Mast Unit
The T500XD is a trailer mounted portable land rig designed to API 4F, 7K
and 8C standards. Dual MTU V2000 diesel engines provide power to the
hydraulic system for drilling operations.
The trailer mounted Telemast
system consists of fewer loads and offers rapid set-up and deployment.
Automated pipe handling, slip actuation and breakout systems set this
machine apart from conventional oilfield equipment. Our Half-Triple concept
is designed to utilize Range 3 drill pipe for increased drilling efficiency and
quick trip times.
The mast unit is mounted on a 4 axle trailer with tandem tag axle and
includes hydraulic components necessary to transmit power to the feed,
rotation and auxiliary functions. Quick coupled hoses transmit the hydraulic
supply from the Power Unit to the rigs Mast Unit.
Telescoping construction permits long head travel and working height, yet
short overall length in the transport position. Equipped with a 30" (762 mm)
cylinder operated slide, the mast is free-standing, all pullback loads are
directed into the floor, not the rig frame. The mast is anchored to the rig floor
via locking pins.
Feed System - The top head is raised and lowered by hydraulic traverse
cylinders through 2-7/16" (63 mm) OD wire rope (370 Tons Nominal Breaking
Strength per strand) and 77" PD Nylatron sheaves. As the tophead is raised,
the inner mast section extends by a ratio of 1:2 until it reaches its fully
extended position at 56ft of head travel.
Top Head Travel : 56ft (17.07m)
Hookload : 500,000 lbs. Actual (227,227 kg)
Hoist Speed (Both Engines) :
0 - 130,000 lbs. @ 136 fpm (regen),
101,000 lbs. - 285,000 lbs. @ 106 fpm,
286,000 lbs. - 305,000 lbs. 100 fpm,
306,000 lbs. - 419,000 lbs. @ 76 fpm
420,000 lbs. - 500,000 lbs. @ 64 fpm
Pulldown Capacity : 80,000 lb (36.363 kg)
Pulldown Speed: 0 - 180 fpm loaded, 0 - 200 fpm free head (no load)
Mini Lube System - A multi-point systemis provided to simplify librication
of drill components. Provides centralized grease fitting locations for top head,
crown, jib boom.
Top Drive Details
The hydraulic top drive is powered by a radial piston motor and is mounted to
a tilting slabback to facilitate pipe handling functions via the LoadSafe. A
floating sub is provided to extend the life of threads by removing feed cylinder
and pipe weight forces from threads while making and breaking tool joints.
Casing lifting eyes are slabback mounted to work in conjunction with
commercially available elevator links (not included). The top drive includes a
rotation lock and rebound prevention circuitry for use when directional
drilling. An in-line mud saver valve is mounted in the top drive spindle.
Connection at top drive swivel is 3".
Top Drive
Horsepower: 950
Rotation Speed: 0- 140 RPM
Rotation Torque: Up to 35,000 ft/lbs
Swivel: 3" cartridge style
Fluid Pressure Rating: 5000 psi
Air/Mud Fluid Lines - A 4" stand pipe and traveling hose is mast mounted
and includes 1502 class hammer unions for 5000 psi operation.
Main Winch - A hydraulically powered winch is mounted to the side of the
mast for utility lifting operations. The winch is a planetary type with
overrunning clutch, hydraulic brake valve and spring applied hydraulic
release brake. The winch operates independently of the other drilling
functions. Winch is reeved over a hydraulic jib boom which centers the line
over the center of the borehole.
Model: Braden PD12C
Drum Capacity: 547 ft (167 m) of 1/2" cable (12.7 mm)
Bare Drum Pull: 9,600 lb (4,354 kg)
Bare Drum Speed: 151 fpm (46.0 mpm)
150 ft Drum Pull: 8,700 lb (3,946 kg)
150 ft Drum Speed: 165 fpm (50.3 mpm)
Cable Supplied : 150 ft (46 m) of 1/2" cable
(12.7 mm) HSLR (high strength low rotation) cable.
