Ideco 2100E Rig - For Sale
Ideco 2100E Rig for Sale
Ideco Drilling Rig for Sale
Technical Specifications :
Drawworks
IDECO model 2100-E (s/n E-78) with 1-1/2” LEBUS grooving, FOSTER type 37-AH / 24-AH
air catheads, KOOMEY model CBS-RT2 crown block saver and (2) (GE 752 1000-HP series
wound DC motors JANUARY -2012) with 10-HP blower motors fitted with HUNT vertical air
cure filters.
Last Overhaul: ID/TEC 03/2007 (New brake bands, kicker plates: 01/2008)
Auxiliary Brake
Baylor Elmagco model 7040W (s/n 10961W) rated @ 78,000 LB-FT torque @ 50 RPM with
PWM-20 control system, Drillers control, transformer with EXP rig floor emergency stop unit
& emergency stop indicator lamp. Note: Torrington bearing p/n 23040-W-BRC3 (34).
New coupling: 12/2005.
Battery Back-Up System
GBC model 18384–205 (s/n 1086): Input 230 VAC for charging – 240 VDC for Baylor brake
with Siemens 100 AMP, 250 VDC isolating switch and 12 VDC battery 20 N battery bank.
Anti-Collision System
MAN4 Hitec (s/n 038371) AE-1005 power supply unit Kinetic Energy Monitoring System: With
control unit (230V input / 28V output), direct-mount encoder (p/n CHHGTX-0004A), Drillers
display unit, emergency stop, audible alarm and height & weight sensors.
New optical sensor :
01/2008. New drum tracking assy (A000565) and sensor (A000382) 09/2008).
Brake Water Cooling System
O&M model ESH-180-2F8 (unit s/n 151494): Designed for 300 GPM @ 55 DEG C ambient
c/w (2) Caterpillar 399 radiator coolers (Dolphin 08/2007) with 96” diameter fans each driven
by Baldor 10-HP (575 VAC, 60 Hz, 1760 RPM, EXP), 40-BBL water tank, Halco Supreme
model 2500 (3” x 2” x 12.5”) centrifugal pumps (2) each driven by Baldor 25-HP (600 VAC,
60 Hz, 1775 RPM, EXP) motor, 3” suction & discharge with check valves & butterfly valves
for 100% redundancy. Control panel with starters, switches, run lights. Sensors for: high
temperature - low fluid level - low flow.
Top Drive
(VARCO Upgrade: 5/2011) Not available
DS 11SA VFD Drive Unit Consists of :
VFD is available
1 Incomer/ Rectifier Cubicle
1250 Af, Lsi, Blit – In Cb W / Uv Trip
6 Pulse Air Cooled Diode Bridge Rectifier
Surge Suppression Net Work With Status Indicaters
Ground Fault Monitor
Ac Line Reactor
40 Amps Cb For 30 Kava Transformers
80 Amps Chopper Uni
Air Cooled Inverter Cubicle.
Direct Torque Control W/Profibus Communication Card and Speed Feedback Encorder Card
DC Pre Charge Circuit
Inverter Fault Indication Display
420 Kw 600/690 Volt Air Cooled Vfd Modules inculding Mode Filters and Out
Put Reactors
DC Input Isolation Switsh 175 Amps
Enclsure for Plc
Resistor Bank,- Edge Wound Air Cooled Resistor
Control Cubicle
60A Fused Switch For Aux Motor Starter
600 Vac Aux Motor Starter
2 Mavaier Ac Unit
Model 11SA with power distribution center (600 VAC, 60 Hz, 3-PH, 1200 AMPS), drive system
interconnecting multi-conductors providing interface between Drillers panel, top drive and
control electronics and fitted with emergency shutdown :
ABB Inverter Invo 1 and 2 Model
ABB Rectifier
Siemens Plc Panel Model CPU- 315-2dp (S7-300)
Abb Main Circuit Breaker (600 Vac, 1200 Amp)
Drillers Control Panel Varco System-3D-55701-60-1
Bartec Profix TYPE-073136-4025/0010 EX 11 -2 (1) EEX edm LIAL 11B T4, FNR 5068/09,
16X Digital Input Prof ADDR 08, Part No- 140698-2
PTB-02 ATEK 1159.
