Harbour Tug for Sale 2007 built 1500bhp Harbour Tug in Mediterreanean
Built 2007, Greece Class RINA C+TUG UMS Class valid : 09.07.2012
LOA : 23.0m Beam : 7.46m Depth : 3.65m GT/NT : 80/20 M/E: 2 x CATERPILLAR3412C, total 1440BHP Propellers : 2 x Fixed Pitch in nozzles Gensets : 1 x 85 KW Volvo 1 x 60 KW Deutz FiFi : 2 x Monitors 250 m3 /h an auxiliary fire pump is connected Towing Hook : Mampey Quick release towing hook DCX 25tons Bollard Pull : 23tons Accommodatiom Crew 2x2 Officers 1x1 Mess room Tank CapacityFuel oil 44 m3 Ballast 20 m3 Navigation equipment-Navtex - Compass - Radar - Echosounder Communications : Radio telephone -SART- Portable VHF - EPIRB - INTERPHONE - VHF Delivery Mediterranean
Price & terms : Please enquire using the email form below.
If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you.
We can arrange delivery of equipment and towage of rigs and vessels where needed.
The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) : Harbour Tug - 2007 Built for sale Tug for sale Tug in Mediterreanean for sale 1500 bhp Tug for sale 2007 Built Harbour Tug for sale -----------------------------------------------------------------------------------------------------------------------------
Offshore Lattice Boom Crane for sale New Offshore Crane for Sale Offshore Lattice Boom Crane- 80 ton General Specification Slewing Angle : 360º(Continus) Slewing Speed(Full Load) : 0~0.6rpm Luffing Time(Full Load) : 150s Up/down Luffing Angle : +15° ~ +82° Parking Angle : -10° ~ +15° Operator Cabin : Left Side Main Winch Data Lifting Capacity(SWL) : 80T@13m,6T@45m,See Loading Chart; No. Of Fall : 4 Working Radius : 9.2m(Min) / 45m(Max) Main Lifting Speed(0-80T) : 0~6m/min Main Lifting Speed(0-40T) : 0~18m/min Hook Travel : 60m Aux Winch Data Lifting Capacity(SWL) : 5T@47m, Man Riding :1.5T No. Of Fall : 1 Working Radius : 10.2m(Min) / 47m(Max) Main Lifting Speed(Full Loading) : 0~90m/min Lifting Height : 62m Note : All operational speeds stated above are based on average volumetric efficiencies provided by our suppliers of hydraulic components. A speed variation tolerance of +10% to -5% is within the accepted range and should be taken into consideration. Hydraulic Arrangement Hydraulic Systems The hydraulic transmission will be designed for optimum performance within the constraint of available horsepower. High pressure hydraulic system uses power more efficiently and applies power as needed. All motions controls offer infinitely variable speed and full reversing characteristics. Two full flow filters will be installed. The filter(s) will be adequately sized for full flow operation without causing pump cavitation. Replaceable wire mesh filter cartridge of minimum absolute value of 40 micron will be used. The pumps will have overflow suction independent of the reservoir, and the arrangement of piping can avoid air pockets. Hoisting Circuit Each winch is driven by a common open loop hydraulic system including piston pump, piston motor and epicycles gearbox. Each winch is fitted with oil immersed, multi-disc and dynamically rated “fail safe” brake. The fixed displacement hoist motors offer a constant operating speed. Slewing Circuit The slew circuit is driven by a common open loop hydraulic system. Dynamic braking of slewing is by means of hydrostatic compensation. Similarly positive locking brakes are fitted in the circuit and used as static brake. Luffing Circuit Luff circuit is driven by a common open loop hydraulic system. Each winch is fitted with oil immersed, multi-disc,dynamically rated “fail safe” brake. an additional luff ratchet cylinder is included, providing a positive means of locking the luff drum whenever the prime mover is shutdown. Hydraulic Piping 1. Pipes: No pipe threads will be used for the high-pressure lines larger than 3/8". Hydraulic components that have pipe threaded ports lines will have a minimum working pressure 300PS. . 2. Pipe fittings: Zinc plated mild steel material. External fittings are painted and protected by Denso tape or equivalent against corrosion. 3. Hoses: High rubber quality for best resistance against sunlight and salinity, Wire breaded for applicable specified hydraulic pressure ratings 4. Hose couplings: Zinc plated mild steel material, External couplings are painted and protected by Denso tape or equivalent against corrosion. Hydraulic Oil Tank 1. Level gauge with isolating valve (to top cover) 2. Inspection and cleaning cover 3. Filter with fine mesh stainless steel strainer and ventilation 4. A relief valve will be installed in the discharge line of pump. Cooling Circuit The air-oil heat exchanger will be provided and sized to ensure continuous operation of the crane under the ambient temperatures given on the data sheets. Electric Arrangement Standards, Codes and Protection Refer to Codes Of Practice and Standards. The electrical systems onboard the crane complies with these standards for good offshore electrical design and engineering practices. Standard Lighting The following are provided as standard lighting packages for the crane. More lights can be added according to client's request. Description : Aviation Warning Light Quantity : 1 Size : 85W Location : Boom Tip Power Supply : UPS Description : Aviation Warning Light Quantity : 1 Size : 85W Location : Mast Power Supply : UPS Description : Florescent Access Light (with 90 min back-up battery) Quantity : 2 Size : 2 x 36 W Location : Access Way Outside Cabin Power Supply : Main Description : Florescent Access Light Quantity : 2 Size : 2 x 36 W Location : Machinery House Power Supply : Main Description : Florescent Access Light (with 90 min back-up battery) Quantity : 1 Size : 2 x 18 W Location : Cabin Power Supply : Main Description : High Pressure Sodium Floodlight Quantity : * Size : 400 W Location : Boom Power Supply : Main Power Supply Main Power Supply : 415 VAC , 03 Phase , 50Hz Uninterrupted Power Supply : 230 VAC , 01 Phase , 50Hz Others Junction box(es) is provided at the pedestal interface for connection to client supply. By default only SS316 junction boxes are installed onboard. Generally cable wires will be multi-stranded copper and protected against mechanical damage. All power and control cables are with XLPE/EVA/GSWB/EVA construction. Occasionally able of XLPE/EVA/CWB/EVA is used when big power cable is part of the design. All electrical lines are tagged accordingly for ease of maintenance. All outdoor equipments and instruments are Ingress Protected IP56. Indoor equipments and instruments are rated with IP44 as minimum. Ordinarily, the power supply for crane is transmitted from pedestal to slewing platform through the centre slip ring to ensure the crane can work at any angle. Controls and Instruments Cabin : The following instruments are arranged on the console to permit the operator to maintain an uninterrupted view of the loads and instrumentation. The two(2) motion controls joysticks designed according to API-2C, are ergonomically correct and easy to handle. All instruments are clearly labeled. 