Towing Tug  for Sale
1991 Built Tug for sale

Built : 1991
Class : JG Coastal
LB :11.94x4.95
M/E : MHI SBB-MTC 500ps x 2/300rpm

Inspectable Place: West Japan

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Towing Tugs 1991 Built for Sale
1991 Built Towing Tug for sale
Used TowingTug for Sale
Tug for sale
-------------------------------------------------------------------------------------------------------------------------------------

New Coiled Tubing Unit for Sale
Coiled Tubing Unit - New - 25K
25K Coiled Tubing Unit for Sale
New CT Rig for Sale

Specifications

Section 1 – Truck: 8x4 (Tandem-Tandem)
- Truck Chassis : Kenworth, 8 x 4 (twin steer) or equivalent.
- Engine : Detroit 550 hp at 2100RPM
- Transmission : Eaton Fuller, 18 forward, 4 reverse
- Front Tires : 65R22.5 x 18 Ply
- Rear Tires : 11:00 R24.5, 14 Ply
- Suspension : Accuride Steel Flotation
- Front Axle : Six foot Centres, 20,000 lbs
- Rear Axle : 46,000 lbs
- Weight : approx. 19,500 lbs. (approx. 9,000 kg.)
- Wheelbase : Length from centre of front axle to rear of frame 420”

Section 2 – Fabco Power Transfer Case
- Rear bogies can be disengaged and power transferred to the top of the transfer
 case, which drives the pumps and the compressor
- Single-piece construction provides rigidity necessary to withstand off-highway use
- Constant mesh gears assure long service life
- Ball bearing mounted gears and shafts prevent premature malfunctions
- Upper rear outlet capped off
- Upper front outlet SAE “E”, 4-bolt hydraulic pump mount

Section 3: 2000 PSI Hurricane Compressor
- Belt driven via a pulley arrangement to attain the maximum operating speed required
for the unit.  Belt drive is recommended to reduce shock to the drive system
- 600 CFM
- Maximum Pressure: 2,000 PSIG
- 1800 RPM maximum speed
- 4-Stage compressor
- First Stage: 4-cylinders, 5-1/2” bore
- Second Stage: 2-cylinders, 3” bore
- Third Stage: 1-cylinder, 2-1/2” bore
- Fourth Stage: 1-cylinder, 1-3/8” bore
- Stroke: 4-3/4”
- 26-Quart oil capacity
- 10-1/2 Gallon Coolant capacity
- Inter-Stage pressure gauge

- Oil pressure gauge
- High 1st-Stage pressure
- High Inter-stage and Discharge Temperature
- Low oil pressure
- Relief valves after each stage and discharge
- Air cleaner, 2-stage, heavy-duty
- Inter-coolers and traps between each stage
- Full flow oil filter
- Self-contained cooling system

Optional
Compressor with 1st,2nd, 3rd Stage Overhead Cooling

Overhung Drive: SAE ‘D’ Pump Drive with pump case vent, filled with oil, splined inboard shaft,
and Keyed outboard shaft. SAE #2 Flywheel Flexplate with splined shaft. SAE #2 Flywheel
Housing.

Section 4: Control Panel Assembly
- A full width Control Console is installed at the rear of the unit.  Console face is stainless steel
construction and fully engraved, or back coloured lexan reversed engraved with all gauge and
control information
- Air pressure gauge
- Auxiliary systems hydraulic pressure gauge
- B.O.P. control valve bank, c/w two-tier activation system
- B.O.P  accumulator bleed valve (on accumulator bottle)
- B.O.P  pressure gauge.
- Circulation and wellhead pressure gauge (0 – 6,000 psig)
- CTU air supply valve
- Dual acting, +25,000 lb. Weight indicator
- Engine coolant temperature gauge

- Engine emergency kill valve (red knob)
- Engine oil pressure gauge
- Engine starter switch
- Engine stop control (Normal)
- Engine tachometer
- Engine throttle control
- Engine volt meter
- Horn control valve
- Injector brake release pressure gauge

- Injector chain tension control
- Injector chain tension pressure gauge
- Injector control (“Speed Control and Direction Control”)
- Injector “in-hole – out-hole” pressure controls (drive pressure)
- Injector “in-hole – out-hole” pressure gauges
- Injector pump, charge pressure gauge
- Injector skate pressure control c/w pressure gauge.
- Installed near Control Panel will be a back-up hydraulic pump system (Injector Skate Pressure,
- Stripper Pressure & BOP).  Other miscellaneous gauges and controls to provide full operation
of the unit.

- Light switches
- Panel mounted circuit breakers
- Stripper Pack and Retract pressure gauge
- Stripper pump control valve
- Stripper Pack/Retract hydraulic control valve
- Tubing reel brake release control valve
- Tubing reel manual control
- Tubing reel tension control valve (Reel Drag)
- Tubing reel tension gauge (Reel Drag)

Section 5: Tubing Reel Assembly
- The OS 4500 reel utilizes lightweight but extremely strong elliptical heads to support the reel
spool.
- 1-1/2” Rotary Swivel Joint, rated at 10,000 psig, Working Pressure the swivel will be flange
mounted to the main reel shaft to permit continuous circulation during tubing operations.
- The OS 4500 utilizes a direct planetary drive; this eliminates the drive chain and guard
assembly.
- The Spring applied Hydraulic actuated failsafe brake is mounted between the hydraulic
drive motor and the planetary drive.
- Reel maximum capacity: 4500 m. (14,753 ft.) of 1-1/4” diameter coiled tubing.
- Core size is 60” width is 48” OD is 106”

- Reel is a transverse type (side to side movement).  No leadscrew is used.
- Reel is mounted on a heavy-duty tubular support tower, which is mounted on a heavy-
duty tubular steel skid base. (The base may be modified to suit customer)
- Reel outer spokes are built from hollow structural steel tubes.
- Reel supplied with chain and load boomer transport locking system
- Rotation pins for transverse movement (Driver side only)
- The External High Pressure Manifold is complete with two (2) inlets and two (2) separate
low torque - FMC or equivalent plug valves.  Connected to this arrangement is a diaphragm
protector (for monitoring of the Circulating Pressure), which in turn is attached to the Rotating
Swivel Joint.

- The Internal Pressure Manifold is provided with a medium pressure ball valve between
the reel axle and the coiled tubing.
- The reel shaft is manufactured from steel pipe with a steel stub shaft welded at one end,
the second end will have the planetary drive adaptor ring. The end of the shaft opposite the
drive system is bored out to allow passage of a medium via the Rotary Swivel Joint to the
coiled tubing. Tubing reel shaft is supported by one (1) bearing on the swivel side and by the
planetary drive on the drive side. This is then mounted on a heavy-duty steel frame assembly.
The tubing reel can be removed from the truck deck by removing the transport/operational
locking pins.

Section 6: 25K Injector
- Tubing Injection/Retraction Speed: 0 – 400 ft. / min.
- Rated at 25,000 lb. Pull; 15,000 lb. Push
- The 25K Injector Head has been engineered to meet the most rigorous applications for
land or offshore applications.
- Gripper Blocks are of rugged design.
- Drive chains use a 1-1/2” pitch, 3-strand oilfield roller chain with the pins going all the way
through the gripper blocks for extra strength.  Drive chains will be fitted with one (1) set of gripper
blocks in a size requested by the customer (1” through 2”)
- Bottom adjustable shaft, complete with grease nipple is mounted on sealed spherical roller
bearings

- High ratio planetary drives power the drive sprockets, which provides accurate control at low
speeds. - Variable displacement piston hydraulic motors and fail-safe disc brakes complete the
assembly.
- Fail-safe disc brakes are located between the motors and the gearboxes.
- Variable displacement piston hydraulic motors, eliminating the need to stop to shift gears.
- Drive shafts, skates, sprockets, idler shafts and cross shafts are made from high quality steel.
- Independent, full floating, self-centering roller skate is utilized to apply tubing friction pressure to
tubing push/pull.

- Gripping force is applied using a superior flat black chain with rollers.
- Lightweight, high strength tubular steel construction.
- Maximum width 2’ 9-5/8”
- Base 23” x 37”
- Overall Height 54”
- Hydraulic cylinders apply tubing friction pressure through each of the skates.
- These hydraulic cylinders are conservatively sized to provide extra squeeze to prevent slipping on
even lubricated coil tubing.  Cylinders are positioned for easy removal for service.

- Independent accumulators cushion all skate pressure cylinders.
- Pressure lubrication system is incorporated into the design of the injector
- All grease nipples are easily accessible
- Electrical or mechanical, Load Cell is positioned between the bottom of the injector and the
base frame.
- Hydraulic hoses on injector are routed to a common Bulkhead Injector head is mounted into a
separate Upper and Lower welded tubular support and protective framework.
- Removable mount for tubing stripper/packer in lower sub-frame weldment with all hydraulic
connections made through the injector bulkhead.
- The injector component design is made as accessible as possible with only high quality
materials used to ensure durability.
- Excess lubricant catch pan with drain fitting is installed in injector sub-frame with drain plug.
- All welded components are sandblasted, primed and painted in a single colour to customer
specifications.