Quill RPM gauge, torque gauge, pipe handler controls, control, mode selection, torque limit
controls (forward/reverse), emergency stop. System protection shutdowns.
Mast
Dreco Beam Leg model M-14230-1600 (s/n DHW-253-L153-09/81)
NOI inspection: 08/2010 :
142ft H x 30ft W x 1,660,000 LBS (GNC) rated @ 1,200,000 LBS API SHL (12 lines).
Racking board capacity: 25,000ft (270 stands 5” DP) with 14 stands DCs & Ingersoll Rand
model BU7A-PTAB air winch (s/n BU8690397). Wind rating: 100 MPH full setback, 115 MPH
no setback.
Raising Line: 2-1/4”D, 6 x 41, EIPS, RRL, IWRC, 145’ 6”L w/ open-closed spelter
sockets & 132ft 6”L w/ open-open spelter (01/2012)
Mast Load off Headache Rack : 140 MT
Crown
Dreco model 860C-742 rated @ 650-T SHL (740-T gross) w/ (7+1) 60"OD x 10”D
shaft x 1-1/2" sheaves (Replaced 02/2011).
Casing Stabbing Board
Dreco counter-balanced-adjustable type to API Spec 4E (s/n NDSC-5003): with
positive-engaging brake and Ingersoll Rand model ML500K 0.5-T air winch (s/n 14024)
with remote pendant control.Recert: AOTC # 452 (08/2005).
Deadline Anchor
Superior model E-120 (s/n R-2164) equivalent to Dreco model LOF-100-T: 50-T capacity, 29”
diameter, leg mount for 1-1/2” line and Martin Decker type E-80 tension type load cell sensator.
Drilling Line
Powered reel with 5-7/8” diameter shaft and 7,500ft of 1-1/2” drilling line to API 9A.
Substructure
Dreco Slingshot (s/n E7-475-579): 33ft H x 40ft W x 40ft L (27ft 3” clear height)
rated @ 1,200,000 LBS with 800,000 LBS setback load. Drip-pan enclosure for
rotary and setback, telescopic/adjustable bell nipple. (1) set 45ft L steps, (1) set
25ft L steps, handrails, Allen Get-Away evacuation slide, 6ft W x 44ft L V-door,
2-piece catwalk (5ft W x 60ft L x 21”H). Raising Lines (01/2012):
2 x 1-1/2”D x 750ft L ungalvanized, 6 x 36 IWRC, 1960 BT, RHO, MBL c/w open
spelter socket fitted by resin one end & other end open.
Slingshot Raising System
Lantec model 4135 (2) hydraulic raising winches (NOV Service: 6/2010):
Powered by Abcor HPU (s/n R10-HU-SWN). Lamprell Service: 06/2004,
with Baldor model M4316 (s/n 11/81) (Intersel 04/2003) 75-HP motor
(575V, 69.6 amp, 60-HZ, 3-PH, 1760-rpm, EXP), 200-gal hydraulic tank,
local & remote controls.Raising Lines (01/2012): 2 x 2-1/4”D x 132.6ft L &
145ft L, SWL 47.2 ton, 6 x 36, IWRC, RRL wire rope slings .
BOP Handling System
Dreco 50-Ton SWL (s/n 0156101330-1, 0156101330-2): 25-ton SWL hoists
(2) (NOV Service: 12/2011), hydraulic rack & pinion with remote control console
(powered by Abcor unit). Raising Lines (09/2011): 2 x 1-1/4”D x 43.5ft L, EWL,
6 x 36, IWRC, RHRL wire rope slings w/ 1-1/4" G416 Crosby open spelter
socket both ends.
Doghouse
7ft 10"W x 7ft H x 20ft L with lighting panel, Drillers remote BOP station and Petron remote.