1. Motion Control Joysticks: 2. “Dead-Man” Type - Position sensitive with motion and speed infinitely variable and proportional to movement from spring-return central position. - Luff and slew (single left) joystick - Main and auxiliary hoist (single right) joystick - Prime Mover Start/Stop Switch - Prime Mover Emergency Shutdown Switch - Slew Brake Control Lever for option - Safe Load Indicator System - Visual and Audible Annunciator Panel - Boom Hoist Down Override Switch - Pressure Gauges: Boast Control / Hoist / Slew / Luff - Electrical Switches: - Lighting - Windshield Wipers & Washer - Warning Horn - Air Conditioning - Main and Auxiliary Hoist selector - Tachometer Hoist Mechanisms Hoist Winch Data Feature : Hoist Drum Description : Material Details : Cast Steel Remark : 100% NDT Description : Groove Remark : Reeving not over 3 layers Description : Support End Details : Anti-friction Bearing Feature : Braking Description : Type Details : 1 x Band Brake Remark : Asbestos free lining, for man riding winch only. Details : 1 x Multi-disc Brake Remark : Positive Locking Details : 1x Load valve Remark : As dynamic Brake Description : Safety Factor Details : Minimum 2.0 Feature : Rope Anchors Description : Type Details : Bolted rope clamp Remark : For ease of rope replacement Description : Safety Factor Details : Minimum 1.1 Remark : Ensures rope breaking strength when over loaded Feature : Ratios Description : Drum to Rope Details : Min.19 : 1 Remark : Drum pitch diameter over rope diameter Feature : Safety Description : Drum flange beyond top layer Details : 2.5 x rope diameter Remark : To avoid rope jumping out of drum unintentionally Description : Fleet angle Details : < 2.5⁰ Remark : Ensures smooth and even rope spooling at all times Description : Dead turns on the drum Details : Min.5 Remark : Amount of rope that is not in used even at the maximum hoist reach of the crane Luffing System Anti-backward limit is used to prevent the boom over luffing in order to protect boom. Feature : Hoist Drum Description : Material Details : Cast Steel Remark : 100% NDT Description : Groove Remark : Reeving not over 3 layers Description : Support End Details : Anti-friction Bearing Feature : Braking Description : Type Details : 1x Load valve Remark : As dynamic Brake Details : 1 x Multi-disc Brake Remark : Positive Locking Details : ratchet and pawl Remark : Luffing locking device Description : Safety Factor Details : Minimum 2.0 Feature : Rope Anchors Description : Type Details : Bolted rope clamp Remark : For ease of rope replacement Description : Safety Factor Details : Minimum 1.1 Remark : Ensures rope breaking strength when over loaded Feature : Ratios Description : Drum to Rope Details : Min.19 : 1 Remark : Drum pitch diameter over rope diameter Feature : Safety Description : Drum flange beyond top layer Details : 2.5 x rope diameter Remark : To avoid rope jumping out of drum unintentionally Description : Fleet angle Details : < 2.5⁰ Remark : Ensures smooth and even rope spooling at all times Description : Dead turns on the drum Details : Min.5 Remark : Amount of rope that is not in used even at the maximum hoist reach of the crane. Boom Luffing-in limit buffer Mast The Luffing sheaves are placed on the mast (A-frame) which is fitted with a top platform for maintenance and inspection of the mast head sheaves, luff hoist rope and anchor connections. Access to the Top Platform is by ladder from the machinery deck. The mast is pin connected to the machinery deck. Bridle N/A Slew Mechanisms Slew Bearing Brand- ROTHE-ERDE XUZHOU or equivalent Rolling Element- Triple Cylindrical Roller Lubrication - Grease holes in diagonal orientation in outer ring - Lubrication lines are fitted on the machinery deck for refilling grease into the bearing Slew Drive Type- Fixed displacement hydraulic motor Gearbox- Epicyclical Brake- Oil immersed multi-disc brake(s) Operating Conditions- Slew design wind speed 24m/s Pinions- Four(4) Emergency slewing is possible with one (1) pinion Boom Length- 45M & 47M Type- Reinforced Lattice Structure Pins- High Tensile Connectors- Cast Steel Welding Test- NDT 100% MPI, 100% UT/RT Boom Top Platform- Both Sides Safety Hardwood blocks- To prevent rubbing of ropes on boom bracing damaging paint and cause unnecessary rusting. Walkway paths- 760mm wide grating along and inside of boom for maintenance access Handrails- Along boom section Boom Bottom Type- Reinforced Lattice Structure Material- High tensile low alloy low carbon seamless chords with mild steel bracings Boom Intermediate Section Type- Reinforced Lattice Structure Material- High tensile low alloy low carbon seamless chords Boom Head Type- Reinforced Lattice Structure Material - High tensile low alloy low carbon seamless chords - With Mild Steel Bracings - High Strength Steel Head Plate Reeving System Sheaves Materials- Steel Processing Technique- Cast Ratio- 20 : 1 (Sheave diameter / Rope diameter) Lubrication- Lubrication through sheave pin Bearing- Heavy duty sealed cylindrical roller Ropes Rope Size (mm) Main Hoist and Auxiliary Hoist : Minimum 5.0 Luff Hoist and Pendant : Minimum 4.0 Rotation Characteristic - Main Hoist and Auxiliary Hoist : Non-Rotating Luff Hoist : Low Rotation Pendant : Non-Rotating Construction - Main Hoist and Auxiliary Hoist : RH and WSC Luff Hoist : RH and IWRC Pendant : WSC End Connections : Solid Thimble Finishing : Compacted and Galvanized Hooks Basic design factor of the hook is more than 4.0. The hooks are made of cast steel and tested to -40°C, or -6°C below lowest design temperature. All hooks come with lockable safety latch and swivel bearings. Hook blocks will be of significant weight to prevent unraveling of rope while unloaded. Machinery Deck Machinery Turret Basic design factor of the hook is more than 4.0. The hooks are made of cast steel and tested to -40°C, or -6°C below lowest design temperature. All hooks come with lockable safety latch and swivel bearings. Hook blocks will be of significant weight to prevent unraveling of rope while unloaded. Operator Cabin Structure- 5 mm steel plate Floor Area- 1685mm x 1300mm Position- Port of crane Acoustic Shield- Noise level during operation ≤ 75 dBA Weather Shield- Complete sealed through for water runoff Visionary Forward Windows- Clear Safety Glass Side Windows- Clear Safety Glass; open-able Rear View Mirror- N/A Safety Equipment Safety Bar- Front & side windows to prevent accidental fall Horn- Electric warning horn Fire Extinguisher- 1.5kg Dry Powder Accessibility Headroom- 2.1 meters Door- Side slip door with lock Maintenance - Removable panels for access to cables & hoses - Rooftop access for air conditioner