Tug Boat For Sale
Description:
Type of Ship : Harbour and towing Tug Boat with FiFi Built Year : 18 Oct,2008 Class : ZC Navigation/service area : Coastal/A1 GRT/NRT : 493t/147Mt
Dimensions Loa : 38.80 m Lpp : 35.00 m Breadth (M) : 10.20 m Depth(M) : 4.80 m Draft(light/loaded) : 2.65/3.43 m Light/loaded displacement : 714.90/1019.40 Mtons Material(hull/deck) : Steel/steel
Engine M/E(type/output/rpm/set) : G8300zc6B,1500kwx500rpm,2sets, Made in Wuxi,China Aux.(type/output/rpm/set) : 495AZD/35.30KW/1500RPM,/1sets, Made in China 6135Zcaf/1330KW/1500RPM/2sets, Made in China Generator(type/output/rpm/set) : STC-30/30KW/1500RPM/1sets, Made in China T2H2XV-120-2/120kw/1500rpm/2sets, Made in China
Bow thrust : Fitted Oil : Light oil Navaids : 1 STR6000,1 FT1500,1 H3E/H3E/J2B/F1B,1 SAR-9, 1 SEP-406,2 STV160,1 GPS,/2 MAGNETIC COMPASS, 1 SOUNDER ECHO
FiFi : Main fire pump 3BA6/60m³/h/0.50Mpa, Fire extinguisher 11sets,others 6uints
Propulsion : 1 Gear 1.757:1,2 stern shaft Dia.240mm,2 Dia.2000mm fixed Cu propeller
Annual survey : 27 Sept.,2009
Price & terms : Please enquire using the email form below.
If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you.
We can arrange delivery of equipment and towage of rigs and vessels where needed.
The details mentioned above are believed to be accurate but are not guaranteed. -------------------------------------------------------------------------------------------------------- Search words (for official use only) - Tug Boat - 2 x 2040hp - For Sale 2008 Built Tug for Sale Tug Boat 2008 Built For Sale Tug For Sale --------------------------------------------------------------------------------------------------------
VFD Land Rig for Sale 3000 HP Land Drilling Rig 3000hp SCR Drilling Rig
General Overview Depth rating : 29,520 ft., (5”DP) Horsepower : 3,000 HP Max. Hook load : 1,500,000 lbs
Drawworks Type : Single or Double Drum HP rating : 2,000 HP Drilling line : 1-3/4” EIPS Main brake : Disc Drive Type : A/C or D/C
Mast Type : Cantilever Height : 152 ft (Optional heights) Static Hookload Cap : 1,500,000 lbs Width at Drill Floor : 30 ft
Substructure Type : Slingshot or Swing-Lift Clear Height : 35 ft Casing load : 1,961,560 lbs Setback load : 800,000 lbs
Top Drive Type : Varco TDS-8SA (Optional) Rating : 750 ton Max. Torque : 63,047ft/lbs
Rotary Table Kelly Bushing : Pin Drive Table opening : 37-1/2”
Power Generation Generator type : Cat SR-4B (x 4) Generator rating : 2,150 KVA (each) Engine type : Cat 3516B (x 4) HP rating : 1,860 BHP (each)
Mud Pumps Type : F Series HP rating : 1,600 HP Pressure Rating : 5,000 psi
Power Control Type : SCR or VFD (Optional)
Mud System Active system capacity : 3,000 bbls Reserve system capacity : Optional Shale shakers : Brandt, Derrick
Instrumentation Manufacturer MD Totco Type Rig Sense
Desert Package Rolling Gear & Trailers Optional
The details mentioned above are believed to be accurate but are not guaranteed.
-------------------------------------------------------------------------------------------------------------------- Search words (for official use only) - VFD Land Rig for Sale US made 3000hp Land Rig For sale New Chinese made Land Rig For Sale SCR Rig Builders 3000hp Land Rig Brokers, Dealers 3000hp Land Rig For Sale Land Drilling Rig For Sale New Build Land Drilling Rig - 3000hp 3000HP SCR Rig ------------------------------------------------------------------------------------------------------------------------
Cabot 900 Series - Driling Rig for Sale 2013 Refurbished - 900hp - Drilling Rig
Description: Cabot 900 Series Refurbished 2013 900 HP, 350,000# Country: USA
Carrier and Drawworks : Consisting of Model 2346 single drum drawworks, Parmac V-80 assist brake and rotary drive. Two Caterpillar 3408 475 hp ea. diesel engines powering drawworks, rotary drive and roading chassis. 117’, 350,000# API capacity telescoping mast includes racking board and hydraulic catworks. Mounted on Cabot 900 series chassis. 17’ telescoping type substructure with pipe slide, BOP dolly and track system.
Model 2346 Drawworks : 12” x 46” brake rims, 23” x 44” drum barrel. 60,000# single line pull 30” 2-plate clutch. LeBus type grooved jacket for 1-1/8” wire line. Includes turn back rollers. NEW & REBUILT
Assist Brake : Parmac V-80 brake with overrunning clutch. Includes supply and discharge water manifold with air operated supply. Inlet and outlet valves. Driller’s console includes air pressure regulator for brake modulation control and hand valve control of friction brake function. NEW
Water Manifold : Water inlet circuit from hammer union alongside rig to assist brake and to water circulating brake rims. Control valve in assist brake inlet line modulated by hand valve at driller’s control. Independent discharge line from assist brake and rim brakes to hammer union alongside rig.
Charge Pump : 3 x 4, 11-3/4” impeller, 1150 RPM, 15 HP, 55’-70’ total head and 350 GPM maximum volume required. NEW
Reservoir : 60 BBL volume built inside water tank for extra cooling. NEW Driller’s Console : Located at 17’ high elevated position with folding platform hinged to mast. Pneumatic control for drum clutch, engine throttle, engine emergency shutdown, transmissions and rotary clutch also included. Stairs with handrails form platform to carrier walkway. Mechanical controls located adjacent to controls for drawworks brake. NEW Cabot Carrier Model C9-962-300 : Triple axel front, triple rear axel carrier with 12 x 4 drive, 300” wheel base (bogie center to bogie center). High strength steel fabricated frame. Eaton EFA-22T5 triple axles (66,000# service rating) with 16-1/2” x 6” air brakes on all wheels and with spring suspension. Eaton DP480P double reduction powered tandem and NeWay air suspension leading third axle, all with 16- 1/2” x 7” air brakes, walking beams suspension an powered tandem (68,000# service rating). Has spring safety brakes mounted on two powered axles. Six 18:00 x 22.5 16-ply nylon highway tread front tires and twelve dual mounted 10:00 x 20 12-ply all purpose rear tires. Ross 503 steering with Garrison hydraulic power assist. One-man cab with heater, defroster, two bus type rear view mirrors, driver’s instrument panel, adjustable bucket seats with shock absorber mounted and seat belts. Mechanical support legs, 2-sets required (2 legs per set), rear and midship for greater lateral stability. One 125-gallon roading fuel tank with float valve for inlet from location fuel supply, one tool box, clearance and directional lights, tow bars front and rear.