Section 7: Guide Arch
- Forty-eight (48”) or Sixty-inch (60”) tubing guide arch assembly is complete with nylatron guide
arch rollers.
Alternate sizes of tubing guide arches are available.
- Guide Arch comes with 5 equal spaced hold down clamps for even tubing load.
- The guide arch hinges midway to reduce size for ease of transport.

Section 8: Hydraulic Hose Package
Injector Control Hoses :
- Complete with 65 ft. of hose (each hose) for injector operation from the Control Console.

Section 9: Fasi Knuckle Boom Crane
- Mounted near the rear of the truck chassis
- Total extension of crane = 13.3m
- Lifting capacity at 2.1m = 10,500kg
- Crane controls are mounted at rear of crane or at another location as designated by customer
- Outriggers are controlled and mounted at the rear of the truck

Section 10: Injection Pump – Model 3517 CAT Pump
- Small triplex injection pump for soap or chemicals
- Storage cabinet houses the triplex pump
- Maximum volume: 14 gpm
- Maximum discharge pressure: 3,000 psi
- Maximum speed: 800 rpm
- Crankcase capacity; 4.2 quarts
- Inlet ports; 1-1/2” NPT
- Discharge ports: 1” NPT
- Wetted seal port keeps high-pressure seals completely lubricated
- Lubricated low-pressure seal provides double protection against leakage
- 316 stainless steel valves, seats and springs

Section 11: Tank and Stand
- Stainless steel storage tank for soaps, chemicals or other agents is kept from freezing in winter
by heat from the engine water jacket. In addition a Proheat heater is tied into the engine water
jacket, it too may provide heat to the tanks.
- The triplex pump uses this storage tank to draw its supply for the injection of chemicals, soap,
etc. into the coil tubing.

Section 12: Cold Weather Package
- Diesel fired Proheat, coolant heater provides a dependable means of preheating or maintaining
heat in water-cooled engines and fluid circuits.
- The heater simply pumps coolant from the engine, increases the temperature of the fluid and
returns to the engine.
- Since the heater runs on diesel fuel and a 24-volt power source, it operates independently from
the vehicle engine.  A temperature regulating switch in the unit automatically cycles the heater
to maintain a temperature from 70 degrees C. to 85 degrees C.
- The heater is operated by a push-pull switch.  Thermostat and timer controlled heating elements
are positioned in the hydraulic tank and the soap tank.  This enables heat generated from the
heater/engine to keep these fluids warm during shutdown or travel to a well site

Section 13: BOP Control
The system proposed below is a hydraulic-over-hydraulic system and consists of the following
components :
- Nitrogen (N2) back-up activation switch, c/w lift-up arming feature
- Pressure reducing valve and gauge for variable pressure out to the auxiliary BOP
- There are two control panels, one at the rear of the unit and one at the front of the unit.

Section 14: Mounted Mid-Ship Of The Unit
- Two (2) 11-gallon accumulators
- Nitrogen storage bottle bracket (N2 bottle to be supplied by Customer)

Section 15: Hydraulic Tanks
There Are Two Hydraulic Tanks
- The Main Hydraulic Tank Contains 80 gallons.
- The BOP Hydraulic tank Contains 30gallons.

Section 16: Tool Boxes
There Are a Total Of Two Tool Boxes.
- The Tool Box Is Mounted On The Drivers Side Of The Unit.This Box Is Of Rugged Steel
Construction, c/w Two Doors That Open out Horizontally To Each Side.The Dimensions
are Height 40”, Width 30”,  Depth 20”.
- The Junk Box Is Mounted On The Passenger Side of The unit This Box Is Of Rugged Steel
Construction, c/w Two Doors That Open Vertically.The Dimensions Are Height 20”, Width 36”,
Depth 20”.

Section 17: Miscellaneous
- Two Methanol Tanks, (1) one for soap tank, (1) one for air lines.
- Steps on compressor drive belt and soap pump box and reel for ease of access.
- Check valves coming from Air Compressor, (1) one in-line popet type, (1) one flapper type.
- Numbered bulkhead connections on control panel and from Triplex Pump Box
- Pintle Hitche locks with releasing of air brakes.
- Sight glasses on tanks will be on front of all tanks for easy viewing and will have dial
temperature gauge build in.
- Valve to shift Pro-heat from engine and soap tank to hydraulic tank and compressor will be
mounted in triplex box. The engine coolant will then warm the soap tank.
- Rig Lights will be Halogen with 8 external and one for each toolbox and one for the control panel.
- Drum reversal to be mounted beside control panel for easy access. Hub odometer will be
mounted on truck.

- Headache rack mounted on compressor to protect compressor and cab.
- Toolboxes will extend down to lowest point on truck for maximum space.
- 6’ Air Hose quick connection at back of truck and in truck cab.
- Brake lockout valve for front chain and back chain of injector to be mounted on control panel.
- Inside of toolboxes to be painted white.
- Top of toolboxes will mount flush with top of deck with grip material to provide a non-slip surface.
- Hose bundles to injector head to be wrapped in nylon fire hose, or suitable material that meets
customer approval.

- Aluminum checker plate to be used unit in centre of unit to reduce weight.
- The seller will do supply and Mounting of Fabco Power Transfer Case.
- Modify front bumper for tire chain holders.
- Rear hose bundle box to be constructed with a steel frame and aluminum bar grate sides and
bottom to reduce weight.

Section 18 – Documentation and General
- Four (4) sets of electronic manuals to be supplied with each unit
- Operational temperature range: -40 to +40 Degrees C.
- All components supplied by the seller will be NEW and UNUSED.
- All components painted to customer specifications – single color scheme.
- Mounting of all components is included in stated pricing.
- All equipment will be tested and fully operational prior to final shipment.
- Inspections at the seller’s plant are welcomed at the convenience of the purchaser.
- Purchaser will be responsible for travel, food and lodging costs during inspection.

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
------------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
New Coiled Tubing Unit for Sale
Coiled Tubing Unit - 25K
New 25K CT Rig for Sale
CT Rig for Sale
25K coiled tubing unit for sale
Rig for sale - New 25K Coiled Tubing Unit
------------------------------------------------------------------------------------------------------------------------------------

Marine Gensets for Sale
Cat 3516 B Containerized units 690V, 60 Hz set
Diesel Generator Sets

Cat 3516 B containerized units 690V, 60 Hz set – 5 units available

2.1 Diesel Generator Sets
2.1.1 7 off  690 Volt Pon Cat Diesel – Hyundai Generator skids, Containerised equipped with
ventilation insulation and exhaust for supply of power.

2.2  Main Generator Diesel Skid
- Seven (7) containers of A-0 in walls and roof to be delivered for 7 Diesel engine and
generator skids for supply of El. Power 2300 kVA, 690 V, 60 Hz.
Free access distance between engine/generator and container walls to be preferable
600mm. Each container shall have two A-0 sliding doors. One door installed on
each side of the container. When the containers are placed alongside each other, the
sliding doors to meet for entering from one container to the next one. The doors are not
to protrude outside the container.
- Each container has a ventilation system with registers in and out.
- The containers are arranged as separate engine rooms with fuel system, external top-mounted
exhaust system, lube oil system, cooling water system based on air cooled radiator system with
internal radiators, starting system, bilge system, light, fire fighting system, instrument, alarms and
automatic start/stop system according to class requirement. Brackets for installation of fire/flame
detectors to be installed.
- Lifting eyes for chain blocks are installed above all diesel engines in container for maintenance
work such as lifting in/out pistons or cylinder liners.

2.3 Main Generator Diesel Engines A standard built-on factory supplied fresh water cooling
system based on air cooled radiator system with fresh water pump, radiator (in machinery space)
with electrical driven cooling fans, electrical water heater with circulation pump. (and flexible pipe
connections to engine.) A standard built-on factory supplied fuel system with fuel injection pump,
fuel feed pump, primary fuel filter duplex element-filter with water separator, secondary fuel
filter, double walled high pressure fuel lines, flexible fuel connections, Woodward ProAct II
actuator mounted on engine, Woodward 2301 D ( or similar ) electronic governor. The fuel oil
system includes: Internal separate A60 insulated fuel tank in each container for 8 hours running
at 100% load. Internal A60 insulated fuel tank for 18 hours running at 100% load installed in
the emergency diesel generator container. A standard built-on factory supplied lube oil system
consisting of direct driven lube oil pump, duplex lube oil filter, bypass lube oil filter, lube
oil cooler, electrical lube oil priming pump, also prepared to drain the oil- sump, starter
cabinets. A standard built-on factory supplied dry exhaust gas system equipped with air
inlet filters, turbocharger, charging air cooler, insulated exhaust-manifold, flexible expansion
joints, and exhaust silencer 35 dBA with spark arrestors. Combustion air intake is arranged
outside. Turning motor or turning gear with handle. Flexible high elastic coupling fitted to
engine flywheel and generator shaft The power stated is valid for conditions in accordance
with ISO 3046/1 Lifting eyes for transport and installation.