maintenance - Side access to front of cabin for window clearing and wiper replacement Other Accessories Chair- Fully adjustable cushioned type Hour Meter- Digital / Analog Communication- Equipment (PA Speakers Telephone set, VHF/UHF radios and lound speaker with microphone system) free issue by shipyard. Control Console- See Controls and Instruments Power- Power socket Lighting- See electrical system Windshield Wiper- Electrical type Air Conditioning- Roof top unit Engraved Stainless Steel Plate - Design certified load chart Rope specification chart - API monogram Prime Movers Prime Mover Data – Diesel Engine Brand : Caterpillar Model : 3406 Rating : 345KW @ 1800RPM Starting System - Primary Battery : Attempts x seconds Secondary : Attempts x seconds Drive Output - Primary Battery : Splitter Gearbox Consumables - Primary Battery : Fuel Grade Secondary : ASTM D975 No.2-D Diesel fuel or equivalent Primary Battery : Coolant Secondary : ASTM D4985 or equivalent Primary Battery : Lubrication Secondary : API CG-4 oils or equivalent Prime Mover Sizing The prime mover is appropriately sized for the following conditions: 1 operation @ full load with full speed Safety Features Cabin An annunciator is mounted in the cabin to alert the operator of possible risky crane operation to avoid unfavorable incidents. This will be a solid state unit “first out” alarm sequence giving both audible and visual warning and fitting with test and acknowledgement buttons. The audible and visual alarming signals are provided as following : - High Return Pressure(filter jammed) - Hoist Up Limit - Hoist Down Limit - Luff Up Limit - Luff Down Limit with override for stowing - Engine Overspeed - Engine Water High Temperature - Engine Lube Oil Low Pressure - Engine Fuel Low Pressure - Hydraulic Temperature High - Hydraulic low level Powerpack The following are provided at the power pack for status monitoring: - Engine Lube Oil Pressure Gauge- Engine Lube Oil Temperature Gauge - Engine Fuel Pressure Gauge- Engine Water Temperature Gauge - Engine Tachometer- Engine Emergency Stop Button - Fuel Tank Level Switch- Hydraulic Oil Level Gauge - Hydraulic Pump Cavitations- Hydraulic Pump Filter Indicator Crane Operation Limit Limit switches are provided to define safe working limits of all crane operations including hoisting and luffing. Operation : Main/Aux. Hoist Detection Level : Upper Working Limit Action : Stop Up Motion Deactivation : Hoist Down Detection Level : Lower Working Limit Action : Stop Down Motion Deactivation : Hoist Up Operation : Boom Hoist Detection Level : Lower Working Limit Action : Stop Boom Down Motion Deactivation : Boom Up or Override for Stowing Detection Level : Upper Working Limit Action : Stop Boom Up Motion and A&V warning Deactivation : Boom Down Detection Level : Ultimate Up Limit Action : Stop Boom Up Motion and A&V warning continued Deactivation : Boom Down Luff-in decelerator and stop in limit is controlled by the incoming boom and provides gradual deceleration until minimum radius. Operation shutdown occurs and luff brakes automatically engage overriding the manual control in the operator cabin. Safe Load Indicator The Safe Load Indicator will provide the following to the operator: - Crane rated capacity (T) - Actual load on hooks (T) - Boom radius (meters) - Boom angle (Deg rees) - Visual alarm at 90% SWL - Intermittent horn at 100% SWL - Loud continuous horn at 105% SWL - Overload cut off switch - Mechanical boom angle installed at the boom where visible from operator cabin Standard Practises - All ladders are welded with square rungs in diamond orientation with ladder cages. - All handrails are made of galvanized pipe 48.3mm OD, except those on boom sections for weight saving purposes - Cable trays are SS316 perforated. Cables and hoses are secured with SS cable ties. - All machined pins, end covers, and small adaptors are zinc plated to approximately 15 micron thickness. - All fasteners M12 and below used are SS304. All fasteners above M12 are Grade 8.8 or equivalent, fluorocarbon coated. - Slew bearing fasteners are ISO Grade 10.9, fluorocarbon coated - Clear labels on all critical equipment onboard - SS304 and/or white traffolyte with black inscriptions are chosen as standard for labeling Surface Treatement External Treatment : Pedestal, crane house and boom - - Surface preparation to ISO 8501-1, SA 2.5 - First coat zinc rich epoxy primer to 50 µm dry film thickness - Second coat two pack epoxy to 100 µm dry film thickness - Third coat polyurethane finish to 65 µm dry film thickness - Total : three coats to 200 µm dry film thickness Internal Treatment : Pedestal and crane house - - Surface preparation to ISO 8501-1, SA 2.5 - First coat zinc rich epoxy primer to 40 µm dry film thickness - Second coat two pack epoxy to 75 µm dry film thickness Oil tank (integrated in crane house) - - 16.2.2.1 Surface preparation to ISO 8501-1, SA 2.5 - 16.2.2.2 First coat zinc rich epoxy primer to 40 µm dry film thickness Boom - No treatment as fully closed steel box structure Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed. ----------------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) - Offshore Lattice Boom Crane for sale Offshore Crane - 80 Ton - For Sale 80 ton Offshore Lattice Boom Crane New Offshore Crane for Sale New 80 ton Offshore Crane for Sale 80 ton New Offshore Crane ---------------------------------------------------------------------------------------------------------------------------------------
Coiled Tubing Rig for Sale Used Coiled Tubing Rig For Sale in Canada Description This high performance CT Unit is built upon a 2000 Volve ACL with a rebuilt engine (2006) as well as a rebuilt transmission and clutch (2007). It features a rear enclosed operator cabin, dual injector hose reels and, a model RT25 Injector upgrade (2007) Specifications Injector : 25,000 Ib Air Compressor : Hurricane Air Compressor rated at 9.3cbm (330cfm) at 14MPa Pump : Triplex Pump rated at 50L per minute at 21MPa Crane : Knuckle Crane rated at 6350kg (7ton) with 6.7m each Accumulator : Single Accumulator, 11Gal Coil Tubing OD size range : 1.000” to 2.375” (25.4mm to 60.3mm) Hydraulic Pressure at maximum pull capacity : 2650 psi (18.3MPa) Continuous pull capacity : 25,000 lbs (11,340 kg) Snubbing capacity : 25,000 lbs (11,340 kg) Maximum speed : 200ft/min (60.9m/min) Injector width : 32 in (81.3 cm) Injector depth (in direction of guide arch) : 42.5 in (108 cm) Drive Ratio : 29.37:1 Maximum displacement : 3.34 cub.inch (54.7 cub.cm) Minimum displacement : 1.51 cub.inch (24.7 cub.cm) Injector weight : 2,800 lbs (1,270 kg) Injector Height (from base to top of frame, not including lift eyes) : 62 in (157.5 cm) Reel Capacity CT Size : Capacity 1-1/4” : 3100m 1-1/2” : 2200m 1-3/4” : 1600m 2” : 1260m Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed.