Walkway and Stairs : Includes walkway alongside of unit on driller’s side extending from rear of unit to engine area. Stairways stairs including handrails. NEW
Deadline Anchor : Hercules 118 type wire line anchor.
Front Guy Line Anchorage : Guy lines anchor to front of carrier. Includes wireline, tail chain, forged steel boomers, thimbles and clamps.
Drawworks Power : Two Caterpillar 3408 475 hp ea. Series Diesel Engines. No. 1 engine equipped with Allison CLBT-6061. No. 2 engine CLBT -6061 torque converter transmission with lock-up providing five forward and one reverse speed. Each engine equipped with variable speed governor, belt driven Bendix V-1000 (24 CFM) air compressor, horn warning system for high water temperature/low oil pressure, commercial silencing muffler, dry type air cleaner, air starters, and engine instruments. REEBUILT -0- HRS
Specifications : Basic Output : 475 HP per engine at 2100 RPM; Total HP 950 Cooling : Radiator with suction fan Starting : Air Transmission Speed : 5 forward, 1 reverse Shift Control : Air over hydraulic with air position indicator
Drawworks Drive : Allison CLT-6061 and CLBT-6061 combination torque converter transmission, each driving through Model 450 right angle drive to drawworks final drive compound. 5 forward speeds and 1 reverse to drawworks and rotary. REBUILT Rotary Drive : Heavy duty propeller type drive for rotary table through 27-1/2” size. Includes full air rotary clutch, herringbone reduction gear and oil bath chain elevated rotary drive from drawworks to rig floor. Elevated drive hinge mounted. REBUILT
Easy transport and rig-up on rig carrier. Chain drive always remains made up.
Specifications: (With Typical 3.75:1 Ratio Rotary Table) Maximum Rotary Table Speed – 220 RPM Rotary Speeds – 5 Forward and 1 Reverse Elevated Rotary Drive Chain – 1-1/2” Two Strand Propeller Shaft – Spicer 1880 final Drive, Spicer 1810 ahead of Elevated Drive Rotary Clutch – Two Plate 18”
Hydraulic Power : 36 GPM 2000 PSI (maximum) Pressure system, provided by either of two pumps. Tong selector valve and throttle control at driller’s position.
Wire Line Capacity: 335’ Max Pull: 8,800# (1st layer) Max. Speed: 95 FPM (At 35 GPM) (1st layer)
Mast : 117’, 350,000# Capacity, telescoping open face structural mast with legs of cold drawn AISI seamless alloy heat treated steel tubing. Constructed in two sections, the upper section telescoping into the lower section for over the road position. Adjustable support screws in mast legs; folding ladder, level and tilt indicator. MAST IS REBUILT AND HAS MPI INSPECTION
Crown Block Assembly : Integral type, welded box construction drilling crown assembly. Five 30” sheaves and one 36” offset sheave for fast line. 1-1/8” grooving ALL NEW BEARINGS
Crown Nest : With guard rail and expanded metal floor
Hydraulic Mast Raising, Lowering And Extending Mechanism : Two double acting, three stage telescoping type hydraulic rising and retracting cylinders. Upper mast section extending with two extending cylinders. Additional to mast hydraulics for dtwo engine rigs so that earthier engine of two engines rig may be used for hydraulic power functions. Includes pump, drive, manifolding, lines, control valves, oil reservoir and fluid. NEW
Mast Support : At front and rear of carrier, supporting mast in over-the –road position. NEW
Racking Board : Heavy duty welded construction with derrick man’s platform of expanded metal. Side-mounted racking fingers furnished to facilitate uniform racking and prevent swarming. Has locking pins at open ends. Maximum capacity 10,300’ of 4-1/2” drill pipe (6-1/2” tool joints) and automatic unfolding and folding of the Racking Board during extension and lowering of upper section of mast
Wind Guys : One set wind guys consisting of two 3⁄4” cables from crown and two 9/16” cables from racking board. Each equipped with 10’ tail chain. Used on Cabot cross type substructure.
Rig Base : 9’ wide x 40’ long x 6-1/2” deep. Structural steel covered with 1⁄4” plate top and bottom, complete with access hinged and loading capabilities. NEW
Substructure : Cabot “T” Type 17’ high “Scoping” Substructure.
Features - Derrick base and rig base 11’ x 13’ x 15’ with 5000 psi mud lines, BOP cart and rails, stairs, walkways, safety railings, V-door ramp, and catwalk.
Maximum rotary (casing load) is 450,000 lbs. simultaneous with a setback load of 200,000 lbs. for a total of 550,000 lbs. substructure capacity.
Generator House : 1 - 2010 Generac Series SD500 (500 KV AC) generator set powered by 16.12 liter Volvo diesel engine with 637 hours. Electric started, radiator, gauges, power manager digital control platform.
1 - 2500 Cat SR-5 455 KW Ac generator, rebuilt. Powered by Cat 3456 691HP engine with electric starter, gauges, Cat EMCPII diagnostic system, skidded.
1 - Sullivan Palatek rotary screw air compressor powered by 30HP electric motor with air tank.
All of the above mounted in 9’9” wide X 42’ long utility house with 2010 Square D motor controls and switch gear with EGS 75KV A transformer, safety florescent light, skidded.
Power Mud Pumps : 1 - Sentry S1-1000, 6 3⁄4” x 10” with quick change fluid end with pressurized lubrication system (1 1⁄2” x 2” lines wash pump) with electric 5” x 6” x 12” charge pumps with Sentry pulsation dampeners, 3 -5000psi relief valve, 3”- 5000psi pressure gauge all powered by 2010 Detroit Diesel 12V2000 engines- 1050 HP each, air volume tank, diesel day tank, oilfield type master skid.
1 – Gardner Denver PZ-8 with quick charge fluid end, pressurized lubrication system; pulsation down power, 3” 3000 psi relief valve, 3000 psi pressure gauge powered by CAT D-398 with air starter, air volume tank, diesel day tank, oilfield mater skid
3 Tank Mud System (700Bbls) : Shaker Tank - 4’ high x 9’8” wide x 32’ long mud shaker tank with 2 compartments. 7 1⁄2 HP mud agitators, 2- Derrick FLG-503 linear motion shale shake, 580gpm, 8 cone Odrill desilter, top mounted walkways, stairs, safety rails and safety florescent lights, All oilfield skidded.
Desander Tank - 4’ high x 9’8” wide x 42’ long mud desander tank with 2 compartments, 2 - 5hp mud agitators with 10’ electrical control room, for starters and control panels. 2-60hp 5’x6”x11” centrifugal pumps, All top mounted walkways, safety rails, and safety florescent lights. All oilfield skidded.
Suction Tank - 4’ high x 9’8” wide x 31’ long mud suction tank with 2 compartments, 1-5hp mud agitator, 2 60hp 5”x 6”x14” centrifugal pumps, 10’ porch with mud mixing hopper and electrical florescent lights. All oilfield skidded.
