5000psi Annular BOP for sale - Used & Refurbished
Annular BOP For Sale - 5000psi

Annular BOP model Spherical
11” x 5.000 PSI – WP
Top studded x bottom flanged 5.000 PSI – WP

2 nos. available

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

----------------------------------------------------------------------------------------------------------------------------
Search words :
Used Annular BOP for sale
5000psi Annular BOP for sale
Refurbished Annular BOP model Spherical 5000psi
Spherical Annular BOP for sale
Annular BOP model Spherical 5000psi
---------------------------------------------------------------------------------------------------------------------------

Caterpillar 345C Excavator for Sale
Mining Equipment - 2006 Caterpillar Used Excavator

Year : 2006
Manufacturer : CATERPILLAR
Model : 345C
Condition : Used

EROPS, Air Conditioner, Auxiliary Hydraulics, Boom Length: 22'8", Coupler, Quick, Guarding,
Pattern Changer, Straight Travel Pedal,
Hours : 8,268
Location : USA

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------------------------
Search words :
Caterpillar 345C Excavator for Sale
Used Caterpillar 345C Excavator for Mining
2006 Caterpillar Excavator for Sale in USA
Mining Equipment Used Caterpillar Excavator
2006 Caterpillar 345C Used Excavator for Sale
-------------------------------------------------------------------------------------------------------------------------

New Coiled Tubing Unit for Sale
Coiled Tubing Unit - New - 25K
25K Coiled Tubing Unit for Sale
New CT Rig for Sale

Specifications

Section 1 – Truck: 8x4 (Tandem-Tandem)
- Truck Chassis : Kenworth, 8 x 4 (twin steer) or equivalent.
- Engine : Detroit 550 hp at 2100RPM
- Transmission : Eaton Fuller, 18 forward, 4 reverse
- Front Tires : 65R22.5 x 18 Ply
- Rear Tires : 11:00 R24.5, 14 Ply
- Suspension : Accuride Steel Flotation
- Front Axle : Six foot Centres, 20,000 lbs
- Rear Axle : 46,000 lbs
- Weight : approx. 19,500 lbs. (approx. 9,000 kg.)
- Wheelbase : Length from centre of front axle to rear of frame 420”

Section 2 – Fabco Power Transfer Case
- Rear bogies can be disengaged and power transferred to the top of the transfer
 case, which drives the pumps and the compressor
- Single-piece construction provides rigidity necessary to withstand off-highway use
- Constant mesh gears assure long service life
- Ball bearing mounted gears and shafts prevent premature malfunctions
- Upper rear outlet capped off
- Upper front outlet SAE “E”, 4-bolt hydraulic pump mount

Section 3: 2000 PSI Hurricane Compressor
- Belt driven via a pulley arrangement to attain the maximum operating speed required
for the unit.  Belt drive is recommended to reduce shock to the drive system
- 600 CFM
- Maximum Pressure: 2,000 PSIG
- 1800 RPM maximum speed
- 4-Stage compressor
- First Stage: 4-cylinders, 5-1/2” bore
- Second Stage: 2-cylinders, 3” bore
- Third Stage: 1-cylinder, 2-1/2” bore
- Fourth Stage: 1-cylinder, 1-3/8” bore
- Stroke: 4-3/4”
- 26-Quart oil capacity
- 10-1/2 Gallon Coolant capacity
- Inter-Stage pressure gauge

- Oil pressure gauge
- High 1st-Stage pressure
- High Inter-stage and Discharge Temperature
- Low oil pressure
- Relief valves after each stage and discharge
- Air cleaner, 2-stage, heavy-duty
- Inter-coolers and traps between each stage
- Full flow oil filter
- Self-contained cooling system

Optional
Compressor with 1st,2nd, 3rd Stage Overhead Cooling

Overhung Drive: SAE ‘D’ Pump Drive with pump case vent, filled with oil, splined inboard shaft,
and Keyed outboard shaft. SAE #2 Flywheel Flexplate with splined shaft. SAE #2 Flywheel
Housing.

Section 4: Control Panel Assembly
- A full width Control Console is installed at the rear of the unit.  Console face is stainless steel
construction and fully engraved, or back coloured lexan reversed engraved with all gauge and
control information
- Air pressure gauge
- Auxiliary systems hydraulic pressure gauge
- B.O.P. control valve bank, c/w two-tier activation system
- B.O.P  accumulator bleed valve (on accumulator bottle)
- B.O.P  pressure gauge.
- Circulation and wellhead pressure gauge (0 – 6,000 psig)
- CTU air supply valve
- Dual acting, +25,000 lb. Weight indicator
- Engine coolant temperature gauge

- Engine emergency kill valve (red knob)
- Engine oil pressure gauge
- Engine starter switch
- Engine stop control (Normal)
- Engine tachometer
- Engine throttle control
- Engine volt meter
- Horn control valve
- Injector brake release pressure gauge

- Injector chain tension control
- Injector chain tension pressure gauge
- Injector control (“Speed Control and Direction Control”)
- Injector “in-hole – out-hole” pressure controls (drive pressure)
- Injector “in-hole – out-hole” pressure gauges
- Injector pump, charge pressure gauge
- Injector skate pressure control c/w pressure gauge.
- Installed near Control Panel will be a back-up hydraulic pump system (Injector Skate Pressure,
- Stripper Pressure & BOP).  Other miscellaneous gauges and controls to provide full operation
of the unit.

- Light switches
- Panel mounted circuit breakers
- Stripper Pack and Retract pressure gauge
- Stripper pump control valve
- Stripper Pack/Retract hydraulic control valve
- Tubing reel brake release control valve
- Tubing reel manual control
- Tubing reel tension control valve (Reel Drag)
- Tubing reel tension gauge (Reel Drag)

Section 5: Tubing Reel Assembly
- The OS 4500 reel utilizes lightweight but extremely strong elliptical heads to support the reel
spool.
- 1-1/2” Rotary Swivel Joint, rated at 10,000 psig, Working Pressure the swivel will be flange
mounted to the main reel shaft to permit continuous circulation during tubing operations.
- The OS 4500 utilizes a direct planetary drive; this eliminates the drive chain and guard
assembly.
- The Spring applied Hydraulic actuated failsafe brake is mounted between the hydraulic
drive motor and the planetary drive.
- Reel maximum capacity: 4500 m. (14,753 ft.) of 1-1/4” diameter coiled tubing.
- Core size is 60” width is 48” OD is 106”

- Reel is a transverse type (side to side movement).  No leadscrew is used.
- Reel is mounted on a heavy-duty tubular support tower, which is mounted on a heavy-
duty tubular steel skid base. (The base may be modified to suit customer)
- Reel outer spokes are built from hollow structural steel tubes.
- Reel supplied with chain and load boomer transport locking system
- Rotation pins for transverse movement (Driver side only)
- The External High Pressure Manifold is complete with two (2) inlets and two (2) separate
low torque - FMC or equivalent plug valves.  Connected to this arrangement is a diaphragm
protector (for monitoring of the Circulating Pressure), which in turn is attached to the Rotating
Swivel Joint.

- The Internal Pressure Manifold is provided with a medium pressure ball valve between
the reel axle and the coiled tubing.
- The reel shaft is manufactured from steel pipe with a steel stub shaft welded at one end,
the second end will have the planetary drive adaptor ring. The end of the shaft opposite the
drive system is bored out to allow passage of a medium via the Rotary Swivel Joint to the
coiled tubing. Tubing reel shaft is supported by one (1) bearing on the swivel side and by the
planetary drive on the drive side. This is then mounted on a heavy-duty steel frame assembly.
The tubing reel can be removed from the truck deck by removing the transport/operational
locking pins.

Section 6: 25K Injector
- Tubing Injection/Retraction Speed: 0 – 400 ft. / min.
- Rated at 25,000 lb. Pull; 15,000 lb. Push
- The 25K Injector Head has been engineered to meet the most rigorous applications for
land or offshore applications.
- Gripper Blocks are of rugged design.
- Drive chains use a 1-1/2” pitch, 3-strand oilfield roller chain with the pins going all the way
through the gripper blocks for extra strength.  Drive chains will be fitted with one (1) set of gripper
blocks in a size requested by the customer (1” through 2”)
- Bottom adjustable shaft, complete with grease nipple is mounted on sealed spherical roller
bearings

- High ratio planetary drives power the drive sprockets, which provides accurate control at low
speeds. - Variable displacement piston hydraulic motors and fail-safe disc brakes complete the
assembly.
- Fail-safe disc brakes are located between the motors and the gearboxes.
- Variable displacement piston hydraulic motors, eliminating the need to stop to shift gears.
- Drive shafts, skates, sprockets, idler shafts and cross shafts are made from high quality steel.
- Independent, full floating, self-centering roller skate is utilized to apply tubing friction pressure to
tubing push/pull.

- Gripping force is applied using a superior flat black chain with rollers.
- Lightweight, high strength tubular steel construction.
- Maximum width 2’ 9-5/8”
- Base 23” x 37”
- Overall Height 54”
- Hydraulic cylinders apply tubing friction pressure through each of the skates.
- These hydraulic cylinders are conservatively sized to provide extra squeeze to prevent slipping on
even lubricated coil tubing.  Cylinders are positioned for easy removal for service.

- Independent accumulators cushion all skate pressure cylinders.
- Pressure lubrication system is incorporated into the design of the injector
- All grease nipples are easily accessible
- Electrical or mechanical, Load Cell is positioned between the bottom of the injector and the
base frame.
- Hydraulic hoses on injector are routed to a common Bulkhead Injector head is mounted into a
separate Upper and Lower welded tubular support and protective framework.
- Removable mount for tubing stripper/packer in lower sub-frame weldment with all hydraulic
connections made through the injector bulkhead.
- The injector component design is made as accessible as possible with only high quality
materials used to ensure durability.
- Excess lubricant catch pan with drain fitting is installed in injector sub-frame with drain plug.
- All welded components are sandblasted, primed and painted in a single colour to customer
specifications.