------------------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) - Coiled Tubing Used Rig for Sale Coiled Tubing Unit for Sale in USA CT Rig for Sale Used Coiled Tubing Unit for Sale in USA Rig for sale in Canada - Used Coiled Tubing Unit Used Coiled Tubing Rig For Sale in Canada -----------------------------------------------------------------------------------------------------------------------------------
Refrigerated Shipping Containers Reefer Shipping Containers For Sale
Cladding & Frames
External Internal
OPI 1300 Triplex Mud Pump 1300 AWS Model Triplex Mud Pump for Sale Used Triplex Mud Pump for Sale 1300hp OPI Triplex Mud Pump for Sale Technical Specification of OPI 1300 Fluid End Description / Specification Model : AWS 1300 Piston Size : 4 ½” Pressure (psi) ranges : 12000psi Suction line : 4” Delivery line : 3” Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) - OPI 1300 Triplex Mud Pump Used Mud Pump For Sale in India 1300 HP Triplex Mud Pump 1300hpTriplex Mud Pumps for Sale in India Mud Pumps for sale OPI Triplex Mud Pumps for sale in India Used Triplex Mud Pump For Sale 12000psi Triplex Mud Pump for Sale in India -----------------------------------------------------------------------------------------------------------------------------------
Krupp Wheeler Excavator Digger for Sale Used Krupp Wheeler Excavator Digger 1400hp Krupp Wheeler Excavator Digger for Sale
General 1,400 Hp.2 Diesel engines Some spare parts Originally bought in 1985 but only worked 3 years Maintained, engines run monthly And looks like new
Specifications Wheel Diameter : 36'1" Bucket Capacity : 12 Buckets @ 2.4 CY/YD each Wheel Drive HP : Twin 700 HP Motors (1400 HP) Rated Capacity : 4000-8500 CY/HR Wheel Boom Length : 76'1" Discharge Boom : 88'6" Length Bucket Discharges per Minute : 61.2 Cutting Face Height : 65.6 ft Cutting Face Depth : 4.9 ft
Immediate delivery Price & terms : Please enquire using the email form below.
The details mentioned above are believed to be accurate but are not guaranteed. ---------------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : Krupp Wheeler Excavator Digger for Sale Used Krupp Wheeler Excavator Digger Diesel Engine Krupp Wheeler Excavator Digger for Sale 1985 built Krupp Wheeler Excavator with Spare Parts Diesel Engine Krupp Wheeler Excavator Digger - 1400hp - For Sale 1400hp Krupp Wheeler Excavator Digger - For Sale ------------------------------------------------------------------------------------------------------------------------------------------
Type : Tug Boat Dimensions : Loa:L:23m/ B:8m/ D:3,5m Class : Bureau Veritas (BV) Build : New Building Accom / Pax : 4 persons Machinery : Caterpillar C32 ACERT 970 bkW @ 1800 rpm C rating TOTAL 2600bhp Speed : Abt. 11.0 knots Capacities : Bollard Pull :abt. 30 TBP Fuel Oil Tank 81.000 litres Fresh Water Tank 16.600 litres
Prefab Camps, Prefab Accommodation for sale Prefab Houses, Prefab Homes Prefab Buildings, Prefab Offices Prefabricated Houses, Prefabricated buildings Prefabricated Camps, Prefabricated Accommodation
The advantages of the houses
The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : Prefab Houses for Construction sites Prefab Houses for Oilfields Prefabricated Houses for Sale Prefabricated Camps for Sale Prefabricated Accommodation for Sale ---------------------------------------------------------------------------------------------------------------------------------
Driltech D35K Drilling Rig for Sale Drilling Rig - Driltech D35K - For Sale
Model : D35K Drill Rig Manufacturer : Driltech Year : 1991 Condition : Used Description : 1991 Driltech D35K Drill Rig 850 CFM / 350 PSI Air Compressor Caterpillar 3406 diesel deck engine (has issues as machine has been parked for 5 years) 35,000 lbs of pullback 22" table opening Included 23 pieces of 20ft x 4-1/2" OD drill pipe. Mounted on a Ford L8000 truck diesel engine Location : Western Europe Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed. ----------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : Driltech D35K Drilling Rig - 1991 Built for Sale 1991 Built Driltech D35K Drilling Rig for Sale Used Driltech D35K Drilling Rig for Sale Driltech Used Drilling Rig for Sale Driltech D35K Drilling Rig for Sale in Western Europe -----------------------------------------------------------------------------------------------------------------------------------
Small Size Bulk Carrier For Sale Bulk Carrier for Sale
Particulars 6.150 tdw on 8,48 m Singledecker with box hold Built : 1977 LR Class Dims 80.25 x 16.04 x 10.50 m 1 hold, 7373/7271 cbm gr/bl – 1 hatch Steel tanktop 15 ts/m2 Cranes 2 x 8 tons sidemounted Hanshin 3000 bhp - MDO burner
The details mentioned above are believed to be accurate but are not guaranteed.