Rig Houses : Top doghouse-10’ wide x 40’ long with benches, 12 lockers, tool and bolt room, knowledge box, Satellite Auto Driller, Martin Decker 3 pin geolograph recorder, 2-220Volt electrical heaters, insulated, safety florescent lights, windows, covered porch, with electrically lowered stairs and landing with safety rails. All oilfield skidded.
Water tank- 9” high x 10’ wide x 42’ long with 8’x 10’ storage room with high pressure Cat wash down pump, water pump, 1-220 volt electric heater, has 4 hydraulic cylinders with control valve to raise and lower top dog house, safety florescent lights. All oilfield skidded.
Fuel/Accumulator Trailer : 53’ Aluminum step deck 2 axle spread trailer with 3,500 Gal. Baffled fuel tank, Cameron 5 station 8 bottle closing unit with electric Cat triplex pump. Skid mounted. Five Star wireline retrievers with line capacity of 15,000 ft., depth measuring counter hydraulic control with 15hp electric motor, oil caddy for motor oil, hydraulic oil and gear oil, used oil tank.
Blowout Preventer : 1 - 11” 5000Lb. Shaffer Style (U.S. Casting) studded 4” and 4 1⁄2” pipe and Blind rams.
1 - 11” 5000Lb. Shaffer Annular studded top, flange bottom
Choke manifold with two manual chokes
Handling Equipment : 4 – New pipe tubs 1 – New center tub with catwalk and V-door 1 – 40’ x 4 1⁄4 Hex Kelly with split master bushings NEW 1 – Varco Hydaulic spinner with forward and reverse 2 – BJ type B rotary tongs with heads to 9 5/8” 1 – BJ 4” Bottleneck drill pipe elevators 1 – BJ 4 1⁄2” Bottleneck drill pipe elevators 1 – 5 1⁄2” casing elevators 1 – 7” casing elevators 1 – 8 5/8” casing elevators 1 – Set each 4” and 4 1⁄2” drill pipe slips 1 – Set each 5 1⁄2”, 7”, and 8 5/8” casing slips 2 – Elevator links 1 – Tong line pull gauge 1 – All mud hard lines, vibrating lines, Kelly hose 12 – Fire extinguishers
Rig is refurbished with all new parts and has only drilled 5 wells since going to the field. Price: US$1,750,000
------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : Cabot 900 Series Land Rig for Sale 900hp Land Drilling Rig for Sale 2013 Refurbished Cabot Drill Rig for Sale Cabot 900 Drilling Rig For Sale 900hp Land Drilling Rig For Sale in USA Cabot 900 Series Refurbished Drill Rig -----------------------------------------------------------------------------------------------------------------------
Mid-Continent U-15 Drawworks Used Mid-Continent U-15 Drawworks for sale For further information, please contact rigs@worldoils.com --------------------------------------------------------------------------------------- Search words(for official use only) : Used Mid-Continent U-15 Drawworks for sale Mid-Continent Drawworks for sale Used Mid-Continent U15 Drawworks for sale Drawworks for sale -------------------------------------------------------------------------------------------
Multi Purpose Supply/Utility/Dive Vessel for Sale Multi Purpose Supply Vessel for Sale - New building New Multi Purpose Utility Vessel for Sale New building Supply Vessel
Vessel : Build : 2009 Classification : RINA C+HULL + MACH, SUPPLY VESSEL,COASTAL GRT / NRT : 222/67
Auto Pilot : 1 x NAVITRON Autopilot - NT 921 MK II - Autopilot set
GPS Navigator : 1 x JRC GPS - JNAV 500 - GPS Navigator set
VHF : 2 x ICOM V.H.F - IC-M31 -Marine hand held V.H.F.
EPRIB : 1 x Jotron EPIRB - 95475 - Tron 40S EPIRB
Portable VHF (GMDSS) : 1 x ICOM VHF - IC-M411- Marine VHF set ( with DSC funtuanility)
SART : 1 x Jotron SART- SART 20 - Radar Transponder
Navtex Receiver : 1 x JRC Navtex - NCR 333 - Navtex receiver set
AIS : 1 x JRC A.I.S. - JHS 182 -AIS-Automatic identification system
Atlas Copco T3W Drilling Rig for Sale Atlas Copco T3W Drilling Rig - 2009 Built - For Sale
Model : T3W Drill Rig Manufacturer : Atlas Copco Year : 2009 Condition : Used
Description :
2009 Atlas Copco T3W Drill Rig S/N: 21307 Caterpillar C15 Diesel Deck Engine Ingersoll-Rand HR2.5 900 CFM / 350 PSI Air Compressor Rated 40,000 lb. Pullback Capacity 3x4 Centrifugal Mud Pump, Hydraulic Powered 7-Gallon Hammer Lubricator 18 GPM, 4-Piston Bean Water Injection Pump 9-Rod Carousel with Single Arm Rod Loader 18,000 lb. Drawworks with Dual Controls Includes 600' ft of Drill Pipe (20 ft x 3-1/2" OD x 2-3/8" IF Threads) Mounted on 2009 International WorkStar 7600 Truck Caterpillar C13 Engine with Jake Brake Front Tires : 425/65R22.5 Rear Tires : 11R22.5 VIN: 1HTWXSBTX95090452 Hendrickson Suspension with Locking Rear Differential
Location : USA
--------------------------------------------------------------------------------------------------------- Search words (for official use only) : Drilling Rig - Atlas Copco T3W for Sale 2009 Built Atlas Copco T3W Drilling Rig for Sale Used Atlas Copco T3W Drilling Rig for Sale Atlas Copco T3W Used Drilling Rig for Sale Atlas Copco T3W Drilling Rig for Sale in USA -------------------------------------------------------------------------------------------------------
Deck Barge For Sale Used Deck Barge For Sale Deck Barge For Sale in Asia 85M Deck Barge For Sale in Singapore
Specifications : Built : 2011 BV Class
Principal Dimensions : Lenght overall : 85.60m Designed waterline length : 82.30 Length within perpendiculars : 79.30m Breadth : 28.50m Breadth at design waterline : 24.00m
Depth moulded : 6.00m Design draft : 4.20m Deadweight : ~4500t Displacement : ~6280t
Complement : 14P Service : Unrestricted Continous power : 956kw/850rpm Design speed : ~10kn Deck cargo carrier, Deck load : 15t
--------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) - Deck Barge For Sale Deck Barge for Sale - 85M 2011 built 85M Used Deck Barge for Sale in Singapore 2011 built Barge for Sale in Asia Deck Barge for Sale - 85M - 2011 Built Deck Barge for Sale in Malaysia ------------------------------------------------------------------------------------------------------------------------------
Platform Supply Vessel for Sale DP2 Platform Supply Vessel for Sale - Newbuildings MMC887 PSV FiFi 1 for Sale Newbuildings DP2 PSV For sale Classification : ABS +A1, (E) Offshore Support Vessel, +AMS, +DPS-2, +FFV Class 1
Other Compliances : International Load Line Convention 1966, International Tonnage Convention 1969, COLREG 1972, SOLAS 1974 with amendments (where applicable), International Radio Communication Regulations, MARPOL 73/78 (Annex I, II, IV, V, VI)
Principal Dimension : Length O.A : abt. 88m LPP : abt. 82.00m Breadth MLD. : abt.19m Design Draft : abt. 5m Max Draft : abt. 6m Deadweight : abt. 5145 Tonnes Gross Tonnage : abt. 3601 Tonnes Net Tonnage : abt. 1429 Tonnes Deck Cargo : abt. 1000 Tonnes Deck Strength : 5 Tonnes/sqm Speed : abt. 14.3 knots at 100% MCR, 5m draft Economic Speed: abt. 13 knots at 75% MCR Deck Area : 1000 sqm Complement : 52 men Fuel Type : Gas Oil
Tank Capacity (Approximation) : Potable F.W. : 1770 cbm F.O. (Total) : 1100 cbm Liquid Mud / Brine (S.G 2.4) : 680 cbm Dry Bulk Cargo Tank (Cement/Baryte) : 400 cbm Drill Water / Water Ballast : 1830 cbm Methanol (SG 0.9) : 430 cbm
Bulk Handling System : Suitable for Carriage of Cement/Baryte Class : ABS Total Capacity : 400 sqm approx. (in 5 tanks) Working pressure : 80 psi
Main Propulsion : Main Propulsion – 2 x 2000 kW Fixed Pitch azimuth thruster c/w electrical motor. Bow Thruster - 1 x 910 kW Tunnel Thrusters CPP c/w electric motor speed at 1800 rpm driven. Retractable Thruster - 1 x 800 kW Retractable Thrusters CPP c/w electric motor speed at 1200 rpm driven.