Install BOPC closing unit Remote control panel EEGRB08AP- HMI/PLC Siemens
Simatic Mult Touch Panel
Power Control System
Ross Hill model 1400, 4-bay SCR (s/n 5546/81): (4) AC generator controls
(600V, 1445 AMP, 1550 KVA), (4) GE 1600 AMP circuit breakers
(CAT # TPR-5616-Noarhc), (4) DC SCR bridges (input: 600V, 1470 AMP
AC; output: 750 DC, 1800 AMP DC) with (4) GE 1600 AMP circuit breakers
(CAT # TPY-5616), (1) GE 1600 AMP circuit breaker for MCC
(CAT # TPRR-561-NRHC), (11) GE 7700 line control center panels
(230VAC, 3-PH, 4W, 60-HZ, CAT # 474X0443001), (1) GE 600/220VAC circuit breaker
(CAT # TB-43F) for (3) 220VAC transformers, (1) GE 600 VAC circuit
breaker (CAT # TJK-436F000) for (1) 460VAC transformer. Main in-coming
plug panel with lockouts for DW, MP-1, MP-2 and RT functions.
PCR upgrade by M&I Electric Industries (w/o W834-700-97):
- RHCC upgrade: AC control modules (4),
- 600VAC (primary), 460VAC (secondary) 300KVA xformer for all auxiliary DC drives
- Install 0-200 milli-Amp meters from actuators to read kW load sharing: Run mode 1200-RPM,
35-45 mA. Full load 160 Ma.
- Install DC Amp meters from generator exciters to read load sharing.
- PLC alarm system installed for: (a) engines; low coolant level, high coolant temp,
low oil pressure, metal particle detector, generator overspeed, (b) brake-water
cooling; low fluid level, high coolant temp, (c) mud pit purge panels (2) for H2S
& CH4 (PLC activates alarms via Gaitronics PA system).
Shunt To Series Motor Modfication- Nov – January-2012.
Installed Dynamic Brake Model 1461, Dc Power Cable And Control Cable Inter Connection,
Sproket Slip Pc Card, Hed, Voltage Feed Back Pc Card , Dc Module, And Power Recptacle
For Dc Power Out Lets.
Transformers
- Ross Hill Controls type HSUL (3): 600V-127/200Y, 100-KVA, 60-HZ, 1-PH, Cat #100S9XH6C,
4.9% imp, 150 C Temp Rises (s/n 70101-881, 70102-881, 70103-881).
- Sunbelt: 600V/480Y/277, 300-KVA, 60-HZ, 3-PH 5.64% imp, 150 C Temp Rise (s/n 22459).
- ITC type HTUL: 600V/240Y, 25-KVA, 50/60-HZ, 3-PH, Cat #2832H3DC, 3.6% imp, 150 C Temp
Rise, (s/n 726856-10/81).
- Victor (UAE) model GPTS/100K: 100-KVA, 50/60-HZ, 3-PH, Class H, 115 C temp rise, 600V
delta primary, 480V star secondary, 96A primary, 120A secondary, standard IEC726 (s/n 18216/06).
- Marcus type IW: 600V/416/240, 112-KVA, 112-HZ, 3-PH, 3.4% imp, 150 C Temp Rise
(s/n 8803-797).
Aux. Brake Controller
Baylor model PWM-20 for model 425L Drillers console.
A/C Units (2)
Trane model TTA120-A300BC, 10-TON single compressor split units
Cable Grasshopper
8ft W x 30ft L electric cable tray skid with oscillating cable arm to rig floor and (1 lot) cable trays
with covers.