-------------------------------------------------------------------------------------------------------------------- Search Words(for official use only) : Small bulk ship for Sale Bulk Ship for Sale Mini Bulker For Sale Small cargo ship for sale Mini Bulk Ship For Sale -----------------------------------------------------------------------------------------------------------------------
Floating Crane for Sale 2600 ton Sheerleg Floating Crane For Sale or Charter Over 2500 ton Floating crane For Sale (self-propelled) New Self Propelled Floating Crane for Rent
Specifications LOA ：108.0M Water line length ：108.0M LBP (length between perpendiculars) ：104.9M Breadth ：44.6M Depth ：7.8M Draft ：5.1M Displacement ：22252T Main Engine ： Ningdong - G8300ZC6B G8300ZC7B
Main Engine power ：1471KW×2 RPM ：500r/min Gear box ：MG49.54 2.9827:1 Rating crew ：14 Working personnel ：16 Navigation area ： Coastwise/Offshore / Cover sea area Max lifting ： 2×650t+2×650t（Main hook） 1×250t+1×250t（Aux hook) Main hook safe working load - Boom elevation (deg) : 70 Working load (t) : 2 x 650+2 x 650 Radius (m) : 33.1 Lifting height (m) : 86 Boom elevation (deg) : 65 Working load (t) : 2 x 650+2 x 650 Radius (m) : 40.1 Lifting height (m) : 82.8 Boom elevation (deg) : 60 Working load (t) : 2 x 500+2 x 500 Radius (m) : 46.7 Lifting height (m) : 79 Boom elevation (deg) : 55 Working load (t) : 2 x 400+2 x 400 Radius (m) : 52.9 Lifting height (m) : 74.7 Boom elevation (deg) : 50 Working load (t) : 2 x 300+2 x 300 Radius (m) : 58.8 Lifting height (m) : 69.8 Boom elevation (deg) : 45 Working load (t) : 2 x 200+2 x 200 Radius (m) : 64.2 Lifting height (m) : 64.4 Aux hook safe working load - Boom elevation (deg) : 70 Working load (t) : 2 x 250 Radius (m) : 42.9 Lifting height (m) : 100 Boom elevation (deg) : 65 Working load (t) : 2 x 250 Radius (m) : 50.7 Lifting height (m) : 95.9 Boom elevation (deg) : 60 Working load (t) : 2 x 250 Radius (m) : 58.1 Lifting height (m) : 91.2 Boom elevation (deg) : 55 Working load (t) : 2 x 250 Radius (m) : 65 Lifting height (m) : 85.8 Boom elevation (deg) : 50 Working load (t) : 2 x 250 Radius (m) : 71.5 Lifting height (m) : 79.8 Boom elevation (deg) : 45 Working load (t) : 2 x 250 Radius (m) : 77.4 Lifting height (m) : 73.3
The ship is now designed to live in 30 people, including 10 double rooms, 6 single rooms, 4 Suites; Equipped with a 20 persons conference room.
Winch Quantities : tool hook 8 sets, anchor machine 1 set, anchor windlass 6 sets, mooring winch 4 sets, luffing winch 4 sets, main hook winch 4 sets, aux hook winch 2 sets, boat and lifting winch 4 sets (Note: 2 sets of anchor windlass and mooring winch are shared)
Winch Type : All are electric, including 19 sets of main winches using transducer, the electronic control systems are made by domestic public company HITE, the main parts of the system are imported. The max test lifting is 2860 tons, which is the requirement for class (which can lift this weight to 88 meters height), if short-term lifting, 3000 tons is no problem, because when the vessel over the bridge, its max pull capacity is 3,600 tons. According to the lifting height, it can 3200 tons in manageable range. Price & terms : Please enquire using the email form below.
The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------- Search words(for official use only) - Floating Crane for Sale New Floating Crane for Sale: Over 2500 ton Over 2500ton Sheerleg Floating Crane for Charter 2600ton Sheerleg Floating Crane for Sale or Rent New Floating crane 2600 ton (self-propelled) - 2011 built Self Propelled Floating Crane Over 2600 ton Floating Crane for Rent New Self Propelled Floating Crane for Rent -----------------------------------------------------------------------------------------------------------------------
Drilling Rig - Speedstar SS-15 II For Sale Speedstar SS-15 II Drilling Rig 1977 Built for sale
Model : SS-15 Drill Rig Manufacturer : Speedstar Year : 1977 Condition : Used
Description : 1977 Speedstar SS-15 II Drill Rig Mounted on a 1977 GMC Truck 13 Speed transmission Rig Serial #: 7154 4 1/4" Kelly 18 GPM John Bean water injection system Double Drum Drawworks with air clutches Sandreel Table Drive 750 cfm / 300 psi Sullair air compressor/low hours installed prior to purchase in 2002 C60 Engine, Easy start, runs great, burns no oil Table Drive, 8 1/2" opening, hydrostatically driven Air Controls Easy load, Rod tray with 17 pieces of 3-1/2" API x 4-1/2" OD x 20' Rods (340') in rack + 25 foot Kelly Bar/365' ft total Line oiler, electric/air 4 hydraulic leveling Jacks 35' mast height above table Safety Shut Down Machine runs exceptionally well 6" Bit basket 10" Bit basket Pipe rollers Drill Rod Clamps Chain Wrench 260' ft of additional drill rod available at an extra cost Location : USA Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you.
The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) - Speedstar SS-15 II Drilling Rig For Sale Drilling Rig Speedstar SS-15 II 1977 Built for sale Used Drilling Rig Speedstar SS-15 II for sale Used Speedstar SS-15 II Drilling Rig for sale in USA Land Drilling Rig For Sale 1977 Built Speedstar SS-15 II Drilling Rig for sale -----------------------------------------------------------------------------------------------------------------------------------------
The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------- Search words(for official use only) : Crane Ship for Sale Crane Ship Crane Vessel 120 T Crane ship for sale Floating Crane for Sale Floating Crane Vessel for Sale --------------------------------------------------------------------------------------------------------------------
Cabot 900 Series - Driling Rig for Sale 2013 Refurbished - 900hp - Drilling Rig
Description: Cabot 900 Series Refurbished 2013 900 HP, 350,000# Country: USA
Carrier and Drawworks : Consisting of Model 2346 single drum drawworks, Parmac V-80 assist brake and rotary drive. Two Caterpillar 3408 475 hp ea. diesel engines powering drawworks, rotary drive and roading chassis. 117’, 350,000# API capacity telescoping mast includes racking board and hydraulic catworks. Mounted on Cabot 900 series chassis. 17’ telescoping type substructure with pipe slide, BOP dolly and track system.
Model 2346 Drawworks : 12” x 46” brake rims, 23” x 44” drum barrel. 60,000# single line pull 30” 2-plate clutch. LeBus type grooved jacket for 1-1/8” wire line. Includes turn back rollers. NEW & REBUILT
Assist Brake : Parmac V-80 brake with overrunning clutch. Includes supply and discharge water manifold with air operated supply. Inlet and outlet valves. Driller’s console includes air pressure regulator for brake modulation control and hand valve control of friction brake function. NEW
Water Manifold : Water inlet circuit from hammer union alongside rig to assist brake and to water circulating brake rims. Control valve in assist brake inlet line modulated by hand valve at driller’s control. Independent discharge line from assist brake and rim brakes to hammer union alongside rig.