A standard built-in on factory supplied starting system consisting of electrical starting
motors, charging rectifier, starting batteries in battery boxes – separate starting system
for each engine. The diesel engines have a starting battery capacity for a minimum of
3 starts of each engine. The emergency generator has a minimum starting battery capacity
for a minimum of 6 automatic starting attempts and 3 manual starting attempts. Instrument,
Alarms and Automatic Start/Stop System

2.4 Main Generator Diesel Control panel
Alarm sensor for: - Low lube oil pressure - High lube oil temperature - High diff. Pressure over
lube oil filter - High water temperature - Low cooling water flow - Fuel leaks in double walled
fuel lines - Low cooling water level in expansion tank - Charging air pressure - High exhaust
gas temperature after turbocharger

Auto-stop device for: - Low lube oil pressure - High water temperature - Overspeed
Automatic start and shut down system with following functions: - LCD display showing
voltage, rpm, oil pressure and temperature, water temperature, Charge air pressure and
exhaust temperature after turbo - Automatic start attempts according to class
requirement. - Automatic shutdown for low oil pressure, high water temperature and
overspeed - Start switch - Stop switch - Hour meter - Converter for serial
communication - Common alarm and shutdown alarm - Stop System - 24 V stop
solenoid valve. The control system includes interface prepared for a dynamic position
keeping system and a power management system arranged according to
Lloyds Rules & Regulations.

2.5 Additional Information
Diesel Oil The diesel engine complies with conditions in accordance with ISO 3046/l
Lubricating oil Lubricating oil shall comply with the diesel engine manufacturer’s
recommendation. Viscosity class SAE 40 (ISO VG 150) Content of additives should
meet the requirements of MIL-L-2104 C or API Service CD. Turbocharger The oil may
be mineral oil or synthetic oil having a viscosity of 30-55 cSt/50deg.C. The technical
specification for the Diesel engines is as follows:
Output particulars 7 Engines : Engine output  Min 1920 kW   Output speed : 1.800 RPM
2.5 Main Generators  All the generators are supplied with: - - Automatic voltage
regulator - Equipment for parallel operation - Anti condense heater - PT-100 temperature
sensors in windings - PT-100 temperature sensors in bearings - MCT Brattberg cable
entry in container. - Termination box for power cables. - Foundations.

Price & terms : Please enquire using the email form below.

 If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-------------------------------------------------------------------------------------------------------------------
Search words(for official use only) :
Diesel Generator Sets for Sale
Containerized Marine Gensets for Sale
5 Marine Gensets for Sale
Containerized 5 Generator Units for Sale
Cat 3516B Marine Gensets Containerized
------------------------------------------------------------------------------------------------------------------

Pipelaying barge For sale
292 Men Pipelaying Diving Maintenance Accommodation Barge
112M Pipelaying barge For sale
Pipelaying Accommodation Barge for Sale
2008 built Pipelaying barge For sale
Pipelay Capability for 200 mm – 1500 mm Pipe

Principal particulars
Class : ABS +A1 unrestricted service with MODU code attestation
Built : 2008
Gross Tonnage : 13,575 T
Nett Tonnage : 4,072
Dead Weight 10,233 T

Dimensions
Length overall : 111.63 m
Breadth moulded : 31.7 m
Depth : 9 m
Designed Draught : 4.8 m

Pipelaying facilities
Pipelay Equipment
Pipelay capability for 200 mm to 1500 mm
90 ton pipe lay tensioner capacity (30 m/min)
100 ton pipe lay abandonment / recovery winch
Automatic tensioner transfer system
Pipelay conveyor and transfer system rated to 32 ton

7 welding stations with semi-automatic welding system (STT & flux core)
1 NDT station
2 field joint stations
Dark Room
Stinger/Ramp
3 degree sloping production firing line
34 m outrigger stinger adaptable to different project requirements

Diving capability
In-built moon-pool (5.5 m x 5.5 m)
Support services for modular saturation diving spread
8 POINT MOORING SYSTEM
8 x single drum 90 ton mooring winches
c/w tensional sensor, wire length counter
8 fairleads, with 1500m of 52mm wire rope.
9 x 10 ton Delta Flipper anchors9 x Pennant Buoys

Helideck
Size : 22 x 22 m for Sikorsky S61

Safety systems
Mass Evacuation Slide and Raft System
Life rafts to 590 person capacity
600 life jackets/12 life rings
1 x fast rescue boat
Active high specification smoke and fire monitoring and extinguisher
system in all accommodation, engine, winch, paint and boiler rooms
Sprinkler system
Machinery guarding systems
Dedicated boat landing transfer points

Environmental
Sewage treatment system meeting MARPOL standards
Spill prevention systems

Other facilities
Hospital with 2 beads
Well equipped galley
Mess room with seating for 180 people
Large cinema, TV room for 110 people
Recreational Room for 60 people seating

Internet and email room
Well equipped gym
Laundry and large food storage facilities
5 Specialist Personnel Office rooms
2 Client office rooms
3 General office rooms
2 Control rooms with CCTV and metering

Navigation /Radio Control room with helicopter coms
Conference room for 25 people
Prayer room
Paramedic room
Change room with lockers and wash facilities
Work shop with Lathe, Drill press plus other tooling
2 water makers of 40 ton per day capacity

Machinery
Generators : 5 x Mitsubishi 1200 kva 60 cycle.
Emergency Generator : 1 x Diesel Caterpiller 500 kva 60 cycle.

Tank capacities
Fuel Oil : 2211 m3
Potable Water : 1926 m3
Grey Water 23 m3
Black Water 23 m3
Bilge 23 m3
Dirty Oil 27 m3
Cooling Water 750 m3

Pumps
Fire/General Service : 2 x 130 m 3 hr 80 m head
Fuel Oil : 2 x  20 m3 hr 30 m head
Ballast Water : 2 x 300 m3 hr 30 m head
Potable Water : 1 x 120 m3 hr 35 m head
Domestic F Water : 1 x 30 m3 hr 35 m head
Domestic S Water : 1 x 30 m3 hr 35 m head
Emergency Fire : 1 x 50 m3 55 m head

Deck area
Clear deck area over 2000 m2,
Deck Strength 12.5 t/m2 rating
Carriage Capacity over 11,000 tons
Provision on deck for suitable crawler crane

Accommodation
High Standard of Accommodation
Tank Top Cabins 30 x 2 = 60
Tween Deck Cabins 30 x 2 = 60
Deck 1 Cabins 24 x 2 = 48
Main Deck 1 x 2 = 2
Deck 2 Cabins 32 x 2 = 64
Deck 3 Cabins 28 x 2 = 56
Additional Deck 3 Cabins 2 x 1 = 2
Total Berths 292
Cabins with en-suites and fully air conditioned

Price & terms : Please enquire using the email form below

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Pipelaying barge For sale
112M Pipelaying Barge For sale
Pipelaying Diving Maintenance Accommodation Vessel
292 Men Pipelaying Diving Maintenance Accommodation Barge For Sale
2008 built Pipelaying barge For sale
Pipelaying accommodation Barge for Sale
Diving Accommodation Vessel with Pipelaying
------------------------------------------------------------------------------------------------------------------------------------------

Landing Craft for sale
69M LCT for sale
LCT type Cargo/RORO Ship
1981 built LCT type Cargo/RORO Ship for sale

Built : 1981
Class : KST
GRT : 576t
DWT : 1,071t

LOA / LBP : 68.57m / 54.43m
Beam/Depth/Draft :  13.5m / 3.5m / 2.8m
Pax / Crew : 13 persons / 6 persons
Engine : 3 X Mitsubishi DS6R2-MTK2 950PS/1400rpm

Speed : Max. 14kts / Ser. 10~11kts
Fuel Cons. : Bunker A/65L pr hour each engine (total 195L per hour)
A/E : 2 X Daewoo AD136t

F.O.T : 30,000ltrs
F.W.T : 30 tons
Car Capa : 45 cars or 5 ton X 22 trucks
Crane: 1 X 10 ton
Cargo hold : 4( 2 in port side / 2 in stb'd side ) Capa : 670cbm
Vertical clearance : 4.5m

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------------------------
Search words(for offcial use only) -
Landing Craft for sale
69M LCT for sale
LCT type Cargo/RORO Ship for sale
1981 built Landing Craft for Sale
-----------------------------------------------------------------------------------------------------------------------------

Aluminium Crewboats for Sale
14M Waterjets Aluminium Fast Crewboats
2006 built Waterjets Aluminium Fast Crewboats for sale
Used Aluminium Crewboats For Sale

General
4 Units  -  14mtrs Waterjets Aluminium Fast Crewboats
Year built : 2006
Speed : 30knots max.
24 Passengers
Main engines : 2 x 315hp Cummins USA 2005/2006 Turbo Marine Diesel 6BTA 5.9 litres 6 cylinder
Fuel consumption : 56 litres/hour
Inspection : Indonesia

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------------------------------------------------------------
Search words(for official use only) :
Aluminium Fast Crewboats in Indonesia
Used Aluminium Crewboats For Sale
14M Waterjets Aluminium Fast Crewboats
Aluminium Crewboats in Singapore
2006 built Fast Aluminium Crewboats for Sale
----------------------------------------------------------------------------------------------------------------------------

Accommodation Barge for Time Charter

Principal Particulars :
Classification : ABS & KR
Year Built  : 2009
Length Overall  : 110.57m
Breadth : 31.70m
Depth Mould : 7.30m
Summer Load Draft : 5.0m
Lightship Weight Draft : 1.80m