Explosion proof lighting is provided for nighttime operations. Lighting is 240V
and is routed through an AC distribution panel and is fed from customer
supplied generators:
(3) 400W Metal Halide units on mast crown
(3) 60W Fluorescent units on RH side of mast
Transport Dimensions : Trailer Load 1
Length : 59ft
Weight : 10ft
Height : 13ft 6"
Est. Weight : 150,000 including the tandem tag dolly
Power Unit
The three axle trailer mounted unit includes the engine packages and
hydraulic power systems. Four outriggers are supplied to provide a stable
platform for the power trailer. Quick coupled hoses transmit the hydraulic
supply to the rigs Mast Unit.
Power : 2 x MTU 12V-2000TA DDEC Tier 2, 760 bhp (567 kw) @ 1,800 rpm
w/ electric start, includes (2) two 220 gal fuel tanks, diesel air shut down
system and silencer style muffler with heat wrap on exhaust components.
Battery shut-off switch is included.
Cooling : 2 x Two core, side by side package, 130°F (54.4°C) ambient rating,
with 60" hydraulically driven fan.
Hydraulic System
Each engine is directly coupled to a pump drive gearbox
to power its hydraulic power system. To obtain full system performance, both
engines must be operated at 1800 rpm. However, when drilling conditions
permit, one engine can be operated for fuel savings and to provide
maintenance capability without stopping the drilling process. Each engine
has an identical hydraulic system so either unit can be run with the same
performance. The hydraulic system includes a 1000 gallon tank with full
return oil filtrations. All pumps are protected by suction line strainers and all
hydraulic circuits are protected by relief valves and oil cooler system.
Walkway platforms are provided for access to hydraulic tank during
maintenance operations.
Hydraulic System
Pumps : Each engine powers (9) pumps. (8) piston and (1) one gear type
Filters : (18) twin element 10-micron replaceable elements with magnetic
particle strainers on return ports. High pressure 10-micron elements are
located on the power unit, mast unit and LoadSafe
Tank Capacity : 1,000 gal. Magnetic strainers and shut-off valves on all
suction ports
Electric Heating : (10) 2,000W elements are provided in the hydraulic tank
Water Injection, Bean 35 gpm
A fixed displacement gear pump hydraulically drives the triplex piston pump
for coring and grouting. RPM adjustment is achieved through use of a flow
control valve and includes a gauge to monitor discharge pressure.
Pump Model : FMC Bean W1122BCD
Maximum Flow: 35 gpm (132.5 lpm) @ 1,000 psig (69 bar)
Tool Lubricator, Piston Pump
An air operated piston pump provides "rock drill" oil for DTH operations.
Lubricator is activated and controlled from the operators station.
Oil Flow : 0 - 5 g/hr (0 -18.9 l/hr)
Max Pressure: 1,000 psi (69 bar)
Reservoir Capacity: 18.1 gal (68.5 l)
Air Manifold - A manifold is provided for air drilling operations. The system
included a hydraulically actuated valve for the main air control and drill string
vents. Includes connections for DTH lubricator and water injections supplies.
Safety Equipment - (4) Four fire extinguisher and (4) four emergency stop
buttons are provided. One of each is located on all 4 corners of the power
unit.
Tool Box - A lockable tool box is located on the right hand side of the rig.
Capacity - 9 cu ft (.25 cu m).
Transport Dimensions : Trailer Load 2
Length : 49ft
Width : 10ft
Height : 12ft
Est. Weight: 85,000 lbs
Sub Base
The sub base is a cantilever design which offers a stable platform and
compact footprint and is a multi-piece package consisting of 5 transport
loads. The sub base includes a walking system which allows the rig to be
accurately position over the conductor hole and provides quick moves from
hole to hole while operating on pad drill sites. The walking system also
allows for re-leveling of the machine if required. The sub structure set-up
and walking systems are operated by a radio control module. Includes
staircases, walkways and railings as required.