Charge Pump : 3 x 4, 11-3/4” impeller, 1150 RPM, 15 HP, 55’-70’ total head and 350 GPM maximum volume required. NEW
Reservoir : 60 BBL volume built inside water tank for extra cooling. NEW Driller’s Console : Located at 17’ high elevated position with folding platform hinged to mast. Pneumatic control for drum clutch, engine throttle, engine emergency shutdown, transmissions and rotary clutch also included. Stairs with handrails form platform to carrier walkway. Mechanical controls located adjacent to controls for drawworks brake. NEW Cabot Carrier Model C9-962-300 : Triple axel front, triple rear axel carrier with 12 x 4 drive, 300” wheel base (bogie center to bogie center). High strength steel fabricated frame. Eaton EFA-22T5 triple axles (66,000# service rating) with 16-1/2” x 6” air brakes on all wheels and with spring suspension. Eaton DP480P double reduction powered tandem and NeWay air suspension leading third axle, all with 16- 1/2” x 7” air brakes, walking beams suspension an powered tandem (68,000# service rating). Has spring safety brakes mounted on two powered axles. Six 18:00 x 22.5 16-ply nylon highway tread front tires and twelve dual mounted 10:00 x 20 12-ply all purpose rear tires. Ross 503 steering with Garrison hydraulic power assist. One-man cab with heater, defroster, two bus type rear view mirrors, driver’s instrument panel, adjustable bucket seats with shock absorber mounted and seat belts. Mechanical support legs, 2-sets required (2 legs per set), rear and midship for greater lateral stability. One 125-gallon roading fuel tank with float valve for inlet from location fuel supply, one tool box, clearance and directional lights, tow bars front and rear.
Walkway and Stairs : Includes walkway alongside of unit on driller’s side extending from rear of unit to engine area. Stairways stairs including handrails. NEW
Deadline Anchor : Hercules 118 type wire line anchor.
Front Guy Line Anchorage : Guy lines anchor to front of carrier. Includes wireline, tail chain, forged steel boomers, thimbles and clamps.
Drawworks Power : Two Caterpillar 3408 475 hp ea. Series Diesel Engines. No. 1 engine equipped with Allison CLBT-6061. No. 2 engine CLBT -6061 torque converter transmission with lock-up providing five forward and one reverse speed. Each engine equipped with variable speed governor, belt driven Bendix V-1000 (24 CFM) air compressor, horn warning system for high water temperature/low oil pressure, commercial silencing muffler, dry type air cleaner, air starters, and engine instruments. REEBUILT -0- HRS
Specifications : Basic Output : 475 HP per engine at 2100 RPM; Total HP 950 Cooling : Radiator with suction fan Starting : Air Transmission Speed : 5 forward, 1 reverse Shift Control : Air over hydraulic with air position indicator
Drawworks Drive : Allison CLT-6061 and CLBT-6061 combination torque converter transmission, each driving through Model 450 right angle drive to drawworks final drive compound. 5 forward speeds and 1 reverse to drawworks and rotary. REBUILT Rotary Drive : Heavy duty propeller type drive for rotary table through 27-1/2” size. Includes full air rotary clutch, herringbone reduction gear and oil bath chain elevated rotary drive from drawworks to rig floor. Elevated drive hinge mounted. REBUILT
Easy transport and rig-up on rig carrier. Chain drive always remains made up.
Specifications: (With Typical 3.75:1 Ratio Rotary Table) Maximum Rotary Table Speed – 220 RPM Rotary Speeds – 5 Forward and 1 Reverse Elevated Rotary Drive Chain – 1-1/2” Two Strand Propeller Shaft – Spicer 1880 final Drive, Spicer 1810 ahead of Elevated Drive Rotary Clutch – Two Plate 18”
Hydraulic Power : 36 GPM 2000 PSI (maximum) Pressure system, provided by either of two pumps. Tong selector valve and throttle control at driller’s position.
Wire Line Capacity: 335’ Max Pull: 8,800# (1st layer) Max. Speed: 95 FPM (At 35 GPM) (1st layer)
Mast : 117’, 350,000# Capacity, telescoping open face structural mast with legs of cold drawn AISI seamless alloy heat treated steel tubing. Constructed in two sections, the upper section telescoping into the lower section for over the road position. Adjustable support screws in mast legs; folding ladder, level and tilt indicator. MAST IS REBUILT AND HAS MPI INSPECTION
Crown Block Assembly : Integral type, welded box construction drilling crown assembly. Five 30” sheaves and one 36” offset sheave for fast line. 1-1/8” grooving ALL NEW BEARINGS
Crown Nest : With guard rail and expanded metal floor
Hydraulic Mast Raising, Lowering And Extending Mechanism : Two double acting, three stage telescoping type hydraulic rising and retracting cylinders. Upper mast section extending with two extending cylinders. Additional to mast hydraulics for dtwo engine rigs so that earthier engine of two engines rig may be used for hydraulic power functions. Includes pump, drive, manifolding, lines, control valves, oil reservoir and fluid. NEW
Mast Support : At front and rear of carrier, supporting mast in over-the –road position. NEW
Racking Board : Heavy duty welded construction with derrick man’s platform of expanded metal. Side-mounted racking fingers furnished to facilitate uniform racking and prevent swarming. Has locking pins at open ends. Maximum capacity 10,300’ of 4-1/2” drill pipe (6-1/2” tool joints) and automatic unfolding and folding of the Racking Board during extension and lowering of upper section of mast
Wind Guys : One set wind guys consisting of two 3⁄4” cables from crown and two 9/16” cables from racking board. Each equipped with 10’ tail chain. Used on Cabot cross type substructure.
Rig Base : 9’ wide x 40’ long x 6-1/2” deep. Structural steel covered with 1⁄4” plate top and bottom, complete with access hinged and loading capabilities. NEW
Substructure : Cabot “T” Type 17’ high “Scoping” Substructure.
Features - Derrick base and rig base 11’ x 13’ x 15’ with 5000 psi mud lines, BOP cart and rails, stairs, walkways, safety railings, V-door ramp, and catwalk.
Maximum rotary (casing load) is 450,000 lbs. simultaneous with a setback load of 200,000 lbs. for a total of 550,000 lbs. substructure capacity.
Generator House : 1 - 2010 Generac Series SD500 (500 KV AC) generator set powered by 16.12 liter Volvo diesel engine with 637 hours. Electric started, radiator, gauges, power manager digital control platform.