Generators
KATO synchronous, brushless, 2-bearing AC (1500 KW, 347/600V, 1875 KVA, 3-PH, 60 HZ,
0.8 PF, 1200 RPM, 1806 AMP, 90 DEG C temp rise, field volt 100, field AMP 4.3) :
1. Model 1500-685361111 - type 21676 - Cat. #6P7-2050 - s/n 36739-85926-1
2. Model 1500-685361111 - type 21676 - Cat. #6P7-2050 - s/n 36741-85926-2
3. Model 1500-680361111 - type 21676 - Cat. #6P7-2050 - s/n 36738-84485-3
4. Model 1500-680361111 - type 21676 - Cat. #6P7-2050 - s/n 36740-84485-2
DC Motors
GE-752 and Juliot series -wound rated at 1000-HP continuous (750 VDC, 1150 AMP, 965 RPM)
with Class H insulation, pressurized connection box, auxiliary lockout switch and 10-HP
(460 VAC, 60-HZ, 3275 RPM, EXP) blower motors mounted on HUNT model 752V-RHB/LHB
vertical air cure filters. Note: Power cable connections are pin type and 20-pin receptacle is
Pyle National male (p/n ZREP 20332 PN). Refurbished January 2012
Main Engines (4)
Caterpillar series D3512 DITA (4), 1435-HP/1000-KW @ 1200-RPM fitted with
Woodward EG-10P actuators, injector group 4P 9075, turbo group 12 8187, marine duty
air cleaners, Spinner II oil centrifuges with AMOT metal particle detectors & oil level switch
gauges, Racor primary fuel filters, Bicera crankcase explosion relief valves, 12” exhaust outlets,
HMSO protection system for low oil pressure, high water temperature and over speed air
inlet shutoff.
- CAT #1 - 3512 Arrangement # 2W 8869 (s/n 67Z 01953)
- CAT #2 - 3512 Arrangement # 2W 8869 (s/n 67Z 02173)
- CAT #3 - 3512 Arrangement # 2W 8869 (s/n 67Z 02213)
- CAT #4 - 3512 Arrangement # 2W 8869 (s/n 67Z 02212)
Engine Cooling
O&M (drawing # 10569-402) (s/n 1-151426/7/8/9) desert-duty jacket water heat exchangers with
updraft design rated @ 150 PSI MAWP (O&M #128156) & converted to standard over-sized
water tanks with independent water pump to after-cooler.
Fuel Tank #1
Crude Settling Tank: 8.5ft D x 30ft L x 300-BBL (48m3) horizontal, cylindrical on
10ft W x 40ft L x 3-runner skid with 27” manhole, 2” vent, 4” fill connection, 2” drain,
sight-level gauge and 3” x 2” centrifugal transfer pump with 3-HP, 60-HZ, 460VAC motor.
Fuel Tank #2
Clean Crude Tank: 9.8ft D x 26ft L x 346-BBL (55m3) horizontal, cylindrical on
8ft W x 33ft L x 2-runner skid with 24” manhole, 2” vent, 4” fill connection, 2” drain
and sight-level gauge.
Fuel Day Tank
HEMT 50-BBL (7.5m3) skidded crude day-tank: With Roper type 1 gear transfer pump driven by
3-HP 460V 60-HZ motor.
Diesel Tank
HEMT 60-BBL (10m3) rectanguler (s/n A318-2333) on 19.7ft L x 8.2ft W x 5.9ft H skid with
fuel filtration unit and Roper type 1 gear transfer pump driven by 3-HP 460V 60-HZ motor.
Air Compressors (2)
Gardner-Denver model EDFQLC (s/n R-00329, R028331), oil-injected, rotary screw type rated
@ 309 SCFM (each) @ 125 PSI driven by model 24CA-3240 AC motor 75-HP, 575VAC, 60-HZ
(s/n 97600010, 97600011) inside high ambient NEMA 4 enclosure (spare air-end common
for Rigs -10/31/32).
Cold-Start Compressor #1 Not Available
Air Dryer (2008)
Great Lakes model GPS-1000-N4-116 (s/n 31303) heatless, regenerative dessicant (p/n 692001)
type, 1000 SCFM flow @ 100 psig with ASME coded twin towers rated @ 150 psig, solid state
timer, pilot air filter, 110V Nema 4 control, model GC-1000-SA coalescing pre-filter and model
GP-1660 particulate after-filter.
Vertical Air Receivers (3)
Horizontal Air Receivers (2) Not Available
Air Hoist :
Ingersoll-Rand type FA2.5-16M rated @ 2.5-T SWL (s/n 73185)new installed 02/2012.
Air Hoist :
Ingersoll-Rand type FA5-MR24MK1G rated @ 4.5-T SWL (s/n A017075) new
installed 02/2012.