Floor Height : 22ft
Clearance : 19ft under table bushing
Ground Pressure :
Dead Load : 26 psi
Live Load : 57 psi
Walking, Mast Down : 41 psi
Walking Mast Up : 56 psi
HPU for Sub Base is provided with both manual and radio remote controls :
Diesel Engine - 4-cylinder Perkins
Hydraulic System : Single fixed volume pump
Hydraulic Tank - 750 gal. with (3) 2,500W in-tank heaters
Walking System
The walking system consists of 4 hydraulically operated pad systems which
are located at each corner of the parallel lift sections. Lift cylinders raise the
machine 6" off of the ground and slide cylinders translate the machine 12" in
any direction in 5 degree increments. Walking Speed is 30 fph.
Transport Dimensions : Misc. Loads 4 - 7
Rig Floor and Control Room - The rig floor and control room are mounted on
a three axle trailer assembly that is integrated to the sub base during rig up
operations. The rig floor contains 37-1/2" false table adapter and a 27-1/2"
Master Bushing. The hydraulic roughneck is floor mounted and provides
make-up and breakout of tubulars up to 9-1/2" OD. A hydraulic slip lifter is
provided. Slips are provided for the following :
6-1/2" Collar
8" Collar
4-1/2" Drill Pipe
5-1/2" Casing
9-5/8" Casing
13-3/8" Casing
Power Breakout
The arm swings beneath the top head by a hydraulically powered geared
actuator. The lower jaws grab and hold the lower joint while the upper jaws
grab and rotate the upper joint to make or break the connection. Units
height is adjustable by 24" to allow for variances in the landed height of the
drill string. 2 sets of jaw dies are required to cover the full diameter range of
this unit. 8 x 3528-0011 dies are required for clamping diameters under 4-
1/2". Torque is adjustable in both the make and break directions and is
monitored via a hydraulic pressure gauge.
Range : 4-1/2" - 9-5/8" diameter
Clamping Force : Adjustable to 61,500 lbs @ 3000 p
Break/Make Torque : 60,000 ft/lbs @ 3500 psi
Main Deck Lighting :
(18) Metal Halide units on sub base
for the driller and LoadSafe operator. All rig and LoadSafe controls are within
easy reach of the operators. The control room is positioned to provide good
visibility of the rig floor and camera systems provide the operators with views
of the area around the LoadSafe and BOP. Accommodations are provided
for third party instrumentation packages.
Monitors : (3) 15" touch screen type
Controls : (2) control positions. (1) each for driller and LoadSafe operator.
Driller has (2) screens, (3) multi-function joysticks and additional control
switches. The LoadSafe operator has (1) screen and (2) multi-function
joysticks.
Seating : (2) fully adjustable swiveling chairs
Lighting : (2) 120V 60W fluorescent fixtures
Electrical Accessory Circuits: (10) duplex outlets, 80 amps total accessory
supply
Heating : air handler, 24,000 btu
Cooling : air handler, 11,000 btu
Power Requirement : 100 amp, 240V AC Single Phase. Routed through a
distribution panel.
The control room is equipped with hardware for wireless remote connectivity
which allows for monitoring of rig system from a remote location.
Transport Dimensions : Trailer Load 8
Length : 53ft
Width : 10ft
Height : 13ft6"
Est. Weight : 85,000 lbs
LoadSafe
The LoadSafe automated pipe handling system is skid mounted and provides
hands-free pipe handling for drill pipe, drill collars and casing. The LoadSafe
lifts tubulars from the horizontal position into alignment with tilting top head
and advances forward or slides back to allow easy interface with the top drive
spindle and will pass 24" casing. Built-in holding clamp allows for make-up or
break-out of tool joints from top drive spindle.
Two (2) pipe arms per side are provided with indexing systems insure that
one pipe is loaded at a time. Arms are positioned to allow the use of Range
2 or Range 3 tubulars.
Arm Length: 129" per side.