Power Plant : 1) Prime Mover(Diesel Engine) - 4 x 1825 kW Cummins Engine c/w generator, 480/3/60 2) Emergency / Harbour Generator - 1 x 350 kW approx, 480/3/60
Deck Machinery : 1) Anchor Windlass - Electro-Hydraulic driven, 2 Declutchable Drum, 2 Declutchable cable lifter, 2 Fixed Warping End Nominal Pull : 10 MT, 0 – 20m/min
2) Deck Crane - 2.0MT SWL at outreach 10.0M. 3) Others - 2 x Capstan (7.5mt pull) and 2 x Electric Mooring Winch(10mt pull)
Fire Fighting : 1) External Fire Fighting System – Class FiFi 1 having 2 in nos main fire pump (1600cbm/h) driven by generator engine front PTO c/w 2 x Fire Monitors (1200m3/h) and with fixed water spraying system as per classification rules.
2) Fixed Fire Protection System - Engine Room, Paint Store & Emergency Generator Room installed with fixed CO2 Fire protection system
Navigation Equipment : 1) Echo Sounder 2) Radars 3) Voyage Data Recorder 4) Magnetic Compass 5) Auto Pilot 6) AIS 7) Weather Facsimile Receiver 8) Doppler Speed Log 9) Ship Security Alert System
Communication Equipment : 1) GMDSS for Area A3 2) PA/Talk back 3) Auto Telephone System
Dynamic Position System : Dynamic positioning system according to ABS DPS-2 c/w with 2 off DP operator stations, 1 off cJoy Operating Terminal, 1 off cJoy Wing Terminal(Portable), 2 off Gyrocompass, 2 off Wind sensors, 2 off Motion reference units, 1 off Spotbeam, 1 off RADius Position reference system, 2 off DGPS, 2 off UPS, 2 off Alarm and Event Printer.
The following basic operational modes are included : • Joystick Mode • Auto Pilot Mode • Auto Heading Mode
Accommodation : Fully Air-Conditioned c/w hot water heating and air distribution system. One off electrical heater to be installed in cabins. 16 x 1 man cabin – 16 men 10 x 2 men cabin – 20 men 4 x 4 men cabin – 16 men Total – 52 men Dispensary – 1 men
Spare Parts : Class Standard requirements applied. Price & terms : Please enquire using the email form below.
The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------ Search words (for official use only) : Platform Supply Vessel for Sale DP2 PSV FiFi 1 for Sale - Newbuildings MMC887 Platform Supply Vessel Newbuildings PSV-DPII FiFi 1 for Sale MMC887 PSV for Sale --------------------------------------------------------------------------------------------------------------------
Pipelaying barge For sale 292 Men Pipelaying Diving Maintenance Accommodation Barge 112M Pipelaying barge For sale Pipelaying Accommodation Barge for Sale 2008 built Pipelaying barge For sale Pipelay Capability for 200 mm – 1500 mm Pipe Principal particulars Class : ABS +A1 unrestricted service with MODU code attestation Built : 2008 Gross Tonnage : 13,575 T Nett Tonnage : 4,072 Dead Weight 10,233 T Dimensions Length overall : 111.63 m Breadth moulded : 31.7 m Depth : 9 m Designed Draught : 4.8 m Pipelaying facilities Pipelay Equipment Pipelay capability for 200 mm to 1500 mm 90 ton pipe lay tensioner capacity (30 m/min) 100 ton pipe lay abandonment / recovery winch Automatic tensioner transfer system Pipelay conveyor and transfer system rated to 32 ton 7 welding stations with semi-automatic welding system (STT & flux core) 1 NDT station 2 field joint stations Dark Room Stinger/Ramp 3 degree sloping production firing line 34 m outrigger stinger adaptable to different project requirements
Diving capability In-built moon-pool (5.5 m x 5.5 m) Support services for modular saturation diving spread 8 POINT MOORING SYSTEM 8 x single drum 90 ton mooring winches c/w tensional sensor, wire length counter 8 fairleads, with 1500m of 52mm wire rope. 9 x 10 ton Delta Flipper anchors9 x Pennant Buoys
Helideck Size : 22 x 22 m for Sikorsky S61
Safety systems Mass Evacuation Slide and Raft System Life rafts to 590 person capacity 600 life jackets/12 life rings 1 x fast rescue boat Active high specification smoke and fire monitoring and extinguisher system in all accommodation, engine, winch, paint and boiler rooms Sprinkler system Machinery guarding systems Dedicated boat landing transfer points Environmental Sewage treatment system meeting MARPOL standards Spill prevention systems Other facilities Hospital with 2 beads Well equipped galley Mess room with seating for 180 people Large cinema, TV room for 110 people Recreational Room for 60 people seating Internet and email room Well equipped gym Laundry and large food storage facilities 5 Specialist Personnel Office rooms 2 Client office rooms 3 General office rooms 2 Control rooms with CCTV and metering Navigation /Radio Control room with helicopter coms Conference room for 25 people Prayer room Paramedic room Change room with lockers and wash facilities Work shop with Lathe, Drill press plus other tooling 2 water makers of 40 ton per day capacity Machinery Generators : 5 x Mitsubishi 1200 kva 60 cycle. Emergency Generator : 1 x Diesel Caterpiller 500 kva 60 cycle. Tank capacities Fuel Oil : 2211 m3 Potable Water : 1926 m3 Grey Water 23 m3 Black Water 23 m3 Bilge 23 m3 Dirty Oil 27 m3 Cooling Water 750 m3 Pumps Fire/General Service : 2 x 130 m 3 hr 80 m head Fuel Oil : 2 x 20 m3 hr 30 m head Ballast Water : 2 x 300 m3 hr 30 m head Potable Water : 1 x 120 m3 hr 35 m head Domestic F Water : 1 x 30 m3 hr 35 m head Domestic S Water : 1 x 30 m3 hr 35 m head Emergency Fire : 1 x 50 m3 55 m head Deck area Clear deck area over 2000 m2, Deck Strength 12.5 t/m2 rating Carriage Capacity over 11,000 tons Provision on deck for suitable crawler crane Accommodation High Standard of Accommodation Tank Top Cabins 30 x 2 = 60 Tween Deck Cabins 30 x 2 = 60 Deck 1 Cabins 24 x 2 = 48 Main Deck 1 x 2 = 2 Deck 2 Cabins 32 x 2 = 64 Deck 3 Cabins 28 x 2 = 56 Additional Deck 3 Cabins 2 x 1 = 2 Total Berths 292 Cabins with en-suites and fully air conditioned Price & terms : Please enquire using the email form below If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you.