Man Rider :
Not Available
Mud Pumps (2)
1.Emsco Model T-1600 triplex, 7-1/2" bore x 12" stroke (s/n 74, 102) with Southwest
style 2-piece forged fluid ends (p/n KOP Femt1316SUCSW, Femt1316DISSW), Ideco
unitized V-belt pump drive, HYDRIL type K-20 5M WP pulsation dampener (RX-39),
suction/discharge strainers, 0-10M PSI pressure gauge, Falcon type C flanged RRV
(1,500-5,000 PSI operating range), Demco 2” 5M WP bleed-off valve, Halco type S
(1-1/2" x 2"R x 8-1/2”) centrifugal liner wash pump (s/n 04181) with Marathon 3-HP
EXP motor. Each pump powered by (2) GE-752, 1000-HP seres-wound DC motors
with 10-HP blower motor (January -2012) mounted over Hunt vertical air cure filter.
Power ends fitted with dual electric & mechanical lube system.
S/N 74: New bull gear & pinion (02/2004). New bearings main/pinion (08/2007)
S/N 102: New bull gear, pinion, eccentric & crosshead bearings (03/2005)
Mud Pump (1)
Loadmaster model LMF-1600 triplex, 7" bore x 12" stroke (s/n LMF-101) with single piece forged
fluid ends, metal to metal liner lock system, self-aligning rids with dual tube rod clamps, unitized
V-belt drive (8/8VP3000 Kevlar V-belts), model KB-75 5M WP pulsation dampener (RX-39),
suction/discharge strainers, 0-40,000 kPa pressure gauge, Retsco 3” type C flanged RRV
(1,500-5,000 PSI operating range), 2” 5M WP bleed-off valve, liner wash pump (1” x 1-1/2")
with 3-HP EXP motor (230/460V, 3-PH, 60-HZ), powered by (1) GE 752 1000-HP series -wound
DC motor(A) Jouliot 1000 HP Series Wound DC Motor (B) (January 2012)each with 10-HP
blower motor mounted over Hunt Air Cure filter. Power end fitted with triple redundant lube
system : Internal splash/gravity feed, internal gear-driven pump, external gear pump driven
by 480V, 3-PH, 60-HZ EXP electric motor and pressurized lubrication to lower crosshead slides.
Mud Lines & Manifold:
Gate Valves (6) : Demco 5” 5M WP
Gate Valves (4) : Demco 3” 5M WP
Gate Valves (4) : Demco 2” 5M WP
Gate Valves (1) : Demco 4” 5M WP
Plug Valves (4) : 2” 10M WP with Fig.1502 unions (cement manifold)
Mud Gauges (2) : Oteco 0-6000 PSI
Bleed-off Choke : CIW 2-1/16” 5M WP manual choke
Transmitter Flange : Petron instrument flange with Fig.1502 misaligning unions
Dual Standpipes : 4”ID 5M WP x 160 DEG goosenecks with Fig.1002 top unions
Cement Standpipe : 2” x 12m x 10M WP with flexible hose
Dual Sub Lines : 5” 5M WP with Fig.1002 unions
Dual Kill Lines : 2” XXHVY 10M WP
HP Hoses - Standpipes to TDS Swivel (2) :
Not Available
HP Hoses - Sub Base to Standpipe Manifold (3) : Not Available
HP Hoses - Mud Pumps to Sub Base to Standpipe Manifold (5) :
Not Available.
Rotary Table
Ideco model 375-E (s/n 176): Rated bearing deadload capacity 700-T. Rated
rotating load 434-T. Ideco model T-2 2-speed gearbox (s/n 5305900), GE-752
1000-HP series -wound DC moto (January 2012) with 10-HP (460VAC, 60-HZ,
3275 RPM, EXP) high-output blower motor mounted over HUNT vertical air
cure filter.
Last Service: ID/TEC 09/2005.
Master Bushing (2)
CAM-Tech model MPCH (s/n NDSC-5236) & (spare) Varco model MPCH
(s/n R-2157): 37-1/2” pin drive c/w API bowls (#1-2-3), 4-leg & 2-leg slings,
bit breaker adapter plate.
In Service: 01/2007.