Only one set of jaws I required to cover the full range of tubular diameters
(4" -24"). The jaws are simply moved to one of 4 locations on the clamp
arms to accommodate 4 separate diameter ranges.
Diameter Range 1: 4" - 10"
Diameter Range 2: 10" - 14"
Diameter Range 3: 14" - 20"
Diameter Range 4: 20" - 24"
Six (6) hydraulic outriggers are provided to level the machine for stable
operation.
Capacity: Up to Range 3
Lift: Up to 10,000 lbs
Average Trip Time: 1,000 fph
Transport Dimensions : Skid Load 3
Length : 53ft
Width : 9ft
Height : 6ft
Est. Weight : 55,000 lbs
BOP Carraige
BOP Carriage is designed to interface with the customers supplied BOP
transport and skid system. A trolley mounted hoist lifts BOP and rolls it into
position over the borehole. A twin beam track system is mounted to the
bottom of the rig floor during initial rig-up. This system includes a 15 ton
chain hoist.
Interface Connections
Includes (18) hydraulic hoses and (3) electrical cord sets required to connect
the Power Unit to the Mast Unit and the LoadSafe.
Paint Standard Colors
Rig Mast Trailer Unit, Sub Base and LoadSafe are painted Schramm Red.
Rig mast and control room are painted white. Mast crown, top drive and
railinngs are painted safety yellow. Two part polyurethane enamel. Sherwin
Williams Polane G+.
Rig Performance Parameters
TBD prior to order acceptance.
Start-up and Initial Testing
Drill rig components will be built in West Chester, PA, USA for deployment to
Alpha Hunter Drilling LLC rig-up yard for integration, set-up and start-up
testing. Schramm will be responsible for functional and initial testing in West
Chester and start-up testing of the rig components listed in the Scope of
Supply at the Alpha Hunter yard in PA, WV or OH (TBD) once the drilling
package is assembled. Alpha Hunter Drilling LLC will be responsible for the
components it supplies.
Horizontal Well Testing
Schramm service technicians and engineers will be on-site during the drilling
of two (2) horizontal wells by Alpha Hunter Drilling personnel in the PA, WV
or OH location of their choosing. Alpha Hunter Drilling LLC will be
responsible for the rig operation.
Training and Field Service Support
Schramm will train Alpha Hunter Drilling crews in the operation and
maintenance of the drilling rig and will be either on-site or available on a 24/7
basis during the first 6 months after delivery.
Other Considerations
It is understood that the T500XD is a prototype drilling rig, and as such, may
require additional testing, extra time for set-up, trouble shooting and field
modifications not typically associated with a production model. Alpha Hunter
Drilling will cooperate and coordinate with Schramm personnel to facilitate
testing and repairs as may be required. Schramm personnel can have
access to the rig when and where appropriate and may bring visitors to either
aid in the repairs or maintenance, or for the purpose of demonstration to
potential customers. Prototype specifications are subject to change and will
be mutually agreed to prior to implementation and may affect final price or
delivery.
Price & terms : Please enquire using the email form below.
If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.
We can arrange delivery of equipment and towage of rigs and vessels where needed.
The details mentioned above are believed to be accurate but are not guaranteed.
--------------------------------------------------------------------------------------------
Search words (for official use only) -
Schramm T500XD Trailer Mounted Drilling Rig for Sale
Trailer Mounted Portable Land Drilling Rig for Sale
Schramm Drilling Rig T500XD - For Sale
Schramm T-500 Rig for Sale
-------------------------------------------------------------------------------------------
.png)
.png)
.png)
.png)
.jpg)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
Search Here
Landrig11481019973580.jpg "JC40 DB Land Drilling Rig for Sale")
Landrig11481019973580.jpg "JC40 DB Land Drilling Rig for Sale")
1630580594643.jpg "Offshore Supply Vessel - 1997 Built - For Sale")
1630580594643.jpg "Offshore Supply Vessel - 1997 Built - For Sale")