Section 7: Guide Arch
- Forty-eight (48”) or Sixty-inch (60”) tubing guide arch assembly is complete with nylatron guide
arch rollers.
Alternate sizes of tubing guide arches are available.
- Guide Arch comes with 5 equal spaced hold down clamps for even tubing load.
- The guide arch hinges midway to reduce size for ease of transport.

Section 8: Hydraulic Hose Package
Injector Control Hoses :
- Complete with 65 ft. of hose (each hose) for injector operation from the Control Console.

Section 9: Fasi Knuckle Boom Crane
- Mounted near the rear of the truck chassis
- Total extension of crane = 13.3m
- Lifting capacity at 2.1m = 10,500kg
- Crane controls are mounted at rear of crane or at another location as designated by customer
- Outriggers are controlled and mounted at the rear of the truck

Section 10: Injection Pump – Model 3517 CAT Pump
- Small triplex injection pump for soap or chemicals
- Storage cabinet houses the triplex pump
- Maximum volume: 14 gpm
- Maximum discharge pressure: 3,000 psi
- Maximum speed: 800 rpm
- Crankcase capacity; 4.2 quarts
- Inlet ports; 1-1/2” NPT
- Discharge ports: 1” NPT
- Wetted seal port keeps high-pressure seals completely lubricated
- Lubricated low-pressure seal provides double protection against leakage
- 316 stainless steel valves, seats and springs

Section 11: Tank and Stand
- Stainless steel storage tank for soaps, chemicals or other agents is kept from freezing in winter
by heat from the engine water jacket. In addition a Proheat heater is tied into the engine water
jacket, it too may provide heat to the tanks.
- The triplex pump uses this storage tank to draw its supply for the injection of chemicals, soap,
etc. into the coil tubing.

Section 12: Cold Weather Package
- Diesel fired Proheat, coolant heater provides a dependable means of preheating or maintaining
heat in water-cooled engines and fluid circuits.
- The heater simply pumps coolant from the engine, increases the temperature of the fluid and
returns to the engine.
- Since the heater runs on diesel fuel and a 24-volt power source, it operates independently from
the vehicle engine.  A temperature regulating switch in the unit automatically cycles the heater
to maintain a temperature from 70 degrees C. to 85 degrees C.
- The heater is operated by a push-pull switch.  Thermostat and timer controlled heating elements
are positioned in the hydraulic tank and the soap tank.  This enables heat generated from the
heater/engine to keep these fluids warm during shutdown or travel to a well site

Section 13: BOP Control
The system proposed below is a hydraulic-over-hydraulic system and consists of the following
components :
- Nitrogen (N2) back-up activation switch, c/w lift-up arming feature
- Pressure reducing valve and gauge for variable pressure out to the auxiliary BOP
- There are two control panels, one at the rear of the unit and one at the front of the unit.

Section 14: Mounted Mid-Ship Of The Unit
- Two (2) 11-gallon accumulators
- Nitrogen storage bottle bracket (N2 bottle to be supplied by Customer)

Section 15: Hydraulic Tanks
There Are Two Hydraulic Tanks
- The Main Hydraulic Tank Contains 80 gallons.
- The BOP Hydraulic tank Contains 30gallons.

Section 16: Tool Boxes
There Are a Total Of Two Tool Boxes.
- The Tool Box Is Mounted On The Drivers Side Of The Unit.This Box Is Of Rugged Steel
Construction, c/w Two Doors That Open out Horizontally To Each Side.The Dimensions
are Height 40”, Width 30”,  Depth 20”.
- The Junk Box Is Mounted On The Passenger Side of The unit This Box Is Of Rugged Steel
Construction, c/w Two Doors That Open Vertically.The Dimensions Are Height 20”, Width 36”,
Depth 20”.

Section 17: Miscellaneous
- Two Methanol Tanks, (1) one for soap tank, (1) one for air lines.
- Steps on compressor drive belt and soap pump box and reel for ease of access.
- Check valves coming from Air Compressor, (1) one in-line popet type, (1) one flapper type.
- Numbered bulkhead connections on control panel and from Triplex Pump Box
- Pintle Hitche locks with releasing of air brakes.
- Sight glasses on tanks will be on front of all tanks for easy viewing and will have dial
temperature gauge build in.
- Valve to shift Pro-heat from engine and soap tank to hydraulic tank and compressor will be
mounted in triplex box. The engine coolant will then warm the soap tank.
- Rig Lights will be Halogen with 8 external and one for each toolbox and one for the control panel.
- Drum reversal to be mounted beside control panel for easy access. Hub odometer will be
mounted on truck.

- Headache rack mounted on compressor to protect compressor and cab.
- Toolboxes will extend down to lowest point on truck for maximum space.
- 6’ Air Hose quick connection at back of truck and in truck cab.
- Brake lockout valve for front chain and back chain of injector to be mounted on control panel.
- Inside of toolboxes to be painted white.
- Top of toolboxes will mount flush with top of deck with grip material to provide a non-slip surface.
- Hose bundles to injector head to be wrapped in nylon fire hose, or suitable material that meets
customer approval.

- Aluminum checker plate to be used unit in centre of unit to reduce weight.
- The seller will do supply and Mounting of Fabco Power Transfer Case.
- Modify front bumper for tire chain holders.
- Rear hose bundle box to be constructed with a steel frame and aluminum bar grate sides and
bottom to reduce weight.

Section 18 – Documentation and General
- Four (4) sets of electronic manuals to be supplied with each unit
- Operational temperature range: -40 to +40 Degrees C.
- All components supplied by the seller will be NEW and UNUSED.
- All components painted to customer specifications – single color scheme.
- Mounting of all components is included in stated pricing.
- All equipment will be tested and fully operational prior to final shipment.
- Inspections at the seller’s plant are welcomed at the convenience of the purchaser.
- Purchaser will be responsible for travel, food and lodging costs during inspection.

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
------------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
New Coiled Tubing Unit for Sale
Coiled Tubing Unit - 25K
New 25K CT Rig for Sale
CT Rig for Sale
25K coiled tubing unit for sale
Rig for sale - New 25K Coiled Tubing Unit
------------------------------------------------------------------------------------------------------------------------------------

1200bhp Towing Tug For Sale
Newbuilding 1200bhp Towing Tug For Sale

Principal Particulars
Class : NKK
Length Overall : 23.500m
Length B.P. : 21.322m
Breadth Moulded : 7.315m
Depth Moulded : 3.200m
Draft Moulded : 2.700m
Trial Speed : approx 10 knots

Machinery
Main Engine : Cummins KTA19-M3, 2 x 600BHP / 1800 rpm
Gear box : Twin Disc MG5170, Ratio: 5.00:1
Propeller : 2 x Solid Fixed Pitch Propellers
Main Generator : 2 x Cummins / Yanmar 24kw

Tankage
Fuel oil : 82.70M³
Fresh water : 25.00M³
Ballast : 29.00M³

Deck Machinery
Anchor : 2 x stockless bower anchors (360kg)
Chain Cable : 17.5mm Nine (9) lengths of Grade U2 chain
Anchor Windlass : 17.5mm anchor windlass
Towing Hook : 1 x 20 tons

Navigation & Communication Equipment
Echo sounder : 1
GPS : 1
Radar : 1
6” Compass : 1
4” Spare compass : 1
SSB Transceiver : 1
ICOM VHF IC-M45 : 1
EPIRM : 1
Klaxon horn : 1
Battery clock : 1
Barometer : 1
Binocular : 1
Clinometer : 1
Marine clock : 1
Ship bell : 1
Floodlight : 4
Searchlight : 1

Auxiliary Equipment
F.O. Transfer pump : 1 x 4HP Wonder three phase induction motor c/w self-priming
pump 2DV Y100L-4
Bilge & Ballast pump : 1 x 4HP Wonder phase induction motor c/w self-priming pump
2DV Y100L-2
GS pump & fire pump : 1 x 4HP Wonder three phase induction motor c/w self-priming
pump 2 DV Y100L-2
Oily water separator : 0.25M³/hr

Fire Fighting System
2½ IB Fireman Axe : 1 set
Three Foam : 1 unit
Extinguisher fire buckets : 3 sets
Fire extinguisher : 8 sets
Portable diesel fire pump : 1 set

Life Saving Equipment
Life Raft : 8 sets
Life Buoy light : 4 sets
Fireman outfit : 1 set
Life Jackets with lights : 14 sets
Parachute distress : 12 units
Smoke signal : 2 sets
10 men Liferaft with Hydrostatic release units : 2 sets

Accommodation
Total Complement : 10 Crews

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) :
Newbuilding 1200bhp Towing Tug For Sale
Towing Tug For Sale
1200 bhp Towing Tug in Singapore
1200 bhp Towing Tug in Malaysia
1200 bhp Towing Tug in Far East
---------------------------------------------------------------------------------------------------------------------------

DP-II WorkBoat 75m for Sale
WorkBoat for Sale

Principal Particulars
Length Overall : 75.00 m
Length Waterline : 71.40 m
Breadth Moulded : 20.40 m
Depth Moulded : 7.00 m
Design Draft : 5.30 m
GRT / NRT : 3906/1171
Class : American Bureau of Shipping
DPS·2 For Unrestricted Service

Deck Equipment
Anchor Windlass :
1 x electro-hydrau lic Macgregor / PC-HAW/GG-50
Gypsies :
suit for 50 mm chains rated pull 10.6 mt @ 10 m/min
Warping drum : 400 mm (dia) x 660 mm (L)
Bow Anchors : 2 x 3,060 kg StockJess Bower anchors
Chains :
495 Total Length x 38 mm (dia) Grade 2
Capstan :
2 x 5 mI@ l 5m/minelectro-hydraulic;
MacGregor / PC·HVC-05/400
Mooring Winch :
4 x 50 mt @ 10m/min eleclro-llydraulic;
Macgregor / PC-HMW/SD-4O/090D
Drum Capacity : 1500 m (L) x 38 mm
(0)SWR
Deck Crane Capacity : 45T@ 8m
Personel Lift : 1.5 T@ all radi
Provision Crane :
1 x electro-hydraulic Amco Veba /807/3S - 3 Ton @ 1.7m

Accomodation
Beths : 8 x 1 berth cabins = 8
6 x 2 berth cabins = 12
30 x 4 berth cabins = 120
Total : 140
Hospital : 1 x 2 berth cabin = 2
All cabins fully air-conditioned & c/w attached washroom.