Hook-Block
Ideco Shorty model UTB-525-6-60 (s/n 618): 525-T API rating with unitized hook
and (6) 60” OD x 1-1/2”D grooved sheaves. Hang-off sling: 1-1/4” D x 114ft L.
NOV Service: 02/2010.
Swivel
National Oilwell model P-500 (s/n T-5268): API 500-T rating with 5M PSI WP - 15
DEG API angle gooseneck, 4” Fig.1002 union, 7-5/8” LH REG connection and
spare washpipe assy (p/n 703429-G1U).
Kelly Spinner
Varco type 6600 pneumatic (s/n 6D15X545): With (1) motor for RH/LH rotation,
control lines, foot valve and 6-5/8” REG LH box-up/pin-down.
Kelly
Inter Drill 5-1/4” hexagonal, 6-5/8 REG LH box x 4-1/2 IF pin (6-3/8” OD x 2-13/16” ID)
x 40ft L x 37ft working length (s/n K5BA004).
Choke Manifold
CIW (s/n 00-1293) 10M WP (11) valve, H2S trim: EEC Ultraflow type E-C 3-1/16” 10M
WP (BX-154) hydraulic drilling choke with control panel (see below), J-2 transmitter
flange and EEC style H-2 3-1/16” 10M WP manual choke.
Wesco Recert: 10/2007.
-
MGV (1) : CIW model FC 2-1/16” 10M WP, BX-152
-
MGV (6) : CIW model FC 3-1/16” 10M WP, BX-154
-
MGV (2) : CIW model FC 4-1/16” 10M WP, BX-155
-
MGV (1) : CIW model FC 4-1/16” 5M WP, RX-39
-
MGV (1) : CIW model FC 3-1/8” 5M WP, RX-35
Choke Control Console (2008)
MCM (CIW style) with digital pump stroke counter, 0 - 40,000 kPa drill pipe pressure gauge,
0 - 70,000 kPa casing pressure gauge, choke position indicator, choke speed adjustment
switch, hydraulic fluid supply with back-up hand pump, hydraulic pressure gauge and limit
switches-brackets-clamps for two pumps.
(Spare Choke Control Console) Valvcon (CIW style) with EEC digital pump stroke counter,
0 - 40,000 kPa drill pipe pressure gauge, 0 - 70,000 kPa casing pressure gauge, choke
position indicator, choke speed adjustment switch, hydraulic fluid supply with back-up
hand pump, hydraulic pressure gauge and limit switches-brackets-clamps for two pumps.
BOP Closing Unit
BOPC DCS TM 9 Station Control System Cordyne Industrial Motor And Drives
330-2K50-E40GD-U23M-6-1 (s/n 6131): 330-GAL 6-station with 400-GAL reservoir, (22)
Nippon 15-GAL accumulator bottles, (2) Graco model 208-003 type K-50 air pumps
(45:1 ratio, 3.3 GPM each, s/n A5535), Gardner-Denver model PS-172 triplex
(type UET40-HTHT-600) with WEG40-HP explosion proof motor (460 VAC, 1770 RPM).
GPES Recert: 12/2005.
-
Accumulator : Model TB3305B.
- Manifold : Model UMGT2R06P10 hydraulic w/ 1”, motor-driven, failsafe regulator
- TR Regulator (auto) : Model PTR-5-1500-0-10 (s/n 9018)
- TR Regulator (manual) : Model MTR-5-1500-0-10 (s/n 04020)
- Driller’s Remote : Model AOGPR006-FC, 6-station air-operated w/ open/close display
- Toolpushers Remote : Model EE GRB08AP-HMI/PLC Siemens Touch Panel
- Air Inter-connect Cable Assy : Model 100-JG37JG
- Air Shuttle Valve Assy : Model SV12SV19 (operates 4-way c/valve - both remotes)
- Low Pressure Alarm : Model LHP - Low Fluid Level Alarm: Model LFL
- Pipe Rack Assy : Model PRMG40-13 32’L with 15 x 1” x 6M WP steel control lines
- Control Hoses : Spec. 070-5000 5M WP S/S armored (10 x 34ft L, 2 x 38ft L, 12 x 8ft L)
Drillers Console
Petron model IDS-2000 RIG SITE MONITOR with Pentium-based computer,
1.4 KVA UPS (2), remote printer and display with graphics printout and DrilGraph
remote. Sensors for active pits (5) including: PVT, trip tank, flow-out, pump SPM,
TD, ROP, bit tracking, pipe velocity, hook load, WOB, pump pressure, rotary RPM,
rotary torque. IDS indicator model HKL-A000063. IDS indicator sensor
model P000010 (2).