At Summer Load Draft :
Displacement : 17373.18 Tons
Dead Weight : 11344.69 Tons
Lightship Weight : 6017.49 Tons
Main Deck Strength : 15 Tons/m2
Net Tonnage : 3363 Tons
Gross Tonnage : 11210 Tons

Deck Equipment :
8-point Anchor : 8 Single drum
Mooring Winches : electro-hydraulic winches
Drum Capacity :
(1500m x 52mmø IWRC)
Wire c/w load monitoring
System and 8 sets of CCTV
Mooring Wire : 8 x 1500m x 52mmø IWRC
Mooring Anchors : Flipper Delta Anchors  ( 9 x 8,000 kg)

Crane :
250T, Crawler Crane
Boom Length 65m
(Charterer Option)

Machinery :
Generator :
4 units CAT3412/500Kw,@1500rpm
Heat-Exchanger Cool, Batter Start
Emergency G/E :
1 unit Cummins/136Kw,@1500rpm
Air Cool, Battery Start
Portable G/E : 1 unit SINFON/50Kw,@1500rpm
Air Compressors : 2 x 80 m3/hr @10 bar

Capacities :
Fuel Oil : 1500 m3 approx
Fresh Water : 1400 m3 approx
Sea Water Ballast : 7500 m3 approx
Sewage : 125 m3 approx
Bilge Holding Tank : 70 m3 approx
Dirty Oil Tank : 52 m3 approx
Settle Tank : 48 m3 approx
F.O Daily Tank : 48 m3 approx

Accomodation :
Single Berth : 10 x 1 Berth
Double Berth : 14 x 2 Berth
Four Men Berth : 83 x 4 Berth
Total : 370 Berth

Discharge Rates :
Fire Water Transfer : 2 x 160 m3/hr @ 100m head
G.S Transfer : 1 x 130 m3/hr @ 80m head
Em’cy Fire : 1 x 100 m3/hr @ 65m head
Ballast Water : 2 x 500 m3/hr @ 40m head (Centrifugal)
F.W Transfer : 2 x 30 m3/hr
F.O Transfer :
1 x 10 m3/hr
 1 x 45 m3/hr

Radio & Navigation Equipment :
2 x SSB Radio : 2 x VHF Radio Telephone
1 x MF/HF Radio Sys’ : 2 x Inmarsat Mini M System
1 x Inmarsat C Sys’ : 1 x Navtex Receiver
1 x GPS   : 3 x VHF Handby Talky
1 x Radar 24 n/miles : With Battery Charger
1 x Weather Fax  : 1 x Wind Speed Indicator

Other Facilities :
Hospital : 1 x 3 Bed, Locker, Toilets
Galley : 1 Cooking, Utensils, Refrigerator etc.
Medic Room : 1 on Main Deck
Radio & Control Room : 1 x Radio Equipment on Roof Top
Site Manager Room : 1 on Main Deck
Office : 5 on Deck -3, 6 on Deck -4, and 3 on Roof Top
Mess Room : Upto 180 person
Conference Room : 1 on Deck -3, & 1 on Roof Top

Fire Fighting & Survivial Equipment :

Fire Monitors :
2 Units for Helideck
2 Units for Deck 3
Fire Hose Station : 19 x 50mmø 15m Fire Hose / Nozzle
Portable Fire : 4 x 6.7 Kg CO2

Extinguishers :
2 x 22.5kg Dry Powder
27 x 4.5kg Dry Powder
8 x 2.25kg Dry Powder
3 x 1kg Dry Powder
3 x 9 L Foam Applicator

CO2 System : Machine Room, Winch, Power Pack Room, Paint Store, Deisel Engine

Fire Alarm / Central :
1 Central  Panel
 32 Manual Call Points
Life Rafts : 46 x 25 men on each side of Barge
Life Jackets : 200% coverage of the total maximum Onboard
Ring Buoys : 10 Lifebuoy over 27.5m
Rescue Boat : 1 x 6 Persons rigid Rescue Boat with Davit

Other Facilities :
Sewage Treat  :
1 x 370 men  Capacity
Vacuum Unit
Recreation Treat  : 1 on Deck – 4
Cinema Room : 2 on Deck – 4 (Smoking / Non-smoking)
Water Maker : 2 x 80 tons/day
Workshop : 1 x Workshop (15m x 40m)
Gymnasium : 1 on Deck – 5
Forklift  : 1 x 3 tons
Helideck  : Sikorsky  S – 61N

Fixed auto water sprinkler system for whole Accomodation
Fixed  Auto smoke detection sys’ for whole Accomodation

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------------------------------------------
Search words -
Barge for Time Charter
2009 Built Accommodation Barge
Accommodation Barge for Time Charter
Accommodation Barge 2009 Built for Time Charter
--------------------------------------------------------------------------------------------------------------------------

Jackup Drilling Rig For Sale
F&G L-780 Mod. 0 Jackup Rig For Sale
F&G Jackup Drilling Rig For Sale

Specifications

Rig Type : Jackup
Rig Design : F&G L-780 Mod. 0
Year Built : 1981
Upgrade : 2003
Class : ABS
Water Depth - Ft : 300
Drilling Depth - Ft : 11,000 (upgradable to 17,000
with Cantilever load limitations)

Quarters : 100
Dimensions : 180' x 175' x 25'
Helideck : 73' diameter for Sikorsky S-61 - CAP-437 compliant
Variable Deckload - Operating : 4,486 kips
Variable Deckload - Transit : 3,403 kips
Number of Legs : 3
Leg Length : 406' 8"
Usable Leg Below Hull : 356'

Spud Can Diameter : 39.5'
Cantilever Reach : 40'
Transverse Movement : 10' port or starboard of centerline
Max Combined Structure Load : 1,000 kips
Bulk Mud & Cement : 9,600 cu ft
Liquid Mud : 1,713 bbls
Fuel Oil : 2,359 bbls
Drill Water : 5,600 bbls

Potable Water : 1,041 bbls
Sack Storage : 3,000 sacks
Drawworks : National 1320 UE w/1-3/8" drill line
Derrick : Pyramid 30' x 30' x 157', 1,044
million lb. hook load capacity

Top Drive : Varco TDS-4 w/- PH-85 pipe handler
Pipe Handling System : Varco ST-80 Iron Roughneck
Rotary : Oilwell C-375, 37-1/2 inch
Top of Rotary Table to Bottom of Barge : 56 ft.
Mud Pumps : (2) National 12-P-160
Main Engines : (5) Caterpillar D-399
Annular BOP : (1) Hydril 29-1/2" 500 psi; (1) Hydril 21-1/4" 2K
Ram BOP : (1) 21-1/4" Cameron double 2K; (2)
13-5/8 Cameron Type U (doubles )10K

Diverter : Hydril MSP 29-1/2"
Solids Control : (4) MI Swaco BEM 650 Shale Shakers
Cranes : (2) 2 Seatrax S7216, w/110' boom and 110' boom
Mooring System : (4) 1-1/4" x 2,500' EIPS wire, Baldt
10,000lb LWT anchors

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need, please send us an
email to mail@worldoils.com stating your requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
----------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) :
Used Jackup Drilling Rig For Sale
F&G L-780 Mod. Offshore Jackup Rig For Sale
Oil & Gas Jackup Drilling Rig For Sale
F&G Jackup Rigs for Sale
Used Offshore Drilling Jackup Rigs For Sale
--------------------------------------------------------------------------------------------------------------------------------

Wire Rope and Umbilical Spooling Units for Lease
Umbilical Spooling Unit for Hire
200 KIP Spooling Unit for Lease Wire Rope Spooling Unit for
Charter Spooling Unit for Hire - 52,000 lbs

Specifications
Spooling Unit : 52,000 lbs
Hydraulic Power Unit (HPU) : 8,500 lbs
Spool Flange Diameter : 223 in
Spool Width : 117 in
Shaft Diameter :
6 in
12 in

Approx. Air Required :
100 psi
375 cfm

Water : 80 GPM for heat exchanger
Male Camp Lock : 2 in
Female Camp Lock : 2 in
Input and Discharge Hose : 50 ft

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------
Search words(for official use only) -
Wire Rope and Umbilical Spooling Units for Lease
Umbilical Spooling Units
52,000 lbs Spooling Unit for Hire
200 KIP Spooling Unit
-----------------------------------------------------------------------------------------------

Lattice Boom Offshore Crane for sale
300 ton Offshore Lattice Boom Crane
New Offshore Crane for Sale

Newbuildings - Can be delivered in 8 months

General Specification
Slewing Angle : 360º(Continus)
Slewing Speed(Full Load) : 0~0.3rpm
Luffing Time(Full Load) : 360s Up/down
Luffing Angle : +15° ~ +82.5°
Parking Angle : -6° ~ +15°
Operator Cabin : Left Side

Main Winch Data
Lifting Capacity(SWL) : See Loading Chart;
No. Of Fall : 12 Falls for 300T ; 6 falls for 145T
Working Radius : 11.2m(Min) / 57m(Max)
Main Lifting Speed(0-125T) : 3m/min for 300T ; 6m/min for 145T
Hook Travel : 63m

Aux Winch Data
Lifting Capacity(SWL) : 30T@62m, Man Riding :1.5T
No. Of Fall : 1
Working Radius : 13.4m(Min) / 62m(Max)
Main Lifting Speed(Full Loading) : 0~25m/min
Lifting Height : 68m

Note :
All operational speeds stated above are based on average volumetric efficiencies provided by
our suppliers of hydraulic components. A speed variation tolerance of +10% to -5% is within
the accepted range and should be taken into consideration.