The details mentioned above are believed to be accurate but are not guaranteed. ---------------------------------------------------------------------------------------------------------------------------------------- Search words(for official use only) - Pipelaying barge For sale 112M Pipelaying Barge For sale Pipelaying Diving Maintenance Accommodation Vessel 292 Men Pipelaying Diving Maintenance Accommodation Barge For Sale 2008 built Pipelaying barge For sale Pipelaying accommodation Barge for Sale Diving Accommodation Vessel with Pipelaying ------------------------------------------------------------------------------------------------------------------------------------------
80K Trailer Mounted Coiled Tubing Unit for Sale CT Rig for Sale Coiled Tubing Unit New Coiled Tubing Unit for Sale Specifications
Section 1 – Unitized Trailer 1.1 Trailer One (1) only custom gooseneck style trailer mounted coiled tubing unit (TM CTU).
Features and Specifications : Height : 13 ft.-6 in. maximum (equipment installed) Length : 53” ft. maximum Width : 8 ft.-6 in. maximum
1.2 Folding Wing Walks Features and Specifications : - Ladders and walkways will be of strong lightweight design for ease of handling and storage. - Folding walkways grip strut type, 2 ft. wide along both sides of trailer with ground access ladders. - Walkways flush with equipment deck when folded down; - Catwalks will not interfere with equipment in stored position. - Ladders, one (1) each side to upper level from lower deck and two (2) from lower deck to ground on each side of trailer.
1.3 Tool Box and Racks Features and Specifications : - One (1) each, above deck toolbox with tools storage are provided. - One (1) set of racks and hold-downs for injector telescoping aluminum support legs. - One (1) set of racks and hold downs for injector 3-ft.steel, maintenance support legs.
1.4 Hoses - Injector supply, injector control and BOP hoses are spooled on hydraulically powered hose reels and are equipped with quick disconnects (QD's) on one end. - Hose support clamps and chains will be utilized on all hose groups of four (4) or more. Hose clamps will be installed to allow enough hose slack for easy connection of hoses. Tagged with stainless steel washers behind QD's.
1.5 Assembly, Painting, Unitization, Testing and Manuals - Complete complex of equipment will be sandblasted, primed and painted. Color to be specified by the customer. - Trailer deck covered with grip strut type decking where equipment is not located. - All equipment skids will be attached with heavy-duty pins / mounts for fast easy removal and installation. Pins to have a generous tapered point to help with installation. - Guards installed to protect fittings and hoses that would otherwise be exposed for potential damage. - All hydraulic valve functions and directions clearly defined and labeled. All hose connections and mating bulkhead connections labeled with identification numbers. - All pins have retaining chains. Chain length will be generously long to allow easy pin installation. Chain will be fixed to the pin in a manner that will not interfere with tapping pins in place with a hammer. - Lifting and attachment pad eye sizes and thickness match relevant standards and accommodate standard size shackles. - Supply and installation of all required fittings, hoses, connections and miscellaneous items necessary to complete the unitization of trailer and equipment. Including all labor and hardware required to assemble and install all coiled tubing components on the trailer. - All components and equipment will be assembled, fitted and function tested before shipment. The seller will supply all fuels, lubricants and other necessary fluids to conduct these tests. - All controls will be clearly labeled. - Three (3) each, operating manuals will be supplied.
Section 2 - Control Cabin and Operator’s Console
2.1 Control Cabin The control cabin is constructed of an aluminum box tubing frame with sheet aluminum outer skin. The cabin provides all hydraulic, pneumatic and mechanical controls for coiled tubing operations and hydraulically telescopes to allow the operator clear visual access to the reel and injector head. Telescoping control has local access on the trailer deck beside the cabin.
Features and Specifications: - Cabin is insulated and the interior walls are covered with white, washable panels. - Two (2) side access doors incorporate: Window, rain gutter, and stainless steel hardware (each side of cabin). Sliding type read and side windows with rain gutters and lockable doors have key locks. - One (1) interior 12 VDC, fluorescent light is provided. Light will be located to minimize front window glare and maximize interior visibility. Interior wiring is sub-surface mounted. 110 vac outlets and lighting is also provided for use with provided generator system. - One (1) "Captain's," swivel style chair for operator. - A bench seat is fitted against the rear of the cabin with storage space below. - Two AC units to provide a Minimum cooling capacity up to 4.5 Kw - Air horn provided as a ground personnel alert device; button mounted on the control panel. - Two (2) 12 VDC, spot and floodlights are mounted externally on front of cabin and are adjustable from cabin interior.
Cabin Dimensions Height : 6 ft.-4 in. floor to ceiling Length : 7 ft.-0 in. front to back wall Width : 7 ft.-6 in. between inside walls Weight : 7,000 lb. including control panel and hydraulic controls.
2.2 Operator Control Console Features and Specifications : - One (1) 4-bank valve for BOP directional control, with isolation valve and a flip up lock out safety latch. Directional control valve has internal load checks to prevent pressure drop when individual banks are operated. - BOP pressure gauge. 0-5000 psi with a 2 1/2" face. - Emergency air over oil pump and with manual hand pump feature to operate BOP, stripper and injector traction circuits in the event normal supply pressure is lost. - Stripper circuit, includes: pressure regulator, directional control valve and gauge 0-3,000 psi, 2 1/2" face, for stripper / packer operation. - 8" face hydraulic weight indicator gauge for injector pull and push force, scale is in 250 lbs. increments. - Supply valves, bleed valves and gauges for injection traction circuits. Common inlet supply controlled by a pressure reducing valve. Gauges are 0-2,000 psi. - Joystick controller for precise injector speed and direction control. - Injector brake is automatic. - Relief valve for injector force (pull / push) control. - Pressure gauge for injector drive. 4" face, 0-3000 psi. - On / off air valves, for injector chain and tubing reel lubrication. - Hydraulic valve, 3-bank directional control is used for control of tubing reel pay-off/take-up, levelwind arm raise / lower and levelwind override. This bank valve is of mid-inlet design to allow two separate inlet supplies and one common return. The override control handle is taller and located for ease of operation. The reel take-up / pay-off handle has a normal position safety lock to prevent accidental shifting during operation.