Weight Indicator :
- Petron type EB (16”) model AWE9-1 (s/n 0325).
- MD-Totco type EB (16”) series AWE (s/n 1024).
- Petron type E80 (s/n M2073) tension type sensator.
- MD-Totco type E80 (s/n 0202309) tension type sensator.
Hydraulic Analog Gauges/Sensors:
for tong torque, pump PSI, flow indicator, trip tank
Auto Driller
Mattco Bearcat (s/n 8036): with pneumatic controller and feedback.
Drift Recorder
Martin Decker-Totco 8 DEG & 16 DEG: double recorders c/w accessories.
PA system
Atkinson Dynamics Intercoms Model AD 26-8 Gaitronics Page-Party with 12-stations
(rig floor/choke manifold/shaker tank/suction tank, workshop, offices [3],
SCR/substructure/guard cabin/elect store) and tied in with the PLC via a tone
generator for CH4, H2S and enginge control audible alarms.
Monkey Board PA
Atkinson Dynamics Intercoms Model AD26-8: For Driller-Derrickman with type
hands-free remote at monkey board.
Rig Workshop
Toes design 3-section Mechanic/Welder workshop, store & cool-store on 3-runner skid.
Each section: 10mL x 3.2mW x 3.2mH with roof and 2-TON SWL lifting beams over
Welders workshop. Includes small air receiver
Diesel Genset (Unit s/n NDSC-5232)
Engine :
CAT D3306 DITA (s/n 85Z10817, a/n 7C 9312), 1500-RPM, 296-HP with
Woodward type PRG governor
Alternator : CAT SR4 (s/n F5A07024), 400V, 1500-RPM, 244-KVA, 195-KW, 50-HZ
Fuel Tank : NSF 2m3 x 1.9mL x 1.4mW x 1.6mH x 0.9-T (JN 8017-04/08)
Motor Genset (Unit s/n NDSC-5234)
Motor : Marathon 4J444T: 100-HP/600VAC/60HZ/1185RPM (s/n AE580153)
Alternator : Newage model 350-28700, 415VAC, 50-HZ, 65 KW (Intersel 10/2006)
Rig Offices
Air-conditioned, 4-office, laboratory, mess, storeroom with (6) cabins, each on
3-runner skid, mounted on two (2) 3-runner master skids with (2) independent
50-KW genset power supply sources:
Skid #1 :
- Toolpusher cabin with TP office (front) and Materialman (rear) with WC
- PE cabin with office, WC
- Client cabin with office, shower, bedroom. Installed: 10/2005
Skid #2 :
- Service Company cabin with (4) rooms (4 beds) e/w ablution (s/n NDSC-5270)
- Senior mess and CM/CE office
- 55m3 potable water tank with (2) pumps, filtration and chlorine injection
Skid #3 :
- Mud lab cabin with 1-man accommodation
- 2-room cabin with 2 beds for TP & PE
- Safety training cabin. Installed: 12/2005
Skid #4 :
CH Mech/ CH ELECT: Single skid 10.5mL x 3.5mW with furnished,
WC/shower & bedroom. Installed: 2011
DP Bins (10 : 37ft L x 8ft W on 3-runner skid (35-T SWL)
DC Bins (04) : 37ft L x 8ft W on 3-runner skid (35-T SWL)
Junk Bins (3) : 30ftL x 7ft W on 3-runner skid (35-T SWL)
Pipe Racks : 42”H x 27ft L (8), 20”H x 27ft L (8), 42”x13”L (2)
Seatainers (5) : 20ft L x 8ft W x 8ft H (10-T SWL)
Tool House : 27ft L x 7ft 10"W x 8"H on 3-runner skid.