Fire Fighting Equipment & Anti-Pollution Equipment
Internal
Emergency Fire Pump :
1 x 40 cbm/hr @ 45m head; Bombas Azcue
BA Recharging Comp :
1 x 100 hr/min @ 200 bar Brand/ModeITBA
CO2 system in engine room
Fire Detection & Alarm System in living spaces & engine room.

Radio and Navigation Equipment
GMDSS : Furuno RC-1800T 250W (Area 3) comprising :
SSB : 1 x Furuno FS·2570 with buiH in DSC
Inmarsat C : Felcom-15 SSAS & LRIT
VHF Radio : 2 x Furuno FM-8800S with built in DSC
Navtex Receiver : 1 x Furuno NX-700 (518 KHz)
SART : 2 x McMurdo S4
EPIRB : 1 x McMurdo E5
Portable VHF Radios : 3 x McMurdo R2 (25KHz)
Radar (S-Band) : 1 x Furuno FAR-2137S ARPA 96 NM
Radar (X-Band) : 1 x Furuno FAR-2117 RP-ARPA 96 NM
Echo Sounder : 1 x Furuno FE·700
GPS : 3 x Veripos LD3 System
GPS : 1 x Furuno GP-150
Gyrocompass : 3 x Anschuetz Standard 22
Autopilot : 1 x Anschuetz Pilotstar D
Magnetic Compass : 1 x Cassens & Plath REFLECTA 1
Weather Fax : 1 x Furuno FAX408
Speed Log : 1 x Furuno DS-80
Wind Indicator :
3 x Gill lnstruments WindObserver II 1390-PK-006
AIS : 1 x FurunoFA·15O
VDR : 1 x Furuno VR-3000
DP : Converteam Duplex C-Series
Joystick : Converteam Independent Joystick
Vessel also fitted with Vingtor PA Talkbalk System &
Self-Powered Telephones

Miscellaneous
Liferafts : 4 x 25 men SOLAS approved type
Life Boat : 2 x 60 men totally enclosed Vanguard
Rescue Boat : 1 x 8 men Rescue Boat
Inboard Diesel Engine Driven Vanguard
Oily Water Separator : l x 1 cbm/hrc/w15ppm
Water Maker : 2 x 20 cbm/day Reverse Osmosis, Coffin
Sewage Treatment Plant : 1 x 140 men; Hamworthy / ST13

Performance
Maximum Speed : 12 knots at MCR
Type of Fuel : Marine Diesel Oil
Fuel Consumption :
Approx 17 cbm/24hr @85%MCR(MainEngine)
Approx 20 cbm/24hr (5 X CAT 3412 gen sets)
Approx 4.5 cbm/24hr (CAT C32 Thruster Engine)

Cargo Capacities
Deadweight : 2660 m/t
Deck Cargo : 800 m/t
Deck Strength : 5.0 mt/m21 uniform loading
Clear Deck Area : 650 sq.m
Fuel Oil : 1,180 cbm
Fresh Water : 830 cbm
Ballast Water : 1,644 cbm
Freezer / Chiller : TBC
Foam / Detergent : TBC

Pumps
Fuel Oil :
1 x 30 cbm/hr @ 20m head; Bombas Azcue
Fresh Water :
1 x 60 cbm/hr @ 40m head; Bombas Azcue
Bilge / Fire Pump :
3 x 60 cbm/hr @ 45m head;BombasAzcue
Bilge / Ballast Pump :
1 x 150 cbm/hr @ 25m head; Bombas Azcue

Propulsion System
Main Engines  :
2 x 1,600 kWm @ 1,000 rpmWartsila 8L20
Main Generators :
5 x S90 ekW @ 1,800 rpm Caterpillar / 3412C cJw alternator SR4
Emergency Generator :
1 x 99 ekw @ 1,800 rpmCaterpiliar / C4.4 rate at 99 ekW/440
V/3 Ph/60Hz
Shaft Generator : NIL
Bow Thruster :
1 x Caterpillar C32 1,000 bhp diesel engine driven HRP 5007 TT
tunnel type (CPP); 11.5 T thrust
Stern Thruster :
HRP 5007 IT tunnel type (CPP); 8T thrust
Steering Gear :
2 x Wagner LA2 7. 1-45-CB2 7.1 TM; 45 deg
Propulsion : 2 x CPP in Kort Nozzles; Ups 40650
Rudders : 2 x Becker Rudder / SA 20S0 203 F.2

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
-----------------------------------------------------------------------------------
Search words (for official use only) -
DP-II WorkBoat 75m for Sale
Workboats for Sale
75m WorkBoat for Sale
----------------------------------------------------------------------------------

Lattice Boom Crane Offshore for Sale
Offshore Lattice Boom Crane - 150 ton

General Specification
Slewing Angle : 360º(Continus)
Slewing Speed(Full Load) : 0~0.6rpm
Luffing Time(Full Load) : 250s Up/down
Luffing Angle : +15° ~ +82°
Parking Angle : -0° ~ +15°
Operator Cabin : Left Side

Main Winch Data
Lifting Capacity(SWL) : 150T@12m,28.5T@46m
No. Of Fall : 4
Working Radius : 9.0m(Min) / 46m(Max)
Main Lifting Speed : (0-150T) : 0~10m/min
Main Lifting Speed : (0-90T) : 0~18m/min
Hook Travel : 51m

Aux Winch Data
Lifting Capacity(SWL)  : 16T@49m, Man Riding :1.5T
No. Of Fall : 1
Working Radius : 11m(Min) / 49m(Max)
Main Lifting Speed(Full Loading) : 0~48m/min
Lifting Height : 56m

Note
All operational speeds stated above are based on average volumetric
efficiencies provided by our suppliers of hydraulic components.
A speed variation tolerance of +10% to -5% is within the accepted range
and should be taken into consideration.

Hydraulic Arrangement
Hydraulic Systems
The hydraulic transmission will be designed for optimum performance
within the constraint of available horsepower. High pressure hydraulic
system uses power more efficiently and applies power as needed.

All motions controls offer infinitely variable speed and full reversing
characteristics. Two full flow filters will be installed. The filter(s) will
be adequately sized for full flow operation without causing pump
cavitation. Replaceable wire mesh filter cartridge of minimum
absolute value of 40 micron will be used. The pumps will have
overflow suction independent of the reservoir, and the arrangement
of piping can avoid air pockets.

Hoisting Circuit
Each winch is driven by a common open loop hydraulic system
including piston pump, piston motor and epicycles gearbox. Each
winch is fitted with oil immersed, multi-disc and dynamically rated
“fail safe” brake.

The fixed displacement hoist motors offer a constant operating speed.

Slewing Circuit
The slew circuit is driven by a common open loop hydraulic system.
Dynamic braking of slewing is by means of hydrostatic compensation.
Similarly positive locking brakes are fitted in the circuit and used as
static brake;

Luffing Circuit
Luff circuit is driven by a common open loop hydraulic system. Each
winch is fitted with oil immersed, multi-disc,dynamically rated “fail safe”
brake. an additional luff  ratchet cylinder is included, providing a positive
means of locking the luff drum whenever the prime mover is shutdown.

Hydraulic Piping
1. Pipes: No pipe threads will be used for the high-pressure lines larger
than 3/8". Hydraulic components that have pipe threaded ports lines will
have a minimum working pressure 300PS.

2. Pipe fittings: Zinc plated mild steel material. External fittings are
painted and protected by Denso tape or equivalent against corrosion.

3. Hoses: High rubber quality for best resistance against sunlight and
salinity, Wire breaded for applicable specified hydraulic pressure ratings

4. Hose couplings: Zinc plated mild steel material, External couplings
are painted and protected by Denso tape or equivalent against corrosion

Hydraulic Oil Tank
1. Level gauge with isolating valve (to top cover)
2. Inspection and cleaning cover
3. Filter with fine mesh stainless steel strainer and ventilation
4. A relief valve will be installed in the discharge line of pump.

Cooling Circuit
The air-oil heat exchanger will be provided and sized to ensure
continuous operation of the crane under the ambient temperatures
given on the data sheets.

Electric Arrangement
Standards, Codes and Protection
Refer to Codes Of Practice and Standards. The electrical systems
onboard the crane complies with these standards for good offshore
electrical design and engineering practices.

Standard Lighting
The following are provided as standard lighting packages for the crane.
More lights can be added according to client's request.

Description : Aviation Warning Light
Quantity : 1
Size : 85W
Location : Boom Tip
Power Supply : UPS

Description : Aviation Warning Light
Quantity : 1
Size : 85W
Location : Mast
Power Supply : UPS

Description : Florescent Access Light
(with 90 min back-up battery)
Quantity : 2
Size : 2 x 36 W
Location : Access Way Outside Cabin
Power Supply : Main

Description : Florescent Access Light
Quantity : 2
Size : 2 x 36 W
Location : Machinery House
Power Supply : Main

Description : Florescent Access Light
(with 90 min back-up battery)
Quantity : 1
Size : 2 x 18 W
Location : Cabin
Power Supply : Main

Description : High Pressure Sodium Floodlight
Quantity : *
Size : 400 W
Location : Boom
Power Supply : Main

Power Supply
Main Power Supply : 415 VAC ,  03 Phase ,  50 Hz
Uninterrupted Power Supply : 230 VAC ,  01 Phase ,  50 Hz

Others
Junction box(es) is provided at the pedestal interface for connection
to client supply.
By default only SS316 junction boxes are installed onboard.

Generally cable wires will be multi-stranded copper and protected
against mechanical damage. All power and control cables are with
XLPE/EVA/GSWB/EVA construction. Occasionally able of
XLPE/EVA/CWB/EVA is used when big power cable is part of
the design.  All electrical lines are tagged accordingly for ease of
maintenance.

All outdoor equipments and instruments are Ingress Protected IP56.
Indoor equipments and instruments are rated with IP44 as minimum.

Ordinarily, the power supply for crane is transmitted from pedestal to
slewing platform through the centre slip ring to ensure the crane can
work at any angle.