Hydraulic Arrangement

Hydraulic Systems
The hydraulic transmission will be designed for optimum performance within the constraint of
available horsepower. High pressure hydraulic system uses power more efficiently and applies
power as needed.

All motions controls offer infinitely variable speed and full reversing characteristics. Two full flow
filters will be installed. The filter(s) will be adequately sized for full flow operation without causing
pump cavitation. Replaceable wire mesh filter cartridge of minimum absolute value of 40 micron
will be used. The pumps will have overflow suction independent of the reservoir, and the
arrangement of piping can avoid air pockets.

Hoisting Circuit
Each winch is driven by a common open loop hydraulic system including piston pump, piston
motor and epicycles gearbox. Each winch is fitted with oil immersed, multi-disc and dynamically
rated “fail safe” brake.

The fixed displacement hoist motors offer a constant operating speed.

Slewing Circuit
The slew circuit is driven by a common open loop hydraulic system. Dynamic braking of slewing
is by means of hydrostatic compensation. Similarly positive locking brakes are fitted in the circuit
and used as static brake

Luffing Circuit
Luff circuit is driven by a common open loop hydraulic system. Each winch is fitted with oil
immersed, multi-disc, dynamically rated “fail safe” brake. An additional luff ratchet cylinder is
included, providing a positive means of locking the luff drum whenever the prime mover is
shutdown.

Hydraulic Piping
1. Pipes: No pipe threads will be used for the high-pressure lines larger than 3/8". Hydraulic
components that have pipe threaded ports lines will have a minimum working pressure 300PS. .
2. Pipe fittings: Zinc plated mild steel material. External fittings are painted and protected by
Denso tape or equivalent against corrosion.
3. Hoses: High rubber quality for best resistance against sunlight and salinity, Wire breaded
for applicable specified hydraulic pressure ratings
4. Hose couplings: Zinc plated mild steel material, External couplings are painted and
protected by Denso tape or equivalent against corrosion.

Hydraulic Oil Tank
1. Level gauge with isolating valve (to top cover)
2. Inspection and cleaning cover
3. Filter with fine mesh stainless steel strainer and ventilation
4. A relief valve will be installed in the discharge line of pump.

Cooling Circuit
The air-oil heat exchanger will be provided and sized to ensure continuous operation of
the crane under the ambient temperatures given on the data sheets.

Electric Arrangement
Standards, Codes and Protection
Refer to Codes Of Practice and Standards. The electrical systems onboard the crane
complies with these standards for good offshore electrical design and engineering practices.

Standard Lighting
The following are provided as standard lighting packages for the crane. More lights can be
added according to client's request.

Description : Aviation Warning Light
Qty : 1
Size : 85 W
Location : Boom Tip
Power Supply : UPS

Description : Aviation Warning Light
Qty : 1
Size : 85 W
Location : Mast
Power Supply : UPS

Description : Florescent Access Light (with 90 min back-up battery)
Qty : 2
Size : 2 x 36 W
Location : Access Way Outside Cabin
Power Supply : Main

Description : Florescent Access Light
Qty : 2
Size : 2 x 36 W
Location : Machinery House
Power Supply : Main

Description : Florescent Access Light (with 90 min back-up battery)
Qty : 1
Size : 2 x 18 W
Location : Cabin
Power Supply : Main

Description : Florescent Access Light
Qty : 1
Size : 2 x 18 W
Location : Slew Well
Power Supply : Main

Description : High Pressure Sodium Floodlight
Qty : *
Size : 400 W
Location : Boom
Power Supply : Main

Power Supply
Main Power Supply : 415 VAC , 03 Phase , 50Hz
Uninterrupted Power Supply : 230 VAC , 01 Phase , 50Hz

Others
Junction box(es) is provided at the pedestal interface for connection to client supply.
By default only SS316 junction boxes are installed onboard.

Generally cable wires will be multi-stranded copper and protected against mechanical
damage. All power and control cables are with XLPE/EVA/GSWB/EVA construction.
Occasionally able of XLPE/EVA/CWB/EVA is used when big power cable is part of the
design. All electrical lines are tagged accordingly for ease of maintenance.

All outdoor equipments and instruments are Ingress Protected IP56. Indoor equipments
and instruments are rated with IP44 as minimum.

Ordinarily, the power supply for crane is transmitted from pedestal to slewing platform
through the centre slip ring to ensure the crane can work at any angle.

Controls and Instruments
Cabin :
The following instruments are arranged on the console to permit the operator to maintain an
uninterrupted view of the loads and instrumentation. The two(2) motion controls joysticks
designed according to API-2C, are ergonomically correct and easy to handle. All instruments
are clearly labeled.

1. Motion Control Joysticks:
2. “Dead-Man” Type
- Position sensitive with motion and speed infinitely variable and proportional to movement
from spring-return central position.
- Luff and slew (single left) joystick
- Main and auxiliary hoist (single right) joystick
- Prime Mover Start/Stop Switch
- Prime Mover Emergency Shutdown Switch
- Slew Brake Control Lever for option
- Safe Load Indicator System
- Visual and Audible Annunciator Panel
- Boom Hoist Down Override Switch
- Pressure Gauges: Boast Control / Hoist / Slew / Luff
- Electrical Switches:
- Lighting
- Windshield Wipers & Washer
- Warning Horn
- Air Conditioning
- Main and Auxiliary Hoist selector
- Tachometer

Hoist Mechanisms
Hoist Winch Data
Feature : Hoist Drum
Description - Material, Details : Cast Steel, Remark : 100% NDT
Description : Groove, Remark : Reeving not over 3 layers
Description : Support End, Details : Anti-friction Bearing

Feature : Braking
Description : Type
Details : 1x Band Brake, Remark : Asbestos free lining, for man riding winch only
Details : 1x Multi-disc Brake, Remark : Positive Locking
Details : 1x Load valve, Remark : As dynamic Brake

Description : Safety Factor
Details : Minimum 2.0

Feature : Rope Anchors
Description : Type, Details : Bolted rope clamp, Remarks : For ease of rope replacement
Description : Safety Factor, Details : Minimum 1.1,
Remarks : Ensures rope breaking strength when over loaded

Feature : Ratios
Description : Drum to Rope
Details : Min.19 : 1
Remark : Drum pitch diameter over rope diameter

Feature : Safety
Description : Drum flange beyond top layer,
Details : 2.5 x rope diameter,
Remark : To avoid rope jumping out of drum unintentionally

Description : Fleet angle
Details : < 2.5⁰
Remark : Ensures smooth and even rope spooling at all times

Description : Dead turns on the drum
Details : Min.5
Remark : Amount of rope that is not in used even at the maximum hoist reach of the crane

Luffing System
Feature : Hoist Drum
Description - Material, Details : Cast Steel, Remark : 100% NDT
Description : Groove, Remark : Reeving not over 3 layers
Description : Support End, Details : Anti-friction Bearing

Feature : Braking
Description : Type
Details : 1x Load Brake, Remark : As dynamic Brake
Details : 1x Multi-disc Brake, Remark : Positive Locking
Details : Ratchet and pawl, Remark : Luffing locking device

Description : Safety Factor
Details : Minimum 2.0

Feature : Rope Anchors
Description : Type, Details : Bolted rope clamp,
Remarks : For ease of rope replacement
Description : Safety Factor, Details : Minimum 1.1,
Remarks : Ensures rope breaking strength when over loaded

Feature : Ratios
Description : Drum to Rope
Details : Min.19 : 1
Remark : Drum pitch diameter over rope diameter

Feature : Safety
Description : Drum flange beyond top layer,
Details : 2.5 x rope diameter,
Remark : To avoid rope jumping out of drum unintentionally

Description : Fleet angle
Details : < 2.5⁰
Remark : Ensures smooth and even rope spooling at all times

Description : Dead turns on the drum
Details : Min.5
Remark : Amount of rope that is not in used even at the maximum
hoist reach of the crane

Boom Luffing-in limit buffer
Anti-backward limit is used to prevent the boom over luffing in order to protect boom.

Mast
The Luffing sheaves are placed on the mast (A-frame) which is fitted with a top platform
for maintenance and inspection of the mast head sheaves, luff hoist rope and anchor
connections. Access to the Top Platform is by ladder from the machinery deck. The
mast is pin connected to the machinery deck.