Mobile Camp
(24) air-conditioned cabins, each on 3-runner skid, mounted
on nine (9) 3-runner master skids.
Accomodation Rig & Camp
Rig Senior Staff : 9 Beds
Camp Senior Staff : 30 Beds
Camp Junior Staff : 68 Beds
Total Beds : 107
M/Skid 1 : (3) cabins: (6) senior rooms (24 beds)
M/Skid 2 : (3) cabins: (4) senior rooms (8 beds) with center ablution
& (2) junior (8 beds)
M/Skid 3 : (3) cabins: (3) junior rooms (12 beds), (1) senior room (1 bed).
Clinic-Medic room (2 beds including sick bay bed) with center ablution (2)
M/Skid 4 : (3) cabins : (6) senior rooms (9 beds)
M/Skid 5 : (3) cabins : (6) senior rooms (11 beds) with center ablution (1)
M/Skid 6 : (3) cabins, 2) junior rooms (8 beds), dry store, cold store
M/Skid 7 : (3) cabins : senior mess, galley, junior mess ( up graded)
M/Skid 8 :
(3) cabins : ablution block, laundry, GRP water tank (55m3)
(2) cabins : 2 x 4-man JS sleeper
Mosque :
30ft L x 10ft W skidded with AC.
RO Unit :
Ecowater Systems model ESM-18CE (2.8m3/hour max output)
with booster pump and model LBR8 UV sterilizer. Installed : 08/2004.
Skid 9 – Camp Generators :
Engines (2) :
Caterpillar model 3406 TA (S/N 2WBO2668/2WBO2667,
A/N 4W3805), 1500 RPM, 362-HP, 270 kW with Woodward type PRG
governor and fitted with crude oil heaters.
Generators (2) :
Caterpillar model SR-4 (S/N 6BA02075/6ba02080,
A/N 5N8662), 1500-RPM, 300-KVA, 240-KW, 400VAC, 50-HZ, 433-AMP.
Electrical DB :
Indent # DC61/4/30916 PDO-A1, Holec # 242.402-1985,
System 3-PH, 4 wire, 414V – 50C/S rated operating voltage, 1200-AMP
rated current main bussbars, 50KA – 1 SEC rated short-time withstand
current, 110 KA rated peak withstand current, IP54 degree of protection.
Fuel Storage :
12,000L settling tank with 4,000L day-tank and transfer pump
Skid 10 – Camp Workshop
20ft L x 8ft W x 9ft H sea container with shelves, workbench, vice, lights, AC
and ABAC model B3800-200CT3-V400CE portable air compressor
(lot #387066-0010) with model 3700060 air end (lot #016781-0299) and
KEW 3-PH type Y90L-2 230/240V 2.2-KW 50-HZ induction motor
(unit s/n NDSC-5287)
Guard Cabin :
18ft L x 10ft W X 8ft H skid with 1.5-T air-conditioner.
Rig Mosque
: 13ft L x 10ft W x 8ft H skid with 1.5-T air-conditioner.
Training Room
Fire Alaram System :
Model No CFP 2/4/8/ Zone Conventional Fire Alarm
System Connected to all the cabins in the camp site And Installed Control
Panel in the Sr Mess Room. Installed May 2012.
Price & terms : Please enquire using the email form below.
If you cannot find the vessel, crane, rig or equipment that you need,
please send us an email to mail@worldoils.com stating your
requirements and we shall find it for you.
We can arrange delivery of equipment and towage of rigs and vessels where needed.
The details mentioned above are believed to be accurate but are not guaranteed.
---------------------------------------------------------------------------------------------------
Search words (for official use only) :
Ideco 2100E Rig for Sale
Land Drilling Rig for Sale
Ideco Drilling Rig for Sale
Ideco Mechanical Land Drilling Rig for Sale
Ideco 2100E - Land Drilling Rig for Sale
---------------------------------------------------------------------------------------------------
.png)
.png)
.png)
.png)
.jpg)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
Search Here
1628684352970.jpg "1970 Built 30,000 LPG Propane Tank - For Sale")
1628684352970.jpg "1970 Built 30,000 LPG Propane Tank - For Sale")