Controls and Instruments
Cabin
The following instruments are arranged on the console to permit the
operator to maintain an uninterrupted view of the loads and instrumentation.
The two(2) motion controls joysticks designed according to API-2C, are
ergonomically correct and easy to handle. All instruments are clearly labeled.
1. Motion Control Joysticks:
2. “Dead-Man” Type
- Position sensitive with motion and speed infinitely variable and proportional to
 movement  from spring-return central position.
-  Luff and slew (single left) joystick
-  Main and auxiliary hoist (single right) joystick
-  Prime Mover Start/Stop Switch
-  Prime Mover Emergency Shutdown Switch
-  Slew Brake Control Lever for option
-  Safe Load Indicator System
-  Visual and Audible Annunciator Panel
-  Boom Hoist Down Override Switch
-  Pressure Gauges: Boast Control / Hoist / Slew / Luff
-  Electrical Switches:
-  Lighting
-  Windshield Wipers & Washer
-  Warning Horn
-  Air Conditioning
-  Main and Auxiliary Hoist selector
-  Tachometer

Hoist Mechanisms
Hoist Winch Data
Feature : Hoist Drum
Description : Material
Details : Cast Steel
Remark : 100% NDT

Description : Groove
Remark : Reeving not over 3 layers

Description : Support End
Details : Anti-friction Bearing

Feature : Braking
Description : Type
Details : 1 x Band Brake
Remark : Asbestos free lining, for man riding winch only.

Details : 1 x Multi-disc Brake
Remark : Positive Locking

Details : 1x Load valve
Remark : As dynamic Brake

Description : Safety Factor
Details : Minimum 2.0

Feature : Rope Anchors
Description : Type
Details : Bolted rope clamp
Remark : For ease of rope replacement

Description : Safety Factor
Details : Minimum 1.1
Remark : Ensures rope breaking strength when over loaded

Feature : Ratios
Description : Drum to Rope
Details : Min.19 : 1
Remark : Drum pitch diameter over rope diameter

Feature : Safety
Description : Drum flange beyond top layer
Details : 2.5 x rope diameter
Remark : To avoid rope jumping out of drum unintentionally

Description : Fleet angle
Details : < 2.5⁰
Remark : Ensures smooth and even rope spooling at all times

Description : Dead turns on the drum
Details : Min.5
Remark : Amount of rope that is not in used even at the
maximum hoist reach of the crane

Auxiliary hoist are designed with same data, except that it
is also designed for personnel lifting.

Luffing System
Feature : Hoist Drum
Description : Material
Details : Cast Steel
Remark : 100% NDT

Description : Groove
Remark : Reeving not over 3 layers

Description : Support End
Details : Anti-friction Bearing

Feature : Braking
Description : Type
Details : 1x Load valve
Remark : As dynamic Brake

Details : 1 x Multi-disc Brake
Remark : Positive Locking

Details : ratchet and pawl
Remark : Luffing locking device

Description : Safety Factor
Details : Minimum 2.0

Feature : Rope Anchors
Description : Type
Details : Bolted rope clamp
Remark : For ease of rope replacement

Description : Safety Factor
Details : Minimum 1.1
Remark :  Ensures rope breaking strength when over loaded

Feature : Ratios
Description : Drum to Rope
Details : Min.19 : 1
Remark : Drum pitch diameter over rope diameter

Feature : Safety
Description : Drum flange beyond top layer
Details : 2.5 x rope diameter
Remark : To avoid rope jumping out of drum unintentionally

Description : Fleet angle
Details : < 2.5⁰
Remark : Ensures smooth and even rope spooling at all times

Description : Dead turns on the drum
Details : Min.5
Remark : Amount of rope that is not in used even at the
maximum hoist reach of the crane.

Boom Luffing-in limit buffer
Mast
The Luffing sheaves are placed on the mast (A-frame) which is fitted with
a top platform for maintenance and inspection of the mast head sheaves,
luff hoist rope and anchor connections. Access to the Top Platform is by
ladder from the machinery deck. The ast is pin connected to the machinery
deck.

Bridle
 N/A

Slew Mechanisms
Slew Bearing
Brand- ROTHE-ERDE XUZHOU or equivalent
Rolling Element- Triple Cylindrical Roller
Lubrication
- Grease holes in diagonal orientation in outer ring
- Lubrication lines are fitted on the machinery deck for refilling grease
into the bearing

Slew Drive
Type- Fixed displacement hydraulic motor
Gearbox- Epicyclical
Brake- Oil immersed multi-disc brake(s)
Operating Conditions- Slew design wind speed 24m/s
Pinions- Four(4)
Emergency slewing is possible with one (1) pinion

Boom
Length - 47M & 49M
Type - Reinforced Lattice Structure
Pins - High Tensile
Connectors - Cast Steel
Welding Test - NDT 100% MPI, 100% UT/RT
Boom Top Platform  - Both Sides

Safety
Hardwood blocks-  To prevent rubbing of ropes on boom bracing
damaging paint and cause unnecessary rusting.
Walkway paths- 760mm wide grating along and inside of boom for
maintenance access Handrails- Along boom section

Boom Bottom
Type- Reinforced Lattice Structure
Material- High tensile low alloy low carbon seamless chords with mild
steel bracings

Boom Intermediate Section
Type - Reinforced Lattice Structure
Material - High Tensile Low Alloy Low Carbon Seamless Chords with
mild steel bracings

Boom Head
Type - Reinforced Lattice Structure
Material
- High Tensile Low Alloy Low Carbon Seamless Chords
- With Mild Steel Bracings
- High Strength Steel Head Plate

Reeving System
Sheaves
Materials - Steel
Processing Technique - Cast
Ratio - 20 : 1 (Sheave diameter / Rope diameter)
Lubrication - Lubrication through sheave pin
Bearing - Heavy duty sealed cylindrical roller

Ropes Rope Size (mm)
Design Factor -
Main Hoist and Auxiliary Hoist : Minimum 5.0
Luff Hoist and Pendant : Minimum 4.0

Rotation Characteristic -
Main Hoist  and Auxiliary Hoist : Non-Rotating
Luff Hoist : Low Rotation
Pendant : Non-Rotating

Construction -
Main Hoist and Auxiliary Hoist : RH and WSC
Luff Hoist : RH and IWRC
Pendant : WSC

End Connections : Solid Thimble
Finishing : Compacted and Galvanized

Hooks
Basic design factor of the hook is more than 4.0. The hooks are made of
cast steel and tested to -40°C, or -6°C below lowest design temperature.
All hooks come with lockable safety latch and swivel bearings.  Hook
blocks will be of significant weight to prevent unraveling of rope while unloaded.

Machinery Deck
Machinery Turret
The Turret is made of high strength steel.  Depending on crane model
and configuration, most mechanical and control components such as the
Power Pack,  Cabin and Winches are placed on the Turret for best operational
efficiency. Kicker  plates are installed for safety as well as handrails around
the Turret.

Operator Cabin
Structure - 5 mm steel plate
Floor Area - 1685mm x 1300mm
Position  - Port of crane
Acoustic Shield  - Noise level during operation ≤ 75 dBA
Weather  Shield  - Complete sealed through for water runoff

Visionary
Forward Windows- Clear Safety Glass
Side Windows- Clear Safety Glass; open-able
Rear View Mirror- N/A

Safety Equipment
Safety Bar - Front & side windows to prevent accidental fall
Horn - Electric warning horn
Fire Extinguisher - 1.5kg Dry Powder
Annunciator - See Safety Features

Accessibility
Headroom - 2.1 meters
Door - Side slip door with lock
Maintenance - Removable panels for access to cables & hoses
-  Rooftop access for air conditioner maintenance
-  Side access to front of cabin for window clearing and wiper replacement

Other Accessories
Chair - Fully adjustable cushioned type
Hour Meter - Digital / Analog
Communication - Equipment (PA Speakers Telephone set, VHF/UHF radios
and loud speaker with microphone system) free issue by shipyard.
Control Console - See Controls and Instruments
Power  - Power socket
Lighting - See electrical system
Windshield Wiper - Electrical type
Air Conditioning  - Roof top unit
Engraved Stainless Steel Plate
- Design certified load chart
Rope specification chart
- API monogram

Prime Movers
Prime Mover Data – Diesel Engine
Brand : Caterpillar
Model : C18 Acert
Rating : 2x372KW(2 sets of diesel engine) @ 1800RPM

Starting System -
Primary Battery : Attempts x seconds
Secondary : Attempts x seconds

Drive Output -
Primary Battery : Splitter Gearbox

Consumables -
Primary Battery : Fuel Grade
Secondary : ASTM D975 No.2-D Diesel fuel or equivalent

Primary Battery : Coolant
Secondary : ASTM D4985 or equivalent

Primary Battery : Lubrication
Secondary : API CG-4 oils or equivalent

Prime Mover Sizing
The prime mover is appropriately sized for the following conditions :
1 operation @ full load with full speed

Safety Features
Cabin
An annunciator is mounted in the cabin to alert the operator of possible
risky crane  operation to avoid unfavorable incidents. This will be a solid state
unit first out” alarm  sequence giving both audible and visual warning and
fitting with test and acknowledgement buttons.

The audible and visual alarming signals are provided as following:-
- High Return Pressure(filter jammed)
- Hoist Up Limit
- Hoist Down Limit
- Luff Up Limit
- Luff Down Limit with override for stowing
- Engine Overspeed
- Engine Water High Temperature
- Engine Lube Oil Low Pressure
- Engine Fuel Low Pressure
- Hydraulic Temperature High
- Hydraulic low level

Powerpack
The following are provided at the power pack for status monitoring:
- Engine Lube Oil Pressure Gauge - Engine Lube Oil Temperature

Gauge
- Engine Fuel Pressure Gauge - Engine Water Temperature Gauge
- Engine Tachometer - Engine Emergency Stop Button
- Fuel Tank Level Switch - Hydraulic Oil Level Gauge
- Hydraulic Pump Cavitations - Hydraulic Pump Filter Indicator

Crane Operation Limit
Limit  switches  are  provided  to  define  safe  working  limits  of  all
crane  operations including hoisting and luffing.