1 - 2500 Cat SR-5 455 KW Ac generator, rebuilt. Powered by Cat 3456 691HP engine with electric starter, gauges, Cat EMCPII diagnostic system, skidded.
1 - Sullivan Palatek rotary screw air compressor powered by 30HP electric motor with air tank.
All of the above mounted in 9’9” wide X 42’ long utility house with 2010 Square D motor controls and switch gear with EGS 75KV A transformer, safety florescent light, skidded.
Power Mud Pumps : 1 - Sentry S1-1000, 6 3⁄4” x 10” with quick change fluid end with pressurized lubrication system (1 1⁄2” x 2” lines wash pump) with electric 5” x 6” x 12” charge pumps with Sentry pulsation dampeners, 3 -5000psi relief valve, 3”- 5000psi pressure gauge all powered by 2010 Detroit Diesel 12V2000 engines- 1050 HP each, air volume tank, diesel day tank, oilfield type master skid.
1 – Gardner Denver PZ-8 with quick charge fluid end, pressurized lubrication system; pulsation down power, 3” 3000 psi relief valve, 3000 psi pressure gauge powered by CAT D-398 with air starter, air volume tank, diesel day tank, oilfield mater skid
3 Tank Mud System (700Bbls) : Shaker Tank - 4’ high x 9’8” wide x 32’ long mud shaker tank with 2 compartments. 7 1⁄2 HP mud agitators, 2- Derrick FLG-503 linear motion shale shake, 580gpm, 8 cone Odrill desilter, top mounted walkways, stairs, safety rails and safety florescent lights, All oilfield skidded.
Desander Tank - 4’ high x 9’8” wide x 42’ long mud desander tank with 2 compartments, 2 - 5hp mud agitators with 10’ electrical control room, for starters and control panels. 2-60hp 5’x6”x11” centrifugal pumps, All top mounted walkways, safety rails, and safety florescent lights. All oilfield skidded.
Suction Tank - 4’ high x 9’8” wide x 31’ long mud suction tank with 2 compartments, 1-5hp mud agitator, 2 60hp 5”x 6”x14” centrifugal pumps, 10’ porch with mud mixing hopper and electrical florescent lights. All oilfield skidded.
Rig Houses : Top doghouse-10’ wide x 40’ long with benches, 12 lockers, tool and bolt room, knowledge box, Satellite Auto Driller, Martin Decker 3 pin geolograph recorder, 2-220Volt electrical heaters, insulated, safety florescent lights, windows, covered porch, with electrically lowered stairs and landing with safety rails. All oilfield skidded.
Water tank- 9” high x 10’ wide x 42’ long with 8’x 10’ storage room with high pressure Cat wash down pump, water pump, 1-220 volt electric heater, has 4 hydraulic cylinders with control valve to raise and lower top dog house, safety florescent lights. All oilfield skidded.
Fuel/Accumulator Trailer : 53’ Aluminum step deck 2 axle spread trailer with 3,500 Gal. Baffled fuel tank, Cameron 5 station 8 bottle closing unit with electric Cat triplex pump. Skid mounted. Five Star wireline retrievers with line capacity of 15,000 ft., depth measuring counter hydraulic control with 15hp electric motor, oil caddy for motor oil, hydraulic oil and gear oil, used oil tank.
Blowout Preventer : 1 - 11” 5000Lb. Shaffer Style (U.S. Casting) studded 4” and 4 1⁄2” pipe and Blind rams.
1 - 11” 5000Lb. Shaffer Annular studded top, flange bottom
Choke manifold with two manual chokes
Handling Equipment : 4 – New pipe tubs 1 – New center tub with catwalk and V-door 1 – 40’ x 4 1⁄4 Hex Kelly with split master bushings NEW 1 – Varco Hydaulic spinner with forward and reverse 2 – BJ type B rotary tongs with heads to 9 5/8” 1 – BJ 4” Bottleneck drill pipe elevators 1 – BJ 4 1⁄2” Bottleneck drill pipe elevators 1 – 5 1⁄2” casing elevators 1 – 7” casing elevators 1 – 8 5/8” casing elevators 1 – Set each 4” and 4 1⁄2” drill pipe slips 1 – Set each 5 1⁄2”, 7”, and 8 5/8” casing slips 2 – Elevator links 1 – Tong line pull gauge 1 – All mud hard lines, vibrating lines, Kelly hose 12 – Fire extinguishers
Rig is refurbished with all new parts and has only drilled 5 wells since going to the field. Price: US$1,750,000
------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : Cabot 900 Series Land Rig for Sale 900hp Land Drilling Rig for Sale 2013 Refurbished Cabot Drill Rig for Sale Cabot 900 Drilling Rig For Sale 900hp Land Drilling Rig For Sale in USA Cabot 900 Series Refurbished Drill Rig -----------------------------------------------------------------------------------------------------------------------
Engine
Max Payload (for offshore) : 32,910 lbs, 14,930 kgs Refrigeration : Daikin, Carrier Transicold or Thermo King Set temperature range : -35ºc to +30ºc in ambient up to +50º Control : Integrated Microprocessor control unit. Slings : Units supplied with DNV certified slings Designed, Built and Certified - BS EN 12079:2006, DNV2.7-1, ISO/CSC
Offshore Heave Compensated Gangway for Sale 20.6M Gangway for Sale Heave Compensated Offshore Access System For Sale 20m heave compensated Offshore Access System (OAS) Suitable for DP2 offshore support vessels 70m length and above can operate in up to 2.5m significant wave height. Gangway is in USA Price & terms : Please enquire using the email form below If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed.
