vessel for Sale Platform Support Vessel for Sale For sale New PSV for Sale MT 6009 PSV for Sale Newbuilding PSV for Sale Platform Support Vessel -------------------------------------------------------------------------------------------------------------
Mini Bulker For Sale 1978 Built Small Bulker For Sale
6.100 tdw on 8.45 m Singledecker with boxhold Built : 1978 Lloyds class
Dims : 80.20x16.0 m 1 boxhold 7373/7271 cbm gr/bale – 1 hatch Tanktop 15 ts/m2 Cranes 2 x 15 tons sidemounted Hanshin 3000 hp - IFO burner Price & terms : Please enquire using the email form below.
------------------------------------------------------------------------------------------------------------------------ Search Words(for official use only) : Bulk Carrier for Sale in Caribs 6000T dwt Bulk Carrier For Sale Small Geared Cargo Ship for sale 6000 dwt bulker for Sale Bulk Vessel for sale ---------------------------------------------------------------------------------------------------------------------------
SCR Land Drilling Rig for Sale Refurbished 1500 HPSCR Land rig for sale National 110 UE Refurbished 1500HP SCR Rig
Specifications : National 110 UE 1500HP Single Drum Drawworks p/b (2) 1000 HP Apollo 752 DC Traction
Swivel : Mud King 450â€Ton Block/Hook : Ideco 525â€Ton Block/Hook Combination.
The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : SCR Land Drilling Rig For Sale Land Drilling Rig For Sale - 1500hp Used 1500 HP SCR Drilling Rig 1500HP Electric Drilling Rig For Sale ----------------------------------------------------------------------------------------------------------------------------
Command Post Containers Approved Germanischer Lloyd Command Post Containers 20' Command Post Containers ISO-containers for Sale Technical Specifications Length : 6058mm (20') Height : 2438 mm (8') Width : 2438mm (8')
Net tara weight : 8000kg Pay load : 4000kg Floor area : Total 32 sqm Mounting time : Less than 30 minutes
Comply with : NS-ISO : 1496-1 and 3874 STANAG : 2413 MIL-STD : 1472F
Approved by : Germanischer Lloyd and C.S.C For price & terms : Please enquire using the email form below. -------------------------------------------------------------------------------------------------------- Search terms (for official use only) : Command Post Containers for Sale 20' Shelter Containers 32sqm Command Post Containers for Sale 3 in 1 Command Post Containers ISO- Shelter Containers for Sale Command Post Containers - 20' in Length ---------------------------------------------------------------------------------------------------------------
Motor Yacht Over 41m for Sale 2008 built Modern Motor Yacht for sale Motor Yacht for Sale - 2008 built
Description She was successfully launched in 2008 before being transferred to the owner. The core hull was built out of kevlar / carbon. The motor yacht main superstructure is fabricated extensively using composite. She has a beam of 8 m / 26.24 ft and has fairly large interior.
A shallow draught of 1.3m (4.27ft) selects the list of overall harbours she can enter, contingent on their individual depth at low tide.
Powered by triple MTU diesel engines, this unit is able to reach a high speed of 53 knots and is propelled by tripple water jets.
She also has an efficient range of 500 nautical miles when underway at her cruise speed of 46 knots. Her total HP is 7200 HP and her total Kilowatts are 5370.
General Class society used: - Completed survey under Maritime & Coastguard Agency (MCA) Length Overall: 41.6 metres / 136.48 feet Gross Tonnes: - Nett Tonnes: - Displacement: 131 - Hull / Superstructure Construction Material : kevlar / carbon / composite
Her Engine(s) is three 2400 Horse Power / 1790 kW MTU. Engine Model: 16V 2000 M93 diesel. Fuel Capacity: 19000 L. Fresh water: 5000.00. Yacht Beam: 8m/26.24ft. Draught Maximum: 1.3m/4.27ft.
Accommodation The large luxury yacht motor yacht is able to sleep a total of 8 guests and 10 crew members.
Price & terms : Please enquire using the email form below If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you.
The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : Modern Motor Yacht for Sale Motor Yacht for Sale - 2008 built Motor Yacht - 2008 built 2008 built Yacht for Sale - over 41m long Over 41m Motor Yacht for Sale 2008 built Modern Motor Yacht for sale Over 41m Modern Motor Yacht Motor Yacht - over 41m - for Sale ---------------------------------------------------------------------------------------------------------------------
Tower Crane for Sale Tower Crane For Sale 2011 Built 2011 built Tower Crane for Sale Comansa 21LC750 Capacity 48Ton Year : 2011 Description : 80 m Jib 78.8 m hooke height Foundation by anchors In options for deliver : Climbing cage J8 Location : Europe Mint condition One time on jobsite IN STOCK Price & terms : Please enquire using the email form below.
The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------ Search words(for official use only) : Tower Crane for Sale Comansa 21LC750 Tower Crane 2011 Built Tower Crane for Sale Tower Crane - Comansa 21LC750 - For Sale 48 ton Capacity -Tower Crane for Sale - 2011 built -----------------------------------------------------------------------------------------------------------------------
Aframax Tankers for Sale Chinese Built Aframax Tankers for sale
Principal Particulars Deadweight : Abt 110,000T Loa : Abt 244mts. Beam : About 43mts Draft : Abt 15.37mts Built : China 2010 Class : Rina/ABS M-B / 7S60MC / 19,415 BHP / AT 105 rpm No. tanks : 12 / 120,570 cbm l : Coiled 3 pimps : / 7,500 twph tot Double bottom Double side Further details including the below will be given to named interests : OCIMF / Q88 Latest class printouts for Rina as primary class, vessels have ABS as 2nd class GA plan Speed and consumption Sale/charter rate & terms : Please enquire using the email form below.
------------------------------------------------------------------------------------------------------------------- Search words(for official use only) : Aframax Tanker for purchase Aframax Tanker for sale Almost New Aframax Tanker For Sale Aframax Tankers available for sale / charter Aframax Tankers for charter -------------------------------------------------------------------------------------------------------------------------
Showing 1057 to 1104 of 2136 results
.png)
.png)
.png)
.png)
.jpg)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
Search Here