Operation : Main/Aux. Hoist
Detection Level : Upper Working Limit
Action : Stop Up Motion
Deactivation : Hoist Down

Detection Level : Lower Working Limit
Action : Stop Down Motion
Deactivation : Hoist Up

Operation : Boom Hoist
Detection Level : Lower Working Limit
Action : Stop Boom Down Motion
Deactivation : Boom Up or Override for Stowing

Detection Level : Upper Working Limit
Action : Stop Boom Up Motion and A&V warning
Deactivation : Boom Down

Detection Level : Ultimate Up Limit
Action : Stop Boom Up Motion and A&V warning continued
Deactivation : Boom Down

Luff-in decelerator and stop in limit is controlled by the incoming boom
and provides  gradual deceleration until minimum radius.  Operation
shutdown occurs and luff  brakes automatically engage overriding the manual
control in the operator cabin.

Safe Load Indicator
The Safe Load Indicator will provide the following to the operator :
- Crane rated capacity (T)
- Actual  load on hooks (T)
- Boom radius (meters)
- Boom angle (Deg rees)
- Visual alarm at 90% SWL
- Intermittent horn at 100% SWL
- Loud continuous horn at 105% SWL
- Overload cut off switch
- Mechanical  boom  angle  installed  at  the  boom  where  visible  from
operator cabin

Standard Practices
In line with West Marine mission to deliver good service and quality to
the customers, here are some of the standard practices adopted into existing
company operation for better product quality.

- All ladders are welded with square rungs in diamond orientation with
ladder cages.
- All handrails are made of galvanized pipe 48.3mm OD,  except those
on boom sections for weight saving purposes
- Cable trays are SS316 perforated.  Cables and hoses are secured with
SS cable ties.
- All machined pins, end covers, and small adaptors are zinc plated to
approximately 15 micron thickness.
- All fasteners M12 and below used are SS304.  All fasteners above M12
are Grade 8.8 or equivalent, fluorocarbon coated.
- Slew bearing fasteners are ISO Grade 10.9, fluorocarbon coated
- Clear labels on all critical equipment onboard
- SS304 and/or white traffolyte with black inscriptions are chosen as
standard for labeling

Special Tools
An Emergency Slewing Handle is an emergency crank used to slew the
crane to a safe direction in the event there is a loss of power to the crane.
An Emergency Lowering Hand Pump is provided to lower the load to
safe level in the event there is loss of power to the crane.
A monorail with girder and chain block Maintenance Jib is with provided
to carry out any maintenance work that is required onboard the crane.

Surface Treatment
External treatment
Pedestal, crane house and boom
- Surface preparation to ISO 8501-1, SA 2.5
- First coat zinc rich epoxy primer to 50 µm dry film thickness
- Second coat two pack epoxy to 100 µm dry film thickness
- Third coat polyurethane finish to 65 µm dry film thickness
- Total; three coats to 200 µm dry film thickness

Internal treatment
Pedestal and crane house
- Surface preparation to ISO 8501-1, SA 2.5
- First coat zinc rich epoxy primer to 40 µm dry film thickness
- Second coat two pack epoxy to 75 µm dry film thickness
Oil tank (integrated in crane house)
- 16.2.2.1 Surface preparation to ISO 8501-1, SA 2.5
- 16.2.2.2 First coat zinc rich epoxy primer to 40 µm dry film thickness

Boom
No treatment as fully closed steel box structure.

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels
where needed.

The details mentioned above are believed to be accurate but are not
guaranteed.
 -------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Lattice Boom Offshore Crane for sale
New Offshore Crane for Sale
150 ton New Offshore Crane
New Offshore Lattice Boom Crane for Sale
Offshore Crane - 150 Ton - For Sale
150 ton Offshore Lattice Boom Crane
New 150 ton Offshore Crane for Sale
 ----------------------------------------------------------------------------------------------------

Double Hull Bulkers - 7500T dwt for Sale
Double Hull New Building Mini Bulk Carriers
New Building Bulk carriers available - slots
Double Hull New Building Mini Bulk Carriers available For Sale
Double Hull Bulk Carriers 7500T Dwt for Sale

Double Hull Bulk Carriers - 7,500MT - 2 slots

Type : Bulk Carrier
Hull Configuration : Double hull-box type
Quantities : 2
Class : I + hull + Mach bulk carrier (esp unrestricted navigation)
Classing body : DNV

DWT (Metric Tons) : 7,500 dwt
Charter : Charter back option available

Day rate : Please enquire

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need, please send us
an email to mail@worldoils.com stating your requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Double Hull Bulkers - 7500 T dwt  for Sale
Double Hull New Bulkers of 7.5k dwt for Sale
7500T dwt Double Hull Bulk Carriers for Sale with charter options
Bulk Carrier slots available at shipyards with charter options
New Building Double Hull 7500T dwt Bulkers For Sale
Double Hull New Building Bulk Carriers available For Sale
New double Hull Mini Bulk Carrier Slots for Sale
New Building Mini Bulkers for sale with charter option
---------------------------------------------------------------------------------------------------------------------------

Mudslayer Odin 200 Drilling Rig for Sale
Drilling Rig - Mudslayer Odin 200 - For Sale

Model : Odin 200 Drill Rig
Manufacturer : Mudslayer
Year : 2025
Condition : Used

Description :

2025 Mudslayer Odin 200 Drill Rig

Includes the following :
200’ 2-3/8" drill pipe
4.5” API sub
50 Gallon Groutslayer Grouter
500 Gallon Mudslayer Mud System Equipped with (3) 5”
Desanding Cones and Mudslayer Shaker Deck
Telescoping Drill Mast. 25’ Under Crown
Houston Machine 2000 Rotary Head with 7000# Pull Back
74 Hp Hatz Diesel NO DEF
Less Than 100 Hours on The Machine
3 ×4 × 8.5 Downhole Pump 118 Series
2000# Sand Line- 200’
Weighs 9500# Perfect for Tight Areas
All Tools and Accessories Needed to Start Drilling Immediately
Clean, Well-Maintained, And Fully Work-Ready
Perfect For Water Well Drilling, Monitoring Wells, Geothermal, And Test Holes.
Great For Anyone Looking to Expand Operations or Add a Reliable, Low-Hour Rig.
Could Use as A Primary Mud Machine and Back Up Drill
This Rig Is Ready to Go to Work Today (per the seller)

Location : USA

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

---------------------------------------------------------------------------------------------------------
Search words (for official use only) :
2025 Built Mudslayer Odin 200 Drilling Rig for Sale
Mudslayer Odin 200 Drilling Rig - 2025 Built for Sale
Used Mudslayer Odin 200 Drilling Rig for Sale
Mudslayer Odin 200 Used Drilling Rig for Sale
Mudslayer Odin 200 Drilling Rig for Sale in USA
-------------------------------------------------------------------------------------------------------

Ice Class Self Unloading Bulk Vessel For Sale
1975 built Self Unloading Bulker with Ice Class for sale
Self Unloader Bulk Carrier with Ice Class For Sale

Self Unloading Bulk Vessel

6150 tdw on 6,75 m
Built 1975 - converted/rebuilt 1985
Lloyds Ice 1 A
3963/2035 gt/nt

Dims 101,95 x 15,3 m

Hold 1 : 3519 cbm Hold 2 : 3391 cbm Total : 6910 cbm / 244.027 cuft
Hold dims hold 1 : 32 x 12,80 -hold 2 : 33 x 12,80 m

Hatch dimensions :
Hold 1 : 14,50 x 12,80 & 15,50 x 12,80 Mtrs
Hold 2 : 14,40 x 12,80 & 14,09 x 12,80 Mtrs

Self discharging gear : Kvaerner Cargo scooper
Disch 300-500 mton hr depend quality of cargo
Outreach boom conveyor : SB side (only) : 22,10 Mtrs
m/e Bofors NOHAB 2356 kW /3520 bhp
Consumption Sea : abt 8 mts MGO/24h In port : 0,8 mts / 24 h
Bowthruster 225 kW / 300 hp

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-------------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Ice Class Self Unloading Bulk Vessel For Sale
Self Unloading Bulker with Ice Class for sale
1975 built Small self Unloading Bulker For Sale
Used Self Unloader Bulk Carrier with Ice Class For Sale
--------------------------------------------------------------------------------------------------------------------------------------

Offshore Lattice Boom Crane for sale
Offshore Lattice Boom Crane - 70 ton
New Offshore Crane for Sale

Brand new 70T lattice boom offshore crane with ABS class
certificate and API 2C monogram

General Specification
Slewing Angle : 360º(Continus)
Slewing Speed(Full Load) : 0~0.85rpm
Luffing Time(Full Load) : 180s Up/down
Luffing Angle : +15° ~ +82°
Parking Angle : -5° ~ +15°
Operator Cabin :Left Side

Main Winch Data
Lifting Capacity(SWL) : 100T@21m,40T@45m,See Loading Chart;
No. Of Fall : 4
Working Radius : 10.0m(Min) / 45m(Max)
Main Lifting Speed(0-125T) : 18m/min
Hook Travel : 95m

Aux Winch Data
Lifting Capacity(SWL) : 20T@48m, Man Riding :1.5T
No. Of Fall : 1
Working Radius : 11.0m(Min) / 48m(Max)
Main Lifting Speed(Full Loading) : 0~67m/min
Lifting Height : 100m

Note :
All operational speeds stated above are based on average volumetric efficiencies
provided by our suppliers of hydraulic components. A speed variation tolerance of
+10% to -5% is within the accepted range and should be taken into consideration.

Hydraulic Arrangement

Hydraulic Systems
The hydraulic transmission will be designed for optimum performance within the
constraint of available horsepower. High pressure hydraulic system uses power
more efficiently and applies power as needed.

All motions controls offer infinitely variable speed and full reversing characteristics.
Two full flow filters will be installed. The filter(s) will be adequately sized for full flow
operation without causing pump cavitation. Replaceable wire mesh filter cartridge
of minimum absolute value of 40 micron will be used. The pumps will have overflow
suction independent of the reservoir, and the arrangement of piping can avoid air
pockets.