----------------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) - Offshore Heave Compensated Gangway for Sale Gangway for sale in USA Certified Heave Compensate Gangway for Sale Heave Compensated Gangway for sale in Europe Offshore Gangway - Heave Compensated Offshore Access System Certified Offshore Gangway for Sale 20.6M Gangway for Sale -------------------------------------------------------------------------------------------------------------------------------------------------
Jackup Drilling Rig For Sale F&G L-780 Mod. 0 Jackup Rig For Sale F&G Jackup Drilling Rig For Sale Specifications Rig Type : Jackup Rig Design : F&G L-780 Mod. 0 Year Built : 1981 Upgrade : 2003 Class : ABS Water Depth - Ft : 300 Drilling Depth - Ft : 11,000 (upgradable to 17,000 with Cantilever load limitations) Quarters : 100 Dimensions : 180' x 175' x 25' Helideck : 73' diameter for Sikorsky S-61 - CAP-437 compliant Variable Deckload - Operating : 4,486 kips Variable Deckload - Transit : 3,403 kips Number of Legs : 3 Leg Length : 406' 8" Usable Leg Below Hull : 356' Spud Can Diameter : 39.5' Cantilever Reach : 40' Transverse Movement : 10' port or starboard of centerline Max Combined Structure Load : 1,000 kips Bulk Mud & Cement : 9,600 cu ft Liquid Mud : 1,713 bbls Fuel Oil : 2,359 bbls Drill Water : 5,600 bbls Potable Water : 1,041 bbls Sack Storage : 3,000 sacks Drawworks : National 1320 UE w/1-3/8" drill line Derrick : Pyramid 30' x 30' x 157', 1,044 million lb. hook load capacity Top Drive : Varco TDS-4 w/- PH-85 pipe handler Pipe Handling System : Varco ST-80 Iron Roughneck Rotary : Oilwell C-375, 37-1/2 inch Top of Rotary Table to Bottom of Barge : 56 ft. Mud Pumps : (2) National 12-P-160 Main Engines : (5) Caterpillar D-399 Annular BOP : (1) Hydril 29-1/2" 500 psi; (1) Hydril 21-1/4" 2K Ram BOP : (1) 21-1/4" Cameron double 2K; (2) 13-5/8 Cameron Type U (doubles )10K Diverter : Hydril MSP 29-1/2" Solids Control : (4) MI Swaco BEM 650 Shale Shakers Cranes : (2) 2 Seatrax S7216, w/110' boom and 110' boom Mooring System : (4) 1-1/4" x 2,500' EIPS wire, Baldt 10,000lb LWT anchors Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed. ---------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) : Used Jackup Drilling Rig For Sale F&G L-780 Mod. Offshore Jackup Rig For Sale Oil & Gas Jackup Drilling Rig For Sale F&G Jackup Rigs for Sale Used Offshore Drilling Jackup Rigs For Sale --------------------------------------------------------------------------------------------------------------------------------
Accom / Pax : 3 Double cabins, shower, 2 x WC, AC Machinery : 2 x Caterpillar C18, Total 1200 bhp Speed : Economical Speed 8 knots
Drilling Rig - Ballerini ST4 - for Sale Ballerini ST4 Drilling Rig for Sale Used Drilling Rig for Sale in Europe
Model : ST4 Manufacturer : Ballerini Year : N/A Condition : Used
Description : Ballerini ST4 drill rig (similar to the Failing 2500 drill rig) Rated for 3,600’ ft (1,100m) depth, casing loads to 66000 lbs. (30,000 kg) Telescopic type mast with 58’ ft working space Drilling Line Spooling Capacity 1400’ ft Sand Line Spooling Capacity 3600; 2 Catheads mounted on sand line drum shaft, 8-5/8” 18” Rotary Table Engine power on board model VM 80HP Mud Pump Model Ballerini 5-1/2 x 8 Winches max shooting 20Ton. Ballerini 5"x 6" Mud Pump 180 HP Deck Engine 1 Kelly 7,50 mt Trailer Mounted Hours of work : 23.000 H Location : Europe
Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you.
The details mentioned above are believed to be accurate but are not guaranteed. --------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) : Used Ballerini ST4 Drilling rig for Sale Ballerini ST4 Drilling Rig for Sale Used Drilling Rig - Ballerini ST4 Drilling Rig for Sale Land Drilling Rig for Sale Used Drill Rig for Sale -------------------------------------------------------------------------------------------------------------------------------
Fast Crew Boat for sale 184 pax Fast Crew boat For Sale 1999 built Fast Passenger Ferry for sale Specification Built : 1999 Flag : Panama Class : BV, I+HULL +MACH +AUT-UMS Hull material : Light alloy LOA / Lbp x B x D : 31.80 / 27.00 x 6.70 x 1.70 m Draft : 2.1 m DWT / GRT / NRT : 50 / 164 / 66 T Passenger capacity : 184 Main engines : MTU 12V2000M70, 790 KW x 3 units Propulsion : MJP450 waterjets x 3 units Generators : CUMMINS, 40KW x 2 units Speed : 29 knots
The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------------------------------ Search words(for official use only) - Fast Crew boats For sale Fast Crewboats from China, Korea, Japan 184 pax Crewboat - 2003 built - for sale Crewboats for sale in Thailand, Malaysia, Indonesia Over 180 person Passenger Ferry for sale Crewboats for sale for West Africa, Nigeria, Libya Crewboats for sale in South America, North, Africa, Middle east 184 person Crewboat for sale Over 180 person Crewboat for sale Crewboats for South America, Brazil, Trinidad --------------------------------------------------------------------------------------------------------------------------------------------
Drawworks :
Engine No2 – Cat SR-4 350 KW, AC Generator p/b Caterpillar C-15 Diesel Engine with Electric start, radiator, electronic control panel.
Gardner-Denver CBSPLA rotary screw air compressor p/b baldor 20HP electric motor, mounted 120 gallon air receiver tank
Gardner-Denver CBSPLA rotary screw air compressor p/b baldor 20 HP electric motor, mounted 120 gallon air receiver tank.
General Electric E9000 Electrical Control Panes
Transformer – Hevi-Duty 112.5 KVA
Above mounted on shopbuilt 102’W x 32’L Utility House with lights, skidded
(2) Mission Magnum 5” x 6” centrifugal mixing pumps p/b marathon 75 HP electric motors
Shaker tank - shopbuilt 9’8”W x 5’H x 42’L, 348 bbl with 10’L covered porch, (3) compartment, (1) maxx 2000 mud agitator p/b 7-1/2 hp electric motor, flat bottom, internal plumbing, top mounted walkways, stairs, safety rails, lights, skidded.
Mission Magnum 5” x 6” centrifugal mixing pump p/b marathon 50 HP electric motor
Shale Shaker - National D235-LP-L1 Single, Single screen linear motion
Desander - National DSN-2H-10CTX with (2) 10” cones
Fuel Tank – shopbuilt 8’Dia. X 26’6”L, 9,976 gallon with 4’L porch, (2) fuel transfer pumps, skidded
Pipe Size
ID
OD
Length
Approx Buoyancy (kgs)
700
720
1400
2000
1850
800
820
4400
Horizontal pulling force @ 210 bar
5 Ton
Speed @ 15 liter / min @ 140 bar
60 m/min
Operation hydraulic oil
Tellus 32
Max water depth
2000 meter
Rope capacity (11 mm Dynex Dux 75 or similar)
20 Meter
Total weight in air
122 kg
Total weight in water
81 kg
Winch dimensions L x W x H
609 x 490 x 402 mm