- Reel brake off / on functioning is automatic. - Relief valve for reel tension (pay-off / take-up pressure) control. - Reel Pressure gauge. 4 1/2" face, 0-3,000 psi. - Two (2) 6" face, 0-5,000 psi, pressure gauges for wellhead pressure and circulating pressure. 4:1, gauge de-boosters are utilized to prevent pumped or well fluids from entering control cabin. Gauges are located in close proximity to the weight indicator on the control panel for ease of operator viewing. - Controls for engine speed, normal and emergency shut down. - Outside injector drive chain tension pressure control valve and pressure / bleed valves with pressure gauge, 2 1/2" face, 0-600 psi. - Engine start button. - Engine gauges include RPM, oil pressure, water temperature, and voltage/amperage. - Two (2), 12 v fans will be mounted at each side of front window. - Console panel is aluminum with engraved labeling for all controls, gauges and valves. Panel is angled for ease of viewing and access to controls. - BOP accumulators consists of one (1) each, 10 gal. bladder type accumulators. Reserve control system accumulator, (1) each 5 gal. bladder type. Both accumulators provide stored volume and pressure for BOP and system control in the event of engine shutdown. These accumulators are mounted directly in front of the control cabin.
Section 3 - Wet Kit Trailer mounted (HPS)
3.1 Hydraulic and Pneumatic Systems Features and Specifications : - HPS (hydraulic power system) is powered by a trailer mounted Engine via a pump drive. The pump drive supplies horsepower to drive the hydraulic pumps. The hydraulic pumps are mounted directly to the pump drive. The pumps are engaged and disengaged by an electric selector switch in the tractor cab. - All the hydraulic system accessories such as: Hydraulic tank, heat exchanger, gauge panel, mounts, supports, etc. are also trailer mounted. This integrated package comprises what is known in the industry as a “wet kit”. This wet kit supplies all the hydraulics required for coiled tubing operations. - A Closed Loop Hydraulic System (Pressure compensated, piston pump) is utilized to power the injector. All necessary controls, filters and valves are supplied for safe operations for maximum injector pull and running speed. - Two (2) additional pump compensated pump are used for tubing reel drive, BOP and Priority (control) and other auxiliary systems. These circuits are designed for optimal performance and minimal heat generation.
Capacities Desiel Engine (Cat C15) or Client perference : 540 HP @ 1800 to 2200 rpm Hydraulic oil reservoir : 140 US gallons. Bladder type BOP accumulators, (total) : 10 gallons. Control console hand pump reservoir : 5 gallons. Control circuit accumulator : 5 gallons. Hight pressure Hydraulic Filter Set : 1 set.
Hose Lengths Injector power : 75 ft. - Mounted on a powered hose reel Injector control : 75 ft. - Stored on trailer deck BOP : 75 ft. - Stored on trailer deck
Section 4 - Tubing Injector
4.1 Injector Head One only supplied, OS 80K (TBG INJ) Features and Specifications : - Hydraulic motor drive, wet-disc style, spring applied / pressure release brakes. - Supplied with 1 1/2" chains for coiled tubing operations. - Drive shaft, sprockets and synchronizing gears, are used to provide superior drive component strength and durability. - Each shaft drive is bearing supported. - Skate design for maximum longevity. - Remote (control console) hydraulic chain traction controls. Each has individual controls to insure redundant system safety. Each cylinder set is equipped with bladder style accumulators to reduce shock loads from tubing abnormalities. - Injector mounted load cell with drive frame support for load cell bladder protection during transporting. - 96" radius tubing guide arch (gooseneck) with steel rollers. Adjustable arch positioning over drive chain center. Pick-up chain provided for easy removal and installation of gooseneck. - Impact resistant steel protective frames. - Four (4) points lift eyes complete with single 4-part lift sling. - High-pressure inline filters assemblies located between injector motors and counter balance valves. - High pressure welded steel plumbing on motor circuits for safety. - Easy access grease fittings to insure proper lubrication. - Piloted lower bearings to insure precision alignment and insure transmission of loads through the side plates to increase component life. - Four (4) Aluminum telescopic support / stabilizer legs with adjustable leveling screw. - Four (4) 3 ft. long steel work legs. - Coupling panel with numbered quick couplings for fast set-up. Numbers match numbered stainless steel washers on hoses retained by hose quick disconnect. - Protective grids on all interior access ways for added protection to operators. - Ladder integrated into frame to access top of injector. - Lifting points located on all four top corners. Complete with four (4) 1/2" wire ropes slings, bails and shackles. - All hydraulic connections will be centrally located on a bulkhead(s). Connections will be clearly labeled, integral check valve type quick connects. Mechanical supports (chain hooks) will be provided to prevent excess strain on hose bundle and quick disconnects. Hose bundles will be equipped with bundle clamps and support chain. - Capable of accepting optional chains sizes 1 1/4" to 2 7/8” - Lower base mounting for standard stripper / packer.
Pull capacity : 80,000 lbs. Maximum 30,000 lbs snubbing. Maximum running speed : 200 ft./min. Load cell & weight indicator system : 80,000 lb. Chain lubrication system, reservoir capacity : 5 gallons. Mounted on carrier.
Section 5 - Tubing Reel
5.1 Reel One (1) only, CTU operational reel with heavy duty skid base design. Reel drum is recessed below the trailer main frame rails to reduce overall unit height. A formed steel pan below the reel serves as a tubing protection and drip pan. Dip pan area has two (2), 2" npt drain ports with plugs.
Both drum flanges are covered with expanded metal for spoke protected and easy viewing of tubing.
Reel drive is via a hydraulic motor and planetary gearbox with integral brake. Crossover relief valve protection is provided for motor. Hydraulic brake system is designed to prevent accidental over pull across tubing guide arch if injector is engaged without the reel brake being released.
Ballscrew levelwind with automatic mechanical drive of tubing support trolley and counter assembly. A hydraulic motor override system allows operator to override mechanical system and position tubing as required. Levelwind arms are hydraulically raised from horizontal position to working height angle from control cabin. A pilot operated check valve provides positive position lock of hydraulic cylinders.