Bridle
N/A

Slew Mechanisms
Slew Bearing
Brand - ROTHE-ERDE XUZHOU or equivalent
Rolling Element - Triple Cylindrical Roller
Lubrication
- Grease holes in diagonal orientation in outer ring
- Lubrication lines are fitted on the machinery deck for refilling grease into the bearing

Slew Drive
Type - Fixed displacement hydraulic motor
Gearbox - Epicyclical
Brake - Oil immersed multi-disc brake(s)
Operating Conditions - Slew design wind speed 24m/s
Pinions - Four(4)
Emergency slewing is possible with one (1) pinion

Boom
Length - 45M & 47M
Type - Reinforced Lattice Structure
Pins - High Tensile
Connectors - Cast Steel
Welding Test - NDT 100% MPI, 100% UT/RT
Boom Top Platform - Both Sides
Safety
Hardwood blocks - To prevent rubbing of ropes on boom bracing damaging paint and
cause unnecessary rusting.
Walkway paths - 760mm wide grating along and inside of boom for maintenance access
Handrails - Along boom section

Boom Bottom
Type - Reinforced Lattice Structure
Material - High tensile low alloy low carbon seamless chords with mild steel bracings

Boom Intermediate Section
Type - Reinforced Lattice Structure
Material - High tensile low alloy low carbon seamless chords
with mild steel bracings.

Boom Head
Type - Reinforced Lattice Structure
Material
- High tensile low alloy low carbon seamless chords
- With Mild Steel Bracings
- High Strength Steel Head Plate

Reeving System
Sheaves
Materials - Steel
Processing Technique - Cast
Ratio - 20 : 1 (Sheave diameter / Rope diameter)
Lubrication - Lubrication through sheave pin
Bearing - Heavy duty sealed cylindrical roller

Ropes
Rope Size (mm)
Design Factor -
Main Hoist and Auxiliary Host : Minimum 5.0
Luff Hoist and Pendant : Minimum 4.0

Rotation Characteristic -
Main Hoist and Auxiliary Host : Non.Rotating
Luff Hoist : Low Rotation
Pendant : Non-Rotating

Construction -
Main Hoist and Auxiliary Host :  RH and WSC
Luff Hoist : RH and IWRC
Pendant : WSC

End Connections -
Main Hoist, Auxiliary Host, Luff Hoist and Pendant :
Solid Thimble

Finishing -
Main Hoist, Auxiliary Host, Luff Hoist and Pendant :
Compacted and Galvanized

Hooks
Basic design factor of the hook is more than 4.0. The hooks are made of cast
steel and tested to -40°C, or -6°C below lowest design temperature. All hooks
come with lockable safety latch and swivel bearings. Hook blocks will be of
significant weight to prevent unraveling of rope while unloaded.

Machinery Deck
Machinery Turret
The Turret is made of high strength steel.  Depending on crane model and
configuration,  most mechanical and control components such as the
Power Pack,  Cabin and Winches are placed on the Turret for best
operational efficiency. Kicker  plates are installed for safety as well
as handrails around the Turret.

Operator Cabin
Structure - 5 mm steel plate
Floor Area - 1685mm x 1300mm
Position - Port of crane
Acoustic Shield - Noise level during operation ≤ 75 dBA
Weather Shield - Complete sealed through for water runoff

Visionary
Forward Windows - Clear Safety Glass
Side Windows - Clear Safety Glass; open-able
Rear View Mirror - N/A

Safety Equipment
Safety Bar - Front & side windows to prevent accidental fall
Horn - Electric warning horn
Fire Extinguisher - 1.5kg Dry Powder

Accessibility
Headroom - 2.1 meters
Door - Side slip door with lock
Maintenance
- Removable panels for access to cables & hoses
- Rooftop access for air conditioner maintenance
- Side access to front of cabin for window clearing and wiper replacement

Other Accessories
Chair - Fully adjustable cushioned type
Hour Meter - Digital / Analog
Communication -
Equipment (PA Speakers Telephone set, VHF/UHF radios and lound speaker with
microphone system) free issue by shipyard.
Control Console - See Controls and Instruments
Power - Power socket
Lighting - See electrical system
Windshield Wiper - Electrical type
Air Conditioning - Roof top unit
Engraved Stainless Steel Plate
- Design certified load chart
Rope specification chart
- API monogram

Prime Movers
Prime Mover Information
Prime Mover Data – Diesel Engine
Brand : Caterpillar
Model : C3412
Rating : 450KW @ 1800RPM

Starting System -
Primary - Electric : Attempts x seconds
Secondary : Attempts x seconds

Drive Output : Splitter Gearbox
Consumables -
Fuel Grade : ASTM D975 No.2-D Diesel fuel or equivalent
Coolant : ASTM D4985 or equivalent
Lubrication : API CG-4 oils or equivalent

Prime Mover Sizing
The prime mover is appropriately sized for the following conditions:
1 operation @ full load with full speed

Safety Features
Cabin
An annunciator is mounted in the cabin to alert the operator of possible risky
crane operation to avoid unfavorable incidents. This will be a solid state unit “first out” alarm
sequence giving both audible and visual warning and fitting with test and acknowledgement buttons.

The audible and visual alarming signals are provided as following :

- High Return Pressure(filter jammed)
- Hoist Up Limit
- Hoist Down Limit
- Luff Up Limit
- Luff Down Limit with override for stowing
- Engine Overspeed
- Engine Water High Temperature
- Engine Lube Oil Low Pressure
- Engine Fuel Low Pressure
- Hydraulic Temperature High
- Hydraulic low level

Powerpack
The following are provided at the power pack for status monitoring:
- Engine Lube Oil Pressure Gauge - Engine Lube Oil Temperature Gauge
- Engine Fuel Pressure Gauge - Engine Water Temperature Gauge
- Engine Tachometer - Engine Emergency Stop Button
- Fuel Tank Level Switch - Hydraulic Oil Level Gauge
- Hydraulic Pump Cavitations - Hydraulic Pump Filter Indicator

Crane Operation Limit
Limit switches are provided to define safe working limits of all crane operations
including hoisting and luffing.

The functions of the limit switches are :
Operation : Main/Aux. Hoist
Detective Level : Upper Working Limit
Action : Stop Up Motion
Deactivation : Hoist Down

Detective Level : Lower Working Limit
Action : Stop Down Motion
Deactivation : Hoist Up

Operation : Boom Hoist
Detective Level : Lower Working Limit
Action : Stop Boom Down Motion
Deactivation : Boom Up or Override for Stowing

Detective Level : Upper Working Limit
Action : Stop Boom Up Motion and A&V warning
Deactivation : Boom Down

Detective Level : Ultimate Up Limit
Action : Stop Boom Up Motion and A&V warning continued
Deactivation : Boom Down

Luff-in decelerator and stop in limit is controlled by the incoming boom and provides gradual
deceleration until minimum radius. Operation shutdown occurs and luff brakes automatically
engage overriding the manual control in the operator cabin.

Safe Load Indicator
The Safe Load Indicator will provide the following to the operator:

- Crane rated capacity (T)
- Actual load on hooks (T)
- Boom radius (meters)
- Boom angle (Deg rees)
- Visual alarm at 90% SWL
- Intermittent horn at 100% SWL
- Loud continuous horn at 105% SWL
- Overload cut off switch
- Mechanical boom angle installed at the boom where visible from operator cabin

Standard Practises
In line with West Marine mission to deliver good service and quality to the customers,
here are some of the standard practices adopted into existing company operation for
better product quality.

- All ladders are welded with square rungs in diamond orientation with ladder cages.
- All handrails are made of galvanized pipe 48.3mm OD, except those on boom sections
for weight saving purposes
- Cable trays are SS316 perforated. Cables and hoses are secured with SS cable ties.
- All machined pins, end covers, and small adaptors are zinc plated to approximately 15
micron thickness.
- All fasteners M12 and below used are SS304. All fasteners above M12 are Grade 8.8 or
equivalent, fluorocarbon coated.
- Slew bearing fasteners are ISO Grade 10.9, fluorocarbon coated
- Clear labels on all critical equipment onboard
- SS304 and/or white traffolyte with black inscriptions are chosen as standard for labeling

An Emergency Slewing Handle is an emergency crank used to slew the
crane to a safe direction in the event there is a loss of power to the crane.

An Emergency Lowering Hand Pump is provided to lower the load to safe
level in the event there is loss of power to the crane.

A monorail with girder and chain block Maintenance Jib is with provided
to carry out any maintenance work that is required onboard the crane.

Surface Treatement
External Treatment :
Pedestal, crane house and boom -
- Surface preparation to ISO 8501-1, SA 2.5
- First coat zinc rich epoxy primer to 50 µm dry film thickness
- Second coat two pack epoxy to 100 µm dry film thickness
- Third coat polyurethane finish to 65 µm dry film thickness
- Total : three coats to 200 µm dry film thickness

Internal Treatment :
Pedestal and crane house -
- Surface preparation to ISO 8501-1, SA 2.5
- First coat zinc rich epoxy primer to 40 µm dry film thickness
- Second coat two pack epoxy to 75 µm dry film thickness
Oil tank (integrated in crane house) -
- 16.2.2.1 Surface preparation to ISO 8501-1, SA 2.5
- 16.2.2.2 First coat zinc rich epoxy primer to 40 µm dry film thickness
Boom -
No treatment as fully closed steel box structure

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
----------------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Lattice Boom Offshore Crane for sale
Offshore Crane - 300 Ton - For Sale
New Offshore Crane for Sale
Offshore Lattice Boom Crane - 300 ton
New Offshore Lattice Boom Crane for Sale
New 300 ton Offshore Crane for Sale
300 ton New Offshore Crane
-----------------------------------------------------------------------------------------------------------------------------------------

Coiled Tubing unit 2006 built for sale
Used Coiled Tubing Rig
Coiled Tubing unit

ParticularsYear : 2006
Make : Kenworth
Model : T800B
Engine : CAT C-15
Odometer : 28048 KM

Hours : 1984
Front : Dual Axle
Rear : Tri Axle
Air compressor : Hurricane 600 CFM

Injector : 20,000 LB
Drum capacity :
1” – 4,800M
1¼” – 3,200M
1½” – 2,300M

Hand tools : Basic assortment
Coil tubing : 3200 M 1¼”
Catch tank

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
-----------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) :
Used Coiled tubing rigs
Coiled Tubing Units
Used Coiled Tubing Units
Coil tubing unit
Used CT rigs
Coiled Tubing Rig
CT rig in Canada
-----------------------------------------------------------------------------------------------------------------------------------

Oil Barge for Sale
3277dwt Oil Barge for Sale
Newbuilding Oil Barge for Sale

Description :
This double hull and double bottom oil barge is designed for
carrying  base oil and finished oil, which flashpoint is below 60°C.