Hoisting Circuit
Each winch is driven by a common open loop hydraulic system including piston
pump piston motor and epicycles gearbox. Each winch is fitted with oil immersed,
multi-disc and dynamically rated “fail safe” brake.

The fixed displacement hoist motors offer a constant operating speed.

Slewing Circuit
The slew circuit is driven by a common open loop hydraulic system.  Dynamic
braking of slewing is by means of hydrostatic compensation. Similarly positive
locking brakes are fitted in the circuit and used as static brake;

Luffing Circuit
Luff circuit is driven by a common open loop hydraulic system. Each winch is fitted
with oil immersed, multi-disc,dynamically rated “fail safe” brake. an additional luff
ratchet cylinder is included, providing a positive means of locking the luff drum
whenever the prime mover is shutdown.

Hydraulic Piping
1. Pipes: No pipe threads will be used for the high-pressure lines larger than 3/8".
Hydraulic components that have pipe threaded ports lines will have a minimum
working pressure 300PS. .
2. Pipe fittings: Zinc plated mild steel material. External fittings are painted and
protected by Denso tape or equivalent against corrosion.
3. Hoses: High rubber quality for best resistance against sunlight and salinity,
Wire breaded for applicable specified hydraulic pressure ratings
4. Hose couplings: Zinc plated mild steel material, External couplings are painted
and protected by Denso tape or equivalent against corrosion

Hydraulic Oil Tank
1. Level gauge with isolating valve (to top cover)
2. Inspection and cleaning cover
3. Filter with fine mesh stainless steel strainer and ventilation
4. A relief valve will be installed in the discharge line of pump.

Cooling Circuit
The air-oil heat exchanger will be provided and sized to ensure continuous operation
of the crane under the ambient temperatures given on the data sheets.

Electric Arrangement
Standards, Codes and Protection
Refer to Codes Of Practice and Standards. The electrical systems onboard the crane
complies with these standards for good offshore electrical design and engineering
practices.

Standard Lighting
The following are provided as standard lighting packages for the crane. More lights can
be added according to client's request.

Description : Aviation Warning Light
Qty : 1
Size : 85 W
Location : Boom Tip
Power Supply : UPS

Description : Aviation Warning Light
Qty : 1
Size : 85 W
Location : Mast
Power Supply : UPS

Description : Florescent Access Light
Qty : 2
Size : 2 x 36 W
Location : Machinery House
Power Supply : Main

Description : High Pressure Sodium Floodlight
Qty : *
Size : 400 W
Location : Boom
Power Supply : Main

Power Supply
Main Power Supply : 440 VAC, 03 Phase,  60Hz

Electric motor(s) (for applicable zone)
Power Consumption : 400Kw+250Kw
Speed : 1790r/m
Starting method : Soft starter

Others
Junction box(es) is provided at the pedestal interface for connection to client supply.
By default only SS316 junction boxes are installed onboard.

Generally cable wires will be multi-stranded copper and protected against mechanical
 damage. All power and control cables are with XLPE/EVA/GSWB/EVA construction.
Occasionally able of XLPE/EVA/CWB/EVA is used when big power cable is part of the
design.  All electrical lines are tagged accordingly for ease of maintenance.

All outdoor equipments and instruments are Ingress Protected IP56. Indoor equipments
and instruments are rated with IP44 as minimum.

Ordinarily, the power supply for crane is transmitted from pedestal to slewing platform
through the centre slip ring to ensure the crane can work at any angle.

Control and Instruments
Cabin :
The following instruments are arranged on the console to permit the operator to maintain
an uninterrupted view of the loads and instrumentation. The two(2) motion  controls
joysticks designed according to API-2C, are ergonomically correct and easy to handle.
All instruments are clearly labeled.

1. Motion Control Joysticks:
2. “Dead-Man” Type
- Position sensitive with motion and speed infinitely variable and proportional to movement
from spring-return central position.
- Luff and slew (single left) joystick
- Main and auxiliary hoist (single right) joystick
3. Prime Mover Start/Stop Switch
4. Prime Mover Emergency Shutdown Switch
5. Slew Brake Control Lever for option
6. Safe Load Indicator System
7. Visual and Audible Annunciator Panel (See SAFETY FEATURES)
8. Boom Hoist Down Override Switch
9. Pressure Gauges: Boast Control / Hoist / Slew / Luff
10. Electrical Switches:
11. Lighting
12. Windshield Wipers & Washer
13. Warning Horn
14. Air Conditioning
15. Main and Auxiliary Hoist selector
16. Tachometer

Hoist Mechanisma

Hoist Winch Data
Feature : Hoist Drum
Description - Material, Details : Cast Steel, Remark : 100% NDT
Description : Groove, Remark : Reeving not over 3 layers
Description : Support End, Details : Anti-friction Bearing

Feature : Braking
Description : Type
Details : 1x Band Brake, Remark : Asbestos free lining, for man riding winch only
Details : 1x Multi-disc Brake, Remark : Positive Locking
Details : 1x Load valve, Remark : As dynamic Brake

Description : Safety Factor
Details : Minimum 2.0

Feature : Rope Anchors
Description : Type, Details : Bolted rope clamp,
Remarks : For ease of rope replacement

Description : Safety Factor, Details : Minimum 1.1,
Remarks : Ensures rope breaking strength when over loaded

Feature : Ratios
Description : Drum to Rope
Details : Min.19 : 1
Remark : Drum pitch diameter over rope diameter

Feature : Safety
Description : Drum flange beyond top layer,
Details : 2.5 x rope diameter,
Remark : To avoid rope jumping out of drum unintentionally

Description : Fleet angle
Details : < 2.5⁰
Remark : Ensures smooth and even rope spooling at all times

Description : Dead turns on the drum
Details : Min.5
Remark : Amount of rope that is not in used even at the maximum
hoist reach of the crane

Luffing System
Feature : Hoist Drum
Description - Material, Details : Cast Steel, Remark : 100% NDT
Description : Groove, Remark : Reeving not over 3 layers
Description : Support End, Details : Anti-friction Bearing

Feature : Braking
Description : Type
Details : 1x Load Brake, Remark : As dynamic Brake
Details : 1x Multi-disc Brake, Remark : Positive Locking
Details : Ratchet and pawl, Remark : Luffing locking device

Description : Safety Factor
Details : Minimum 2.0

Feature : Rope Anchors
Description : Type, Details : Bolted rope clamp,
Remarks : For ease of rope replacement

Description : Safety Factor, Details : Minimum 1.1,
Remarks : Ensures rope breaking strength when over loaded

Feature : Ratios
Description : Drum to Rope
Details : Min.19 : 1
Remark : Drum pitch diameter over rope diameter

Feature : Safety
Description : Drum flange beyond top layer,
Details : 2.5 x rope diameter,
Remark : To avoid rope jumping out of drum unintentionally

Description : Fleet angle
Details : < 2.5⁰
Remark : Ensures smooth and even rope spooling at all times

Description : Dead turns on the drum
Details : Min.5
Remark : Amount of rope that is not in used even at the maximum
hoist reach of the crane

Boom Luffing-in limit buffer
 Anti-backward limit is used to prevent the boom over luffing in order to protect boom.

Mast
The Luffing sheaves are placed on the mast (A-frame) which is fitted with a top platform
for maintenance and inspection of the mast head sheaves, luff hoist rope and anchor
connections. Access to the Top Platform is by ladder from the machinery deck. The
mast is pin connected to the machinery deck.

Slew Mechanisms
Slew Bearing
Brand - ROTHE-ERDE XUZHOU or equivalent
Rolling Element - Triple Cylindrical Roller
Lubrication
- Grease holes in diagonal orientation in outer ring
- Lubrication  lines  are  fitted  on  the  machinery  deck for refilling grease into the bearing

Boom
Length - 48M
Type - Reinforced Lattice Structure
Pins - High Tensile
Connectors - Cast Steel
Welding Test - NDT 100% MPI, 100% UT/RT
Boom Top Platform - Both Sides

Safety
Hardwood blocks - To prevent rubbing of ropes on boom bracing damaging paint and
cause unnecessary rusting.
Walkway paths - 760mm wide grating along and inside of boom for maintenance
access
Handrails  - Along boom section

Boom Bottom
Type - Reinforced Lattice Structure
Material - High Tensile Low Alloy Low Carbon Seamless Chords with stell bracings

Boom Intermediate Section
Type - Reinforced Lattice Structure
Material - High tensile low alloy low carbon seamless chords

Boom Head
Type - Reinforced Lattice Structure
Material
- High tensile low alloy low carbon seamless chords
- With Mild Steel Bracings
- High Strength Steel Head Plate

Reeving System
Sheaves
Materials - Steel
Processing Technique - Cast
Ratio - 20 : 1 (Sheave diameter / Rope diameter)
Lubrication - Lubrication through sheave pin
Bearing - Heavy duty sealed cylindrical roller

Ropes
Rope Size (mm)
Design Factor -
Main Hoist and Auxiliary Host : Minimum 5.0
Luff Hoist and Pendant : Minimum 4.0

Rotation Characteristic -
Main Hoist and Auxiliary Host : Non.Rotating
Luff Hoist : Low Rotation
Pendant : Non-Rotating

Construction -
Main Hoist and Auxiliary Host :  RH and WSC
Luff Hoist : RH and IWRC
Pendant : WSC

End Connections -
Main Hoist, Auxiliary Host, Luff Hoist and Pendant :
Solid Thimble

Finishing -
Main Hoist, Auxiliary Host, Luff Hoist and Pendant :
Compacted and Galvanized

Hooks
Basic design factor of the hook is more than 4.0. The hooks are made of cast steel
and tested to -40°C, or -6°C below lowest design temperature. All hooks come with
lockable safety latch and swivel bearings.  Hook blocks will be of significant weight
to prevent unraveling of rope while unloaded.

Machinery Deck
Machinery Turrent
The Turret is made of high strength steel.  Depending on crane model and configuration,
most mechanical and control components such as the Power Pack,  Cabin and
Winches are placed on the Turret for best operational efficiency. Kicker  plates are
installed for safety as well as handrails around the Turret.