Features and Specifications : - Heavy duty, dual cross member design, trolley tracking guide and counter assembly. - External manifold, 10,000 psi with inlet connections and shut-off valve between swivel and inlet. - Internal plumbing manifold, 10,000 psi with shut-off valve between axles and drum core. Incorporates a "tee" for plug and ball launching. - Spreader bar assembly with slings and shackles for lifting reel without damaging drum flanges is provided. - All hydraulic and pneumatic connections made at quick disconnect coupling panel located at side of reel skid. All connections are numbered. - Mechanical counter and tubing support (trolley). Heavy duty, 4-roller support / guide, free floating counter design. Locking pins are incorporated for strength and positive locking. The counter wheel is case hardened, precision ground for accuracy and long life. - Counter is calibrated in meters. Counter comes complete with a five (5) digit 3/4" high numbers, Veeter Root mechanical counter. Depth display is easily viewed from control cabin. - Reel drum tie down points are provided on one drum flange to secure drum during transport. Minimum working depth capacity : 20,000 ft. (with 1 1/2" tubing). External manifold (field iron inlet piping) : 10,000 psi WP. Internal manifold (tubing connection piping) : 10,000 psi WP. Height : 13 ft.-6 in. (sitting on trailer)
Section 6 – Coiled Tubing
6.1 Tubing One (1) only reel, coiled tubing string. Standard is 1 1/2” OD coil tubing; wall thickness and exact length will be predetermined with customer.
Section 7 - Well Control Equipment
7.1 Quad BOP's One (1) set of 4 1/16” X 10K QUAD BOP’S; rams hydraulically function from top to bottom. BOP’s come complete with integral, ram section equalizing valves. All ram sets have mechanical, manual locking devices and external ram position indicators.
Features and Specifications : - Blind - Shear / cutter - Slips - Pipe - Top and bottom connection CB 34 union x-over to BX 153 flanged connection. CB 34 box up x CB 34 nut & pin down. - Flanged crossover for side outlet. Flange is 2.06" BX 152 ring, 10,000 psi WP x 2" Fig. 1502 hammer union, thread half outlet. - Fitted for 1 1/4" coiled tubing service. - Rated for H2S Service - 17-4PH ram shafts and internal coating to prevent corrosion. - Actuator closing volume 216 Cu.In.
7.2 Stripper / Packer Assembly (Stuffing Box) One (1) only, Packer Assembly, 4 1/6" x 10K side door stripper
Features and Specifications : - Flange mounted to bottom of injector frame. - Hydraulic pack and retract functioning. - All internal components "split" to facilitate insert changes while pipe is in the stripper body. - 10,000 psi WP - H2S service.
Section 8 – Spare Parts
Recommend spare parts required for Coiled Tubing Unit operations.
8.1 Control Cabin and Control Console
Hydraulic Gauges Description / Range / Quantity Panel Mount, 2 ½” face / 0 -160 psi / 2 Panel Mount, 2 ½” face / 0 -600 psi / 2 Panel Mount, 2 ½” face / 0 -1000 psi / 2 Panel Mount, 2 ½” face / 0 -3000 psi / 2 Panel Mount, 2 ½” face / 0 -5000 psi / 2 Panel Mount, 4” face / 0 -600 psi / 2 Panel Mount, 4” face / 0 -3000 psi / 2 Panel Mount, 4” face / 0 -5000 psi / 2 Stem Mount, 2 ½” face / 0 -160 psi / 2 Stem Mount, 2 ½” face / 0 -600 psi / 2 Stem Mount, 2 ½” face / 0 -1000 psi / 2 Stem Mount, 2 ½” face / 0 -3000 psi / 2 Stem Mount, 2 ½” face / 0 -5000 psi / 2 Weight Indicator / - / 1 Additional Description : Quantity Traction pressure, pressure reducing valve : 2 Traction pressure on / off valve : 2 Chain Tension pressure reducing valve : 2 Joy Stick injector directional valve : 1 Stripper pack / retract valve : 1 Air regulator valve for emergency pressure air over oil pump : 1 Windshield wiper control valve : 1 Panel mount, pilot relief valves (R1E02, Denison) : 2 BOP on / off isolation valve : 1 BOP on / off valve for emergency supply : 1 Emergency / normal engine kill valve : 1 Cylinder repair kits for control cabin lifting cylinders : 2 Injector two speed / brake pressure reducing valve : 1 8.2 Hydraulic Power Unit (Power Pack) Description : Quantity Injector Drive Pump : 1 Reel Drive Pump : 1 BOP Supply Pump : 1 System safety relief valve : 1 Injector system high pressure filter elements : 8 Injector drive charge pump filter elements : 4 Low pressure return filter elements : 6 All pump suction strainers : 1(set) BOP accumulator bladder replacement kit : 1 Priority accumulator bladder replacement kit : 1 Pump isolation butterfly valve replacement seals : 2 O-ring kit, 3/32" width : 2 O-ring kit, 1/16" width : 2 Hose reel hydraulic drive motor and sprocket : 1 (each) (M/F) standard hydraulic quick disconnects, sizes 1/4" thru 1" : 2 (sets) Injector male and female quick disconnects : 1(set) 8.3 Tubing Injector Description : Quantity Injector Drive Chains : 1 (set) Seal and repair kits for injector chain traction cylinders : 4 (kits) Seal and repair kits for injector chain tension cylinders : 2 (kits) Gooseneck polyurethane rollers and bearing assemblies : 1 (set) Traction accumulators : 2 Drive system counterbalance valve cartridge : 1 Brake release shuttle valve : 1 Chain traction bearings : 1 (set) Drive motor : 1 Drive chain tension sliding take-up bearings : 2 Drive chain bottom idler bearings : 2 8.4 Tubing Reel Description : Quantity Reel drive hydraulic motor : 1 (each) Levelwind override hydraulic motor : 1 (each) Levelwind follower (pawl) inserts : 2 (each) Counter wheel : 1 (each) Chains and master links for counter : 1 (set) All bearings used in counter assembly : 1 (set) Veeder Root counter and drive coupling : 1 (each) Circulating swivel seal and repair kits : 2 (kits) Nose seals for circulating swivel : 4 (each) Levelwind arm cylinder seal and repair kits : 2 (each) Repair and seal kits for Reel plug valves : 2 (kits) Lenz coiled tubing connectors, 1 1/2" npt x 1 3/4" tubing : 10 (each) 8.5 Well Control Equipment Description : Quantity Reel drive hydraulic motor : 1 (each) Levelwind override hydraulic motor : 1 (each) Levelwind follower (pawl) inserts : 2 (each) Counter wheel : 1 (each) Chains and master links for counter : 1 (set) All bearings used in counter assembly : 1 (set) Veeder Root counter and drive coupling : 1 (each) Circulating swivel seal and repair kits : 2 (kits) Nose seals for circulating swivel : 4 (each) Levelwind arm cylinder seal and repair kits : 2 (each) Repair and seal kits for Reel plug valves : 2 (kits) Lenz coiled tubing connectors, 1 1/2" npt x 1 3/4" tubing : 10 (each) 8.5.2 Stripper Packer / Stuffing Box Assembly Description : Quantity Standard service stripper rubbers for tubing : 25 (each) Standard service energizers for above stripper rubbers : 5 (each) Repair kits to include all consumable and hydraulic seals : 4 (each) 8.6 Spooling Reel (if this option is purchased) Description : Quantity Reel shaft support bearing : 4 (each) Drive shaft support bearing : 1 (each) Reel drive hydraulic motor : 1 (each) Hydraulic extension cylinder repair kit : 1 (kit)
The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) - Trailer Mounted Coiled Tubing Unit for Sale CT Rig for Sale Rig for sale - New Coiled Tubing Unit New Coiled Tubing unit for sale - 80K Trailer Mounted Coiled Tubing Unit - New 80K New Coiled Tubing Unit for sale ------------------------------------------------------------------------------------------------------------------------------
Type
Rope Diam.