Particulars :
Length overall : 230 ft (70.104 m)
Length bp : 67.30 m
Breadth moulded : 60 ft (18.290 m)
Depth moulded : 18 ft (5.490 m)

Draft moulded : 3.63 m
Gross tonnage : 1834 t
Net tonnage : 807 t
Lightship weight : 970.19 mt

Displacement : 4247.55 mt at summer draft
Tank capacity : +/- 3277.50 mt
Hull material : steel

Tank age :
Cargo tank : +/- 3750 cub.mt
Fuel oil : +/- 8 cub.mt
Dirty oil tank : +/- 16 cub.mt
Fresh water : +/- 21 cub.mt
Sewage : +/- 16 cub.mt

Machinery, equipment & piping :
Cargo fuel pump :
2 x 2GC/BL350 Q=350 cub.mt/hr, P=0.8 mpa, 1500 rpm

Diesel engine :
2 x for starting cargo fuel pump, 6135 AZcaf, w=190 kW/220hp, n=1500 rpm

Reduction gear box : 2 x 135 r = 1:1
Generator : 2 x 24 kW daewoo, 415v / 50 hz / 3ph
General pump : 1 x 22 cub.mt/hr x 26 m/h

Fire pump : 1 x 22 cub.mt/hr x 26 m/h
Oily dirty water seperator : 0.5 cub.mt/hr
Hall's anchour : 1 x 900kg, wire cable Ø 28 x 200m

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

 ------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) :
Oil Barge for Sale
Double Hull Barge for Sale - Length 230ft
New 230FT Barge For Sale in Asia
Newbuilding Oil Barge For Sale - 3277DWT
3277 dwt New Oil Barge for Sale in China
18ft depth new barge for Sale
--------------------------------------------------------------------------------------------------------------------------

Ship's Towing Winch for sale
40 ton Towing Winch for Sale
Towing Winch for Sale

Description :

Winding capacity/speed : 40 ton @ 5 mtr / min
Winding capacity/speed : 8 ton @ 15 mtr / min
Drum rpm : 40 ton @ 2.4 rpms
Drum rpm : 8 ton @ 7.3 rpms
Power : 80 hp

Motor Driven Hydraulic Power Pack
Power : 45 kw
Capacity : 190 ltr/min
Pressure : 310 bar

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
------------------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Ship's Towing Winch for sale
40 ton Ship's Winch for sale
Ship's Towage Winch
Ship's Towage Winch for sale - 40 ton
Towing Winch for sale
------------------------------------------------------------------------------------------------------------------------------------------

UMD 110 Land Drilling Rig - For Sale in Europe
New Semi Mobile Drilling Rig For Sale - UMD 110

Main Technical Specifications
Engine type : C 13 ACERT
Nominal engine power hp (kW) : 415 (309)
Transmission : Allison 4500 OFS
Nominal hoisting capacity metric ton (lbs) : 110 (242000)
Workover  depht (m) drill pipe (2 7/8”) : 4500
Drilling depht (m) (4 1/2“) : 1500
Rope diameter (mm) : 26
Mast height (m) : 32
Drilling floor height (m) : 5
Travelling system : 4x3
Working pressure (mpa) : 0, 65-0, 8

Technical Specifications
Drawworks
Main Drum -
Input power (hp) : 450
Barrel size : D18”  W38”
Brake rim size : D44” W12”
Wire line size : 1 ” (26 mm)
Drum speed : 6F/1R
Brake cooling : Water circulation
Brake system : Band / disc / auxiliary (Parmac SSR-28 hydro-brake)
Lubrication : Automatic or manual
Drum clutch : Air flex type
Chain drives :
All chains are fully encloded for oil bath lubrication ensuring longer life
and cleaner operation

Sand Line Drum -
Barrel size : D13”  W37“
Brake rim size : D44” W9½”
Spooling capacity : 16114’
Sand line wire size : 9/16” (14 mm) - 5/8” (16 mm)

Rig Power & Transmission
Diesel engine(s) : Caterpillar C-13 ACERT, 415Hp, 2.100rpm
Transmission(s) : Allison OFS 4500 series with torque converter
Right angle gear box : Min 500 HP gear box in oil bath gear case
Compound box :
Twin engine drive through transmission includes disconnect clutches at
compound shaft for engines

Mast  & Crown Block
Mast -
Mast complete set : Design and conform to API 4F specification
Mast height : 32m  ( 118ft  )
Max. static hook load capacity : 1.100kN  ( 250.000lbs )
Racking capacity : 1.500m ( 4 ½’’ DP, 19.2m double )
Height of the monkey board : 17.2m ( from floor )
Accessories : Standpipe , exproof  lightning....etc
Mast type : Hydraulic telescopic

Crown Block -
Crown block complete set : Design and conform to API 4F  specification
Max. hook load : 1.100kN (250.000lbs )
Number of sheaves : (2)  Main + (1) fast line  +  (1) deadline +  (1) sandline
+  (2) sheaves for service winch

Sheaves OD :
Fast Lines Ø32" ( Ø813mm )
Dead Line Ø28" ( Ø711mm )
Sand Line Ø28" ( Ø711mm )

Dia. of sheave’s grove :
Fast & Dead Lines Ø1" ( Ø26mm )
Sand & Winch Lines  Ø 5/8" ( Ø16mm )

Traveling Block  & Hook
Traveling block : 1.100kN Max. statik load, 3 sheaves, Ø32’’ sheaves
dia. Ø1’’  (Ø26mm ) groove dia.

Hook : 1.100kN Max. statik load, 3tons spring stroke.
Elevator link(s) : 1.100kN rated load capacity.

Swivel
Static hook load, ton : 110
Working pressure, psi : 5,000
Maximum speed, rpm : 300
Coupling thread to stem : 4-1/2" Reg LH
Coupling thread to kelly : 6-5/8" Reg LH
Stem I.D. : 2-1/2"

Trailer  & Other  Systems
Trailer :
Three axles semi mobile trailer, 12 wheels, fabricated high tensile steel vehicle
frame reinforced at points of greatest stress. Highway equipment and cab included.
Installed fuel tank.

Tool box. Auxilary drill line drum, all axles dressed brake, folding walkwayss on
both sides of trailer.

Hydraulic jacks : Four hydraulic operated leveling jacks
Hydraulic service winch : 5 metric tons drum pull capacity
Deadline anchor : Deadline anchor attached directly to trailer frame
Air system : Compressor (engine drive), air tank, relief valves, air dryer, gauges, all clutches

Hydraulic system :
Hydraulic pump, system operate hydraulic cylinders on mast, hydraulic jacks,
hydraulic pipe tong, and hyraulic winch. Control valves, hydraulic oil tank, filters, pipes,
hydraulic and air valve connections, fittings.

Electrical lighting system : All the electrical equipments on the mast, and substructure
are ex-proof type

Instrumentation : Driller control panel, weight indicator, gauges, air valves, cables , hoses,
fittings, transducers, paint

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.



--------------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) :
UMD 110 Drilling Rig For Sale in Europe
New UMD 110 Semi Mobile Drilling Rig For Sale
New Semi Mobile Drilling Rigs
Land Drilling Rigs For Sale
New Land Drilling Rig
--------------------------------------------------------------------------------------------------------------------------------

Crane Barge for Sale
Used Crane Barge for Sale
Crane Barge for Sale - 2001 built

General Specifications
Build Year : 2001
ABS : International Load Line

Dimensions : 188.2’ x 60’ x 12’
Gross Tonnage : 1054
Net Tonnage : 316
Hull Material : Steel

Spuds : Two square 42” x 85’ spuds with three spudwells
Spud Winches : Two CAT 7 Skagit RB90 3 Drum, Tier 3

Offices : Two water tight conex boxes with built in offices
Storage : Overhead steel storage with handrails
Generators : 19-457 Multiquip, 120 kW
Welders : One 400 Amp Miller Electric C.C.

Air Compressors :
Ingersoll Rand 25 hp electric with air dryer 105 cfm, MOD UPG-25

Price & terms : Please enquire using the email form below.