Operator Cabin
Structure - Steel plate
Position - Port of crane
Acoustic Shield - Noise level during operation ≤ 75 dBA
Weather  Shield - Complete sealed through for water runoff

Visionary
Forward Windows - Clear Safety Glass
Side Windows - Clear Safety Glass; open-able
Rear View Mirror - N/A

Safety Equipment
Safety Bar - Front & side windows to prevent accidental fall
Horn - Electric warning horn
Fire Extinguisher - 1.5kg Dry Powder

Accessibility
Headroom - 2.1 meters
Door - Side slip door with lock
Maintenance
- Removable panels for access to cables & hoses
- Rooftop access for air conditioner maintenance
- Side access to front of cabin for window clearing and wiper replacement

Other Accessories
Chair - Fully adjustable cushioned type
Communication - Equipment (PA Speakers Telephone set, VHF/UHF radios
and lound speaker with microphone system) free issue by shipyard.
Control Console - See CONTROLS AND INSTRUMENTS
Power - Power socket
Lighting - See ELECTRICAL SYSTEM
Windshield Wiper -  Electrical type
Air Conditioning - Roof top unit
Engraved Stainless Steel Plate
- Design certified load chart
Rope specification chart
- API monogram

Safety Features
Cabin
An annunciator is mounted in the cabin to alert the operator of possible risky
crane operation to avoid unfavorable incidents. This will be a solid state unit  “first out” alarm
sequence giving both audible and visual warning and fitting with test and acknowledgement buttons.

The audible and visual alarming signals are provided as following :
- High Return Pressure(filter jammed)
- Hoist Up Limit
- Hoist Down Limit
- Luff Up Limit
- Luff Down Limit with override for stowing
- Hydraulic Temperature High
- Hydraulic low level

Crane Operation Limit
Limit  switches  are  provided  to  define  safe  working  limits  of  all  crane  operations including
hoisting and luffing.
The functions of the limit switches are :
Operation : Main/Aux. Hoist
Detective Level : Upper Working Limit
Action : Stop Up Motion
Deactivation : Hoist Down

Detective Level : Lower Working Limit
Action : Stop Down Motion
Deactivation : Hoist Up

Operation : Boom Hoist
Detective Level : Lower Working Limit
Action : Stop Boom Down Motion
Deactivation : Boom Up or Override for Stowing

Detective Level : Upper Working Limit
Action : Stop Boom Up Motion and A&V warning
Deactivation : Boom Down

Detective Level : Ultimate Up Limit
Action : Stop Boom Up Motion and A&V warning continued
Deactivation : Boom Down

Safe Load Indicator
The Safe Load Indicator will provide the following to the operator:

- Crane rated capacity (T)
- Actual  load on hooks (T)
- Boom radius (meters)
- Boom angle (Deg rees)
- Visual alarm at 90% SWL
- Intermittent horn at 100% SWL
- Loud continuous horn at 105% SWL
- Overload cut off switch
- Mechanical  boom  angle  installed  at  the  boom  where  visible  from operator cabin

Standard Practices
- All ladders are welded with square rungs in diamond orientation with ladder cages.
- All handrails are made of galvanized pipe 48.3mm OD,  except those on boom sections
for weight saving purposes
- Cable trays are SS316 perforated.  Cables and hoses are secured with SS cable ties.
- All machined pins, end covers, and small adaptors are zinc plated to approximately 15
micron thickness.
- All fasteners M12 and below used are SS304.  All fasteners above M12 are Grade 8.8 or
equivalent, fluorocarbon coated.
- Slew bearing fasteners are ISO Grade 10.9, fluorocarbon coated
- Clear labels on all critical equipment onboard
- SS304 and/or white traffolyte with black inscriptions are chosen as standard for labeling

Surface Treatement
External Treatment :
Pedestal, crane house and boom -
- Surface preparation to ISO 8501-1, SA 2.5
- First coat zinc rich epoxy primer to 50 µm dry film thickness
- Second coat two pack epoxy to 100 µm dry film thickness
- Third coat polyurethane finish to 65 µm dry film thickness
- Total : three coats to 200 µm dry film thickness

Internal Treatment :
Pedestal and crane house -
- Surface preparation to ISO 8501-1, SA 2.5
- First coat zinc rich epoxy primer to 40 µm dry film thickness
- Second coat two pack epoxy to 75 µm dry film thickness
Oil tank (integrated in crane house) -
- 16.2.2.1 Surface preparation to ISO 8501-1, SA 2.5
- 16.2.2.2 First coat zinc rich epoxy primer to 40 µm dry film thickness

Boom -
No treatment as fully closed steel box structure

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
--------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Offshore Lattice Boom Crane for Sale
Offshore Crane - 70 Ton - For Sale
Brand New Offshore Lattice Boom Crane - 70 ton
70 ton Offshore Lattice Boom Crane
New 70 ton Offshore Crane for Sale
70 ton New Offshore Crane
Brand New Offshore Crane for Sale
-------------------------------------------------------------------------------------------------------

CME 55 Crawler Drilling Rig For Sale
CME 55 Crawler Used Drill Rig - 1970 Built

Model : 55 Crawler Drill Rig
Manufacturer : CME Drill
Year : 1970
Condition : Used

Description :

1970 CME 55 Crawler Drill Rig
Ford 6 Cylinder Gas Engine
runs great
no hours gauge
Mounted on a Marooka Carrier MST800
Not sure of year or hours on the Marooka

Location : USA

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------------------------------
Search words (for official use only) :
CME 55 Crawler Drilling Rig For Sale in USA
Used CME 55 Crawler Drilling Rig For Sale
1970 Built CME 55 Crawler Used Drill Rig
Drilling Rig CME 55 Crawler For Sale in USA
CME 55 Crawler Drilling Rig 1970 Built For Sale
----------------------------------------------------------------------------------------------------------------------------

Gottwald HMK 300E Lattice Boom Crane
Lattice Boom Crane - 2006 built - For Sale
2006 built Lattice Boom Crane for Sale

Description
Rubber tyred STS with lattice boom
Year of Manufacture : 2006

Capacity
100 ton/24 mtr.
38 ton/ 50 mtr.

Generator : 30 kVa
Operating hours : 8000
Condition : mint

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.
------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Gottwald HMK 300E Lattice Boom Crane
2006 built Gottwald HMK 300E Lattice Boom Crane
Used Lattice Boom Crane
2006 Built - Lattice Boom Crane - For Sale
Lattice Boom Crane for Sale
Used Gottwald HMK 300E Lattice Boom Crane for Sale
---------------------------------------------------------------------------------------------------------------------------

Utility Tug for Sale
5000BHP Utility Tug For Sale
New Ocean Going Utility Tug For Sale
5000 BHP - New - 37M Twin Screw Utility Tug - For Sale
Twin Screw New Utility Tug

Principal Particulars
Length O.A : 37.00 m
Length W.L. : 35.66 m
Beam mld. : 11.40 m
Depth mld. : 4.95 m

Draft : 4.05 m
Fresh water : 37 cub. mt (approx.)
Fuel oil : 350 cub.mt (approx.)
Complement : 14 men
GRT : below 500

Deck loading : 5 t/sq. mt
Main engine : Niigata 6MG28HX
Gearbox : Nico MGN5023Z

Dimensions
Length, o.a : 37.00 m
Beam, moulded : 11.40 m
Depth, moulded : 4.95 m
Draft, design : 4.05 m
Total compliment : 8 persons

Performance
Bollard pull (ahead) : up to 60 tonnes
Bollard pull (stern) : up to 55 tonnes
Speed : up to 12 knots

Notation
ABS A1 towing vessel (E)
AMS Unrestricted navigation

Capacities
Fuel oil : 350 cub.mt
Fresh water : 37 cub.mt
Lubrication oil : 1.5 cub.mt

Machinery
Main engines :
2 x Niigata 6MG28HX,
2 x 2500BHP at 750 rpm
Gear box :
Niigata MGN 5023Z, ratio 3.59:1
Propeller :
2 x 2700 mm dia, fixed pitch propeller nozzles
Generator :
2 x caterpillar 6406C DITA, 245kW at 1500 rpm
Bow thruster :
2T thrust, electric driven

Deck Machinery
Aft towing winch :
Electro-hydraulic double drum type,
Capacity 600m x 42mm dia. swr, brake holding 120 t
Fwd windlass anchor :
Electro-hydraulic 3t at 10m/min, 2 x 660kg anchors with

357.5m x 22mm grade 2 stud link chain,
centre drum capacity 110m x 52 m dia. P.P rope
Tugger winch : 5t at 10m/min
Capstan : 5t at 15m/min
Towing hook : 60t

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------------------------------------------------
Search words (For official use only) -
Utility Tug for Sale
5000bhp Utility Tug For Sale
Ocean Going / Utility Tug For Sale
New Utility Tug For Sale in Middle East, India
37M Utility Tug For sale
New Twin Screw Utility Tug
Utility Tug For Sale in Singapore, Malaysia, Indonesia
37M 5000bhp Utility Tug For Sale
--------------------------------------------------------------------------------------------------------------------------------------

Continental Emsco G.C. 500 for Sale
1000hp Mechanical Land Rig - Used - For Sale
American 1000HP used Land Rig

Drawworks Continental l Emsco :
G.C 500, with double 22’ Parmac Brake with 2
engine compound, with 320 Quincy Air Compressor. Drawworks powered by two C-15
Cat Engines with Twin Disc Torque converters, 2 Hydraulic Cat Heads, 2 Hydraulic
Handling Winches.

Derrick : Lee C Moore 131, 380,000# SHL

Sub Base : 45’L X 14’H X 24’W Lee C. Moore, 500,000 setback

Block : McKissick 4-sheave 1 1/8” groove, Shorty combo Hook

Kelly : 5” X 42’ Hex with Bash Ross Roller Bushing

Rotary Table : Emsco

Mud Pump : (1) F-1000 Triplex with 5 X 6 Mission Charge Pump Powered by Cat 3412
E with Allison 8000 Series 6 Speed Automatic Transmission.

Mud Pump : (2) F-1000 Triplex with 5 X 6 Mission charge Pump, bowered by 398 Cat.