Wire working load
Wire breaking load
Weight
C2
-16 mm
20kN
150kN
29kg
C3
-20 mm
30kN
220 kN
48kg
C5
-24 mm
50kN
350kN
85kg
C8
-32 mm
80kN
500kN
136kg
C12
-40 mm
120kN
800kN
211kg
C20
-48 mm
200kN
1150kN
325kg
C32
320kN
1750kN
840kg
E
B1
D
H1
L1
L2
R1
R2
S1
S2
W1
W2
158
315
200
360
100
57.5
12
6
160
115
195
390
250
450
125
70
14
7
140
240
480
300
550
150
90
16
8
180
293
585
680
112
18
9
320
225
355
710
440
840
220
135
20
10
400
270
420
520
1020
260
22
11
500
1100
700
1300
350
35
600
Hydraulic Crawler Drill Rig and Air Compressor for Sale Generic Hydraulic Crawler Drilling Rig for Sale Model : Hydraulic Crawler Drill Rig & KSZJ 18/17 Air Compressor Manufacturer : Generic Condition : Used Description : Hydraulic Crawler Drill Rig and Air Compressor KW180 Hydraulic Crawler Mounted Drill Rig 168 Hours Max Pull 12t / Max Push 4.5t Top Drive with 2-3/8" Reg Box Connection Has a 10ft Foot Stroke 2020 Kaishan KSZJ 18/17 Air Compressor Yuchai (Cummins) Diesel Powered Dual Screw Air End 168 Hours 635 CFM @ 250 PSI 180m 3" Drill Rods in 10ft Lengths, 2 3/8" Reg Connections 1x New 7" Step Bit 1x New 4" Step Bit Location : Canada Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------------------- Search words (for official use only) : Generic Hydraulic Crawler Drill Rig and Air Compressor for Sale Generic Used Hydraulic Crawler Drilling Rig and Air Compressor Used Hydraulic Crawler Drilling Rig for Sale Used Generic Hydraulic Crawler Drilling Rig for Sale Generic Air Compressor for Sale ---------------------------------------------------------------------------------------------------------------------------------
1. Ferrying in shallow rivers that for one reason or another can't be dredged. 2. On stretches of river or waterways that freeze (Regions in Canada for example) 3. Artic evacuation or rescue craft 4. Drilling in shallow waters or wetlands 5. Transportation of heavy equipment to remote locations e.g. oil wells/petro-chemical processing plants 6. Mopping up oil spills 7. Ship to shore use 8. Access to off-shore wind farms 9. Fitted with Generators to supply Electricity to remote Work Townships 10 Cabin and work areas Insulated against extreme Cold. Price & terms : Please enquire using the email form below.
Electro-Hydraulic Knuckle Boom Offshore Crane 35T Knuckle Boom Offshore Crane Marine Offshore Crane for Sale 35T Crane for offshore vessels for sale General Crane type : Knuckle Boom Drive system : Electro-hydraulic Application : Offshore crane. Zone classification : Safe Classification : Det Norske Veritas (DNV) Design Criteria Design life : Crane steel structure is designed for a lifetime of 20 years Environmental Conditions Environment - Atmosphere : High in salinity Humidity, relative : 85% Zone classification - Complete crane : Safe Temperature conditions - Design temperature : To minus 10 degrees Celsius Ambient temperature : From minus 20 to plus 45 degrees Celsius. Wind conditions - Acc. to requirements of applicable classification society / design rules & standards. Off-lead- /side-lead angles - Acc. to requirement of applicable classification society / design rules & standards. Technical Data Crane Data - Main lift data : Lift type : Harbour Lifting data - SWL (in air) / T : 35 / 20 Working Radii - Max / M : 23 / 30 Min / M : -4 Wire fall / No. : 2 / 1 Design Data Design Factors - Dynamic Factor : 1.15 Duty Factor : 1.0 Environment Data - Heel + Trim / deg. : 5+2 : Lift type : Deck Lift Lifting data - SWL (in air) / T : 35 / 17.5 Working Radii - Max / M : 20/ 30 Min / M : -4 Wire fall / No. : 2 / 1 Design Data Design Factors - Dynamic Factor : 1.3 Duty Factor : 1.0 Environment Data - Heel + Trim / deg. : 5 + 2 Wave Height (Hs, m) : 0*) Lift type : Personnel Lifting data - SWL (in air) / T : 0.7 Working Radii - Max / M : 30 Min / M : -4 The above are minimum design factors as per DNV/Norwegian Maritime Directorate. Winch Data Winch Type : Main SWL / T : 35 / 17.5 Wire Fall / Pc : 2 / 1 Hoisting Height / m : 75 Auxiliary : NA Operational Speed Main - SWL (m/min) : 0-12 Light Load (m/min) : 0-25 Sec. average up/down : 100 Rpm : 0-0,5 Sec. average out/in : **) Sec. Average out/in : NA Speed is calaculated for middle wire layer on drum **) - To be announced Slewing range Unlimited : 360 deg continuous. Knuckle Boom : Point of articulation: ~21,1 m from crane centre line. Pedestal Diameter, outside : Ø2840 mm Height : 8000mm. Loading forces to deck structure - Dynamic overturning moment : 1750 Tm. Slew brake moment : 160 Tm. Weight Complete crane, total dead weight : ~ 90000 kg (Incl. pedestal, not including hook load). Pedestal : ~ 20000 kg (Height = 9600 mm) Price & terms : Please enquire using the email form below. If you cannot find the vessel, crane, rig or equipment that you need, please send us an email to mail@worldoils.com stating your requirements and we shall find it for you. We can arrange delivery of equipment and towage of rigs and vessels where needed. The details mentioned above are believed to be accurate but are not guaranteed. ------------------------------------------------------------------------------------------------------------------------ Search words(for official use only) : Electro Hydraulic Knuckle Boom Offshore Crane Offshore 35T Crane for offshore vessels for sale 35Ton Electro-Hydraulic Knuckle Boom Offshore Crane Marine Offshore Crane 35T Knuckle Boom Offshore Crane Offshore 35Ton Offshore Knuckle Boom 35T Offshore Knuckle Boom Crane for sale 35 ton Marine Offshore Crane for Sale Offshore Crane for sale - 35Tons -----------------------------------------------------------------------------------------------------------------------
Showing 241 to 288 of 2131 results
.png)
.png)
.png)
.png)
.jpg)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
Search Here
11346757276642.jpg "Ingersoll-Rand T3 (Truckn 3) Drill Rig - 1975 built - for Sale")
11346757276642.jpg "Ingersoll-Rand T3 (Truckn 3) Drill Rig - 1975 built - for Sale")
1628596861265.jpg "1946 Built 18,000 LPG Propane Tank - For Sale")
1628596861265.jpg "1946 Built 18,000 LPG Propane Tank - For Sale")