If you cannot find the Mobile Hospital Unit that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of containers where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Crane Barge for Sale
Used Crane Barge for Sale
Barges for Sale
2001 built Crane Barge
Crane Barge - 2001 built - For Sale
------------------------------------------------------------------------------------------------------------------------------

Sullair 900 cfm / 350 psi Air Compressor
350 psi Air Compressor & JGP/2 900 PSI 2-3/4in x 3-1/4in Air Booster

Model : 900 cfm / 350 psi Air Compressor JGP/2 900 PSI 2-3/4in x 3-1/4in Air Booster
Manufacturer : Sullair
Condition : Used

Description :

(1) SULLAIR 900 cfm / 350 psi Air Compressor
& (1) ARIEL JGP/2 with 900 PSI 2-3/4in x 3-1/4in
Air Booster - Complete Combination unit - Late 1990's models
1st Stage is 900 cfm / 600 psi & 2nd Stage is 900 cfm / 900 psi
DETROIT MTU 12V-2000 DDC Diesel Engine
Electric Starter
Radiator
Control Panel
Heat Exchanger
Skidded

Location : USA

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------------------------------
Search words -
Sullair Air Compressor and Air Booster Combination Unit for sale
Used Sullair 900 cfm / 350 psi Air Compressor  For sale
Air Compressor and Air Booster Combination Unit For sale
900 cfm / 350 psi Air Compressor For sale in USA
ARIEL JGP/2 with 900 PSI 2-3/4in x 3-1/4in Air Booster Combination Unit
---------------------------------------------------------------------------------------------------------------------

Sandvik Cubex 6200 Reverse Circulation Drilling Rig for Sale
Used Sandvik Cubex 6200 Reverse Circulation Drill for Sale

Model : Cubex 6200 Core Drill
Manufacturer : Sandvik
Year : 1999
Condition : Used

Description :

1999 Sandvik Cubex 6200 Reverse Circulation Drill
Set up for mineral exploration applications
Mounted on a track carrier
The drill is currently wired for 480 volts (It can be run off of both 480 and
600 with an available transformer that can be installed for 600 volts
Overhauled in 2019
Set up for RC (Reverse Circulation) drilling
Note : Updated pictures listed here mid-April 2025

Location : USA

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------
Search words (for official use only) :
1999 Built Sandvik Cubex 6200 Reverse Circulation Drill Rig for Sale
Sandvik Cubex 6200 Reverse Circulation Drilling Rig - 1999 Built - For Sale
Sandvik Cubex 6200 Reverse Circulation Used Drilling Rig for Sale
Sandvik Reverse Circulation Drilling Rig for Sale
Sandvik Cubex 6200 Reverse Circulation Drill for Sale in USA
-------------------------------------------------------------------------------------------------------

Caterpillar 993K Wheel Loader - For Sale
Caterpillar Wheel Loader for Mining

2010 Caterpillar 993K
Erops
Air Conditioner
Auto Lube
Counterweight
High Lift
Steer, S.T.I.C.
Product Link

Lighting, Premium Cab,
Standard Glass Seat,
Heated Mirror,
Heated Fuel Ar,
Fast Fill,
Heated Cooling,
Standard Ambient Service Center,
Deluxe Step,

Rear Access Steering,
Standard Camera,
Rear Vision-Waves Radio,
 Am/Fm,
Cd Basic Oil Renewal System (Ors) Tires,
50/65r51 ** Vsdl Bs L5 @ 100%

SMU/Hrs : 13715 Location :  USA

Photos Representative Of Machine But Not Actual Machine

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
--------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Caterpillar 993K Wheel Loader for Sale
Used 2010 Caterpillar Mining Equipment for Sale
Mining Equipment Caterpillar 993K for Sale in USA
2010 Caterpillar 993K Wheel Loader for Sale
-----------------------------------------------------------------------------------------------------------------------

Ringer Crane Barge Pontoon for Sale
Crane Barge for Sale

Description :
Classed A1 Ocean Service Deck Barge
Manufactured in 2001
ABS load line barge and just had its annual inspection done.
The barge has 3 spud pockets, 2 70ft spuds, and 2 each 3 drum
Skagit G-120 280 or 290 ft of boom

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
------------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Ringer Crane Barge Pontoon for Sale
Crane Barge for Sale in USA
2001 manufactured Ringer Crane Barge
Classed A1 Ocean Service Deck Barge for Sale
Ringer Crane Barge for Sale for USA
----------------------------------------------------------------------------------------------------------------------------------------

Platform Supply Vessel for sale
PSV For sale

Classification : ABS

Tonnage :
Gross tonnage : 700 tons
Net tonnage : 210 tons

Dimensions :
Length OA : 54.27 meters
Breadth moulded : 12.19 meters
Depth, moulded : 4.27 meters
Draft, summer : 3.63 meters

Deck Capacity :
Deck cargo : 600.0 tonnes
Deck area : 312.6 sqm (35.13 meters x 8.9 meters)

Tank Capacities :
Dry bulk : 113.20 cbm (4 tanks x 28.3 cbm)
Fresh/drill water : 524.80 cbm
Fuel oil : 252.10 cbm
Liquid mud : 181.60 cbm ( 4 tanks x 45.4 cbm)

Propulsion/Positioning :
Main engines :
2 x Cat D399
HP - 2,679 kW-1,998
Fuel type : Marine Diesel
Bow thruster : 1 x 300hp, Cat 3406

Generators :
Diesel generators : 2 x 210 kW, Cat 3406
Voltage : 440V, 60Hz

Accommodation :
Total berths : 18
3 x 1 person cabins
4 x 2 person cabins
1 x 3 person cabins
1 x 4 person cabins

Communication Equipment :
Radio station :
(1) MF/HF Radiotelephone SEA 330
(1) MF/HF Radio Telex SEA 330
Telex : (1) SEA SAT 3
VHF :
(2) VHF SEA 7156
(2) VHF DSC SEA 7157
Portable VHF : (2) VHF Survival Craft sr-103
SART : (1) SimraD SA 50
EPIRB : (1) ACR 406

Navigation Equipment :
Radars :
One Furuno 1930
One Furuno 1941
Satellite navigator : (1) Furuno Navgator
Navtex receiver : (1) JRC NCR - 300A
AIS : (1) JHS 182


Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Platform Supply Vessel for sale
PSV for Sale in Dubai, Bahrain, Qatar, Kuwait, Middle East
PSV for sale in Asia, Singapore, Malaysia, Indonesia
-----------------------------------------------------------------------------------------------------------------------------

Tug for sale - 2400 BHP

Principal Particulars
Length Overall : 30.00M
Length BP : TBA
Breath Moulded : 8.60M
Depth Moulded : 4.115M
Draft Moulded : 3.50M
Class Notation : GL + Tug
GRT/NRT : TBA
Speed : 11.0 knots (approx)
Endurance : 22 days
Built : 2010
Delivery : Prompt

Tankage
Fuel oil : 190 tons (approx)
Fresh water : 65 tons (approx)
Ballast water : 40 tons (approx)

Machinery
Main engine : 2 x 1200BHP @ 1800RPM Cummins KTA38-M2
Reduction gear : Twin disc MG5321, ratio 5.96:1
Propeller : 2 x 4 blade Kaplan type bronze nozzles
Main generator : 2 x 78kw Cummins 6BT5.9DM

Accommodation
For 12 men with 2 cabins for Captain and Chief Engineer
and 5 x two-men cabins

Pumps
GS and ballast pump : 2 x self-priming pump of 28M3/hr @ 30M head, 415/3/50
F.O. transfer pump : 1 x horizontal gear pump of 8M3/hr at 25m head, 415/3/50
FW pressure set : 1 x freshwater pressure set of 3M3/hr at 15m head
SW pressure set : 1 x salt water pressure set of 3M3/hr at 15m head
Oily Bilge Water Separator : 1 x 0.25M3/hr
Sewage Treatment Plant : for 15 men
Dirty oil pump : 1 x horizontal gear pump of 1.1kw x 1450RPM

Navigation Equipment
1 set Radar
1 set echo sounder
1 set GPS receiver
1 set SSB radio
1 set VHF radio
1 set VHF 2-way radiotelephone
1 set Navtex receiver
1 set EPIRB
1 set Magnetic compass

Deck Machinery
Anchor : 2 x stockless bower anchors of 570kg each
Anchor windlass : 1 x 3 tons @ 12M/min hydraulic anchor windlass suitable for 22mm dia
Towing winch : 1 x single drum towing winch
Brake holding : 80t Winch load : 25t
Drum capacity : 500m x 48mm dia (Wire rope to be supplied by buyer)

Life Saving Equipment
2 x 15 men Liferaft
8 sets Life buoy
15 sets lifejackets
1 x portable manual start diesel engine driven emergency fire pump shall be installed on board

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

------------------------------------------------------------------------------------------------------------------------
Search words(for official use only):
2000bhp tug for sale
2400bhp tug in Singapore
Tug for Towing - 2400bhp
Tug for towing - 2000bhp
Tug For Sale in Indonesia
Tug for Sale in Singapore
Tug For Sale in Malaysia
2000bhp Tug for Sale
2400bhp Tug For sale
---------------------------------------------------------------------------------------------------------------------------