Water Tank : 10’W X 40’L X 8’H 600 BBL

Generator House : 10’W X 40’ X 8’H with 2-400KW Generators powered by C-15
Cat’s, 1- Electric Powered Auxiliary Air compressor

Parts Room : 8’ X 10’

B.O.P. Equipment : 5 Station Closing Unit, 5000 PSI Pipe and Blind Ram’s, 3000 PSI
Annular B.O.P., 5000PSI Choke Manifold.

Pit System : 38’L X 11’6”W X 6’H Suction Pit 470 BBLS. (1) 30’L X 11’6”W X 7’6”H
Shale Pit 470 BBLS Total Pit System 940 BBL with 2-5 X 6 Mission, Electric Powered
Centrifugals. (3) Electric Pit Agitators. (2) Linear Shale Shakers (2) Cone De-Sanders (2)
Mud Hoppers (4) Hydraulic Mud Agitators (1) Degasser 3’ X 12’

Top Doghouse : 8’WX 30”L X 7’6”H, (4) Pen Drilling Recorder, Wild Cat Auto Driller

Fuel Tank : 10,000 Gal Skidded

Change House : 10’ X 15’

Drill Pipe : 10,000 feet double white band 4 1/2 X- Hole

Drill Collars : (14) 6” X 61/4” All Handling Tools for D.P to D.C.

Tool Pusher House : 14’ X 55’

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-------------------------------------------------------------------------------------------------------------------------
Search words(for official use only) -
Continental Emsco GC 500 for Sale
American 1000HP used Land Rig
American Used Land Rigs for sale - 1000HP
Continental Emsco Used Land Rig - 1000HP
US built Used 1000HP Drilling Rig
10000feet Land Rig - Used - For Sale
1000hp Used Land Rig Fro sale - Mechanical
Continental Used 10,500feet Drilling Rig For sale in USA
--------------------------------------------------------------------------------------------------------------------------------

Floating Crane for Sale
1999 Floating crane For Sale - 1000ton (self-propelled)
Self Propelled Used Floating Crane For Sale: 1000Ton

General :

Built year : 1999
Classification : China ZC
Certificate lifting capacity : 1000ton
Safety/testing lifting capacity :1000t
Navigation area : coastal/offshore area

Particulars :

LOA : 73.6m
Breadth : 28.6m
Depth : 4.27m
Hooks : 2*500ton

Good working condition

Long-term supply of parts after sales if clients need

Subject to prior sale

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

--------------------------------------------------------------------------------------------------------------------
Search words (for official use only) -
Floating Crane for Sale
Used Self Propelled Floating Crane for Sale
Floating crane 1000ton (self-propelled) - 1999 built
1999 built Self Propelled Floating Crane
Used Floating Crane in China : 1000Ton
--------------------------------------------------------------------------------------------------------------------

Cyclone 35R Drilling Rig for Sale
Drilling Rig Cyclone 35R 1972 Built for Sale

Model : 35R Drill Rig
Manufacturer : Cyclone
Year : 1972
Condition : As-Is

Description :
1972 Cyclone 35R Drill Rig
Rotary and Cable Tool Combination
Sullair 125 (4 cyl.) Air Compressor
Hercules 4 cyl. Gas Deck Engine
Mounted on Ford truck
Mileage: 254,000 miles
Detroit Diesel V8 Engine

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.



---------------------------------------------------------------------------------------------------------
Search words(for official use only) :
Cyclone Drilling Rig for Sale
Used Drilling Rig for Sale
Used Cyclone 35R Drilling Rig
Drilling Rig for Sale - Cyclone 35R
1972 Built Cyclone 35R Drilling Rig for Sale
Cyclone 35R Land Drilling Rig for Sale
---------------------------------------------------------------------------------------------------------------

SK 775D Carrier Mounted Drilling Rig for Sale
Carrier Mounted Drilling Rig for Sale

Description

Drawworks :
Service King-775D (775 HP)

Power :
(2) 500 HP Detroit 60 Series Diesel Motors

Mast & Substructure :
Derrick Mast Model #SK112-350., Rated Capacity of 350,000 Lbs
12’ KB Substructure, Rated Capacity of 300,000 Lbs

Rotating & Traveling Equipment :
Rotary Table- Sentry S1-RT 17 ½” e
Blocks/Hook- Sentry 190 Ton
Hydraulic Kelly Spinner
Varco Hydraulic Pipe Spinners

Generators :
320 KW Generator with 3406 CAT Motor
365 KW Generator with 3406 CAT Motor

Air Compressor :
100 Gal Tank w/2 Cycle Quincy Pump Driven
by a 20 HP. Electric Motor

Mud Pumps :
(2)  F-1000 Triplex Pumps with D-398 CAT Motors

B.O.P. Equipment :
Annular Preventer- N.A.
BOP- Shaffer 11” x 5M Double Ram
5 Station, 100 Gal. Accumulator
Choke Manifold- Swaco 3-1/8’’ X 5M

Mud Systems :
400 Bbl Mud Tank System
(2) Swaco Mongoose Shale Shakers
Swaco 2 Cone Desander
200 Bbl Pre-Mix Pit

Tubulars :
6200’ G105 Drillpipe With 4-1/2’’ XH Connections
1100’ 4-1/2’’ HWDP with 4-1/2’’ XH Connections
(15)  6 ½” Drill Collars with 4 ½” X-Hole Connections

Pipe Handling Equipment :
Tongs- 1 Set BVM Denver Type C Tongs. 1 Set Varco BJ HT55 Tongs
Pipe Spinners- NOV SSW-30 Hydraulic Pipe Spinner
Slips- 4-1/2’’DP, 6’’DC,
Collar Clamp
Elevators- WTM 225T 4-1/2’’ DP
Lift Subs for Drill Collars

Assorted crossover, bit subs :
6’’ Hex Kelly
4’’ Square Kelly
3 Sets Pipe Racks
Wireline Machine
Pressure Washer
Mud Bucket

Spare Rotary Table

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

------------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) :
Carrier Mounted Drilling Rig for Sale
775 hp Service King Drill Rig for Sale
Drill Rig - 775hp for Sale in USA
Service King Carrier Mounted Drilling Rig in USA
SK 775D Carrier Mounted Drilling Rig in USA
----------------------------------------------------------------------------------------------------------------------------------

Single Ram BOP 11" for sale - refurbished
5000 psi Single Ram BOP for sale

Single type BOP 11” x 5K WP
Top and bottom flanged 11” – 5K
2 each outlets

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-------------------------------------------------------------------------------
Search words(for official use only) :

BOP - Refurbished for sale
Refurbished 5000psi single ram BOP
Single Ram BOP 11" for sale - refurbished
5000 psi Single Ram BOP for sale

-------------------------------------------------------------------------------

Trailer Suction Hopper Dredger for Sale
Dredger For Sale
7000CBM Trailer Suction Hopper Dredger for Sale

Class : zc

Ingersoll Rand A300 Drilling Rig for Sale
Drilling Rig - Ingersoll Rand A300 - For Sale

Model : A300 Drill Rig
Manufacturer : Ingersoll-Rand
Year : 1994
Condition : Used

Description :

1994 Ingersoll Rand A300 Drill Rig
Mounted On A 2007 International 4300 Truck With 98,331 Miles
Drill Rig Has 8948 Hours
Top Head Drive With 800 Ft Lbs. Torque
6000 Psi Hydraulic Pump
300-Gal Water Tank
2 Winches
3l6 Moyno Pump
Slide Bas With Cross Slide Head
Rig Has Probe Hammer And Cathead
Deck Mounted Toolboxes
Under Deck Auger Racks
Telescoping Tower
16 Ft Working Height

A-300 Monitoring Drill Specifications :
Power System :
Power transfer : Transfer case and pump drive
Hydraulic pumps :
Variable displacement : 30gpm
Fixed displacement : 40gpm
Reservoir : 100 gallons
Filtration : 10 micron element

Dimensions :
Length : 25ft. 0 in.
Width :8ft. 0 in.
Height (derrick down) : 10ft. 9 in.
Height (derrick vertical) : 14ft. 10 in.
Weight (less truck) : 8,000lb.
Weight (Including truck) : 16,000lb.

Leveling System :
Hydraulic jacks : 3(1 front; 2 rear)
Diameter/stroke : 5"x30"
Pad diameter : 10 in. diameter

Derrick :
Tubing section : (2)5"x10"x0.25" wall
Length : 12.0 ft.
Rotary head travel : 8ft.

Feed System :
Pulldown/Pullback : 18,000 lb.
Head travel speed : 50ft/min.
Feed motor : Hydraulic; variable speed
Feed chain : Roller

Rotation System :
Motor type : Hydraulic planetary gear
torque : 8,000ft-lb. (96,000 in-lb.)
Speed range (standard) : 0-75 rpm
Side slide (hydraulic) : 12" overall
Spindle adapter : 8 bolt flange

Hoist :
Capacity : 8,000 lb.
Speed : 85ft/min.
Cable : 1/2"x 60ft.

Options :
Cat head : 8"x8-3/4" drum
Pump : Moyno 3L6
"A" rod rack capacity : Capacity of 20 pcs.(5ft)
Twin auger racks capacity : 90ft. of 6¼ x5ft.augers
Three speed rotary head : 0-215 rpm; shift-on-the-fly
Derrick extension : 6ft hydraulic telescoping
Tool boxes : 24"x18"x18"(each)
Auger centering guide : For 4â…œ" to 8¼" hollow stem augers

Location : USA

Price & terms : Please enquire using the email form below.

If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.

We can arrange delivery of equipment and towage of rigs and vessels where needed.

The details mentioned above are believed to be accurate but are not guaranteed.

-----------------------------------------------------------------------------------------------------------------------------------
Search words (for official use only) :
Ingersoll Rand A300 Drilling Rig - 1994 Built for Sale
1994 Built Ingersoll Rand A300 Drilling Rig for Sale
Used Ingersoll Rand A300 Drilling Rig for Sale
Ingersoll Rand A300 Used Land Drilling Rig for Sale
Ingersoll Rand A300 Drilling Rig for Sale in USA
----------------------------------------------------------------------------------------------------------------------------------

---------------------------------------------------------------------------
Search words :
